It has long been desired to achieve mechanical enhancement and structural health monitoring by introducing carbon nanotubes (CNTs) into traditional carbon fiber (CF) composites. Herein, the initiation of micro-damage and crack propagation has been investigated by utilizing in situ electrical resistance changes in interlaminar hybrid CNT network/CF composites during the shear loading process. The results show a clear relationship between the crack propagation and the electrical resistance response particularly when approaching the failure of the single-layer CNT network hybrid composites. Furthermore, the chemically modified CNT network exhibits evident enhancement on main mechanical properties of the CF composites, superior to the thermoplastic toughening method. The characterizations manifest that the multiscale interlayered CNT/CF structure can simultaneously resist the crack propagation along both the in-plane direction and the cross-plane direction, which consequently enhances the flexural and compressive strengths of the composite material. This discovery provides a novel idea for the potential application of CNT network/CF hybrid composites in the integration of mechanical reinforcement and structural health monitoring, namely, that the CNT network acts not only as a reinforcing phase but also as a sensor for the structural health monitoring of the composites. Full article

This paper investigated the durability and structural performance of concrete bridge deck pavements under high temperature and high humidity conditions, focusing on three aspects: mix design, road performance evaluation, and structural optimization design. Through Marshall testing, the surface layer material SMA-13 and the middle layer material AC-13 were identified as suitable for hot and humid climates. The former exhibited excellent high-temperature stability and resistance to water damage, while the latter possessed good structural density and load-bearing capacity. A combination of high-temperature, low-temperature, water stability, and impermeability tests was used to systematically evaluate the adaptability of the mixture in hot and humid environments. Furthermore, the performance of different interfacial bonding materials was analyzed through interlaminar pull-out and direct shear tests. The results revealed that the incorporation of epoxy resin notably enhanced the interlayer bond strength and overall durability of the pavement system in hot and humid environments. The proposed “SMA-13 + epoxy resin + AC-13” configuration demonstrates promising potential for improving the mechanical performance and service life of concrete bridge deck pavements. Full article

Carbon fiber-reinforced polymer (CFRP) laminates are extensively utilized in aerospace and advanced engineering fields because of their outstanding strength-to-weight ratio and superior fatigue durability. However, despite their high in-plane strength and stiffness, CFRP laminates are inherently susceptible to delamination. This weakness stems from the relatively low interlaminar strength of the resin-rich interfaces between layers compared to the much stronger in-plane fiber reinforcement. During mechanical processes such as drilling and punching, out-of-plane stresses and interlaminar shear forces develop, concentrating at these weak interfaces. This study investigates the delamination behavior of CFRP laminates with 3 to 7 plies under drilling and punching, focusing on the effects of ply count and drilling speed. Experimental tests were conducted using an 8 mm punch and drill bit at 2500, 3000, and 3500 rpm, reflecting typical workshop practices for M8 fastener holes. Scanning electron microscopy (SEM) analyses at different magnifications were used to quantify delamination extent. A three-dimensional finite element model was created in ABAQUS/Explicit, integrating the Hashin failure criterion to predict damage initiation within the plies and cohesive surfaces to simulate interlaminar delamination. The analyses show that with proper support, punching can approach the damage levels of drilling for thin CFRP plates, but drilling remains preferable for thicker laminates due to better integrity and tool longevity. Full article

Carbon fiber-reinforced polymer (CFRP) composites have excellent mechanical properties, but their performance is hampered by delamination caused by weak interfacial bonding and resin-rich region (RRR). This research has proposed an interleaving film to improve interlaminar structure and mechanical properties by adding polyacrylonitrile (PAN) fiber into the epoxy interlayer of the CFRP laminates. The PAN fiber/epoxy resin (PANER) interleaving film could be prepared, which was beneficial to hinder crack initiation paths and improve the load transfer. Flexural and compression performance testing results showed optimum performance was obtained when 2 wt.% PAN fiber was added, and an increment of 28.6% was obtained in the flexural strength and 11.7% increment in compressive strength. The damaged energy absorption was improved up to 21.4% and 11.3% for the flexural and compressive properties, respectively. The overall thickness increments in the interlayer with PANER interleaving film were approximately 4–9 μm. X-Ray micro-computed tomography and scanning electron microscopy observations exhibited the potential of PAN fiber in the reduction of RRR, resulting in modes replacement from delamination-dominant failure to crossing-multi-layer failure. In all, PANER interleaving film at the interlayer has been confirmed to be an effective approach to produce a simple reinforcement technology for FRP laminates. Full article

