Busbars are critical components that connect high-current and high-voltage subcomponents in high-power converters. This paper reviews the latest busbar design methodologies and offers design recommendations for both laminated and PCB-based busbars. Silicon Carbide (SiC) power devices switch at much higher speeds compared to traditional silicon devices, making them more susceptible to parasitic elements within the busbar. In high-frequency SiC converters, using thicker copper offers limited improvement in high-frequency current handling due to the reduced skin depth at such frequencies. PCB busbars, however, provide several advantages, including reduced loop inductance, enhanced high-frequency current capacity, simplified assembly, and lower costs. Additionally, they enable the integration of components such as sensors, capacitors, and resistors, which can further optimize overall system performance. This paper also presents optimized busbar designs for both module-based and discrete device-based SiC high-power converters, comparing various SiC power module packages and offering design insights. Finally, this paper showcases a 75 kW three-phase inverter utilizing a PCB busbar, demonstrating its potential for achieving high power density and cost-effectiveness in discrete SiC device-based high-power converters. Full article

The reliability of components of industrial electrical assets fed by power electronics might be at risk due to the type and extent of electrothermal stresses. The move of power electronics toward higher levels of voltage, switching frequency, slew rate, and specific power increases the risk of partial discharge inception and thus of accelerated extrinsic aging and premature failure. The reaction to this challenge is to embrace the concept of partial discharge-free (PD-free) design and operation. This paper presents a PD-free approach to the design of laminated busbars, considering both AC and DC insulation subsystems, and focusing on surface insulation. The availability of a recently proposed model to estimate the inception field is a key tool. The model is validated through PD measurements performed on a laminated busbar, using new automatic software that can identify the type of source generating PD. Combined with electric field calculations, the model provides estimates of the PD inception voltage which are almost coincident with the measurement results. Inception voltages in the order of 10 kV and 20 kV have been observed for AC and DC excitation, respectively. In the case of DC supply, tests at different ambient temperatures, 25 °C and 60 °C, indicate that the inception voltage does not change significantly with temperature. Disposability, scalability to any voltage/power, and capability to work, potentially, for any other type of insulation system, are interesting features of the proposed approach, which are discussed in the paper. Full article

This work focused on the verification of the electrical parameters and the durability of side connectors installed in glass–glass photovoltaic modules. Ensuring the safe use of photovoltaic modules is achieved, among others, by using electrical connectors connecting the PV cell circuit inside the laminate with an external electric cable. In most of the cases for standard PV modules, the electrical connector in the form of a junction box is attached from the back side of the PV module. The junction box is glued to the module surface with silicone where the busbars were previously brought out of the laminate through specially prepared holes. An alternative method is to place connectors on the edge of the module, laminating part of it. In such a case, the specially prepared “wings” of the connector are tightly and permanently connected using laminating foil, between two glass panes protecting against an electrical breakdown. Additionally, this approach eliminates the process of preparing holes on the back side of the module, which is especially complicated and time-consuming in the case of glass–glass modules. Moreover, side connectors are desirable in BIPV applications because they allow for a more flexible design of installations on façades and walls of buildings. A series of samples were prepared in the form of PV G-G modules with side connectors, which were then subjected to testing the connectors for the influence of environmental conditions. All samples were characterized before and after the effect of environmental conditions according to PN-EN-61215-2 standards. Insulation resistance tests were performed in dry and wet conditions, ensuring full contact of the tested sample with water. For all modules, before being placed in the climatic chamber, the resistance values were far above the minimum value required by the standards, allowing the module to be safely used. For the dry tests, the resistance values were in the range of GΩ, while for the wet tests, the obtained values were in the range of MΩ. In further work, the modules were subjected to environmental influences in accordance with MQT-11, MQT-12, and MQT-13 and then subjected to electrical measurements again. A simulation of the impact of changing climatic conditions on the module test showed that the insulation resistance value is reduced by an order of magnitude for both the dry and wet tests. Additionally, one can observe visual changes where the lamination foil is in contact with the connector. The measurements carried out in this work show the potential of side connectors and their advantage over rear junction boxes, but also the technological challenges that need to be overcome. Full article

Silicon carbide (SiC) metal oxide semiconductor field effect transistors (MOSFETs) have many advantages compared to silicon (Si) MOSFETs: low drain-source resistance, high thermal conductivity, low leakage current, and high switching frequency. As a result, Si MOSFETs are replaced with SiC MOSFETs in many industrial applications. However, there are still not as many SiC modules to customize for each application. To meet the high-power requirement for custom applications, paralleling discrete SiC MOSFETs is an essential solution. However, it comes with many technical challenges; inequality in current sharing, different switching losses, different transient characteristics, and so forth. In this paper, the detailed MATLAB^®/Simulink^® Simpscape model of the SiC MOSFET from the datasheet and the simulation of the half-bridge circuit are investigated. Furthermore, this paper proposes the implementation of the four-paralleled SiC MOSFET half-bridge circuit with an improved symmetric gate driver layout. Moreover, a unique laminated busbar connected directly to the printed circuit board (PCB) is proposed to increase current and thermal capacity and decrease parasitic effects. Finally, the experimental and simulation results are presented using a 650 V SiC MOSFET (CREE) double-pulse test (DPT) circuit. The voltage overshoot problems and applied solutions are also presented. Full article

