Urban renewal and improving the structural resilience of infrastructure are the hotspots of attention in all walks of life. The structural resilience of existing infrastructure and engineering structures is deteriorating with the increase in service life. In order to quickly improve the structural resilience and service life of existing engineering structures, a new method of rapid reinforcement for in-service concrete beams is proposed in this paper, which is the external prestressed reinforcement method of the side façade. The specific procedure involves creating a penetration hole at each end of the side surface of the concrete beam, inserting a prestressed support rod into the hole and subsequently installing a prestressed long bolt within the support rod. External prestress is applied to the side façade of the concrete beam through prestressed bolts. A total of 21 reinforced concrete beams were designed and manufactured, including 3 contrast beams of ordinary concrete, 9 concrete beams reinforced with traditional external prestressing steel and 9 concrete beams reinforced with externally prestressed steel on side façades. Different initial prestressing forces were applied to the reinforced beams, and flexural shear tests and numerical analyses were carried out on the concrete beams. The failure modes and shear resistances were analyzed. This research demonstrates that, in comparison with the control beam, the ultimate bearing capacity of the traditionally externally prestressed concrete beams increased by 137.8% to 140.8%, depending on the initial prestress difference. For the externally prestressed concrete beams applied to the side façade, these increases range from 42.6% to 52.0%. Furthermore, the cracking load and yield load of the reinforced concrete beams are significantly enhanced, thereby improving their operational performance. Additionally, the numerical results confirm that the theoretical calculations align well with the experimental findings. Full article

A quasi-static finite cavity cylindrical expansion model is proposed to investigate the lateral boundary effect during long-rod penetration. Analytical solutions for the cavity pressure in the elastic–plastic stage and plastic stage are obtained, through which a decay function for the lateral boundary effect is constructed. The resistance of the target with finite diameter R_T is obtained by multiplying the decay function with the resistance of infinite target R_T*. Then, a theoretical model for the penetration into the metal targets with finite diameters by long rods is proposed by substituting R_T into the Alekseevskii–Tate model. The proposed model is verified by comparison with existing experimental results. Furthermore, the effect of the target diameter, initial impact velocity and yield criterion on the penetration depth and resistance are investigated. The results showed that the lateral boundary effect should be taken into account if the ratio of the target radius to the rod radius (r_t0/R_P) is less than 25. Full article

In this paper, the mechanical properties, penetration characteristics, and deformation behaviors of FeNiCoCr high-entropy alloys (HEAs) annealed at different temperatures were investigated. The quasi-static and dynamic compression tests were conducted by a universal testing machine and Split Hopkinson Pressure Bar (SHPB) system, respectively. Furthermore, the penetration experiments of long rod projectiles (LRPs) of FeNiCoCr HEAs into semi-infinite steel targets launched by a small caliber ballistic gun with velocities ranging from 650 m/s to 1500 m/s were carried out, in comparison with that of steel LRPs. The microstructures of recovered projectiles were observed by the X-ray diffraction, optical microscope, and transmission electron microscope, which were used to further analyze the deformation behaviors of FeNiCoCr HEAs. The results showed that FeNiCoCr HEAs owned a single face-centered cubic structure. Annealing twins and grain refinement were detected, affecting the yield strength of the alloys. The strength of the alloy annealed at 600 °C was the highest and then decreased with the increasing annealing temperature. At higher strain rates, special adiabatic shear characteristics occurred in the alloys, while twins dominated the whole deformation process of the projectiles. Compared to other annealed alloys, the alloy annealed at 600 °C performed the best penetration performance. While the impact velocity had significant effects on the penetration performance of the alloy annealed at 1000 °C, the penetration performance of the alloy annealed at 850 °C on steel targets was almost the same as that of the steel LRPs. Full article

Preliminary cleaning of the surface of hydraulic cylinder rods is of great importance for subsequent coating. The most widely used surface preparation for thermal spraying is jet-abrasive treatment. The shot blast modes provide the hardness and strength of the material being processed. The impact of the abrasive makes the surface rough, increasing the contact area. Experimental studies of jet-abrasive processing of the hydraulic cylinder rod surface, as well as its activation for the thermal spraying, were carried out. The prepared surface of the rod for thermal spraying must meet the requirements for surface roughness and the size of the hardened layer at work. The experiments made it possible to identify the optimal modes of jet-abrasive treatment, which affect surface roughness and abrasive penetration of abrasive. To obtain the desired roughness values, it is preferable to use the following: a steel shot with an abrasive particle size in the range of 0.3–1.5 mm, taking the compressed air pressure in the range of 0.4–0.7 MPa; processing time—within 3.5–5 min; counterflow angle with the surface—70–90°; consumption of abrasive particles—300–500 kg/h. A special installation for jet-abrasive processing has been designed, which makes it possible to restore the surfaces of long rods by thermal spraying directly at the site of operation of the large machines. Full article

