Search Results (174)

Optical temperature sensors with intrinsic characteristics of explosion-proof are particularly suitable for the petrochemical industry, etc. However, their applications remain limited by environmental compatibility, etc. Here, we developed an all-optic temperature sensor using an anti-bending single-mode optical fiber in a 3.5 m length and a 0.25 mm outer diameter to match a stainless tube with a 0.4 mm inner diameter. The fiber was threaded into the tube, well bonded with epoxy at both ends of the tube, and configured as one arm of a low-coherent Michelson interferometer. Then, the tube with an embedded sensing fiber was fabricated into a spring, whose final length was about 70 mm with an outside diameter of 13 mm. Changes in temperature alter the lengths of the stainless tube spring in a thermoelastic way, thereby modifying the inner fiber length and producing an optical path difference between the sensing fiber and the packaged reference arm of the interferometer. A temperature calibration was carried out from −25 to 65 °C, and the results demonstrated that the hysteresis of the spring sensor was within ±1.16 °C and the sensitivity was 0.34 °C, which was verified by using a platinum resistance temperature sensor (PT-100). This work provides a reference for further intrinsic optical temperature sensor design. Full article

Based on the design concept of double-skin composite columns, this study proposes an enhanced configuration in which the inner steel tube is reinforced with fiber-reinforced polymer (FRP) stirrup-confined ultra-high-performance concrete (UHPC), leading to the development of FRP stirrup-confined UHPC–steel tube (FSCUS) hollow composite columns. Twelve glass FRP stirrup-confined UHPC–steel tube (GFSCUS) hollow composite column specimens were tested under axial compression. Analysis of load–displacement curves, and of load–strain curves of individual components, was performed. The effects of various parameters, including thickness and outer diameter of the steel tube, configuration and spacing of the GFRP stirrup, and steel fiber content of the UHPC, on the compressive behavior of the GFSCUS hollow composite columns were systematically investigated. The test results indicate that the influence of the thickness and outer diameter of the steel tube on the axial compression behavior is primarily governed by the effectiveness of the composite action between the steel tube and the confined concrete under axial compression load. The spacing and configuration of the FRP stirrup, conversely, determine the efficacy of the confinement provided to the concrete. The incorporation of steel fibers enhances both the peak load and the ductility due to their bridging effect. However, an excessive fiber content can restrict the lateral expansion of the concrete, thereby diminish the confining effect of the hoops and leading to a reduction in load-carrying capacity. Full article

Scaffolds, as temporary structural support systems in civil engineering, play an essential role during construction. Independent steel scaffold systems, typically composed of assembled steel tubes, can be erected and function as standalone supports without mutual interference. This feature offers notable advantages over conventional scaffolding, including easier dismantling and higher reusability efficiency. However, the absence of specific design and construction codes for this type of scaffolding has hindered its broader application, underscoring the need for further research into its structural reliability. This study investigates the stability of basic load-bearing units in independent scaffolding through vertical loading tests on three specimens with varying heights and end conditions. The failure modes of the specimens are systematically compared, and the load-transfer mechanism and mechanical behavior of the scaffold units are analyzed. Experimental results, validated against ABAQUS finite element simulations, reveal that the critical region under axial compression lies at the junction between the inner and outer tubes. As specimen height increases, a plastic hinge develops in this region under load. In shorter specimens, the inner and outer tubes interact in a nearly fixed-end condition, without failure of the connecting pins. All three specimens failed by instability, and reducing the specimen height significantly enhanced the load-bearing capacity. When the top of the specimen is pin-supported, the material’s compressive strength is not fully utilized. To improve the axial stability of independent scaffolding, several structural improvements are proposed: replacing the pinned top with a plate-supported end to enhance compressive stability; integrating transverse bracing at the ends to connect individual units into an integrated system, thereby improving overall stability without compromising spatial flexibility; and applying mechanical reinforcement with external collars at the inner–outer tube interface to increase local bending stiffness and reduce initial imperfection, thus strengthening the global buckling resistance of the independent scaffolding system. Full article

