This study investigates shear cutting of high-strength steel sheets, a process known to negatively impact the forming and fatigue properties of the material. The localized deformation near the cut edges imposes sheared-edge damage, especially in advanced high-strength steels where severe shear deformation occurs in the very vicinity of the cut edge. In this work, an extensive experimental investigation was carried out on punched holes of thin sheets, using light optical microscopy and metallographic techniques for sheared-edge damage assessment. These methods provided detailed insights into the sheared-edge damage and offer a thorough understanding of the deformation behavior in the shear-affected zone. Advanced engineering cut-edge investigation methods have been developed based on 2D and 3D stereo light microscopy for non-destructive panoramic cut-edge parameters and cut-edge profile determination along cut-hole circumference. Such methods provide an efficient evaluation instrument for challenging close-cut holes, with the possibility of industrial in-line monitoring and machine learning applications for Industry 4.0 implementation. Additionally, the study compares grain shear angle measurement and Vickers indentation for deformation assessment of the cut edge. It concludes that grain shear angle offers higher resolution. This parameter is therefore postulated as relevant for assessing the sheared-edge zone. The findings contribute to a deeper understanding of sheared-edge damage and improve evaluation methods, potentially enhancing the use of high-strength steels in automotive and safety-critical applications. Full article

This paper reviews the use of instrumented indentation (nanoindentation) for the evaluation of diffusion-bonded materials. The properties of the near-interfacial regions in diffusion-bonded systems are often significantly different from the bulk properties of the parent materials. Examples of such regions include hard and brittle intermetallic compounds which can be detrimental to the strength of the bond. These regions are often only a few micrometres in thickness, which can hinder efforts to measure their properties. Nanoindentation, which can be used to map the properties of heterogeneous materials, offers a means by which the mechanical properties of these interfacial regions may be obtained, which cannot be obtained by other techniques. Full article

Molybdenum disulfide is a 2D material with excellent lubricant properties, resulting from weak van der Waals forces between lattice layers and shear-induced crystal orientation. The low forces needed to shear the MoS₂ crystal layers grant the tribological system low coefficients of friction (COF). However, film oxidation harms its efficacy in humid atmospheres, leading to an increased COF and poor surface adhesion, making its use preferable in dry or vacuum conditions. To overcome these challenges, doping MoS₂ with elements such as Nb, Ti, C, and N emerges as a promising solution. Nevertheless, the adhesion of these coatings to a steel substrate presents challenges and strategies involving the reduction in residual stresses and increased chemical affinity to the substrate by using niobium-based materials as interlayers. In this study, Nb-doped MoS₂ films were deposited on H13 steel and silicon wafers using the pulsed direct current balanced magnetron sputtering technique. Different niobium-based interlayers (pure Nb and NbN) were deposited to evaluate the adhesion properties of Nb-doped MoS₂ coatings. Unlubricated scratch tests, conducted at room temperature and relative humidity under a progressive load, were performed to analyze the COF and adhesion of the coating. Instrumented indentation tests were conducted to assess the hardness and elastic modulus of the coatings. The microstructure of the coatings was obtained by Scanning Electron Microscopy (SEM), Scanning Transmission Electron Microscopy (STEM), and Transmission Electron Microscopy (TEM), with Energy-Dispersive X-Ray Spectroscopy (EDS). Results indicated that niobium doping on MoS₂ coatings changes the structure from crystalline to amorphous. Additionally, the Nb concentration of the Nb:MoS₂ coating changed the mechanical properties, leading to different cohesive failures by different loads during the scratch tests. Results have also indicated that an NbN interlayer optimally promoted the adhesion of the film. This result is justified by the increase in hardness led by higher Nb concentrations, enhancing the load-bearing capacity of the coating. It is concluded that niobium-based materials can be used to enhance the adhesion properties of Nb-doped MoS₂ films and improve their tribological performance. Full article

Determining the stress–strain curve and other plastic properties using instrumented indentation techniques has long been a topic of active study. The potential to use small, geometrically simple specimens and to characterize a component under service without the need to remove material for specimen preparation makes this methodology highly attractive to many industries. In this study, a data-driven approach that leverages machine learning and finite element analysis was used to construct a model called ‘Brilearn’ that predicts the stress–plastic strain curve of metallic materials. The framework consists of a novel model for predicting the hardening curve, the classical Tabor model for predicting the yield stress for materials with yield stress lower than 100 MPa, and an XGBoost model for predicting the yield stress for metals with yield stress higher than 100 MPa. The model was validated against experimental data on Al1100, Al6061-T6, Al7075-T6, and brass and copper alloys, features error predictions of 8.4 ± 8.5% for the yield stress and 3.2 ± 4% for a complete curve ranging from ${\overline{\epsilon }}^p=0$ to ${\overline{\epsilon }}^p=0.15$. The model is especially suited for the determination of the stress–plastic strain curves for components in service since only two simple indentation tests are required. Full article

