This study examines how the effective dielectric characteristics of the human torso affect the carrier-link-margin (CLM) and data-link-margin (DLM) of a biocompatible gelatin-encapsulated implantable medical device (IMD) that consists of a small implantable antenna, battery, printed circuit board (PCB), camera, and sensor operating at 2.5 GHz. The specific absorption rate (SAR) and the radio frequency (RF) link performances of the IMD are tested for ±20% changes in reference to the mean values of the effective relative permittivity, ɛ_eff, and the effective conductivity, σ_eff, of the human body model. An artificial neural network (ANN) with two inputs (ɛ_eff, σ_eff) and five outputs (SAR_1 g, SAR_10 g, fractional bandwidth, CLM, and DLM) is trained by 80% of the total scenarios and tested by 20% of them in order to provide reliable dependent analyses. The highest changes in 1 g SAR value, 10 g SAR value, fractional bandwidth, CLM, and DLM at a 4 m distance for 100 Kbps are 63%, 41.6%, 17.97%, 26.79%, and 5.89%, respectively, when compared to the reference effective electrical properties of the homogeneous human body model. This work is the first to accurately depend on the electrical analyses of the human body for the link margins of an implantable antenna system. Furthermore, the work’s uniqueness is distinguished by the application of the CLM and DLM principles in the sphere of IMD communication. Full article

In recent years, implantable medical devices (IMDs) have introduced groundbreaking solutions for managing various health conditions. However, traditional implanted batteries necessitate periodic surgical replacement and tend to be relatively bulky, posing significant inconvenience to patients. To overcome these limitations, researchers have investigated various wireless power transfer (WPT) techniques, among which the ultrasonic wireless power transmission (UWPT) technique has distinct advantages. However, limited research has been conducted on ultrasonic power transfer at lower operating frequencies. Therefore, this study explores wireless power transfer using scandium-doped aluminum nitride (AlScN) piezoelectric micro-electromechanical transducers (PMUTs) in deionized (DI) water. Experimental results indicate that at an operating frequency of 14.075 kHz, the power transfer efficiency (PTE) can reach up to 2.68% under optimal load resistance conditions. Furthermore, a low-frequency UWPT system based on a AlScN PMUT has been developed, delivering a stable 3.3 V output for implantable medical devices and contributing to the advancement of a full-spectrum UWPT framework. Full article

Implantable medical devices, or IMDs for short, are medical instruments that are placed into the human body through surgery. IMDs are typically used for treating chronic diseases. Currently available IMDs are capable of communicating using wireless channels with other devices, either in close proximity or even connected to the Internet, making IMDs part of the Internet of Medical Things. This capability opens the possibility of developing a wide range of services, like remote patient data control, localization in case of emergency, or telemedicine, which can improve patients’ lifestyle. On the other hand, given the limited resources of such tiny devices, and the access to the Internet, there are numerous security issues to be considered when designing and deploying IMDs and their support infrastructures. In this paper, we highlight security problems related to Internet-connected IMDs, and survey some solutions that have been presented in the literature. Full article

Ultrasonic wireless power transfer technology (UWPT) represents a key technology employed for energizing implantable medical devices (IMDs). In recent years, aluminum nitride (AlN) has gained significant attention due to its biocompatibility and compatibility with complementary metal-oxide-semiconductor (CMOS) technology. In the meantime, the integration of scandium-doped aluminum nitride (Al_90.4%Sc_9.6%N) is an effective solution to address the sensitivity limitations of AlN material for both receiving and transmission capabilities. This study focuses on developing a miniaturized UWPT receiver device based on AlScN piezoelectric micro-electromechanical transducers (PMUTs). The proposed receiver features a PMUT array of 2.8 × 2.8 mm² comprising 13 × 13 square elements. An acoustic matching gel is applied to address acoustic impedance mismatch when operating in liquid environments. Experimental evaluations in deionized water demonstrated that the power transfer efficiency (PTE) is up to 2.33%. The back-end signal processing circuitry includes voltage-doubling rectification, energy storage, and voltage regulation conversion sections, which effectively transform the generated AC signal into a stable 3.3 V DC voltage output and successfully light a commercial LED. This research extends the scope of wireless charging applications and paves the way for further device miniaturization by integrating all system components into a single chip in future implementations. Full article