With the increasing demand for lightweight, high-strength, and ductile structural systems in modern infrastructure, the hybrid composite column has emerged as a promising solution to overcome the limitations of single-material members. This paper proposes an innovative variant of double-skin tubular columns (DSTCs), termed as square double-skin hybrid concrete bar columns (SDHCBCs), composed of one square-shaped outer steel tube, small-diameter concrete-infilled glass FRP tubes (SDCFs), interstitial mortar, and an inner circular steel tube. A series of axial compression tests were conducted on eight SDHCBCs and one reference DSTC to investigate the effects of key parameters, including the thicknesses of the outer steel tube and GFRP tube, the substitution ratio of SDCFs, and their distribution patterns. As a result, significantly enhanced performance is observed in the proposed SDHCBCs, including the following: ultimate axial bearing capacity improved by 79.6%, while the ductility is increased by 328.3%, respectively, compared to the conventional DSTC. A validated finite element model was established to simulate the mechanical behavior of SDHCBCs under axial compression. The model accurately captured the stress distribution and progressive failure modes of each component, offering insights into the complex interaction mechanisms within the hybrid columns. The findings suggest that incorporating SDCFs into hybrid columns is a promising strategy to achieve superior load-carrying performance, with strong potential for application in high-rise and infrastructure engineering. Full article

Acoustic scattering is a highly effective tool for non-destructive control and structural analysis. In many real-world applications, understanding acoustic scattering is essential for accurately detecting and characterizing defects, assessing material properties, and evaluating structural integrity without causing damage. One of the most critical aspects of characterizing targets—such as plates, cylinders, and tubes immersed in water—is the analysis of the phase and group velocities of antisymmetric circumferential waves (A₁). Phase velocity helps identify and characterize wave modes, while group velocity allows for tracking energy, detecting, and locating anomalies. Together, they are essential for monitoring and diagnosing cylindrical shells. This research employs a Sugeno fuzzy inference system (SFIS) combined with a Fuzzy Subtractive Clustering (FSC) identification technique to predict the velocities of antisymmetric (A₁) circumferential signals propagating around an infinitely long cylindrical shell of different b/a radius ratios, where a is the outer radius, and b is the inner radius. These circumferential waves are generated when the shell is excited perpendicularly to its axis by a plane wave. Phase and group velocities are determined by using resonance eigenmode theory, and these results are used as training and testing data for the fuzzy model. The proposed approach demonstrates high accuracy in modeling and predicting the behavior of these circumferential waves. The fuzzy model’s predictions show excellent agreement with the theoretical results, as confirmed by multiple error metrics, including the Mean Absolute Error (MAE), Standard Error (SE), and Mean Relative Error (MRE). Full article

In ocean engineering, the demand for fiber-optic vector hydrophones (FOVHs) is increasing. The performance of a FOVH depends on phase consistency between its pressure and acceleration channels, which should match the acoustic field’s properties. Phase polarity, which refers to the alignment of the output signal with the acoustic field direction, is critical. Incorrect phase polarity during sensor assembly can disrupt phase consistency and invalidate directional measurements. This study investigates phase polarity in mandrel FOVHs that use the Phase Generated Carrier (PGC) technique. We develop a theoretical model combining the PGC algorithm with elastic mechanics to analyze the response of acoustic signals. Our model shows that correct demodulated signal polarity requires a specific physical setup: the pressure sensor’s long arm should be on the inner mandrel and the short arm on the outer, while the accelerometer’s positive axis should follow the vector from the long to its short arm. These results are validated through standing wave tube experiments and lake tests. This research provides practical guidelines for the installation and calibration of FOVHs, ensuring phase consistency in underwater acoustic sensing. Full article

