We experimentally demonstrate an 80 Gbit/s Nyquist-dense wavelength division multiplexed (Nyquist-DWDM) transmission system operating in a simulated atmospheric turbulence channel. The system utilizes eight wavelength-tunable lasers with 100 GHz spacing, modulated by cascaded Mach–Zehnder modulators, to generate phase-locked Nyquist pulse sequences with a 10 GHz repetition rate and a temporal width of 66.7 ps. Each channel is synchronously modulated with a 10 Gbit/s pseudo-random bit sequence (PRBS) and transmitted through controlled weak turbulence conditions generated by a temperature-gradient convection chamber. Experimental measurements reveal that, as the turbulence intensity increases from $C_n^2=1.01\times {10}^{-16}$ to $5.71\times {10}^{-16} {\mathrm{m}}^{-2/3}$, the signal-to-noise ratio (SNR) of the edge channel (C29) and central channel (C33) decreases by approximately 6.5 dB while maintaining stable Nyquist waveform profiles and inter-channel orthogonality. At a forward-error-correction (FEC) threshold of $3.8\times {10}^{-3}$, the minimum receiver sensitivity is −17.66 dBm, corresponding to power penalties below 5 dB relative to the back-to-back condition. The consistent SNR difference (<2 dB) between adjacent channels confirms uniform power distribution and low inter-channel crosstalk under turbulence. These findings verify that Nyquist pulse shaping substantially mitigates phase distortion and scintillation effects, demonstrating the feasibility of high-capacity DWDM free-space optical (FSO) systems with enhanced spectral efficiency and turbulence resilience. The proposed configuration provides a scalable foundation for future multi-wavelength FSO links and hybrid fiber-wireless optical networks. Full article

Modern cellular systems rely on high-capacity and low-latency optical networks to meet ever-increasing data demands. Centralized Radio Access Network (C-RAN) architectures offer a cost-effective approach for deploying mobile infrastructures. In this work, we propose a flexible and cost-efficient fronthaul topology that combines Wavelength Division Multiplexing (WDM) passive optical networks (PONs) with free-space optical (FSO) links. To enhance overall system performance, we introduce Low-Density Parity Check (LDPC) decoding, which provides robust error-correction capabilities against atmospheric turbulence and noise. Our system transmits 20 Gbps, 16-QAM intensity-modulated orthogonal frequency-division multiplexing (OFDM) signals, achieving a substantial reduction in bit error rate (BER). Numerical results show that the proposed WDM-PON-FSO architecture, augmented with LDPC decoding, maintains reliable transmission over 2 km under strong turbulence conditions. Full article

A low-cost, wavelength-tunable single-longitudinal-mode (SLM) thulium–holmium co-doped fiber laser (THDFL) in a 2 μm band with a simple structure is described in the present paper. To obtain a stable SLM and narrow laser linewidth, a five-coupler-based three-ring (FCTR) filter is utilized in the ring cavity of the fiber laser. Tunable SLM wavelength output from THDFLs with kHz linewidths can be achieved by designing the FCTR filter with an effective free-spectral range and a 3 dB bandwidth at the main resonant peak. The measurement results show that the laser is in the SLM lasing state, with a highly stabilized optical spectrum, a linewidth of approximately 9.45 kHz, an optical signal-to-noise ratio as high as 73.6 dB, and a relative intensity noise of less than −142.66 dB/Hz. Furthermore, the wavelength can be tuned in the range of 2.6 nm. The proposed fiber laser has a wide range of applications, including coherence optical communication, optical fiber sensing, and dense wavelength-division-multiplexing. Full article

(1) Objective: This study aims to lay a foundation for noncontact intensive care monitoring of premature babies. (2) Methods: Arterial oxygen saturation and heart rate were measured using a monochrome camera and time-division multiplex controlled lighting at three different wavelengths (660 nm, 810 nm and 940 nm) on a piglet model. (3) Results: Using this camera system and our newly designed algorithm for further analysis, the detection of a heartbeat and the calculation of oxygen saturation were evaluated. In motionless individuals, heartbeat and respiration were separated clearly during light breathing and with only minor intervention. In this case, the mean difference between noncontact and contact saturation measurements was 0.7% (RMSE = 3.8%, MAE = 2.93%). (4) Conclusions: The new sensor was proven effective under ideal animal experimental conditions. The results allow a systematic improvement for the further development of contactless vital sign monitoring systems. The results presented here are a major step towards the development of an incubator with noncontact sensor systems for use in the neonatal intensive care unit. Full article