Implantable medical devices (IMDs) necessitate a consistent energy supply, commonly sourced from an embedded battery. However, given the finite lifespan of batteries, periodic replacement becomes imperative. This paper addresses the challenge by introducing a wireless power transfer system designed specifically for implantable medical devices (IMDs). It begins with a detailed analysis of the four conventional topologies. Following this, the paper provides a thorough explanation for choosing the PS topology, highlighting its advantages and suitability for the intended application. The primary parallel capacitance necessitates power from current sources; thus, a Class-E amplifier was implemented. Additionally, the selected circuit was engineered to deliver 1 W at the biocompatible resonance frequency of 13.56 MHz. The delineation of the resonance parameters hinges on multifaceted solutions, encompassing bifurcation-free operation and the attainment of peak efficiency. To ensure the feasibility of the proposed solution, a Differential-Evolution-based algorithm was employed. The results obtained from simulation-based evaluations indicated that the system achieved an efficiency exceeding 86%. This efficiency level was maintained even in the face of frequency fluctuations and variations in the coupling between the coils, thereby ensuring stable operational performance. This aligns seamlessly with the specified application prerequisites, guaranteeing a feasible and reliable operation. Full article

Electric vehicles (EV) are now considered the present and future of road transportation to reduce the emission of CO₂ into the environment and thus progressively reduce global warming and climate change. However, EVs currently have some weaknesses such as the available range of battery-powered EVs and the recharging time of the batteries. To overcome these problems, some electrification projects have been proposed for road transportation such as the dynamic wireless power transfer (DWPT), where an EV charges as it moves along an electrified lane using magneto-resonant coupling between short tracks mounted on the road pavement and the vehicle’s onboard pickup coils. While the results are encouraging from an electrical point of view, there is concern regarding the magnetic field in the environment produced by the DWPT coils, which can produce adverse health effects in humans and electromagnetic interference (EMI) in electronic devices. The latter also includes implantable medical devices (IMDs) and in particular cardiac implantable electronic devices (CIEDs), which may be present among vehicle passengers and pedestrians in areas surrounding the vehicle. The aim of this study is the numerical analysis of the EMI produced by a DWPT system in CIEDs with leads such as pacemakers, implantable cardioverter defibrillators (ICDs), etc. EMI is mainly produced by the incident magnetic field and the induced voltage at the input port of a CIED; therefore, in this work the magnetic field levels produced by a DWPT system operating at 85 kHz are calculated first, then the voltage at the input port of a pacemaker is evaluated as that produced by the magnetic field incident on the loop surface formed by a lead implanted in the venous system. According to ISO 14117 standard, it is assumed that the lead loop is planar, semicircular in shape and with an area equal to 225 cm². Since the lead can be placed anywhere where a human can be and with any orientation, an innovative and sophisticated roto-translation algorithm is proposed to find the maximum value of the peak-to-peak induced loop voltage in the most critical regions inside the vehicle cabin and beside the vehicle near the DWPT coils. The preliminary results obtained show that there is no EMI risk inside the vehicle for the passengers with CIEDs, while some concern for pedestrians is due to the induced voltage at the input port of a CIED with unipolar leads which can exceed the ISO 14117 limit in the region next to the vehicle. Full article

The Future of Energy is focused on the consolidation of new energy technologies. Among them, Fuel Cells (FCs) are on the Energy Agenda due to their potential to reduce the demand for fossil fuel and greenhouse gas emissions, their higher efficiency (as fuel cells do not use combustion, their efficiency is not linked to their maximum operating temperature) and simplicity and absence of moving parts. Additionally, low-power FCs have been identified as the target technology to replace conventional batteries in portable applications, which can have recreational, professional, and military purposes. More recently, low-power FCs have also been identified as an alternative to conventional batteries for medical devices and have been used in the medical field both in implantable devices and as micro-power sources. The most used power supply for implantable medical devices (IMD) is lithium batteries. However, despite its higher lifetime, this is far from enough to meet the patient’s needs since these batteries are replaced through surgeries. Based on the close synergetic connection between humans and microorganisms, microbial fuel cells (MFCs) were targeted as the replacement technology for batteries in IMD since they can convert the chemical energy from molecules presented in a living organism into electrical energy. Therefore, MFCs offer the following advantages over lithium batteries: they do not need to be replaced, avoiding subjecting IMD users to different surgeries and decreasing medical costs; they do not need external recharging as they operate as long as the fuel is supplied, by the body fluids; they are a more environmentally friendly technology, decreasing the carbon dioxide and other greenhouse gases emissions resulting from the utilization of fossil fuels and the dependency on fossil fuels and common batteries. However, they are complex systems involving electrochemical reactions, mass and charge transfer, and microorganisms, which affect their power outputs. Additionally, to achieve the desired levels of energy density needed for real applications, an MFC system must overcome some challenges, such as high costs and low power outputs and lifetime. Full article