Numerous thermal practical applications utilize shell and tube heat exchanger appliances to transfer heat energy between hot and cold working fluids. Incorporating metal foam to the outer periphery of inner tube improves the heat transfer process from hot water in the tube side to cold water in the shell side and consequently improves heat exchanger performance. In this study, the integration of use of a porous material together with designing a robust adaptive controller could efficiently regulate the outlet cold water temperature to the desired value. This is achieved with respect to the time required for cold water to reach the desired temperature (settling time) and the amount of hot water volume flow during a certain time span. A barrier function-based adaptive sliding mode controller (BF-based adaptive SMC) is proposed, which requires only the information of temperature measurement of cold water. The stability of BF-based adaptive SMC is proved utilizing Lyapunov function analysis. The effectiveness of proposed controller is verified via numerical results, which showed that the proposed controller could achieve considerable accuracy of cold water temperature using suitable design parameters. In addition, the robustness of controller against variation in inlet temperature is also verified. Another improvement to performance of heat exchanger system is achieved by adding the metal foam of aluminum material on inner pipe perimeter with wide range of metal foam to outer inner pipe diameters ratio ($1\le s\le 1.8$). The results showed that the settling time is significantly reduced which enables outlet cold water to reach the required temperature faster. With respect of the case of non-adding metal foam on inner pipe outer circumference, when $s=1.2$, the settling time and hot water temperature are reduced by $1/2$ and $17.3\%$, respectively, while for $s=1.8$, they are decreased by $\le 1/20$ and $35.3\%$ correspondingly. Accordingly, the required volume flow for hot water is reduced considerably. Full article

The prestressed concrete-filled double skin steel tube (CFDST) lattice tower has emerged as a promising structural solution for large-capacity wind turbine systems due to its superior load-bearing capacity and economic efficiency. The steel–concrete composite adapter (SCCA) is a key component that connects the upper tubular steel tower to the lower lattice segment, transferring axial loads. However, the compressive behaviour of the SCCA remains underexplored due to its complex multi-shell configuration and steel–concrete interaction. This study investigates the axial compression behaviour of SCCAs through refined finite element simulations, identifying diagonal extrusion as the typical failure mode. The analysis clarifies the distinct roles of the outer and inner shells in confinement, highlighting the dominant influence of outer shell thickness and concrete strength. A sensitivity-based parametric study highlights the significant roles of outer shell thickness and concrete strength. To address the high cost of FE simulations, a 400-sample database was built using Latin Hypercube Sampling and engineering-grade material inputs. Using this dataset, five neural networks were trained to predict SCCA capacity. The Dropout model exhibited the best accuracy and generalization, confirming the feasibility of physics-informed, data-driven prediction for SCCAs and outperforming traditional empirical approaches. A graphical prediction tool was also developed, enabling rapid capacity estimation and design optimization for wind turbine structures. This tool supports real-time prediction and multi-objective optimization, offering practical value for the early-stage design of composite adapters in lattice turbine towers. Full article

Annular flow is a common flow configuration encountered in fields such as food engineering, energy and power engineering, and petroleum engineering. The annular space formed by the inner and outer pipes exhibits unique characteristics, with the distinct curvatures of the inner and outer pipes rendering the annulus fundamentally different from a circular pipe. The complexity of the annular structure complicates the rapid calculation of turbulent statistics in engineering practice, as modeling these statistics necessitates a comprehensive understanding of their peak characteristics. However, current research lacks a thorough understanding of the peak characteristics of turbulent flows in annuli with varying diameter ratios (the ratio of the inner tube’s diameter to the outer tube’s diameter) between the inner and outer pipes. To gain a deeper insight into the turbulent peak characteristics within annular flows, this study employs numerical simulation methods to investigate the first- and second-order turbulent statistics under different diameter ratios resulting from varying curvatures of the inner and outer pipes. These statistics encompass velocity distribution, the position and magnitude of maximum velocity, turbulence intensity, turbulent kinetic energy, and Reynolds stress. The research findings indicate that the contour plots of velocity, turbulence intensity, and turbulent kinetic energy distributions under different diameter ratio conditions exhibit central symmetry. The peaks of the first-order statistical quantities are located in the mainstream region of the annulus, and their positions gradually shift closer to the center of the annulus as the diameter ratio increases. For the second-order statistical quantities, peaks are observed near both the inner and outer walls, and their positions move closer to the walls as the diameter ratio rises. The peak values of turbulent characteristics show significant variations across different diameter ratios. Both the inner and outer wall surfaces exhibit peaks in their second-order statistical quantities. For instance, the maximum value of Reynolds stress near the inner tube is 101.4% of that near the outer tube, and the distance from the wall where the maximum Reynolds stress occurs near the inner tube is 97.2% of the corresponding distance near the outer tube. This study is of great significance for optimizing the diameter combination of the inner and outer pipes in annular configurations and for evaluating turbulent statistics. Full article

