Search Results (47)

A stable and high-precision autonomous orbit determination scheme for a Low Lunar Orbit (LLO) spacecraft is proposed, leveraging satellite-to-satellite tracking (SST) measurement data and lunar laser ranging data. One satellite orbits around the LLO, while the other satellite orbits around the Distant Retrograde Orbit (DRO). An inter-satellite ranging link is established between the two satellites, while the LLO satellite conducts laser ranging with a Corner Cube Reflector (CCR) on the lunar surface. Both inter-satellite ranging data and lunar laser ranging data are acquired through measurements. By integrating these data with orbital dynamics and employing the Extended Kalman Filter (EKF) method, the position and velocity states of the two formation satellites are estimated. This orbit determination scheme operates independently of ground measurement and control stations, achieving a high degree of autonomy. Simulation results demonstrate that the position accuracy of the LLO satellite can reach 0.1 m, and that of the DRO satellite can reach 10 m. Compared to the autonomous orbit determination scheme relying solely on SST measurement data, this proposed scheme exhibits several advantages, including shorter convergence time, higher convergence accuracy, and enhanced robustness of the navigation system against initial orbit errors and orbital dynamic model errors. It can provide a valuable engineering reference for the autonomous navigation of lunar-orbiting satellites. Full article

This paper investigates the design of optimal low-thrust transfers between relative planar and spatial quasi-satellite orbits (QSOs) in the Earth–Moon system under the Circular Restricted Three-Body Problem (CR3BP). A key contribution is the adaptation of a trajectory optimization framework, previously applied to halo orbit transfers, to accommodate the unique challenges of QSO families, especially the transition between planar and spatial configurations. The method employs a refined beam search strategy to construct diverse initial guess chains, which are then optimized via a successive convexification algorithm tailored for the spatial dynamics of QSOs. Additionally, a linear–quadratic regulator (LQR)-based control scheme is implemented to ensure long-term station-keeping of the final 3D-QSO. Simulation results demonstrate the feasibility of connecting planar and spatial QSOs with minimum-fuel trajectories while maintaining bounded terminal deviations, offering new tools for future Earth–Moon logistics and navigation infrastructure. Key findings include the successful design of low-thrust transfer trajectories between planar QSOs and 1:5 3D-QSOs, with a minimum total $\mathsf{\Delta }V$ of 195.576 m/s over a time of flight (ToF) of 261 days, and a minimum ToF of 41 days with a total $\mathsf{\Delta }V$ of 270.507 m/s. Additionally, the application of LQR control demonstrated the ability to maintain 1:5 3D-QSO families around the Moon with less than 12 mm/s $\mathsf{\Delta }V$ over two months. This research provides valuable insights into the optimization of low-thrust transfer trajectories and the application of advanced control techniques for space missions, particularly those targeting lunar and planetary satellite exploration. Full article

Accurate localization is a key requirement for deep-space exploration, enabling spacecraft operations with limited ground support. Upcoming commercial and scientific missions to the Moon are designed to extensively use optical measurements during low-altitude orbital phases, descent and landing, and high-risk operations, due to the versatility and suitability of these data for onboard processing. Navigation frameworks based on optical data analysis have been developed to support semi- or fully-autonomous onboard systems, enabling precise relative localization. To achieve high-accuracy navigation, optical data have been combined with complementary measurements using sensor fusion techniques. Absolute localization is further supported by integrating onboard maps of cataloged surface features, enabling position estimation in an inertial reference frame. This study presents a navigation framework for optical image processing aimed at supporting the autonomous operations of lunar orbiters. The primary objective is a comprehensive characterization of the navigation camera’s properties and performance to ensure orbit determination uncertainties remain below 1% of the spacecraft altitude. In addition to an analysis of measurement noise, which accounts for both hardware and software contributions and is evaluated across multiple levels consistent with prior literature, this study emphasizes the impact of process noise on orbit determination accuracy. The mismodeling of orbital dynamics significantly degrades orbit estimation performance, even in scenarios involving high-performing navigation cameras. To evaluate the trade-off between measurement and process noise, representing the relative accuracy of the navigation camera and the onboard orbit propagator, numerical simulations were carried out in a synthetic lunar environment using a near-polar, low-altitude orbital configuration. Under nominal conditions, the optical measurement noise was set to 2.5 px, corresponding to a ground resolution of approximately 160 m based on the focal length, pixel pitch, and altitude of the modeled camera. With a conservative process noise model, position errors of about 200 m are observed in both transverse and normal directions. The results demonstrate the estimation framework’s robustness to modeling uncertainties, adaptability to varying measurement conditions, and potential to support increased onboard autonomy for small spacecraft in deep-space missions. Full article

