The structural response of single-story timber houses subjected to the 27 February 2010 Chile tsunami is studied in San Juan Bautista, an island town located nearly 600 km westward from the earthquake’s rupture source, in the Pacific Ocean. The ASCE 7-22 energy grade line analysis (EGLA) is used to calculate flow depths and velocities as functions of the topography and recorded runup. To understand the structural response along the topography, reactions and displacements are computed at six positions every 50 m from the coastline. Houses are modeled using the Robot software, considering dead and live loads cases under the Load and Resistance Factor Design (LRFD) philosophy. The results show that houses located near the coastline experience severe displacements and collapse due to a combination of hydrodynamic forces, drag and buoyancy, which significantly reduces the efficiency of the foundations’ anchorage. Structures far from the coastline are less exposed to reduced velocities, resulting in decreased displacements, structural demand and a tendency to float. Finally, the methodology is validated by applying a nonlinear analysis of the structures subjected to tsunami loads at the different positions considered in this study. Despite their seismic resistance, lightweight timber houses are shown to not be suitable for areas prone to tsunamis. Tsunami-resilient design should therefore consider heavier and more rigid materials in flooding areas and the relocation of lightweight structures in safe zones. Full article

Fibre-reinforced polymer (FRP) reinforcement has been employed as an alternative to conventional steel reinforcement in concrete structures, which is attributed to its excellent strength and corrosion resistance. However, one drawback is that FRP reinforcements are brittle and affect the ductility of concrete structures. One of the recent effective techniques proposed to overcome ductility issues is the compression yielding (CY) concept. The CY mechanism allows the structure to fail differently than the conventional FRP-reinforced concrete structure. Thus, the existing design recommendations as per the current codes for FRP-reinforced concrete structures are not appropriate. Hence, reliability studies are crucial for the development of a functional CY beam design in order to emphasise the structure’s lifetime performance and to guarantee safety requirements. In this study, a reliability-based design approach is developed for a compression-yielded FRP-reinforced concrete beam (CY beam) using load and resistance factor design (LRFD). Firstly, the flexural failure modes of CY beams are discussed. The uncertainties involved in the development of the probabilistic model for the CY beam are defined. A case study is consequently conducted for a CY beam with random variables that are associated with the statistical characteristics of material properties and load. The reliability analysis method employed in this research is the Hasofer–Lind method. The results suggest the importance of choosing appropriate design variables and stochastic parameters for CY blocks that contribute to a higher level of reliability. The reliability index and resistance factors of a CY beam are then evaluated using the Monte Carlo Simulation computational method. The reliability index value of 3.336 is obtained from the simulation, which indicates that the CY beam demonstrates ductile behaviour. The results not only demonstrate ductile behaviour but also contribute to a possible reduction in material costs and a substantial safety margin. When compared to conventional FRP-reinforced concrete beams, for different load ratios, CY beams showed higher resistance and better reliability levels. Full article

This paper presents an analysis of long, large-diameter bored piles’ behavior under static and dynamic load tests for a megaproject located in El Alamein, on the northern shoreline of Egypt. Site investigations depict an abundance of limestone fragments and weak argillaceous limestone interlaid with gravelly, silty sands and silty, gravelly clay layers. These layers are classified as intermediate geomaterials, IGMs, and soil layers. The project consists of high-rise buildings founded on long bored piles of 1200 mm and 800 mm in diameter. Forty-four (44) static and dynamic compression load tests were performed in this study. During the pile testing, it was recognized that the pile load–settlement behavior is very conservative. Settlement did not exceed 1.6% of the pile diameter at twice the design load. This indicates that the available design manual does not provide reasonable parameters for IGM layers. The study was performed to investigate the efficiency of different approaches for determining the design load of bored piles in IGMs. These approaches are statistical, predictions from static pile load tests, numerical, and dynamic wave analysis via a case pile wave analysis program, CAPWAP, a method that calculates friction stresses along the pile shaft. The predicted ultimate capacities range from 5.5 to 10.0 times the pile design capacity. Settlement analysis indicates that the large-diameter pile behaves as a friction pile. The dynamic pile load test results were calibrated relative to the static pile load test. The dynamic load test could be used to validate the pile capacity. Settlement from the dynamic load test has been shown to be about 25% higher than that from the static load test. This can be attributed to the possible development of high pore water pressure in cohesive IGMs. The case study analysis and the parametric study indicate that AASHTO LRFD is conservative in estimating skin friction, tip, and load test resistance factors in IGMs. A new load–settlement response equation for 600 mm to 2000 mm diameter piles and new recommendations for resistance factors $\mathsf{\phi }$_qp, $\mathsf{\phi }$_qs, and $\phi$_load were proposed to be 0.65, 0.70, and 0.80, respectively. Full article