Recycled concrete is widely recognized as favorable for environmental protection and sustainable development. However, recycled concrete, especially containing abandoned brick aggregate, is rarely used in main structural members due to its inherent defects. Concrete-filled double steel tube columns (CFDSTCs), consisting of an outer and an inner steel tube with concrete filling the entire section, are effective in load bearing and deformation resistance. The structural application of abandoned brick aggregate, resulting from urbanization renewal, might be widened through CFDSTCs. This paper presents an experimental and analytical study aiming to investigate the axial compressive behavior of recycled-brick-aggregate-concrete-filled double steel tube columns (RBCDSTs). A total of six specimens were tested under concentric compression, including five RBCDSTs and one concrete-filled single steel tube column. The varied parameters included the replacement ratios (0% and 25%) of brick aggregate and the thickness ratio of the inner and outer steel tubes (0.75, 1, and 1.25). Theoretical analysis was also carried out. A new constitutive model of RBCDST was proposed and used in finite element analysis. The investigation indicated that, under the current conditions, the presence of the inner steel tube only increased the strength by 0.14%. When the inner and outer diameter ratio is 0.73, using a 25% replacement rate of bricks in the entire cross-section or only in the ring area of the cross-section will result in 21.1% and 10.1% strength decreases, respectively. For every 0.6% increase in the diameter-to-thickness ratio of the outer tube, the strength of RBCDST increases 16.3% on average. Full article

Interface debonding between the steel tube and grouting materials in grouting jacket connections (GJCs) of offshore wind turbine supporting structures leads to negative effects on the load-carrying capacity and safety concerns. In this paper, an interface debonding defect detection and localization approach for scale underwater GJC specimens using surface wave measurement is proposed and validated numerically. A multi-physics finite element model (FEM) of underwater GJCs with mimicked interface debonding defects, surrounded by water, and coupled with surface-mounted piezoelectric lead zirconate titanate (PZT) patches is established. Under the excitation of a five-cycle modulated signal, the surface stress wave propagation, including transmission, diffraction, and reflection, within the outer steel tube, grouting material, and inner steel tube is simulated. The influence of mimicked interface debonding defects of varying dimensions on stress wave propagation is systematically analyzed through stress wave field distributions at distinct time intervals. Additionally, the response of surface-mounted PZT sensors in the underwater GJC model under a one-pitch-one-catch (OPOC) configuration is analyzed. Numerical results demonstrate that the wavelet packet energy (WPE) of the surface wave measurement from the PZT sensors corresponding to the traveling path with a mimicked interface debonding defect is larger than that without a defect. To further localize the debonding region, a one pitch and multiple catch (OPMC) configuration is employed, and an abnormal value analysis is conducted on the WPEs of PZT sensor measurements with identical and comparable wave traveling patches. The identified debonding regions correspond to the simulated defects in the models. Full article

Coaxial downhole heat exchangers (CDHEs) extract heat directly from geothermal reservoirs through a closed loop, minimizing environmental impacts. However, the heat extraction efficiency is generally lower than that of groundwater harvesting technology. This study proposes integrating spiral fins on the CDHE outer tube’s inner surface to enhance heat transfer performance. Numerical simulations demonstrate that placing spiral fins on the inner wall of the outer tube significantly enhances rotational velocity and turbulence within the annular flow channel, outperforming configurations with fins on the outer wall of the inner tube. The intensified swirling flow extends to the bottom of the CDHE, promoting effective mixing of hot and cold fluids and consequently improving the heat transfer coefficient. This study also investigates the influence of fin pitch and height on heat transfer and flow characteristics. The results show that both the Nusselt number (Nu) and flow resistance increase as fin pitch decreases, causing the performance evaluation criteria (PEC) to initially increase and then decrease. Additionally, increased fin height enhances the heat transfer coefficient, but also leads to a greater pressure drop. The optimal performance was achieved with a fin pitch of 500 mm and a fin height of 10 mm, attaining a maximum PEC of 1.53, effectively balancing heat transfer enhancement and hydraulic resistance. These findings provide guidance for the structural optimization of coaxial downhole heat exchangers. Full article