Spacecraft catering to the Lunar Gateway or other “permanent” stations in the lunar vicinity would require frequent travel between periodic orbits around the Earth–Moon $L_1$ and $L_2$ Lagrange points. The transition through the Hill sphere is often characterized by close passages of our nearest neighbor—rendering the optimization problem numerically challenging due to the increased local sensitivities. Depending on the mission requirements and resource constraints, transfer architectures must be studied, and trade-offs between flight time and fuel consumption quantified. While direct low-thrust transfers between the circular restricted three-body problem periodic orbit families have been studied, the asymptotic flow in the neighborhood of the periodic orbits could be leveraged for expansion and densification of the solution space. This paper presents an approach to achieve a dense mapping of manifold-assisted, low-thrust transfers based on initial and terminal coast segments. Continuation schemes are utilized to attain the powered intermediate time-optimal segment through a multi-shooting approach. Interesting insights regarding the linear correlation between $\Delta$V and change in reduced two-body osculating elements associated with the initial-terminal conditions are discussed. These insights could inform the subsequent filtering of the osculating selenocentric periapsis map and provide additional interesting and efficient solutions. The described approach is anticipated to be extremely useful for future crewed and robotic cis-lunar operations. Full article

This research addresses minimum-fuel pinpoint lunar landing at the South Pole, focusing on trajectory design and near-optimal guidance aimed at driving a spacecraft from a circular low lunar orbit (LLO) to an instantaneous hovering state above the lunar surface. Orbit dynamics is propagated in a high-fidelity ephemeris-based framework, which employs spherical coordinates as the state variables and includes several harmonics of the selenopotential, as well as third-body gravitational perturbations due to the Earth and Sun. Minimum-fuel two-impulse descent transfers are identified using Lambert problem solutions as initial guesses, followed by refinement in the high-fidelity model, for a range of initial LLO inclinations. Then, a feedback Lambert-based impulsive guidance algorithm is designed and tested through a Monte Carlo campaign to assess the effectiveness under non-nominal conditions related to injection and actuation errors. Because the last braking maneuver is relatively large, a finite-thrust, locally flat, near-optimal guidance is introduced and applied. Simplified dynamics is assumed for the purpose of defining a minimum-time optimal control problem along the last thrust arc. This admits a closed-form solution, which is iteratively used until the desired instantaneous hovering condition is reached. The numerical results in non-nominal flight conditions testify to the effectiveness of the guidance approach at hand in terms of propellant consumption and precision at landing. Full article

In this research, a feedback nonlinear control law was designed and tested to perform acquisition and station-keeping maneuvers for a lunar navigation constellation. Each satellite flies an Elliptical Lunar Frozen Orbit (ELFO) and is equipped with a steerable and throttleable low-thrust propulsion system. Lyapunov stability theory was employed to design a real-time feedback control law, capable of tracking all orbital elements (including the true anomaly), expressed in terms of modified equinoctial elements (MEEs). Unlike previous research, control synthesis was developed in the complete nonlinear dynamical model, and allows for driving the spacecraft toward a time-varying desired state, which includes correct phasing. Orbit propagation was performed in a high-fidelity framework, which incorporated several relevant harmonics of the selenopotential, as well as third-body effects due to the gravitational pull of the Earth and Sun. The control strategy at hand was successfully tested through two Monte Carlo campaigns in the presence of nonnominal flight conditions related to estimation errors of orbit perturbations, accompanied by the temporary unavailability and misalignment of the propulsive thrust. Full article