Carbon Fiber Reinforced Composite (CFRP) is widely used in deep-sea pressure-resistant structures. With the increase in submergence depth demand leading to the increase in the thickness of the CFRP shell plate, there is a significant thickness effect on its compression performance. In order to study the mechanism of the decrease in compression performance of the laminate, uniaxial compression tests, interlaminar shear tests, out-of-plane tensile tests, damage characterization, and FEM analysis were carried out on three thicknesses of laminates. The results showed that the compressive strength, interlaminar shear strength, out-of-plane tensile strength of laminates and FEM compression model decreased by 10.3%, 12.7%, 23.6%, and 13.6% when the thickness of the laminate was increased from 2 mm to 12 mm. Concurrently, the compression failure mechanism is transformed from the overall strength failure to the instability–crush failure mode caused by the initial delamination. The effects of out-of-plane tensile strength and interlaminar shear strength on compressive properties were also considered. It provides support for the regulation of compression performance of large-thickness laminates and the safety of deep-sea pressure-resistant structures in service. Full article

To reduce reflective cracking in asphalt pavements, gravel base layers are commonly employed to disperse stress and delay structural damage. However, the loose nature of gravel bases results in complex interlayer contact conditions, typically involving interlocking between gravel particles in the base and aggregates in the asphalt surface course. In order to accurately simulate this interaction and to improve the interlayer shear performance, a mesoscale finite element model was developed and combined with macroscopic tests. Effects due to the type and amount of binder material, type of asphalt surface layer, and external loading on shear strength were systematically analyzed. The results indicate that SBS (Styrene–Butadiene–Styrene)-modified asphalt provides the highest interlayer strength, followed by SBR (Styrene–Butadiene Rubber)-modified emulsified asphalt and unmodified base bitumen. SBS (Styrene–Butadiene–Styrene)-modified asphalt achieves optimal interlaminar shear strength at a coating rate of 0.9 L/m². Additionally, shear strength increases with applied load but decreases with increasing void ratio and the nominal maximum aggregate size of the surface course in the analyzed spectra. Based on simulation and experimental data, an equivalent macro–meso predictive model relating shear strength to key influencing factors was established. This model effectively bridges mesoscale mechanisms and practical engineering applications, providing theoretical support for the design and performance optimization of asphalt pavements with gravel bases. Full article

Most numerical studies on carbon fiber-reinforced polymer (CFRP) lightning damages fail to account for delamination, a factor that plays a significant role in the subsequent analysis of residual strength. This study establishes an electro-thermo-mechanical coupled numerical model incorporating delamination effects to predict lightning-induced damage in carbon fiber-reinforced plastic (CFRP) composites. Subsequently, parametric investigations evaluate the influence of varying input loads and stacking sequences on interlaminar pyrolysis and delamination damage, with damage assessment quantitatively conducted based on simulated post-strike uniaxial ultimate compressive loads. Post-strike uniaxial compressive strength reduction with cohesive elements is 28.91%, demonstrating closer alignment with experimental reduction (36.72%) than the 21.12% reduction predicted by the interlaminar-effect-neglecting model. Under combined thermal expansion and shockwave overpressure, the 28.91% compressive strength reduction demonstrates closer alignment with the experimental 36.72% reduction than the 25.13% reduction observed under isolated shockwave overpressure. The results highlight the critical role of thermal delamination in compressive strength reduction, with distinct waveform-dependent mechanisms: under C-waveform lightning currents, arc thermal effects cannot be neglected; D-waveform strikes exhibit predominant contributions from impact loading to delamination damage, with thermally driven delamination likewise pronounced. Increased current amplitude correlates with amplified mechanical damage severity, while premature symmetry in ply stacking sequences exacerbates compressive performance degradation. This work enhances multi-physics modeling fidelity by bridging thermal delamination and mechanical degradation pathways, offering foundational insights for optimizing lightning strike resistance in advanced aerospace composite systems. Full article

Drilling-induced damage in fiber-reinforced polymer composite materials was measured excavating four laminates, basalt (B₁₄), glass (G₁₄) and their two sandwich type hybrids (B₄G₆B₄, G₄B₆G₄), with 6 mm twist drills at 1520 revolutions per minute and 0.10 mm rev⁻¹ under dry running with an uncoated high-speed steel (HSS-R), grind-coated high-speed steel (HSS-G) or physical vapor deposition-coated (high-speed steel coated with Titanium Nitride (TiN) and Titanium Aluminum Nitride (TiAlN)) drill bits. The hybrid sheets were deliberately incorporated to clarify how alternating basalt–glass architectures redistribute interlaminar stresses during drilling, while the hard, low-friction TiN and TiAlN ceramic coatings enhance cutting performance by forming a heat-resistant tribological barrier that lowers tool–workpiece adhesion, reduces interface temperature, and thereby suppresses thrust-induced delamination. Replacement of an uncoated, grind-coated, high-speed-steel drill (HSS-G) with the latter coats lowered the mechanical and thermal loads substantially: mean thrust fell from 79–94 N to 24–30 N, and peak workpiece temperatures from 112 °C to 74 °C. Accordingly, entry/exit oversize fell from 2.5–4.7% to under 0.6% and, from the surface, the SEM image displayed clean fiber severance rather than pull-out and matrix smear. By analysis of variance (ANOVA), 92.7% of the variance of thrust and 86.6% of that of temperature could be accounted for by the drill-bit factor, thus confirming that the coatings overwhelm the laminate structure and hybrid stacking simply redistribute, but cannot overcome, the former influence. Regression models and an artificial neural network optimized via meta-heuristic optimization foretold thrust, temperature and delamination with an R² value of 0.94 or higher, providing an instant-screening device with which to explore industrial application. The work reveals TiAlN- and TiN-coated drills as financially competitive alternatives with which to achieve ±1% dimensional accuracy and minimum subsurface damage during multi-material composite machining. Full article

