The digital integrated circuit (IC) design industry is continuously evolving. However, the rapid advancements in technology are accompanied by major reliability concerns. Conventional clock-based synchronous designs become exceedingly susceptible to transient errors, caused by radiation rays, power jitters, electromagnetic interferences (EMIs), and/or other noise sources, primarily due to aggressive device and voltage scaling. quasi-delay-insensitive (QDI) asynchronous (clockless) circuits demonstrate inherent robustness against such transient errors, owing to their unique architecture. However, they are not completely immune. This article presents a hardened QDI Sleep Convention Logic (SCL) asynchronous architecture, which can fully recover from radiation-induced single-event effects such as single-event upset (SEU) and single-event latch-up (SEL). Multiple benchmark circuits are designed based on the proposed architecture. The simulation results indicate that the proposed designs offer substantial energy savings per operation, dissipate substantially less power during idle phases, and have lower area footprints in comparison to designs based on an existing resilient Null Convention Logic (NCL) architecture at the cost of increased latency. In addition, a formal verification framework for the proposed architecture is also presented. The performance and scalability of the proposed verification scheme are demonstrated using several multiplier benchmark circuits of varying width. Full article

Monotonic circuits are a class of input–output mode (IOM) asynchronous circuits that are relaxed compared to quasi-delay-insensitive (QDI) IOM asynchronous circuits in terms of signaling the completion of internal processing. Some recent works have demonstrated the superiority of monotonic logic over QDI logic for arithmetic circuits such as adders and multipliers. This paper presents a new monotonic asynchronous two-bit full adder (TFA) that can be duplicated and cascaded to form a ripple-carry adder (RCA). While an RCA is a slow adder with respect to synchronous design, with respect to IOM asynchronous design an RCA is a noteworthy adder since it has perhaps the least reverse latency that is not attainable through other IOM asynchronous adders. Conventionally, an RCA is constructed via a cascade of one-bit full adders (OFAs). An OFA adds two input bits along with any carry input and produces a sum bit and any carry output. On the other hand, a TFA simultaneously adds two pairs of input bits along with any carry input and produces two sum bits and any carry output. Using our proposed monotonic TFA, we realized an RCA to compare its performance with RCAs constructed using different asynchronous OFAs, and RCAs constructed using existing TFAs. We considered the popular delay-insensitive dual-rail scheme for encoding the adder inputs and outputs, and two 4-phase handshake protocols, namely return-to-zero handshaking (R0H) and return-to-one handshaking (R1H) for communication separately. We used a 28 nm CMOS process for implementation and considered a 32-bit addition as an example. Based on the design metrics estimated, the following inferences were derived: (i) compared to the RCA using the state-of-the-art monotonic OFA, the RCA incorporating the proposed TFA achieved a 26% reduction in cycle time for R0H and a 28.5% reduction in cycle time for R1H while dissipating almost the same power; the cycle time governs the data application rate in an IOM asynchronous circuit, and (ii) compared to the RCA comprising an early output QDI TFA, the RCA incorporating the proposed TFA achieved a 22.3% reduction in cycle time for R0H and a 25.4% reduction in cycle time for R1H while dissipating moderately less power. Also, compared to the existing early output QDI TFA, the proposed TFA occupies 40.9% less area for R0H and 42% less area for R1H. Full article

Predicting hard disk failure effectively and efficiently can prevent the high costs of data loss for data storage systems. Disk failure prediction based on machine learning and artificial intelligence has gained notable attention, because of its good capabilities. Improving the accuracy and performance of disk failure prediction, however, is still a challenging problem. When disk failure is about to occur, the time is limited for the prediction process, including building models and predicting. Faster training would promote the efficiency of model updates, and late predictions not only have no value but also waste resources. To improve both the prediction quality and modeling timeliness, a two-layer classification-based feature selection scheme is proposed in this paper. An attribute filter calculating the importance of attributes was designed, to remove attributes insensitive to failure identification, where importance is gained based on the idea of classification tree models. Furthermore, by determining the correlation between features based on the correlation coefficient, an attribute classification method is proposed. In experiments, the models of machine learning and artificial intelligence were applied, and they included naïve Bayesian, random forest, support vector machine, gradient boosted decision tree, convolutional neural networks, and long short-term memory. The results showed that the proposed technique could improve the prediction accuracy of ML/AI-based hard disk failure prediction models. Specifically, utilizing random forest and long short-term memory with the proposed technique showed the best accuracy. Meanwhile, the proposed scheme could reduce training and prediction latency by 75% and 83%, respectively, in the best case compared with the baseline methods. Full article