Energy storage technology is crucial for promoting the replacement of traditional energy with renewable energy and regulating the energy supply–demand relationship. This paper investigates a triplex-tube thermal energy unit storage to solve the intermediate heat storage and heat transfer problem of hot water supply and demand in clean heating systems. A multi-objective optimization method based on the elitist non-dominated sorting genetic algorithm (NSGA-II) was utilized to optimize the geometric dimensions (inner tube radius $r_1$, casing tube radius $r_2$, and outer tube radius $r_3$), focusing on heat transfer efficiency ($\epsilon$), heat storage rate ($P_t$), and mass (M). On this basis, the influence of the optimization variables was analyzed. The optimized configuration ($r_1=0.014$ m, $r_2=0.041$ m, and $r_3=0.052$ m) was integrated into a modular design, achieving a 2.12% improvement in heat transfer efficiency and a 73.23% increase in heat storage rate. Experimental results revealed that higher heat transfer fluid (HTF) temperatures significantly reduce heat storage time, while HTF flow rate has a minimal impact. Increasing the heat release temperature extends the phase change material (PCM) heat release duration, with the flow rate showing negligible effects. The system’s thermal supply capacity is susceptible to heat release temperature. Full article

As environmental pollution has become a global concern, regulations on carbon emissions from maritime activities are being implemented, and interest in using renewable energy as fuel for ships is growing. Hydrogen, which does not release carbon dioxide and has a high energy density, can potentially replace fossil fuels as a renewable energy source. Notably, storage of hydrogen in a liquid state is considered the most efficient. In this study, a 0.7 m³ liquid hydrogen fuel tank suitable for small vessels was designed, and a structural analysis was conducted to assess its structural integrity. The extremely low liquefaction temperature of hydrogen at −253 °C and the need for spatial efficiency in liquid hydrogen fuel tanks make vacuum insulation essential to minimize the heat transfer due to convection. A composite insulation system of sprayed-on foam insulation (SOFI) and multilayer insulation (MLI) was applied in the vacuum annular space between the inner and outer shells, and a tube-shaped supporter made of a G-11 cryogenic (CR) material with low thermal conductivity and high strength was employed. The material selected for the inner and outer layers of the tank was STS 316L, which exhibits sufficient ductility and strength at cryogenic temperatures and has low sensitivity to hydrogen embrittlement. The insulation performance was quantitatively assessed by calculating the boil-off rate (BOR) of the designed fuel tank. Structural integrity evaluations were conducted for nine load cases using heat transfer and structural analyses in accordance with the IGF code. Full article

Ground-source heat pump (GSHP) systems with medium-depth and deeply buried pipes in cold regions are highly important for addressing global climate change and the energy crisis because of their efficient, clean, and sustainable energy characteristics. However, unique geological conditions in cold climates pose serious challenges to the heat transfer efficiency, long-term stability, and adaptability of systems. This study comprehensively analyses the effects of various factors, including well depth, inner-to-outer tube diameter ratios, cementing material, the thermal conductivity of the inner tube, the flow rate, and the start–stop ratio, on the performance of a medium-depth coaxial borehole heat exchanger. Field tests, numerical simulations, and sensitivity analyses are combined to determine the full-cycle thermal performance and heat-transfer properties of medium-depth geological formations and their relationships with system performance. The results show that the source water temperature increases by approximately 4 °C and that the heat transfer increases by 50 kW for every 500 m increase in well depth. The optimization of the inner and outer pipe diameter ratios effectively improves the heat-exchange efficiency, and a larger pipe diameter ratio design can significantly reduce the flow resistance and improve system stability. When the thermal conductivity of the cementing cement increases from 1 W/(m·K) to 2 W/(m·K), the outlet water temperature at the source side increases by approximately 1 °C, and the heat transfer increases by 13 kW. However, the improvement effect of further increasing the thermal conductivity on the heat-exchange efficiency gradually decreases. When the flow rate is 0.7 m/s, the heat transfer is stable at approximately 250 kW, and the system economy and heat-transfer efficiency reach a balance. These findings provide a robust scientific basis for promoting medium-deep geothermal energy heating systems in cold regions and offer valuable references for the green and low-carbon transition in building heating systems. Full article