Planetary photogrammetry remains an important technical means of producing high-precision planetary maps. High-quality control networks are fundamental to successful bundle adjustment. However, current software tools used by the planetary mapping community to construct and edit control networks exhibit very low efficiency. Moreover, redundant and invalid control points in the control network can further increase the time required for the bundle adjustment process. Due to a lack of targeted algorithm optimization, existing software tools and methods are unable to meet the photogrammetric processing requirements of massive planetary remote sensing images. To address these issues, we first proposed an efficient control network construction framework based on approximate orthoimage matching and hash quick search. Next, to effectively reduce the redundant control points in the control network and decrease the computation time required for bundle adjustment, we then proposed a control network-thinning algorithm based on a K-D tree fast search. Finally, we developed an automatic detection method based on ray tracing for identifying invalid control points in the control network. To validate the proposed methods, we conducted photogrammetric processing experiments using both the Lunar Reconnaissance Orbiter (LRO) narrow-angle camera (NAC) images and the Origins Spectral Interpretation Resource Identification Security Regolith Explorer (OSIRIS-REx) PolyCam images; we then compared the results with those derived from the famous open-source planetary photogrammetric software, the United States Geological Survey (USGS) Integrated Software for Imagers and Spectrometers (ISIS) version 8.0.0. The experimental results demonstrate that the proposed methods significantly improve the efficiency and quality of constructing control networks for large-scale planetary images. For thousands of planetary images, we were able to speed up the generation and editing of the control network by more than two orders of magnitude. Full article

This research studies the potential of frozen low lunar orbits to be used in the design of constellations for global and regional communication or navigation. We introduce a robust two-stage approach to the frozen low lunar orbit design based on the successive application of non-gradient techniques, the Bayesian optimization and the Nelder–Mead method. The developed methodology has a number of advantages over existing numerical design techniques and allows revealing orbits with the periodic behavior of the eccentricity vector over long propagation intervals in the full dynamical model. By leveraging a convenient nomogram with constellation visibility parameters and lower bound coverage curves, we have identified most suitable low-altitude orbital configurations of Walker type and then adjust them to be frozen. The frozenness condition can be achieved without changing the orientation of orbital planes. Visibility and coverage metrics (multiplicity of continuous coverage for specified sites, polar regions, or the whole lunar surface; position dilution of precision) of candidate constellations are analyzed. Several promising designs of frozen constellations in near-circular low lunar orbits are singled out. The frozen orbit stability and the station-keeping cost are discussed. Full article

Reiner Gamma is a potential target for low-orbiting spacecraft or even surface-landed missions in the near future. Unfortunately, thus far, no comprehensive low-altitude (below 20 km) or surface measurements of the magnetic field, magnetic source and plasma environment have been made post-Apollo to complement and complete our understanding of the solar wind interaction with lunar magnetic anomalies and swirl formation. Acquiring the detailed geological knowledge of the Reiner Gamma region is significant for the above scientific targets. In this study, the following research work in the lunar Reiner Gamma magnetic anomaly region was carried out for the regional geological investigation: (1) topographic and geomorphologic analysis; (2) element, mineral, and sequence analysis; and (3) a 1:10,000 regional geological map analysis. Our work helps define measurement requirements for possible future low-orbiting or surface-landed missions to the Reiner Gamma area or similarly magnetized regions of the lunar surface. Full article