This study presents a novel inverse identification approach to determine the elastoplastic parameters of a 2 µm thick GaN semiconductor thin film deposited on a sapphire substrate. This approach combines instrumented nanoindentation with finite element (FE) simulations and an artificial neural network (ANN) model. Experimental load–depth curves were obtained using a Berkovich indenter. To generate a comprehensive database for the inverse analysis, FE models were constructed to simulate load–depth responses across a wide range of GaN thin film properties. The accuracy of both 2D and 3D simulations was compared to select the optimal model for database generation. The Box–Behnken design-based data sampling method was used to define the number of simulations and input variables for the FE models. The ANN technique was then employed to establish the complex mapping between the simulated load–depth curves (input) and the corresponding stress–strain curve (output). The generated database was used to train and test the ANN model. Then, the learned ANN model was used to achieve high accuracy in identifying the stress–strain curve of the GaN thin film from the experimental load–depth data. This work demonstrates the successful application of an inverse analysis framework, combining experimental nanoindentation tests, FE modeling, and an ANN model, for the characterization of the elastoplastic behavior of GaN thin films. Full article

This study investigates the tribocorrosion performance of a cast Co-Cr-Mo alloy prepared using casting and electromagnetic stirring (EMS) at specific frequencies. The tribocorrosion behaviour of the alloy was evaluated when exposed to Ringer’s lactate solution to optimize the EMS parameters and improve its properties. The research focuses on biomedical implant applications and explores how EMS affects alloy wear and corrosion resistance. As did the friction coefficient and wear volume, the wear rate of samples produced with EMS frequencies of 75 Hz and 150 Hz decreased. These improvements are attributed to the ability of EMS to refine grain size and homogenize the microstructure, thereby increasing the resistance to tribocorrosion. Techniques such as scanning electron microscopy (SEM) and profilometry were used for surface and wear analysis, while mechanical properties were evaluated through instrumented indentation tests. The findings confirm that EMS improves the alloy’s durability and tribocorrosion resistance, making it highly suitable for demanding biomedical applications such as joint replacements. This highlights the importance of advanced manufacturing techniques in optimizing biomedical alloys for simulated body conditions. Full article

The Instrumented Indentation Test (IIT) mechanically characterizes materials from the nano to the macro scale, enabling the evaluation of microstructure and ultra-thin coatings. IIT is a non-conventional technique applied in strategic sectors, e.g., automotive, aerospace and physics, to foster the development of innovative materials and manufacturing processes. However, material plasticity at the indentation edge biases the characterization results. Correcting such effects is extremely challenging, and several methods have been proposed in the literature. However, comparisons of these available methods are rare, often limited in scope, and neglect metrological performance of the different methods. After reviewing the main available methods, this work innovatively proposes a performance comparison within a metrological framework currently missing in the literature. The proposed framework for performance comparison is applied to some available methods, i.e., work-based, topographical measurement of the indentation to evaluate the area and the volume of the pile-up, Nix–Gao model and the electrical contact resistance (ECR) approach. The accuracy and measurement uncertainty of the correction methods is compared considering calibrated reference materials to establish traceability of the comparison. Results, also discussed in light of the practical convenience of the methods, show that the most accurate method is the Nix–Gao approach (accuracy of 0.28 GPa, expanded uncertainty of 0.57 GPa), while the most precise is the ECR (accuracy of 0.33 GPa, expanded uncertainty of 0.37 GPa), which also allows for in-line and real-time corrections. Full article

In this work, a transparent nanostructured ceramic magnesium aluminate spinel (MgAl₂O₄) was fabricated by Spark Plasma Sintering (SPS) from commercial spinel nano-powders at different temperatures (1300, 1350 and 1400 °C). The sintered samples were thoroughly examined to assess their microstructural, optical, and mechanical properties. Various techniques such as SEM, AFM, spectrophotometer with an integrating sphere, instrumented Vickers indenter, Pin-on-Disk tribometer, scratch tester, and sandblasting device were employed to characterize the sintered samples. The results indicated the significant impact of the sintering temperature on the properties of the spinel samples. Particularly, the samples sintered at T = 1350 °C exhibited the highest Real In-line Transmission (RIT = 72% at 550 nm and 80% at 1000 nm). These samples demonstrated the highest hardness value (HV = 16.7 GPa) compared to those sintered at 1300 °C (HV = 15.6 GPa) and 1400 °C (HV = 15.1 GPa). The measured fracture toughness of the sintered samples increased substantially with increasing sintering temperature. Similarly, the tribological study revealed that the friction coefficient of the sintered spinel samples increased with the sintering temperature, and the spinel sintered at 1350 °C exhibited the lowest wear rate. Additionally, sandblasting and scratch tests confirmed the significant influence of the sintering temperature on the mechanical properties of the fabricated spinels. Overall, the spinel sintered at 1350 °C presented the best compromise in terms of all the evaluated properties. Full article