At present, most cone penetration test experiments use cables to transmit data. The cables not only make the exploration operation very complicated, but also hinder the realization of automatic exploration. An excessively long cable can also bring about additional attenuation and noise during the transmission of probe signal. In order to simplify the procedures of exploration operation and to improve the detection accuracy, a cableless cone penetration test system is proposed in this study. It improved the system by using magnetic communication and converts the electrical signal into a magnetic signal at the connection of two adjacent probe rods for relay transmission. Exploratory experiments were carried out to evaluate the feasibility and accuracy of the new system. The experimental results show that the experimental data collected by the new system is more accurate than that collected by traditional CPT equipment with cable. The new system simplifies exploration operations and enables real-time data transmission to detect abnormalities in time. This anomaly usually means that the probe is pressed against hard rock. It is more convenient and accurate to use the new system for exploration. Full article

The study concerns a protection system applied against kinetic-energy penetrators (KEPs) composed of steel plates sandwiching a rubber layer. Laminated steel-elastomer armours represent non-explosive reactive (NERA) armours that take advantage of a so-called ‘bulging effect’ to mitigate KEP projectiles. Upon an impact, the side steel plates deform together with the deforming rubber interlayer. Their sudden deformation (bulging) in opposite directions disturbs long and slender KEP projectiles, causing their fragmentation. The presented discussion is based on the experimental investigation, confirming that the long-rod projectiles tend to fracture into several pieces due to the armour perforation. A numerical simulation accompanies the ballistic test providing an insight into the threat/target interactions. The presented experimental–numerical study explains the principles of the analysed protection mechanism and proves the efficiency of the materials composition making up the laminated non-reactive protection system. Full article

Magnesium hydride (MgH₂) has received significant attention due to its potential applications as solid-state hydrogen storage media for useful fuel cell applications. Even though MgH₂ possesses several attractive hydrogen storage properties, it cannot be utilized in fuel cell applications due to its high thermal stability and poor hydrogen uptake/release kinetics. High-energy ball milling, and mechanically-induced cold-rolling processes are the most common techniques to introduce severe plastic deformation and lattice imperfection in the Mg/MgH₂. Furthermore, using one or more catalytic agents is considered a practical solution to improve both the de-/rehydrogenation process of MgH₂.These treatments are usually dedicated to enhance its hydrogen storage properties and deduce its thermal stability. However, catalyzation of Mg/MgH₂ powders with a desired catalytic agent using ball milling process has shown some disadvantages due to the uncontrolled distribution of the agent particles in the MgH₂ powder matrix. The present study has been undertaken to employ a cold gas-dynamic spray process for catalyzing the fresh surfaces of mechanically-induced cold-rolled Mg ribbons with Ni powder particles. The starting Mg-rods were firstly heat treated and forged 200 times before cold rolling for 300 passes. The as-treated ribbons were then catalyzed by Ni particles, using cold gas-dynamic spray process. In this catalyzation approach, the Ni particles were carried by a stream of Ar gas via a high-velocity jet at a supersonic velocity. Accordingly, the pelted Ni particles penetrated the Mg-substrate ribbons, and hence created numerous micropores into the Mg, allowed the Ni particles to form a homogeneous network of catalytic active sites in Mg substrate. As the number of coating time increased to three times, the Ni concentration increased (5.28 wt.%), and this led to significant enhancement of the Mg-hydrogen storage capacity, as well as improving the de-/rehydrogenation kinetics. This is evidenced by the high value of hydrogen storage capacity (6.1 wt.% hydrogen) and the fast gas uptake kinetics (5.1 min) under moderate pressure (10 bar) and temperature (200 °C). The fabricated nanocomposite MgH₂/5.28 wt.% Ni strips have shown good dehydrogenation behavior, indicated by their capability to desorb 6.1 wt.% of hydrogen gas within 11 min at 200 °C under 200 mbar of hydrogen pressure. Moreover, this system possessed long cycle-life-time, which extended to 350 h with a minimal degradation in the storage and kinetics behavior. Full article

