Search Results (10)

The study of low-speed jets into crossflow is critical to the performance of gas turbines. Film cooling is a method to maintain manageable blade temperatures in turbine sections while increasing turbine inlet temperatures and turbine efficiencies. Initially, cooling holes were cylindrical. Film cooling jets from these discrete round holes were found to be very susceptible to jet liftoff, which reduces surface effectiveness. Shaped holes have become prominent for improved coolant coverage. Fan-shaped holes are the most common design and have shown good improvement over round holes. However, fan-shaped holes introduce additional parameters to the already complex task of modeling cooling effectiveness. Studies of these flows range in hole lengths from those found in actual turbine blades to very long holes with fully developed flow. The flow within the holes themselves is difficult to study as there is limited optical access. However, the flow within the holes has a strong effect on the resulting properties of the jet. This study presents velocity and vorticity fields measured using high-resolution magnetic resonance velocimetry (MRV) to study three different fan-shaped hole geometries at two blowing ratios. Because MRV does not require line of sight, it provides otherwise hard-to-obtain experimental data of the flow within the film cooling hole in addition to the mainflow measurements. By allowing measurement within the cooling hole, MRV shows how a poor choice of diffuser start point and angle can be detrimental to film cooling if overall hole length and cooling flow velocity are not properly accounted for in the design. The downstream effect of these choices on the jet height and counter-rotating vortex pair is also observed. Full article

Background: Congenital heart diseases (CHDs) are often associated with significant neurocognitive impairment and neurological delay. This study aims to elucidate the correlation between type of CHD and Doppler velocimetry and to investigate the possible presence of fetal brain abnormalities identified by magnetic resonance imaging (MRI). Methods: From July 2010 to July 2020, we carried out a cross-sectional study of 63 singleton pregnancies with a diagnosis of different types of complex CHD: LSOL (left-sided obstructive lesions; RSOL (right-sided obstructive lesions) and MTC (mixed type of CHD). All patients underwent fetal echocardiography, ultrasound evaluation, a magnetic resonance of the fetal brain, and genetic counseling. Results: The analysis of 63 fetuses shows statistically significant results in Doppler velocimetry among the different CHD groups. The RSOL group leads to higher umbilical artery (UA-PI) pressure indexes values, whereas the LSOL group correlates with significantly lower values of the middle cerebral artery (MCA-PI) compared to the other subgroups (p = 0.036), whereas the RSOL group shows a tendency to higher pulsatility indexes in the umbilical artery (UA-PI). A significant correlation has been found between a reduced head circumference (HC) and the presence of brain injury at MRI (p = 0.003). Conclusions: Congenital left- and right-sided cardiac obstructive lesions are responsible for fetal hemodynamic changes and brain growth impairment. The correct evaluation of the central nervous system (CNS) in fetuses affected by CHD could be essential as prenatal screening and the prediction of postnatal abnormalities. Full article

In order to study the protection performance of silane coating on in-service concrete structures in a sulfate environment, we collect concrete samples in the field to simulate the concrete erosion process by accelerated erosion with wetting–drying cycles. We place the samples into protected, exposed and control groups corresponding to a corrosive environment with silane protection, corrosive environment without protection and general environment for three different service conditions. A combination of ultrasonic velocimetry, CT (Computed Tomography) scan imaging, NMR (Nuclear Magnetic Resonance) pore structure analysis, strength testing and other methods are used to analyze the strength, ultrasonic wave velocity, pore structure and other characteristics of the specimens during sulfate erosion. Based on the test results, the protective effect of silane coating on concrete structures under sulfate attack is quantitatively analyzed, and an index for judging the damage rate of specimens is proposed to quantitatively analyze the protective effect of silane coating. The research results show that the damage of the concrete structure under silane protection in a sulfate-attack environment can be reduced by more than 50%; its integrity damage index and strength damage index are easily affected by the location of local defects, which leads to a decrease in the protection efficiency of the surface silane coating. Full article