Nanostructured cemented carbides with Co binders have shown excellent mechanical properties in various applications. Nevertheless, their corrosion resistance has shown to be insufficient in different corrosive environments, leading to premature tool failure. In this study, WC-based cemented carbide samples with different binders were produced using 9 wt% of FeNi or FeNiCo with the addition of Cr₃C₂ and NbC as the grain growth inhibitors. The samples were investigated using electrochemical corrosion techniques: the open circuit potential E_corr, the linear polarization resistance (LPR), the Tafel extrapolation method, and the electrochemical impedance spectroscopy (EIS) at room temperature in the solution of 3.5% NaCl. Microstructure characterization, surface texture analysis, and instrumented indentation were conducted to investigate the influence of corrosion on the micro-mechanical properties and the surface characteristics of the samples before and after corrosion. The obtained results indicate a strong binder chemical composition’s effect on the consolidated materials’ corrosive behavior. Compared to the conventional WC-Co systems, a significantly improved corrosion resistance was observed for both alternative binder systems. The study shows that the samples with the FeNi binder are superior to those with the FeNiCo binder since they were almost unaffected when exposed to the acidic medium. Full article

The mechanical properties of biological tissues influence their function and can predict degenerative conditions before gross histological or physiological changes are detectable. This is especially true for structural tissues such as articular cartilage, which has a primarily mechanical function that declines after injury and in the early stages of osteoarthritis. While atomic force microscopy (AFM) has been used to test the elastic modulus of articular cartilage before, there is no agreement or consistency in methodologies reported. For murine articular cartilage, methods differ in two major ways: experimental parameter selection and sample preparation. Experimental parameters that affect AFM results include indentation force and cantilever stiffness; these are dependent on the tip, sample, and instrument used. The aim of this project was to optimize these experimental parameters to measure murine articular cartilage elastic modulus by AFM micro-indentation. We first investigated the effects of experimental parameters on a control material, polydimethylsiloxane gel (PDMS), which has an elastic modulus on the same order of magnitude as articular cartilage. Experimental parameters were narrowed on this control material, and then finalized on wildtype C57BL/6J murine articular cartilage samples that were prepared with a novel technique that allows for cryosectioning of epiphyseal segments of articular cartilage and long bones without decalcification. This technique facilitates precise localization of AFM measurements on the murine articular cartilage matrix and eliminates the need to separate cartilage from underlying bone tissues, which can be challenging in murine bones because of their small size. Together, the new sample preparation method and optimized experimental parameters provide a reliable standard operating procedure to measure microscale variations in the elastic modulus of murine articular cartilage. Full article

A more-and-more-accepted alternative to the time-consuming and technique-sensitive, classic, incremental-layering technique of resin-based composites (RBCs) is their placement in large increments. The so-called bulk-fill RBCs had to be modified for a higher polymerization depth and already have a 20-year history behind them. From the initial simple mechanisms of increasing the depth of cure by increasing their translucency, bulk-fill RBCs have evolved into complex materials with novel polymerization mechanisms and bioactive properties. However, since the materials are intended to replace the tooth structure, they must be comparable in mechanical behavior to the substance they replace. The study compares already established bulk-fill RBCs with newer, less-studied materials and establishes their relationship to dentin with regard to basic material properties such as hardness and indentation modulus. Instrumented indentation testing enables a direct comparison of tooth and material substrates and provides clinically relevant information. The results underline the strong dependence of the measured properties on the amount of filler in contrast to the small influence of the material classes into which they are classified. The main difference of RBCs compared to dentin is a comparable hardness but a much lower indentation modulus, emphasizing further development potential. Full article

Bone resorption and inadequate osseointegration are considered the main problems of titanium implants. In this investigation, the texture and surface roughness of porous titanium samples obtained by the space holder technique were modified with a femtosecond Yb-doped fiber laser. Different percentages of porosity (30, 40, 50, and 60 vol.%) and particle range size (100–200 and 355–500 μm) were compared with fully-dense samples obtained by conventional powder metallurgy. After femtosecond laser treatment the formation of a rough surface with micro-columns and micro-holes occurred for all the studied substrates. The surface was covered by ripples over the micro-metric structures. This work evaluates both the influence of the macro-pores inherent to the spacer particles, as well as the micro-columns and the texture generated with the laser, on the wettability of the surface, the cell behavior (adhesion and proliferation of osteoblasts), micro-hardness (instrumented micro-indentation test, P–h curves) and scratch resistance. The titanium sample with 30 vol.% and a pore range size of 100–200 μm was the best candidate for the replacement of small damaged cortical bone tissues, based on its better biomechanical (stiffness and yield strength) and biofunctional balance (bone in-growth and in vitro osseointegration). Full article