The Wave Equation Analysis of Pile Driving (WEAP) has been widely used to determine drivability, predict static resistance, and assure the integrity of piles in soils. Assigning static and dynamic properties of Soil-based Intermediate Geomaterials (S-IGMs) remains a challenge in WEAP, partly attributed to IGMs that act as transition geomaterials between soil and hard rock. Furthermore, reliable static analysis methods for unit resistance predictions are rarely available for driven piles in S-IGMs in the default WEAP method. To alleviate these challenges, this study presents improved WEAP methods for steel piles driven in S-IGMs, including proposed damping parameters and Load and Resistance Factor Design (LRFD) recommendations based on newly developed static analysis methods and the classification of S-IGMs. A back calculation approach is used to generate the appropriate damping parameters for S-IGMs for three distinct subsurface conditions utilizing a database of 34 steel H- and pipe piles. Newly developed WEAP and LRFD procedures are also recommended. Additional independent 22 test pile data are used to compare and evaluate the accuracy and efficiency of the proposed WEAP methods with the default WEAP method. Compared with the default WEAP, bearing graph analysis results revealed that the selected proposed WEAP method, on average, reduces the underprediction of pile resistances by 6% and improves the reliability with a 43% reduction in the coefficient of variation (COV). Calibrated resistance factors for the proposed WEAP method increase to as high as 0.75 compared to the current AASHTO recommendation of 0.50. An economic impact assessment reveals that the proposed WEAP method is more efficient than the default WEAP method as the average difference in steel weight for 32 test piles is 0.06 kg/kN, almost close to zero, reducing the construction challenges in the current engineering practice. Full article

Over the years, structural engineering codes and specifications in Canada and elsewhere have moved from an allowable stress design (ASD) approach to a load and resistance factor design (LRFD) philosophy. LRFD methodology takes better account of the inherent variability in both loading and resistance by providing different factors of safety for loads of distinct natures with regard to their probability of overload, frequency of occurrences and changes in point of application. The method also results in safer structures because it considers the behavior at collapse. While resistance factors for traditional construction materials based on LRFD in the National Building Code (NBC) of Canada are available, they cannot be used for non-conventional ones. This is because the resistance of such materials due to various load effects has unique bias factors (λ_R) and coefficients of variation (V_R), which greatly impact their reliability index (β). In this study, relationships between the resistance factor ϕ and critical load effects from the NBC load combinations at ultimate limit states are developed for a wide range of resistance bias factors and coefficients of variation. The relationships are presented in the form of charts that are useful for researchers and code-writing professionals who have expertise in the various fields of structural engineering but lack proper background in reliability theory. The developed spectra showed that for the same ϕ, β increases with an increase in the live-to-dead load (L/D) ratio until it reaches 1; thereafter, the shape of the relationship will depend on the statistics of the resistance as well as on the magnitude of ϕ. For a small ϕ and V_R, β will keep increasing with an increase in the L/D ratio from 1 until 3, albeit at a lesser rate. For L/D > 3, the relationship between the critical β and applied load is just about constant. This finding is also true for load combinations involving snow and wind. Application of the method is illustrated by a practical example involving the shear strength of a corrugated web steel beam. Full article