The Apollo basin is a well-preserved double-ringed impact basin located on the northeastern edge of the South Pole–Aitken (SPA) basin. The Apollo basin has been flooded and filled with large volumes of mare lavas, indicating an active volcanism history. Based on orbital data, we reveal that the Apollo basin exhibits an overall asymmetric configuration in the distribution of mare basalts as well as its topography, chemical compositions, and crustal thickness. The Apollo basin is an excellent example for assessing the influences of the above factors on mare basalts petrogenesis and evaluating mare basalt genesis models. It was found that the generation of mare basalt magmas and their emplacement in the Apollo basin seems to be strongly related to local thin crust (<30 km), but the formation of basaltic magmas should be independent of the decompression melting because the mare units (3.34–1.79 Ga) are much younger than the pre-Nectarian Apollo basin. The mare basalts filled in the Apollo basin exhibits a large variation of TiO₂ abundances, indicating the heterogeneity of mantle sources, which is possible due to the lunar mantle overturn after the LMO solidification or the impact-induced mantle convection and migration. However, the prolonged mare volcanic history of the Apollo basin is not well explained, especially considering the low Th abundance (<2 ppm) of this region. In addition, the central mare erupted earlier than other mare units within the Apollo basin, which seems to contradict the predictions of the postbasin loading-induced stresses model. Laboratory investigations of the Chang’E-6 mare basalt samples could possibly answer the above questions and provide new insight into the mare volcanic history of the lunar farside and the connections between mare volcanism and impact basin formation/evolution. Full article

High-precision lunar scene 3D data are essential for lunar exploration and the construction of scientific research stations. Currently, most existing data from orbital imagery offers resolutions up to 0.5–2 m, which is inadequate for tasks requiring centimeter-level precision. To overcome this, our research focuses on using in situ stereo vision systems for finer 3D reconstructions directly from the lunar surface. However, the scarcity and homogeneity of available lunar surface stereo datasets, combined with the Moon’s unique conditions—such as variable lighting from low albedo, sparse surface textures, and extensive shadow occlusions—pose significant challenges to the effectiveness of traditional stereo matching techniques. To address the dataset gap, we propose a method using Unreal Engine 4 (UE4) for high-fidelity physical simulation of lunar surface scenes, generating high-resolution images under realistic and challenging conditions. Additionally, we propose an optimized cost calculation method based on Census transform and color intensity fusion, along with a multi-level super-pixel disparity optimization, to improve matching accuracy under harsh lunar conditions. Experimental results demonstrate that the proposed method exhibits exceptional robustness and accuracy in our soon-to-be-released multi-scene lunar dataset, effectively addressing issues related to special lighting conditions, weak textures, and shadow occlusion, ultimately enhancing disparity estimation accuracy. Full article

The physical properties of lunar regolith are crucial for exploration planning, hazard assessment, and characterizing scientific targets at global and polar scales. The dielectric constant, a key property, offers insights into lunar material distribution within the regolith and serves as a proxy for identifying volatile-rich regoliths. Miniature radio frequency (Mini-RF) on the Lunar Reconnaissance Orbiter (LRO) provides a potential tool for mapping the lunar regolith’s physical nature and assessing the lunar volatile repository. This study presents global and polar S-band Mini-RF dielectric signatures of the Moon, obtained through a novel deep learning inversion model applied to Mini-RF mosaics. We achieved good agreement between training and testing of the model, yielding a coefficient of determination (R² value) of 0.97 and a mean squared error of 0.27 for the dielectric constant. Significant variability in the dielectric constant is observed globally, with high-Ti mare basalts exhibiting lower values than low-Ti highland materials. However, discernibility between the South Pole–Aitken (SPA) basin and highlands is not evident. Despite similar dielectric constants on average, notable spatial variations exist within the south and north polar regions, influenced by crater ejecta, permanently shadowed regions, and crater floors. These dielectric differences are attributed to extensive mantling of lunar materials, impact cratering processes, and ilmenite content. Using the east- and west-looking polar mosaics, we estimated an uncertainty (standard deviation) of 1.01 in the real part and 0.03 in the imaginary part of the dielectric constant due to look direction. Additionally, modeling highlights radar backscatter sensitivity to incidence angle and dielectric constant at the Mini-RF wavelength. The dielectric constant maps provide a new and unique perspective of lunar terrains that could play an important role in characterizing lunar resources in future targeted human and robotic exploration of the Moon. Full article