In this study, we report the successful development of a novel high-sensitivity intensity-based Surface Plasmon Resonance imaging (SPRi) biosensor and its application for detecting molecular interactions. By optimizing the excitation wavelength and employing a wavelength division multiplexing (WDM) algorithm, the system can determine the optimal excitation wavelength based on the initial refractive index of the sample without adjusting the incidence angle. The experimental results demonstrate that the refractive index resolution of the system reaches $1.77\times {10}^{-6}$ RIU. Moreover, it can obtain the optimal excitation wavelength for samples with an initial refractive index in the range of 1.333 to 1.370 RIU and accurately monitor variations within the range of 0.0037 RIU without adjusting the incidence angle. Additionally, our new SPRi technique realized real-time detection of high-throughput biomolecular binding processes, enabling analysis of kinetic parameters. This research is expected to advance the development of more accurate SPRi technologies for molecular interaction analysis. Full article

This research investigates the integration of free-space optics (FSO) with fiber Bragg grating (FBG) sensors in self-healing ring architectures, aiming to improve reliability and signal-to-noise ratio in temperature sensing within sensor systems. The combination of FSO’s wireless connectivity and FBG sensors’ precision, known for their sensitivity and immunity to electromagnetic interference, is particularly advantageous in demanding environments such as aerospace and structural health monitoring. The self-healing architecture enhances system resilience, automatically compensating for failures to maintain consistent monitoring capabilities. This study emphasizes the use of intensity wavelength division multiplexing (IWDM) to manage the complexities of increasing the multiplexing number of FBG sensors. Challenges arise with the overlapping spectra of FBGs when multiplexing several sensors. To address this, a hybrid approach combining an unsupervised autoencoder (AE) with a convolutional neural network (CNN) is proposed, significantly enhancing the accuracy and efficiency of sensor signal detection. These advancements signify substantial progress in sensor technology, validating the effectiveness of the AE-CNN hybrid model in refining FBG sensor systems and underscoring its potential for robust and reliable applications in critical sectors. Full article

Mode division multiplexing (MDM) is currently one of the most attractive multiplexing techniques in optical communications, as it allows for an increase in the number of channels available for data transmission. Optical modal converters are one of the main devices used in this technique. Therefore, the characterization and improvement of these devices are of great current interest. In this work, we present a dataset of 49,736 near-field intensity images of a modal converter based on a long-period fiber grating (LPFG) written on a few-mode fiber (FMF). This characterization was performed experimentally at various wavelengths, polarizations, and temperature conditions when the device converted from ${\mathrm{LP}}_{01}$ mode to ${\mathrm{LP}}_{11}$ mode. The results show that the modal converter can be tuned by adjusting these parameters, and that its operation is optimal under specific circumstances which have a great impact on its performance. Additionally, the potential application of the database is validated in this work. A modal decomposition technique based on the particle swarm algorithm (PSO) was employed as a tool for determining the most effective combinations of modal weights and relative phases from the spatial distributions collected in the dataset. The proposed dataset can open up new opportunities for researchers working on image segmentation, detection, and classification problems related to MDM technology. In addition, we implement novel artificial intelligence techniques that can help in finding the optimal operating conditions for this type of device. Full article

This paper introduces a new bidirectional integration approach that combines fiber sensor/free space optics (FSO) communication using an intensity and wavelength division multiplexer (IWDM) techniques-based long-distance fiber Bragg grating (FBG) sensor strain-sensing system. By implementing coarse wavelength division multiplexing (CWDM), the system achieves the simultaneous transmission of optical communication and fiber optical sensor (FOS) sensing signals, resulting in a highly capable, flexible, and cost-effective solution. The proposed FSO transmission technique addresses complex fiber cable installation concerns with topographical limitations. This bidirectional structure ensures the reliability and stability of the long-distance FBG sensor system, supported by extensive research and experimentation. A hybrid stacked gated recurrent units and long short-term memory (SGRU-LSTM) model is proposed to enhance strain measurement accuracy by predicting and measuring the central wavelength of overlapped strain-sensing FBG sensor signals. The results demonstrate the superiority of the proposed model in peak wavelength detection accuracy. The primary benefit of integrating communication and sensing is the significant reduction in construction costs by eliminating the requirement for two individual fiber optic systems, as the integration allows for a single system to fulfill both functions, resulting in more efficient and cost-effective implementation. Overall, this paper contributes to advancing long-distance FBG sensor systems by integrating fiber sensor/FSO communication and deep learning techniques, improving transmission distance, multiplexing capacity, measurement accuracy, system survivability, and cost-effectiveness. Full article