The load and resistance factor design (LRFD) method is normally used to design B-regions of reinforced concrete (RC) flexural members. The design includes many checks corresponding to different limit states. The LRFD method requires many loop calculation steps in the design, demonstrating its relative inefficiency. It cannot be applied to compare limit states directly and quantitatively. Different design limit states are separated and isolated. How to improve the analytical calculation efficiency of the LRFD method and to realize direct and quantitative comparisons between limit states are very important problems in structural engineering. This paper presents an innovative unified flexural resistance design (UFRD) method and a unified flexural resistance evaluation (UFRE) frame to solve these problems to some extent. The main contents include the unified flexural resistance (UFR) principles, formulas for the unified flexural resistance design (UFRD) method, the operation procedure to facilitate its usage, the UFRE framework to compare limit states, and three examples. The results show that the UFRD method can provide the same design outcomes as the LRFD one. However, UFRD calculations are simpler, requiring at most 20% of the calculation steps of the LRFD method. The UFRE frame can make different limit states compare with each other directly and quantitatively, which cannot be realized by the LRFD method. It helps expose some potential and insufficient flexural resistance hazards for some limit states, such as the only 10% relative strength reservation of one example. Thus, the UFRD method and the UFRE frame supplement and develop the LRFD method to some degree. The simplicity and practicality of the approach and the frame make them appropriate for many applications. Full article

Load and resistance factor design (LRFD) is widely used in building codes for reliability design. In the calculation of load and resistance factors, the third-moment method (3M) has been proposed to overcome the shortcomings (e.g., inevitable iterative computation, requirement of probability density functions (PDFs) of random variables) of other methods. With the existing 3M method, the iterative is simplified to one computation, and the PDFs of random variables are not required. In this paper, the computation of load and resistance factors is further simplified to no iterations. Furthermore, the accuracy of the proposed method is proved to be higher than the existing 3M methods. Additionally, with the proposed method, the limitations regarding applicable range in the existing 3M methods are avoided. With several examples, the comparison of the existing 3M method, the ASCE method, the Mori method, and the proposed method is given. The results show that the proposed method is accurate, simple, safe, and saves material. Full article

The total ultimate resistance (or bearing capacity) of driven piles considering setup effects is composed of initial ultimate resistance and setup resistance, and the setup effects of driven piles are mainly reflected by the setup resistance. In literature, a logarithmic empirical formula is generally used to quantify the setup effects of driven piles. This paper proposes an increase factor (M_setup) to modify the resistance factor and factor of safety calculation formula in accordance with the load and resistance factor design (LFRD) principle; here, the increase factor is defined as the ratio of the setup resistance (R_setup) to the initial ultimate resistance (R₀) of driven piles. Meanwhile, the correlation between R₀ and R_setup is fully considered in the resistance factor and factor of safety calculation. Finally, the influence of four key parameters (ratio of dead load to live load ρ = Q_D/Q_L, target reliability index β_T, M_setup, correlation coefficient between R₀ and R_setup, ρ_R0,Rsetup) on the resistance factor and factor of safety are analyzed. Parametric research shows that ρ has basically no effect on the resistance factor, which can be taken as a constant in further research, and ρ has a significant influence on the factor of safety. The value of M_setup has almost no effect on the resistance factor and factor of safety. However, β_T and ρ_R0,Rsetup have a significant influence on the resistance factor and factor of safety, so the value selection of β_T and ρ_R0,Rsetup are crucial for reliability-based design of driven piles. Through this study, it is concluded that considering setup effects in reliability-based design of driven piles will greatly improve the prediction for design capacity. Full article

Belitic calcium sulfoaluminate (BCSA) cement is a sustainable alternative to Portland cement that offers rapid setting characteristics that could accelerate throughput in precast concrete operations. BCSA cements have lower carbon footprint, embodied energy, and natural resource consumption than Portland cement. However, these benefits are not often utilized in structural members due to lack of specifications and perceived logistical challenges. This paper evaluates the performance of a full-scale precast, prestressed voided deck slab bridge girder made with BCSA cement concrete. The rapid-set properties of BCSA cement allowed the initial concrete compressive strength to reach the required 4300 psi release strength at 6.5 h after casting. Prestress losses were monitored long-term using vibrating wire strain gages cast into the concrete at the level of the prestressing strands and the data were compared to the American Association of State Highway and Transportation Officials Load and Resistance Factor Design (AASHTO LRFD) predicted prestress losses. AASHTO methods for prestress loss calculation were overestimated compared to the vibrating wire strain gage data. Material testing was performed to quantify material properties including compressive strength, tensile strength, static and dynamic elastic modulus, creep, and drying and autogenous shrinkage. The material testing results were compared to AASHTO predictions for creep and shrinkage losses. The bridge girder was tested at mid-span and at a distance of 1.25 times the depth of the beam (1.25d) from the face of the support until failure. Mid-span testing consisted of a crack reopening test to solve for the effective prestress in the girder and a flexural test until failure. The crack reopen effective prestress was compared to the AASHTO prediction and AASHTO appeared to be effective in predicting losses based on the crack reopen data. The mid-span failure was a shear failure, well predicted by AASHTO LRFD. The 1.25d test resulted in a bond failure, but nearly developed based on a moment curvature estimate indicating the AASHTO bond model was conservative. Full article