The selection of restorative materials with regard to the longevity and durability of a restoration is of crucial importance for daily dental practice and requires that the degradation of the material in the oral environment can be assessed. The aim of this study was to investigate the extent to which the mechanical properties of four (Esthet X, Ceram X, Filtek Supreme XT, and Filtek Supreme XT flow) resin-based composites (RBCs) alter during storage in saliva substitutes (artificial saliva) for 24 h and 28 days and in the context of simulated, more aggressive clinical conditions, including cycles exposure to de- and remineralization, alcohol, or salivary enzymes. For this purpose, flexural strength and modulus were determined in a three-point bending test (n = 20) followed by Weibull analysis, while quasi-static behavior was evaluated by instrumented indentation techniques. Degradation occurred in all RBCs and all aging protocols and was quantifiable at both macroscopic and microscopic levels. The postulated stabilizing effect on degradation through the incorporation of urethane-based co-monomers into the organic matrix or a higher filler loading is refuted. Even though modern RBCs show high clinical survival rates, biodegradation remains an issue that needs to be addressed. Full article

Due to an attractive combination of chemical and physical properties, silicon carbide (SiC) thin films are excellent candidates for coatings to be used in harsh environment applications or as protective coatings in heat exchanger applications. This work reports the deposition of near-stoichiometric and nanocrystalline SiC thin films, at room temperature, on silicon (100) substrates using a DCMS/HiPIMS co-sputtering technique (DCMS—direct current magnetron sputtering; HiPIMS—high-power impulse magnetron sputtering). Their structural and mechanical properties were analyzed as a function of the process gas pressure. The correlation between the films’ microstructure and their mechanical properties was thoroughly investigated. The microstructure and morphology of these films were examined by appropriate microscopic and spectroscopic methods: atomic force microscopy (AFM), scanning electron microscopy (SEM), energy-dispersive X-ray spectroscopy (EDX), X-ray diffraction (XRD), and Raman spectroscopy, while their mechanical and tribological properties were evaluated by instrumented indentation and micro-scratch techniques. The lowest value of the working gas pressure resulted in SiC films of high crystallinity, as well as in an improvement in their mechanical performances. Both hardness (H) and Young’s modulus (E) values were observed to be significantly influenced by the sputtering gas pressure. Decreasing the gas pressure from 2.0 to 0.5 Pa led to an increase in H and E values from 8.2 to 20.7 GPa and from 106.3 to 240.0 GPa, respectively. Both the H/E ratio and critical adhesion load values follow the same trend and increase from 0.077 to 0.086 and from 1.55 to 3.85 N, respectively. Full article

Federal rule changes governing natural gas pipelines have made non-destructive techniques, such as instrumented indentation testing (IIT), an attractive alternative to destructive tests for verifying properties of steel pipeline segments that lack traceable records. Ongoing work from Pacific Gas and Electric Company’s (PG&E) materials verification program indicates that IIT measurements may be enhanced by incorporating chemical composition data. This paper presents data from PG&E’s large-scale IIT program that demonstrates the predictive capabilities of IIT and chemical composition data, with particular emphasis given to differences between ultimate tensile strength (UTS) and yield strength (YS). For this study, over 80 segments of line pipe were evaluated through tensile testing, IIT, and compositional testing by optical emission spectroscopy (OES) and laboratory combustion. IIT measurements of UTS were, generally, in better agreement with destructive tensile data than YS and exhibited about half as much variability as YS measurements on the same sample. The root-mean squared error for IIT measurements of UTS and YS, respectively, were 27 MPa (3.9 ksi) and 43 MPa (6.2 ksi). Next, a machine learning model was trained to estimate YS and UTS by combining IIT with chemical composition data. The agreement between the model’s estimated UTS and tensile UTS values was only slightly better than the IIT-only measurements, with an RMSE of 21 MPa (3.1 ksi). However, the YS estimates showed much greater improvement with an improved RMSE of 27 MPa (3.9 ksi). The experimental, mechanical, and metallurgical factors that contributed to IIT’s ability to consistently determine destructive UTS, and the differences in its interaction with composition as compared to YS, are discussed herein. Full article