Bionic robotics, driven by advancements in artificial intelligence, new materials, and manufacturing technologies, is attracting significant attention from research and industry communities seeking breakthroughs. One of the key technologies for achieving a breakthrough in robotics is flexible sensors. This paper presents a novel approach based on wavelength and time division multiplexing (WTDM) for distributed optical waveguide shape sensing. Structurally designed optical waveguides based on color filter blocks validate the proposed approach through a cost-effective experimental setup. During data collection, it combines optical waveguide transmission loss and the way of controlling the color and intensity of the light source and detecting color and intensity variations for modeling. An artificial neural network is employed to model and demodulate a data-driven optical waveguide shape sensor. As a result, the correlation coefficient between the predicted and real bending angles reaches 0.9134 within 100 s. To show the parsing performance of the model more intuitively, a confidence accuracy curve is introduced to describe the accuracy of the data-driven model at last. Full article

We theoretically proposed a topological multichannel add-drop filter (ADF) and studied its unique transmission properties. The multichannel ADF was composed of two one-way gyromagnetic photonic crystal (GPC) waveguides, a middle ordinary waveguide, and two square resonators sandwiched between them, which can be regarded as two paralleling four-port nonreciprocal filters. The two square resonators were applied with opposite external magnetic fields (EMFs) to support one-way states propagating clockwise and counterclockwise, respectively. On the basis of the fact that the resonant frequencies can be tuned by the EMFs applied to the square resonators, when the intensities of EMFs were the same, the multichannel ADF behaved as a power splitter with a 50/50 division ratio and high transmittance; otherwise, it functioned as a demultiplexer to separate two different frequencies efficiently. Such a multichannel ADF not only possesses excellent filtering performance but also has strong robustness against various defects due to its topological protection property. Moreover, each output port can be switched dynamically, and each transmission channel can operate independently with little crosstalk. Our results have the potential for developing topological photonic devices in wavelength division multiplexing systems. Full article

We propose a simple and cost-effective method, using a direct frequency modulation (FM) and noncoherent detection (NCD) scheme, to suppress the nonlinear optical effects in dense wavelength division multiplexed (DWDM) optical communication. The FM transmitter comprises a directly modulated distributed feedback laser and a saturable semiconductor optical amplifier. In the NCD receiver, an optical slope filter as the FM to intensity modulation (IM) signal convertor is placed before a conventional photodetector. Because the FM signal has more evenly distributed optical power, bit-pattern-dependent nonlinear effects are consequently suppressed. After analyzing the nonlinear effects in the FM-NCD system and traditional IM direct detection (IM-DD) system, we found that the minimum achievable BER of the proposed FM-NCD scheme is 40 dB smaller. Moreover, a 2 Tbps (10 Gb/s × 200 channels) capacity was achieved by the FM-NCD system in 100 km DWDM passive optical networks (PONs), which is twice the capacity of the IM-DD system (10 Gb/s × 100 channels) under the same condition. These results indicate that WDM-PONs with the cost-effective FM-NCD scheme are strong candidates for future broad access networks and show great potential for the combination of optical access and metro networks for future generations of PONs. Full article