In the near future, international space agencies have planned to achieve significant milestones in investigating the utilization of Global Navigation Satellite Systems (GNSS) within and beyond the current space service volume up to their application to lunar missions. These initiatives aim to demonstrate the feasibility of GNSS navigation at lunar altitudes. Based on the outcomes of such demonstrations, dozens of lunar missions will likely be equipped with a GNSS receiver to support autonomous navigation in the lunar proximity. Relying on non-invasive, consolidated differential techniques, GNSS will enable baseline estimation, thus supporting a number of potential applications to lunar orbiters such as collaborative navigation, formation flight, orbital manoeuvers, remote sensing, augmentation systems and beyond. Unfortunately, the large dynamics and the geometry of such differential GNSS scenarios set them apart from current terrestrial and low-earth orbit use cases. These characteristics result in an increased sensitivity to measurements time misalignment among orbiters. Hence, this paper offers a review of baseline estimation methods and characterizes the divergences and limitations w.r.t. to terrestrial applications. The study showcases the estimation of the baseline length between a lunar CubeSat mission, VMMO, and the communication relay Lunar Pathfinder mission. Notably, real GNSS measurements generated by an Engineering Model of the NaviMoon receiver in the European Space Agency (ESA/ESTEC) Radio Navigation Laboratory are utilized. A radio-frequency constellation simulator is used to generate the GNSS signals in these hardware-in-the-loop tests. The performed analyses showed the invalidity of common terrestrial differential GNSS ranging techniques for space scenarios due to the introduction of significant biases. Improved ranging algorithms were proposed and their potential to cancel ranging errors common to both receivers involved was confirmed. Full article

Gateway represents a key element of the Artemis program for the upcoming lunar exploration aimed at establishing a sustainable presence by the mid-2030s. This paper investigates minimum-fuel bi-impulsive orbit transfers from Gateway to low lunar orbits (LLOs) with a maximum time of flight of 48 h. Two distinct scenarios are analyzed: (i) target orbits with free right ascension of the ascending node (RAAN), and (ii) target orbits with specified RAAN. For case (i), a global optimization technique based on a heuristic algorithm is exploited to obtain the minimum-fuel transfer. Several inclinations of the target orbit are considered. For case (ii), two distinct techniques are proposed: (a) a purely heuristic approach, and (b) a semi-analytical method based on local refinement of a Lambert-based solution. Numerical propagations are conducted in all scenarios in a high-fidelity framework that includes all relevant perturbations. A comparison between the different strategies and the related numerical results is provided. Full article

The reachable set of controlled dynamical systems is the set of all reachable states from an initial condition over a certain time horizon, subject to operational constraints and exogenous disturbances. In astrodynamics, rapid approximation of reachable sets is invaluable for trajectory planning, collision avoidance, and ensuring safe and optimal performance in complex dynamics. Leveraging the connection between minimum-time trajectories and the boundary of reachable sets, we propose a sampling-based method for rapid and efficient approximation of reachable sets for finite- and low-thrust spacecraft. The proposed method combines a minimum-time multi-stage indirect formulation with the celebrated primer vector theory. Reachable sets are generated under two-body and circular restricted three-body (CR3B) dynamics. For the two-body dynamics, reachable sets are generated for (1) the heliocentric phase of a benchmark Earth-to-Mars problem, (2) two scenarios with uncertainties in the initial position and velocity of the spacecraft at the time of departure from Earth, and (3) a scenario with a bounded single impulse at the time of departure from Earth. For the CR3B dynamics, several cislunar applications are considered, including L1 Halo orbit, L2 Halo orbit, and Lunar Gateway 9:2 NRHO. The results indicate that low-thrust spacecraft reachable sets coincide with invariant manifolds existing in multi-body dynamical environments. The proposed method serves as a valuable tool for qualitatively analyzing the evolution of reachable sets under complex dynamics, which would otherwise be either incoherent with existing grid-based reachability approaches or computationally intractable with a complete Hamilton–Jacobi–Bellman method. Full article