The mechanical behavior of loess is highly predicated on variation in its moisture content. While the impacts of the water content on the shearing behavior and collapsibility of loess have been extensively studied, its effect on tensile characteristics has received relatively little attention. In this study, a series of tensile tests were conducted on remolded specimens of a clayey loess that were collected from Ili Valley in China. Two sets of loess specimens with varying water contents were prepared separately using wetting and drying methods. The influence of the water content on the tensile stress–strain response, failure mode and tensile strength was investigated by combining the tensile test results and particle image velocimetry (PIV) analysis. On this basis, a nuclear magnetic resonance (NMR) test and scanning electron microscopy (SEM) observations were implemented in order to assist with the interpretation of the underlying mechanism. The test results indicate that the tensile failure process and the variation of tensile strength with varying water contents differ for specimens that are prepared with wetting and drying methods; a finding which arises from the differences in the soil microstructure, clay–water interaction and the distribution of capillary and adsorbed water. This research has shown that the tensile strength of clayey loess is essentially dominated by the clay’s hydration/cementation and the development of capillary and adsorption suction as well as the microstructural evolution that occurs with the change in the water content. Based on the experimental observations, a conceptual model is proposed in order to interpret the effect of water content on loess’ tensile behavior. Full article

In plants, water flows are the major driving force behind growth and play a crucial role in the life cycle. To study hydrodynamics, methods based on tracking small particles inside water flows attend a special place. Thanks to these tools, it is possible to obtain information about the dynamics of the spatial distribution of the flux characteristics. In this paper, using contrast-enhanced magnetic resonance imaging (MRI), we show that gadolinium chelate, used as an MRI contrast agent, marks the structural characteristics of the xylem bundles of maize stem nodes and internodes. Supplementing MRI data, the high-precision visualization of xylem vessels by laser scanning microscopy was used to reveal the structural and dimensional characteristics of the stem vascular system. In addition, we propose the concept of using prototype “Y-type xylem vascular connection” as a model of the elementary connection of vessels within the vascular system. A Reynolds number could match the microchannel model with the real xylem vessels. Full article

Studies that use magnetic resonance velocimetry (MRV) to assess flows through porous media require a sufficiently small voxel size to determine the velocity field at a sub-pore scale. The smaller the voxel size, the less information is lost through the discretization. However, the measurement uncertainty and the measurement time are increased. Knowing the relationship between voxel size and measurement accuracy would help researchers select a voxel size that is not too small in order to avoid unnecessary measurement effort. This study presents a systematic parameter study with a low-Reynolds-number flow of a glycerol–water mixture sent through a regularly periodic porous matrix with a pore size of 5 mm. The matrix was a 3-dimensional polymer print, and velocity-encoded MRV measurements were made at 15 different voxel sizes between 0.42 mm and 4.48 mm. The baseline accuracy of the MRV velocity data was examined through a comparison with a computational fluid dynamics (CFD) simulation. The experiment and simulation show very good agreement, indicating a low measurement error. Starting from the smallest examined voxel size, the influence of the voxel size on the accuracy of the velocity data was then examined. This experiment enables us to conclude that a voxel size of 0.96 mm, which corresponds to 20% of the pore size, is sufficient. The volume-averaged results do not change below a voxel size of 20% of the pore size, whereas systematic deviations occur with larger voxels. The same trend is observed with the local velocity data. The streamlines calculated from the MRV velocity data are not influenced by the voxel size for voxels of up to 20% of the pore size, and even slightly larger voxels still show good agreement. In summary, this study shows that even with a relatively low measurement resolution, quantitative 3-dimensional velocity fields can be obtained through porous flow systems with short measurement times and low measurement uncertainty. Full article

Although recent advances of four-dimensional (4D) flow magnetic resonance imaging (MRI) has introduced a new way to measure Reynolds stress tensor (RST) in turbulent flows, its measurement accuracy and possible bias have remained to be revealed. The purpose of this study was to compare the turbulent flow measurement of 4D flow MRI and particle image velocimetry (PIV) in terms of velocity and turbulence quantification. Two difference flow rates of 10 and 20 L/min through a 50% stenosis were measured with both PIV and 4D flow MRI. Not only velocity through the stenosis but also the turbulence parameters such as turbulence kinetic energy and turbulence production were quantitatively compared. Results shows that 4D flow MRI velocity measurement well agreed with the that of PIV, showing the linear regression slopes of two methods are 0.94 and 0.89, respectively. Although turbulence mapping of 4D flow MRI was qualitatively agreed with that of PIV, the quantitative comparison shows that the 4D flow MRI overestimates RST showing the linear regression slopes of 1.44 and 1.66, respectively. In this study, we demonstrate that the 4D flow MRI visualize and quantify not only flow velocity and also turbulence tensor. However, further optimization of 4D flow MRI for better accuracy might be remained. Full article