This paper presents a methodology for the design of field-programmable gate array (FPGA)-based real-time simulators (RTSs) for power electronic circuits (PECs). The programmability of the simulator results from the use of an efficient and scalable overlay architecture (OA). The proposed OA relies on a latency-insensitive design (LID) paradigm. LID consists of connecting small processing units that automatically synchronize and exchange data when appropriate. The use of such data-driven architecture aims to ease the design process while achieving a higher computational efficiency. The benefits of the proposed approach is evaluated by assessing the performance of the proposed solver in the simulation of a two-stage AC–AC power converter. The minimum achievable time-step and FPGA resource consumption for a wide range of power converter sizes is also evaluated. The proposed overlays are parametrizable in size, they are cost-effective, they provide sub-microsecond time-steps, and they offer a high computational performance with a reported peak performance of 300 GFLOPS. Full article

Remote sensing is recognized as a cornerstone monitoring technology. The latest high-resolution and high-speed spaceborne imagers provide an explosive growth in data volume and instrument data rates in the range of several Gbps. This competes with the limited on-board storage resources and downlink bandwidth, making image data compression a mission-critical on-board processing task. The Consultative Committee for Space Data Systems (CCSDS) Image Data Compression (IDC) standard CCSDS-122.0-B-1 is a transform-based 2D image compression algorithm designed specifically for use on-board a space platform. In this paper, we introduce a high-performance architecture for a key-part of the CCSDS-IDC algorithm, the 9/7M Integer Discrete Wavelet Transform (DWT). The proposed parallel architecture achieves 2 samples/cycle while the very deep pipeline enables very high clock frequencies. Moreover, it exploits elastic pipeline principles to provide modularity, latency insensitivity and distributed control. The implementation of the proposed architecture on a Xilinx Kintex Ultrascale XQRKU060 space-grade SRAM FPGA achieves state-of-the-art throughput performance of 831 MSamples/s (13.3 Gbps @ 16bpp) allowing seamless integration with next-generation high-speed imagers and on-board data handling networking technology. To the best of our knowledge, this is the fastest implementation of the 9/7M Integer DWT on a space-grade FPGA, outperforming previous implementations. Full article

With the growth of the internet of things (IoT), many challenges like information security and privacy, interoperability/standard, and regulatory and legal issues are arising. This work focused on the information security issue, which is one of the primary challenges faced by connected systems that needs to be resolved without impairing system behaviour. Information, which is made available on the Internet by the things, varies from insensitive information (e.g., readings from outdoor temperature sensors) to extremely sensitive information (e.g., video stream from a camera) and needs to be secured over the Internet. Things which utilise cameras as a source of information pertain to a subclass of the IoT called IoVT (internet of video things). This paper presents secured and unsecured video latency measurement results over the Internet for a marine ROV (remotely operated vehicle). A LabVIEW field programmable gate arrays (FPGAs)-based bump-in-the-wire (BITW) secure core is used to provide an AES (advanced encryption standard)-enabled security feature on the video stream of an IoVT node (ROV equipped with a live-feed camera). The designed LabVIEW-based software architecture provides an option to enable/disable the AES encryption for the video transmission. The latency effects of embedding encryption on the stream with real-time constraints are measured and presented. It is found that the encryption mechanism used does not greatly influence the video feedback performance of the observed IoVT node, which is critical for real-time secure video communication for ROV remote control and piloting. The video latency measurement results are taken using 128, 256 and 512 bytes block lengths of AES for both H.264 and MJPEG encoding schemes transmitted over both TCP and UDP transmission protocols. The latency measurement is performed in two scenarios (i.e., with matching equipment and different equipment on either end of the transmission). Full article

Hydropower as renewable energy has continually expanded at a relatively high rate in the last decade. This expansion calls for more accurate scheme design in hydraulic turbine governing system (HTGS) to ensure its high efficiency. Sliding mode control (SMC) as a robust control method which is insensitive to system uncertainties and disturbances raises interest in the application in HTGS. However, the feature of highly coupled state variables reflects the nonlinear essence of HTGS and SMC studies on the related mathematical model under certain fluctuations are not satisfied. In this regard, a novel SMC design with proportional-integral-derivative manifold is firstly applied to a nonlinear HTGS with a complex conduit system. In dealing with certain fluctuations in speed and load around the rated working condition, the proposed SMC is capable of driving the system to the desired state with smooth and light responses in aspects of the key state variables. The exponential reaching law and introduced boundary layer fasten the speed of converging time and suppress chattering. A necessary integral of sliding parameter added to manifold successfully reduces the latency caused by the anti-regulation feature of HTGS. Three operating scenarios are simulated compared with the PSO-PID method, and results imply that the proposed SMC method equips with accurate trajectory tracking ability and smooth responses. Finally, the strong robustness against system uncertainties is tested. Full article