Over the past three decades, we have seen significant advances in the field of wireless implantable medical devices (IMDs) that can interact with the nervous system. To further improve the stability, safety, and distribution of these interfaces, a new class of implantable devices is being developed: single-channel, sub-mm scale, and wireless microelectronic devices. In this research, we describe a new and simple technique for fabricating and assembling a sub-mm, wirelessly powered stimulating implant. The implant consists of an ASIC measuring 900 × 450 × 80 µm³, two PEDOT-coated microelectrodes, an SMD inductor, and a SU-8 coating. The microelectrodes and SMD are directly mounted onto the ASIC. The ultra-small device is powered using electromagnetic (EM) waves in the near-field using a two-coil inductive link and demonstrates a maximum achievable power transfer efficiency (PTE) of 0.17% in the air with a coil separation of 0.5 cm. In vivo experiments conducted on an anesthetized rat verified the efficiency of stimulation. Full article

Wearable and implantable medical devices (IMDs) have come a long way in the past few decades and have contributed to the development of many personalized health monitoring and therapeutic applications. Sustaining these devices with reliable and long-term power supply is still an ongoing challenge. This review discusses the challenges and milestones in energizing wearable and IMDs using the RF energy harvesting (RFEH) technique. The review highlights the main integrating frontend blocks such as the wearable and implantable antenna design, matching network, and rectifier topologies. The advantages and bottlenecks of adopting RFEH technology in wearable and IMDs are reviewed, along with the system elements and characteristics that enable these devices to operate in an optimized manner. The applications of RFEH in wearable and IMDs medical devices are elaborated in the final section of this review. This article summarizes the recent developments in RFEH, highlights the gaps, and explores future research opportunities. Full article

Low-invasive and battery-less implantable medical devices (IMDs) have been increasingly emerging in recent years. The developed solutions in the literature often concentrate on the Bidirectional Data-Link for long-term monitoring devices. Indeed, their ability to collect data and communicate them to the external world, namely Data Up-Link, has revealed a promising solution for bioelectronic medicine. Furthermore, the capacity to control organs such as the brain, nerves, heart-beat and gastrointestinal activities, made up through the manipulation of electrical transducers, could optimise therapeutic protocols and help patients’ pain relief. These kinds of stimulations come from the modulation of a powering signal generated from an externally placed unit coupled to the implanted receivers for power/data exchanging. The established communication is also defined as a Data Down-Link. In this framework, a new solution of the Binary Phase-Shift Keying (BPSK) demodulator is presented in this paper in order to design a robust, low-area, and low-power Down-Link for ultrasound (US)-powered IMDs. The implemented system is fully digital and PLL-free, thus reducing area occupation and making it fully synthesizable. Post-layout simulation results are reported using a 28 nm Bulk CMOS technology provided by TSMC. Using a 2 MHz carrier input signal and an implant depth of 1 cm, the data rate is up to 1.33 Mbit/s with a 50% duty cycle, while the minimum average power consumption is cut-down to 3.3 μW in the typical corner. Full article

Implantable medical devices have been facing the severe challenge of wireless communication for a long time. Acoustically actuated magnetoelectric (ME) transducer antennas have attracted lots of attention due to their miniaturization, high radiation efficiency and easy integration. Here, we fully demonstrate the possibility of using only one bulk acoustic wave (BAW) actuated ME transducer antenna (BAW ME antenna) for communication by describing the correspondence between the BAW ME antenna and components of the traditional transmitter in detail. Specifically, we first demonstrate that the signal could be modulated by applying a direct current (DC) magnetic bias and exciting different resonance modes of the BAW ME antenna with frequencies ranging from medium frequency (MF) (1.5 MHz) to medium frequency (UHF) (2 GHz). Then, two methods of adjusting the radiation power of the BAW ME antenna are proposed to realize signal amplification, including increasing the input voltage and using higher order resonance. Finally, a method based on electromagnetic (EM) perturbation is presented to simulate the transmission process of the BAW ME antenna via the finite element analysis (FEA) model. The simulation results match the radiation pattern of magnetic dipoles perfectly, which verifies both the model and our purpose. Full article