The present paper deals with the practical problem of reducing statistical uncertainty in elastic settlement analysis of shallow foundations by relying on targeted field investigation with the aim of an optimal design. In a targeted field investigation, the optimal number and location of sampling points are known a priori. As samples are taken from the material field (i.e., the ground), which simultaneously is a stress field (stresses caused by the footing), the coexistence of these two fields allows for some points in the ground to better characterize the serviceability state of structure. These points are identified herein through an extensive parametric analysis of the factors controlling the magnitude of settlement; the number of different cases considered was 3318. This is done in an advanced probabilistic framework using the Random Finite Element Method (RFEM) properly considering sampling of soil property values. In this respect, the open source RSETL2D program, which combines elastic finite element analysis with the theory of random fields, has been modified as to include the function of sampling of soil property values from the generated random fields and return the failure probability of footing against excessive settlement. Two sampling strategies are examined: (a) sampling from a single point and (b) sampling a domain (the latter refers to e.g., continuous cone penetration test data). As is shown in this work, by adopting the proper sampling strategy (defined by the number and location of sampling points), the statistical error can be significantly reduced. The error is quantified by the difference in the probability of failure comparing different sampling scenarios. Finally, from the present analysis, it is inferred that the benefit from a targeted field investigation is much greater as compared to the benefit from the use of characteristic values in a limit state design framework. Full article

Load and resistance factor design (LRFD) is a limit state design method that has been applied worldwide. Because the data for determining LRFD factors in Korea has been insufficient, the resistance factors suggested by American Association of State Highway and Transportation Officials (AASHTO) in the US have been used for design in Korea; however, these resistance factors were defined based on the characteristics of the predominant bedrock types in the U.S. As such, it remains necessary to determine resistance factors that reflect the bedrock conditions in Korea. Accordingly, in this study, LRFD resistance factors were determined using 13 sets of drilled shaft load test data. To obtain accurate resistance factors, calibration of the elastic modulus of the drilled shaft and the equivalent load–displacement curve considering the axial load and elastic settlement was conducted. After determining accurate resistance values, a reliability analysis was performed. The resistance factors were determined to be within 0.13–0.32 of the AASHTO factors for the shaft resistance, 0.19–0.29 for the base resistance, and 0.28–0.42 for the total resistance. This is equivalent to being 30–60% of the AASHTO-recommended values for the shaft resistance and 40–60% of the AASHTO-recommended values for the base resistance. These differences in resistance factors were entirely the result of discrepancies in the conditions of the rock in the US and Korea in which the shafts were founded. Full article

Because the methods used to compute the live load distribution for moment and shear force in modern highway bridges subjected to vehicle loading are generally constrained by their range of applicability, refined analysis methods are necessary when this range is exceeded or new materials are used. This study developed a simplified method to calculate the live load distribution factors for skewed composite slab-on-girder bridges with high-performance-steel (HPS) girders whose parameters exceed the range of applicability defined by the American Association of State Highway and Transportation Officials (AASHTO)’s Load and Resistance Factor Design (LRFD) specifications. Bridge databases containing information on actual bridges and prototype bridges constructed from three different types of steel and structural parameters that exceeded the range of applicability were developed and the bridge modeling verified using results reported for field tests of actual bridges. The resulting simplified equations for the live load distribution factors of shear force and bending moment were based on a rigorous statistical analysis of the data. The proposed equations provided comparable results to those obtained using finite element analysis, giving bridge engineers greater flexibility when designing bridges with structural parameters that are outside the range of applicability defined by AASHTO in terms of span length, skewness, and bridge width. Full article