Carbon fiber-reinforced plastics (CFRPs) offer excellent in-plane mechanical performance, but their relatively low interlaminar fracture toughness makes them vulnerable to delamination, particularly around intralaminar discontinuities such as resin-rich regions or fiber gaps. This study investigates the effectiveness of polyamide (PA) mesh inserts in improving interlaminar toughness and suppressing delamination in CFRP laminates with such features. Two PA mesh configurations were evaluated: a fully embedded continuous layer and a 20 mm cut mesh strip placed between continuous and discontinuous plies near critical regions. Fracture toughness tests showed that PA mesh insertion improved interlaminar toughness approximately 2.4-fold compared to neat CFRP, primarily due to a mechanical interlocking mechanism that disrupts crack propagation and enhances energy dissipation. Uniaxial tensile tests with digital image correlation revealed that while initial matrix cracking occurred at similar stress levels, the stress at which complete delamination occurred was approximately 60% higher in specimens with a 20 mm mesh and up to 92% higher in specimens with fully embedded mesh. The fully embedded mesh provided consistent delamination resistance across the laminate, while the 20 mm insert localized strain redistribution and preserved global mechanical performance. These findings demonstrate that PA mesh is an effective interleaving material for enhancing damage tolerance in CFRP laminates with internal discontinuities. Full article

This study proposes a bionic helical configuration design concept, focusing on glass-fiber-reinforced polymer matrix composites. Through a combination of experimental and numerical simulation methods, it systematically investigates the resistance to multiple impacts and damage tolerance. The research designs and fabricates two types of bionic laminates: a cross-helical and a symmetric-helical structures. By conducting repeated impact experiments at 5 J of energy for 1, 5, 10, and 15 impact times and employing advanced characterization techniques, such as ultrasonic C-scan and X-ray CT, the study reveals the mechanisms of interlaminar damage propagation and failure characteristics. Based on experimental findings, a finite element model encompassing the entire impact process and post-impact compression behavior is established. Utilizing this model, three optimized novel bionic configurations are further developed, providing new insights and theoretical support for the structural design of high-performance impact-resistant polymer matrix composites. Full article

The use of composite materials in aerospace structures has led to significant weight reductions and improved performance. However, their behavior under low-energy impact remains a critical concern due to the potential initiation of barely visible damage. This study investigates the crack initiation mechanisms in composite airfoil profiles subjected to low-energy impact, simulating real-world scenarios such as hail or bird strikes. Two types of airfoil profiles were fabricated using bidirectional carbon fiber reinforced polymer (CFRP) with epoxy resin and tested under ASTM D7136 impact conditions. Tensile tests following ASTM D3039 were conducted to assess post-impact mechanical behavior. The damage patterns were analyzed using high-resolution microscopy and non-destructive inspection techniques. Results revealed that damage severity and propagation depend on impact energy levels and airfoil geometry, with SC(2)-0714 exhibiting better impact resistance than GOE777-IL. Microscopic analysis confirmed that delamination initiated at 45° fiber orientations, expanding along interlaminar regions, while airfoil curvature influenced the impact energy dissipation. Full article

Carbon fabric reinforced polyetherketoneketone (CFF/PEKK) composites have garnered significant attention from researchers due to their superior properties and have been successfully applied in various engineering fields. Environmental conditions are known to directly influence the mechanical properties and service life of composites; however, limited literature exists on the mechanical behavior of CFF/PEKK composites under different environmental conditions. This study elucidates the correlation between the bending and shear behaviors of CFF/PEKK composites and environmental factors, thereby offering robust data support for engineering applications. In this work, CFF/PEKK composite laminates with a fiber volume fraction of 55 vol% were fabricated and subjected to saturated moisture absorption treatments at 70 °C. The moisture absorption characteristics of the material were investigated. The bending and shear properties of CFF/PEKK composites were characterized under three environmental conditions: −55 °C dry state (CTD), room temperature dry state (RTD), and 70 °C wet state (ETW). Failure modes and mechanisms of composite specimens were also analyzed. The equilibrium moisture absorption rate of CFF/PEKK composites is approximately 0.27%. Hygrothermal aging resulted in noticeable fiber pull-out in mechanical specimens, indicating damage to the interfacial performance of the composites. Furthermore, no cracks or delamination were observed. Results indicate that in the CTD condition, the bending strength and shear strength of CFF/PEKK composites are higher compared to those in the RTD condition, while the modulus remains relatively unaffected. In the ETW condition, both bending and shear properties exhibit a significant decline, with the most pronounced reduction observed in interlaminar shear strength. No significant differences in failure modes were noted across different environmental conditions. Full article