The need for continuous monitoring of physiological information of critical organs of the human body, combined with the ever-growing field of electronics and sensor technologies and the vast opportunities brought by 5G connectivity, have made implantable medical devices (IMDs) the most necessitated devices in the health arena. IMDs are very sensitive since they are implanted in the human body, and the patients depend on them for the proper functioning of their vital organs. Simultaneously, they are intrinsically vulnerable to several attacks mainly due to their resource limitations and the wireless channel utilized for data transmission. Hence, failing to secure them would put the patient’s life in jeopardy and damage the reputations of the manufacturers. To date, various researchers have proposed different countermeasures to keep the confidentiality, integrity, and availability of IMD systems with privacy and safety specifications. Despite the appreciated efforts made by the research community, there are issues with these proposed solutions. Principally, there are at least three critical problems. (1) Inadequate essential capabilities (such as emergency authentication, key update mechanism, anonymity, and adaptability); (2) heavy computational and communication overheads; and (3) lack of rigorous formal security verification. Motivated by this, we have thoroughly analyzed the current IMD authentication protocols by utilizing two formal approaches: the Burrows–Abadi–Needham logic (BAN logic) and the Automated Validation of Internet Security Protocols and Applications (AVISPA). In addition, we compared these schemes against their security strengths, computational overheads, latency, and other vital features, such as emergency authentications, key update mechanisms, and adaptabilities. Full article

In this paper, we propose a method of wirelessly torque transfer (WTT) and power (WPT) to a drug pump, one of implantable medical devices. By using the magnetic field generated by the WPT system to transfer torque and power to the receiving coil at the same time, applications that previously used power from the battery can be operated without a battery. The proposed method uses a receiving coil with magnetic material as a motor, and can generate torque in a desired direction using the magnetic field from the transmitting coil. The WPT system was analyzed using a topology that generates a constant current for stable torque generation. In addition, a method for detecting the position of the receiving coil without using additional power was proposed. Through simulations and experiments, it was confirmed that WTT and WPT were possible at the same time, and in particular, it was confirmed that WTT was stably possible. Full article

The tremendous development of both optical wireless communications (OWC) and implantable medical devices (IMDs) has recently enabled the establishment of transdermal optical wireless (TOW) links that utilize light waves to transfer information inside the living body to the outside world and conversely. Indeed, numerous emerging medical applications such as cortical recording and telemetry with cochlear implants require extremely high data rates along with low power consumption that only this new technology could accommodate. Thus, in this paper, a typical TOW link is investigated in terms of outage capacity which is a critical performance metric that has so far not been evaluated for such wireless systems in the open technical literature. More precisely, an outage capacity analysis is performed considering both skin-induced attenuation and stochastic spatial jitter, i.e., pointing error effects. Analytical expressions and results for the outage capacity are derived for a variety of skin channel conditions along with varying stochastic pointing errors which demonstrate the feasibility of this cross-field cooperation. Lastly, the corresponding simulation outcomes further validate our suggestions. Full article

Implantable medical devices (IMDs) are susceptible to microbial adhesion and biofilm formation, which lead to several clinical complications, including the occurrence of implant-associated infections. Polylactic acid (PLA) and its composites are currently used for the construction of IMDs. In addition, chitosan (CS) is a natural polymer that has been widely used in the medical field due to its antimicrobial and antibiofilm properties, which can be dependent on molecular weight (Mw). The present study aims to evaluate the performance of CS-based surfaces of different Mw to inhibit bacterial biofilm formation. For this purpose, CS-based surfaces were produced by dip-coating and the presence of CS and its derivatives onto PLA films, as well surface homogeneity were confirmed by contact angle measurements, Fourier transform infrared spectroscopy (FTIR) and scanning electron microscopy (SEM). The antimicrobial activity of the functionalized surfaces was evaluated against single- and dual-species biofilms of Staphylococcus aureus and Pseudomonas aeruginosa. Chitosan-based surfaces were able to inhibit the development of single- and dual-species biofilms by reducing the number of total, viable, culturable, and viable but nonculturable cells up to 79%, 90%, 81%, and 96%, respectively, being their activity dependent on chitosan Mw. The effect of CS-based surfaces on the inhibition of biofilm formation was corroborated by biofilm structure analysis using confocal laser scanning microscopy (CLSM), which revealed a decrease in the biovolume and thickness of the biofilm formed on CS-based surfaces compared to PLA. Overall, these results support the potential of low Mw CS for coating polymeric devices such as IMDs where the two bacteria tested are common colonizers and reduce their biofilm formation. Full article