The fracture failure of a high-speed long rod has historically been a challenge. Since the flying plate and flying rod have a relatively low velocity, it is challenging to achieve a multi-stage fracture of the high-speed long rod within the range of existing technology. In this paper, the linear explosively formed penetrators (LEFPs) sequence with a stable flight velocity of 850 m/s were used to cut a high-speed long rod. We investigated the deformation and fracture of Φ10 mm tungsten alloy long rods having different length-diameter ratios (20, 26, 35) and different speeds (1200, 1400, 1600 m/s) by employing the LEFPs sequence with different spacings (0–40 mm) and different interception angles (30°, 60°). In the meantime, the fractured rods movement pattern was recorded with a high-speed camera to elucidate the change law of the length, speed, linear momentum, and angular momentum of fractured rods. It was found that the length loss rate of the fractured rods is as high as 27%. The fractured rods rotated around the center of mass, and the vertical speed change could reach up to 18% of the muzzle velocity of the long rod, and the greatest reduction of horizontal speed and momentum could reach 37%. The longer the interaction time between LEFPs sequence and the long rod, the more beneficial the failure of the long rod. The application of LEFPs sequence solved the difficult problem of disabling the high-speed long rod, and the quantitative analysis of the fracture failure of the long rod had an important sense for studying the terminal penetration effect of the fractured rods. Full article

Detonation waves will bypass a wave shaper and propagate in the form of a horn wave in shaped charge. Horn waves can reduce the incidence angle of a detonation wave on a liner surface and collide with each other at the charge axis to form overdriven detonation. Detection electronic components of small-caliber terminal sensitive projectile that are limited by space are often placed inside a wave shaper, which will cause the wave shaper to no longer be uniform and dense, and weaken the ability to adjust detonation waves. In this article, we design a double-layer shaped charge (DLSC) with a high-detonation-velocity explosive in the outer layer and low-detonation-velocity explosive in the inner layer. Numerical and experimental simulation are combined to compare and analyze the forming process and penetration performance of explosively formed projectile (EFP) in DLSC and ordinary shaped charge (OSC). The results show that, compared with OSC, DLSC can also adjust and optimize the shape of the detonation wave when the wave shaper performance is poor. DLSC can obtain long rod EFPs with a large length-diameter ratio, which greatly improves the penetration performance of EFP. Full article

Oblique ceramic armor structure composed of an oblique part and a backing part was designed to resist the ballistic impact of long rod penetrators. The front part consisted of an oblique silicon carbide ceramic and a triangular titanium alloy prism. The backing part contained layered silicon carbide and armor steel designed to absorb the residual energy of penetrators. The structure’s response to penetration was examined experimentally by considering different impact locations on oblique targets. Numerical simulations of the experiments were performed to reproduce the penetration and failure processes that occurred in the armor modules. In addition, a simple layer structure with the identical line-of-sight thickness of each material used in the oblique impact was simulated under a normal impact. The rod and target performances with the oblique impact and normal impact were compared and analyzed in detail. The results showed that the oblique structure had a better ballistic performance as a result of an extra short dwell period before penetrating the ceramic in comparison with the normal layer case. The ability of the oblique targets to defeat long rod projectiles differed with the impact location on the ceramic. The present study paves the way for ceramic armor obliquity applications. Full article

The moisture condition of the active layer in Arctic regions can induce severe problems, such as ground subsidence and frost heave. Thus, the water content in the active layer needs to be estimated using a light and portable in-situ testing device. In this study, a penetration-type time domain reflectometry (PTDR) device is developed for the estimation of volumetric water content in the active layer. The developed PTDR is applied at a site for an electrical resistivity survey to characterize the water distribution along a measurement line. A PTDR consists of a PTDR module, connecting rods, and a guide with a hammer. The PTDR module can determine the dielectric constant of a material from the measurement of the travel time of electromagnetic waves. Using remolded soil samples, the dielectric constants measured from the PTDR are calibrated with the volumetric water content. The PTDR calibration demonstrates that the dielectric constant increases with the water content. For the temperature of 0.1 to 15.2 °C, the travel time only slightly depends on the temperature variance. For field application, a PTDR is pressed into the ground and measures the electromagnetic waves and temperature with depth. The results of the field tests show that the volumetric water content measured by the PTDR increases with depth due to the impermeable layer located underneath the active layer. The electrical resistivity survey conducted at the same site provides the electrical resistivity profile for a long distance and shallow depth soils. Furthermore, the electrical resistivity survey and PTDR establish a significant correlation between electrical resistivity and water content. The PTDR developed in this study can be effectively used as an advanced in-situ testing method to estimate the water distribution in the active layer. Full article