As a key component of a large-capacity converter, the laminated busbar can improve the reliability, integration and power density of the converter and has great advantages in reducing the parasitic inductance of the switching loop. The laminated busbar suitable for a high-capacity back-to-back converter has a complex structure, and couple with each side converter. It has been challenging to optimize the equivalent inductance by using the traditional single-converter busbar design method. In this paper, the coupling inductance model of the back-to-back converter is established, and the relationship between the voltage stress of the switch tube and the stray inductance is analyzed in detail. Based on this, the design principle of the laminated busbar is proposed, and an optimized design structure of the laminated busbar suitable for the large-capacity back-to-back converter is given. Finally, the results were effectively verified by simulation analysis and a 180 kW integrated intermediate frequency auxiliary power converter. Full article

At present, the DC busbar design is one of the bottlenecks restricting the improvement of the power density of motor drives. Therefore, this paper proposes a three-dimensional line probe algorithm, which can realize the automatic routing of laminated busbar in motor drives. The specific rules and implementation of this method are introduced in detail in this paper. Finally, an example of busbar design of a vehicle motor drive is given to verify the routing rate and execution speed of the algorithm. Full article

Silicon wafers are crucial for determining the price of solar cell modules. To reduce the manufacturing cost of photovoltaic devices, the thicknesses of wafers are reduced. However, the conventional module manufacturing method using the tabbing process has a disadvantage in that the cell is damaged because of the high temperature and pressure of the soldering process, which is complicated, thus increasing the process cost. Consequently, when the wafer is thinned, the breakage rate increases during the module process, resulting in a lower yield; further, the module performance decreases owing to cracks and thermal stress. To solve this problem, a module manufacturing method is proposed in which cells and wires are bonded through the lamination process. This method minimizes the thermal damage and mechanical stress applied to solar cells during the tabbing process, thereby manufacturing high-power modules. When adopting this method, the front electrode should be customized because it requires busbarless solar cells different from the existing busbar solar cells. Accordingly, the front electrode was designed using various simulation programs such as Griddler 2.5 and MathCAD, and the effect of the diameter and number of wires in contact with the front finger line of the solar cell on the module characteristics was analyzed. Consequently, the efficiency of the module manufactured with 12 wires and a wire diameter of 0.36 mm exhibited the highest efficiency at 20.28%. This is because even if the optical loss increases with the diameter of the wire, the series resistance considerably decreases rather than the loss of the short-circuit current, thereby improving the fill factor. The characteristics of the wire-embedded ethylene vinyl acetate (EVA) sheet module were confirmed to be better than those of the five busbar tabbing modules manufactured by the tabbing process; further, a high-power module that sufficiently compensated for the disadvantages of the tabbing module was manufactured. Full article

In this study, we developed a finite element model to assess the residual stress in the soldering and lamination processes during the fabrication of crystalline silicon (Si) photovoltaic (PV) modules. We found that Si wafers experience maximum thermo-mechanical stress during the soldering process. Then, the Si solar cells experience pressure during the process of lamination of each layer of the PV module. Thus, it is important to decrease the residual stress during soldering of thin Si wafers. The residual stress is affected by the number of busbars, Si wafer thickness, and solder type. Firstly, as the number of busbars increases from two to twelve, the maximum principal stress increases by almost a factor of three (~100 MPa). Such a high first principal stress can cause mechanical failure in some Si wafers. Secondly, thermal warpage increases immediately after the soldering process when the thickness of the Si wafers decreases. Therefore, the number and width of the busbars should be considered in order to avoid mechanical failure. Finally, the residual stress can be reduced by using low melting point solder. The results obtained in this study can be applied to avoid mechanical failure in PV modules employing thin Si wafers. Full article

The temperature of laminated busbars has to be limited to prevent their inner electrical insulators from over-heating. In that purpose, Finite Elements Method (FEM) simulations are usually conducted to evaluate the busbar's temperature. However, the thermal influence of external heat sources such as power modules has to be considered to obtain an accurate temperature repartition estimation. In this paper, the thermal influence of power modules on busbar temperature is first evaluated through simulation and experimental works. Then, a method based on the use of electrical equivalent circuits as boundary conditions is proposed to consider this issue and reduce the computation time. Full article

In order to increase the power rating of electric vehicles, insulated gate bipolar translator (IGBT) modules with multiple power terminals are usually adopted. The transient current sharing of the same polarity power terminals is related to the stray inductance in the branches of the bus-bar. Based on the laminated bus-bar of a three-phase inverter in the electric vehicles that consists of asymmetrical parallel branches, this paper investigates the transient current imbalance sharing caused by the asymmetrical stray inductance in the parallel branches of the bus-bar from the view of energy storing and releasing of stray inductance for the first time. Besides, the partial self-inductance and mutual-inductance model of the parallel branches is set up. Finally, a high-precision partial stray inductance measurement method is proposed, and the accuracy of the partial stray inductance model for asymmetrical parallel branches is verified by experimental tests. Full article