Non steady applied magnetic field impact on a liquid metal has good prospects for industry. For a better understanding of heat and mass transfer processes under these circumstances, numerical simulations are needed. A combination of finite elements and volumes methods was used to calculate the flow and solidification of liquid metal under electromagnetic influence. Validation of numerical results was carried out by means of measuring with ultrasound Doppler velocimetry technique, as well as with neutron radiography snapshots of the position and shape of the solid/liquid interface. As a result of the first part of the work, a numerical model of electromagnetic stirring and solidification was developed and validated. This model could be an effective tool for analyzing the electromagnetic stirring during the solidification process. In the second part, the dependences of the velocity pulsation amplitude and the melt velocity maximum value on the magnetic field pulsation frequency are obtained. The ability of the pulsating force to develop higher values of the liquid metal velocity at a frequency close to the MHD resonance was found numerically. The obtained characteristics give a more detailed description of the electrically conductive liquid behaviour under action of pulsating traveling magnetic field. Full article

Apart from electric vehicles, most internal combustion (IC) engines are powered while burning petroleum-based fossil or alternative fuels after mixing with inducted air. Thereby the operations of mixing and combustion evolve in a turbulent flow environment created during the intake phase and then intensified by the piston motion and influenced by the shape of combustion chamber. In particular, the swirl and turbulence levels existing immediately before and during combustion affect the evolution of these processes and determine engine performance, noise and pollutant emissions. Both the turbulence characteristics and the bulk flow pattern in the cylinder are strongly affected by the inlet port and valve design. In the present paper, large eddy simulation (LES) is appraised and applied to studying the turbulent fluid flow around the intake valve of a single cylinder IC-engine as represented by the so called magnetic resonance velocimetry (MRV) flow bench configuration with a relatively large Reynolds number of 45,000. To avoid an intense mesh refinement near the wall, various subgrid scale models for LES; namely the Smagorinsky, wall adapting local eddy (WALE) model, SIGMA, and dynamic one equation models, are employed in combination with an appropriate wall function. For comparison purposes, the standard RANS (Reynolds-averaged Navier–Stokes) k- $\epsilon$ model is also used. In terms of a global mean error index for the velocity results obtained from all the models, at first it turns out that all the subgrid models show similar predictive capability except the Smagorinsky model, while the standard k- $\epsilon$ model experiences a higher normalized mean absolute error (nMAE) of velocity once compared with MRV data. Secondly, based on the cost-accuracy criteria, the WALE model is used with a fine mesh of ≈39 millions control volumes, the averaged velocity results showed excellent agreement between LES and MRV measurements, revealing the high prediction capability of the suggested LES tool for valve flows. Thirdly, the turbulent flow across the valve curtain clearly featured a back flow resulting in a high speed intake jet in the middle. Comprehensive LES data are generated to carry out statistical analysis in terms of (1) evolution of the turbulent morphology across the valve passage relying on the flow anisotropy map, (2) integral turbulent scales along the intake-charge stream, (3) turbulent flow properties such as turbulent kinetic energy, turbulent velocity and its intensity within the most critical zone in intake-port and along the port length, it further transpires that the most turbulence are generated across the valve passage and these are responsible for the in-cylinder turbulence. Full article

This study investigates dilute aqueous suspensions of bentonite particles using magnetic resonance imaging (MRI) velocimetry. Four different chemical conditions are tested to investigate the influence of pH and type of monovalent electrolyte on the local rheological behavior of bentonite suspensions. The results indicate the shear banding in a dilute suspension of 0.1 vol.% solid due to the formation of a continuous three-dimensional particle network under a certain chemical environment (i.e., pH 4 in 1 × 10⁻² M KNO₃). This network is responsible for the existence of the yield stress in that dilute suspension. Structural changes induced by modification of suspensions’ chemistry are examined via scanning electron microscopy. A previously established method based on processing the torques acquired via conventional rheometric measurement is also applied as an alternative way to recover local flow information. Within the shear rate range covered by our MRI velocimetry, the results of both methods show good agreement. This study suggests that the existence of a master curve (or global flow curve) for dilute suspensions is dependent on the bentonite particle organization, which is influenced by the suspension chemistry and the previous flow history. Full article