This research proposes a method for the simultaneous acquisition of the second harmonic (2f) signal of quartz-enhanced photoacoustic spectroscopy (QEPAS) and the first harmonic (1f) signal of quartz-enhanced photothermal spectroscopy (QEPTS) based on the dual-quartz-enhanced photoacoustic–photothermal spectroscopy. The laser beam is first wavelength-modulated by the injection current and then intensity-modulated by an acoustic-optic modulator. The frequency of the wavelength modulation is half of the QTF1 resonant frequency, and the frequency of the intensity modulation is equal to the QTF2 resonant frequency. A modulated laser beam traveled through the two arms of the QTF1 and converged on the root of the QTF2. The 2f photoacoustic and 1f photothermal signals are concurrently obtained using the frequency division multiplexing technology and lock-in amplifiers, which allows the simultaneous detection of the gas concentration and laser light intensity. CH₄ is chosen as the target gas, and the variations of the 2f photoacoustic and 1f photothermal signals are evaluated at various gas concentrations and light intensities. According to the experiments, the amplitude of the 1f photothermal signal has a good linear connection with light intensity (R² = 0.998), which can be utilized to accurately revise the 2f photoacoustic signal while light intensity fluctuates. Over a wide range of concentrations, the normalized 2f photoacoustic signals exhibit an excellent linear response (R² = 0.996). According to the Allan deviation analysis, the minimum detection limit for CH₄ is 0.39 ppm when the integration time is 430 s. Compared with the light intensity correction using a photodetector for the QEPAS system, this approach offers a novel and effective light intensity correction method for concentration measurements employing 2f analysis. It also has the advantages of low cost and compact volume, especially for mid-infrared and terahertz systems. Full article

Data centers are crucial to the growth of cloud computing. Next-generation data center networks (DCNs) will rely heavily on optical technology. Here, we have investigated a bidirectional wavelength-division-multiplexed (WDM) free space optical communication (FSO) system for deployment in optical wireless DCNs. The system was evaluated for symmetric 10 Gbps 16—quadrature amplitude modulation (16-QAM) intensity-modulated orthogonal frequency-division multiplexing (OFDM) downstream signals and 10 Gbps on-off keying (OOK) upstream signals, respectively. The transmission of optical signals over an FSO link is demonstrated using a gamma–gamma channel model. According to the bit error rate (BER) results obtained for each WDM signal, the bidirectional WDM-FSO transmission could achieve 320 Gbps over 1000 m free space transmission length. The results show that the proposed FSO topology offers an excellent alternative to fiber-based optical interconnects in DCNs, allowing for high data rate bidirectional transmission. Full article

A narrow-linewidth eight-wavelength-switchable erbium-doped fiber laser is proposed, and its performance is demonstrated. A cascaded superimposed high-birefringence fiber Bragg grating is used to determine the lasing wavelengths. The combination of a Fabry–Pérot filter and a single-coupler ring is adopted to achieve the single-longitudinal-mode (SLM) oscillation. By introducing the enhanced polarization-hole-burning effect to suppress the gain competition between different wavelength lasers, the stable lasing output is guaranteed. When the pump power is 200 mW, by adjusting the polarization controller to balance the gain and loss in the laser cavity, 24 switchable lasing modes are achieved, including 8 single-wavelength operations and 16 dual-wavelength operations with orthogonal polarization states. For single-wavelength operations, every laser is in the SLM lasing state, with a high stabilized optical spectrum, a linewidth of approximately 1 kHz, an optical signal-to-noise ratio (OSNR) as high as 73 dB, a relative intensity noise of less than −150 dB/Hz, and very good polarization characteristics. For dual-wavelength operations, the lasers also have a stable spectrum and an OSNR as high as 65 dB. The proposed fiber laser has a wide range of applications, including long-haul coherence optical communication, optical fiber sensing, and dense wavelength-division-multiplexing. Full article

A new design for a tunable multi-channel plasmonic bandpass filter was numerically investigated using the two-dimensional finite element method (2D-FEM). The proposed multi-channel plasmonic bandpass filter consists of a metal-insulator-metal waveguide (MIM-WG) and double-sided arrow-shaped cavities. Silver (Ag) and a non-linear optical medium (InGaAsP) are used in the designed filter. InGaAsP fills the bus waveguide and arrow-shaped cavities. The refractive index of InGaAsP is sensitive to the incident light intensity, therefore the resonance wavelengths can be controlled. Utilizing different incident light intensities (such as 10¹⁷ v²/m² and 2 × 10¹⁷ v²/m²) on the InGaAsP, the filter wavelengths can be tuned over a range from 600 nm to 1200 nm. The proposed filter with a confinement area of 0.5 μm² can be used in wavelength division multiplexing (WDM), photonic systems, coloring filters, sensing, and 5G+ communication. Full article