The environments found in space research pose numerous challenges to the materials used in aerospace structures, such as high incidence of ultraviolet radiation (UV) and micrometeorite impacts. Therefore, this work analyzes the combined effects of exposure to UV radiation and damage caused by sandblasting on the mechanical performance of a hybrid composite of epoxy matrix reinforced with carbon and glass fibers to simulate service conditions both in low Earth orbit (LEO) and in exoplanet environments. The blasting was carried out with silica particles with dimensions compatible with those found in the dust of the Martian atmosphere, and the damage produced by these particles has dimensions similar to those observed in several impact/wear events of structures exposed to LEO conditions. A qualitative analysis of the effect of UV radiation carried out by colorimetry showed a significant change in the color of the material, which became more greenish and yellowish. This color change is indicative of degradation processes in the polymer matrix. FT-IR analysis showed an increase in the carbonyl band with increasing aging time, which is consistent with the color change measured in the material. However, the interlaminar shear strength was not affected by UV radiation in the time used in this work. This behavior was attributed to the fact that UV radiation initially causes deterioration only on the surface of the material. From the results of the bending tests, both the three-point bending test and impulse excitation test, it was found that the effect of UV radiation on the elastic modulus of the composites was more important than the effect of blasting damage. It was also observed that initial UV exposure, prior to sandblasting, has a synergistic effect on the deterioration of flexural strength. Full article

The key structural components of a wind turbine blade, such as the skin, spar cap, and shear web, are fabricated from fiber-reinforced composite materials. The spar, predominantly manufactured via resin infusion—a process of resin injection and curing in carbon fibers—is prone to initial defects, such as pores, wrinkles, and delamination. This study suggests employing the pultrusion technique for spar production to consistently obtain a uniform cross-section and augment the reliability of both the manufacturing process and the design. In this context, this study introduces carbon fiber-reinforced polymer (CFRP/CFRP) and glass fiber-reinforced polymer (GFRP/CFRP) test specimens, which mimic the bonding structure of the spar cap, utilizing pultruded CFRP in accordance with ASTM standards to analyze the delamination traits of the spar. Delamination tests—covering Mode I (double cantilever beam), Mode II (end-notched flexure), and mixed mode (mixed-mode bending)—were performed to gauge displacement, load, and crack growth length. Through this crack growth mechanism, the interlaminar fracture toughness derived was examined, and the stiffness and strength changes compared to CFRP based on the existing prepreg manufacturing method were analyzed. In addition, the interlaminar fracture toughness for GFRP, which is a material in contact with the spar structure, was analyzed, and through this, it was confirmed that the crack behavior has less deviation compared to a single CFRP material depending on the stiffness difference between the materials when joining dissimilar materials. This means that the higher the elasticity of the high-stiffness material, the higher the initial crack resistance, but the crack growth behavior shows non-uniform characteristics thereafter. This comparison provides information for predicting interlaminar delamination damage within the interior and bonding area of the spar and skin and provides insight for securing the reliability of the design life. Full article

The poor interlaminar fracture toughness is a critical limiting factor for the structural applications of aramid fiber/epoxy resin composites. This study investigates the effects of laser-induced graphene (LIG) and short Kevlar fibers on the interfacial toughness and damage detection of aramid composite materials. Mode II tests and tensile tests were conducted to evaluate mechanical properties and damage detection using the piezoresistive characteristics of LIG. The results indicate that LIG combined with short Kevlar fibers significantly enhances the interfacial toughness of the composites, achieving a 381.60% increase in initial Mode II fracture toughness. Although LIG reduced the tensile strength by 14.02%, the addition of short Kevlar fibers mitigated this effect, preserving the overall mechanical performance. Scanning electron microscopy (SEM) analysis revealed enhanced toughening mechanisms, including increased surface roughness, altered crack propagation paths, and fiber bridging. Additionally, LIG enabled real-time damage monitoring, showing a significant increase in resistance upon delamination or crack propagation and a marked increase in resistance upon the tensile fracture. This research indicates that the synergistic effects of LIG and short Kevlar fibers not only enhance the interlaminar toughness of aramid composites but also provide a novel strategy for effective damage detection in fiber-reinforced materials. Full article
