In large-scale low-lift pumping stations, in order to adopt siphon outlet channels under the condition of no water in the outlet channel, a retaining weir needs to be set on the outlet side of the pumping station. To ensure the safe and stable operation of the retaining weir, the problem of energy dissipation of the retaining weir needs to be solved. Based on the VOF two-phase flow model, numerical simulations of three-dimensional turbulent flows were carried out for energy dissipation measures such as stilling basins, toe pier energy dissipation, suspended grid for energy dissipation, and their combinations, and the flow fields, hydraulic characteristics, and energy dissipation effects under different energy dissipation measures were compared. The research shows that the toe pier–suspended grid combined scheme can effectively break and weaken the large-scale vortices behind the retaining weir. Compared with the case of only using a stilling basin for energy dissipation, the maximum bottom velocity is reduced by 31%, and the maximum dissipation rate is increased by 119%. A comprehensive evaluation objective function is established with the relative bottom velocity and energy dissipation rate in the stilling basin as the quantification indexes. Through further analysis, the value of the toe pier–suspended grid combined scheme is the lowest, which is 37.84% lower than that of the traditional stilling basin, and the energy dissipation efficiency is the best. The toe pier–suspended grid combined scheme effectively optimizes flow conditions and improves energy dissipation, offering theoretical and engineering references for the energy dissipation design of retaining weirs in low-lift and large-flow pumping stations. Full article

To address the technical challenge where traditional high-pressure, large-flow emulsion pump stations cannot adapt to the drastic flow rate changes in hydraulic supports due to the fixed displacement of their quantitative pumps—leading to frequent system unloading, severe impacts, and damage—this study proposes an intelligent flow control method based on the digital flow distribution principle for actively perceiving and matching support demands. Building on this method, a compact, electro-hydraulically separated prototype with stepless flow regulation was developed. The system integrates high-speed switching solenoid valves, a piston push rod, a plunger pump, sensors, and a controller. By monitoring piston position in real time, the controller employs an optimized combined regulation strategy that integrates adjustable duty cycles across single, dual, and multiple cycles. This dynamically adjusts the switching timing of the pilot solenoid valve, thereby precisely controlling the closure of the inlet valve. As a result, part of the fluid can return to the suction line during the compression phase, fundamentally achieving accurate and smooth matching between the pump output flow and support demand, while significantly reducing system fluctuations and impacts. This research adopts a combined approach of co-simulation and experimental validation to deeply investigate the dynamic coupling relationship between the piston’s extreme position and delayed valve closure. It further establishes a comprehensive dynamic coupling model covering the response of the pilot valve, actuator motion, and backflow control characteristics. By analyzing key parameters such as reset spring stiffness, piston cylinder diameter, and actuator load, the system reliability is optimized. Evaluation of the backflow strategy and delay phase verifies the effectiveness of the multi-mode composite regulation strategy based on digital displacement pump technology, which extends the effective flow range of the pump to 20–100% of its rated flow. Experimental results show that the system achieves a flow regulation range of 83% under load and 57% without load, with energy efficiency improved by 15–20% due to a significant reduction in overflow losses. Compared with traditional unloading methods, this approach demonstrates markedly higher control precision and stability, with substantial reductions in both flow root mean square error (53.4 L/min vs. 357.2 L/min) and fluctuation amplitude (±3.5 L/min vs. ±12.8 L/min). The system can intelligently respond to support conditions, providing high pressure with small flow during the lowering stage and low pressure with large flow during the lifting stage, effectively achieving on-demand and precise supply of dynamic flow and pressure. The proposed “demand feedforward–flow coordination” control architecture, the innovative electro-hydraulically separated structure, and the multi-cycle optimized regulation strategy collectively provide a practical and feasible solution for upgrading the fluid supply system in fully mechanized mining faces toward fast response, high energy efficiency, and intelligent operation. Full article

Due to the uneven distribution of water resources, there are many water diversion projects around the world, such as the South-to-North Water Diversion Project in China, especially in some plain areas. To transfer water from low to high areas, large low-head pumps have been widely used. The transition process of the pumping station is mainly caused by the sudden change in the flow velocity and pressure of the fluid in the pipeline of the pumping station system caused by the start-up and shutdown processes. The previous research has mainly been based on the one-dimensional characteristic line method. However, due to the characteristics of the low-lift pumping station, the flow passage is short and irregular, and the calculation results often cannot guarantee the accuracy of the calculation. In addition to some faults in the actual operation process, in some pumping stations, accidents or operation-scheduling faults are caused by transient processes, such as a high degree of water hammer, the inability to initiate backward flow, the shutdown load rejection runaway exceeding the standard, and decreased hydraulic efficiency. To avoid transition process failures in the newly designed pumping stations and the modified pumping stations, it is necessary to carry out a research review of the three-dimensional transition process of large low-lift pumps. Especially with the development of computing technology, CFD numerical simulation technology has become the main research method for analyzing the pump transition process. The research on the transition process is mainly based on the combination of numerical simulations and experiments. The reliability of a numerical simulation is verified by an experiment. A numerical simulation can measure some parameters that cannot be measured by an experiment. Dynamic mesh technology has become the main technical means for using CFD numerical simulation to study the three-dimensional transition process, and the secondary development of computing software has become the main trend of future development. This paper analyzes and summarizes the research status of the start–stop transition process of large low-lift pump stations and provides a reference for the protection of the start–stop transition process of pump stations. Full article
