The Gurney flap (GF) is a simple flat plate frequently mounted at the airfoil rear. Several investigations have been devoted to studying the effect of a rigid or even movable GF on the aerodynamic behavior of several devices such as flapping airfoils and vertical or horizontal axis turbines. The present paper proposes a new concept of a deformable Gurney flap (DGF) to improve the output power of a flapping airfoil in vertical mode. The advantage of this model is the full control of the effect on the GF during the flapping movement. The DGF is expandable and contractible which allows for monitoring and adjusting the pressure distribution at the appropriate time and position. By using a 2D transient simulation with a specific dynamic mesh design, an extended numerical analysis has been provided. It was found that this model is able to increase the output power by 19.5%. Furthermore, the concept of the DGF is applied on flapping turbines in hybrid modes such as swing arm mode and D-shaped mode. These modes are investigated to clarify the studied model’s advantage and to demonstrate the possibility of applying this strategy to control the different flapping movements. Full article

The sedimentation of flocs in aquatic environments is a fundamental phenomenon that has not yet been fully elucidated. This study quantitatively examines sedimentation behavior, particularly focusing on sedimentation turbulence, in a two-dimensional system between flat plates, utilizing image analysis. Experiments were conducted in a rectangular container with montmorillonite suspensions coagulated in a sodium chloride solution. The settling motion of flocs was visualized using a green laser from above and captured horizontally with a digital camera. The study employed Particle Image Velocimetry (PIV) to analyze the velocity field in floc sedimentation, using the flocs as tracers to calculate the mean velocity at the sediment–supernatant interface. The results showed that the mean PIV value is affected by rising particles caused by sedimentation turbulence, indicating that PIV analysis of flow fields using flocs as tracers is reliable. The maximum settling velocity was found to increase with the initial interface height and the thickness of the container. The study further notes that flow velocity fluctuations increase during rapid sedimentation, marked by repeated collisions, separation, and the flocculation of variably sized flocs, offering a clear explanation of sedimentation turbulence. Additionally, Fourier analysis of vertical spectra in the container reflects the formation and collapse of flocs. Full article

The present investigation deals with the quantification of fluid oscillation frequencies in a metallic pulsating heat pipe tested at varying heat loads and orientations. The aim is to design a robust technique for the study of the inner fluid dynamics without adopting typical experimental solutions, such as direct fluid visualizations through transparent inserts. The studied device is made of copper, and it is partially filled with a water–ethanol mixture (20 wt.% of ethanol). Heat fluxes locally exchanged between the working fluid and the device walls are first assessed through the inverse heat conduction problem resolution approach by processing outer wall temperature distributions acquired by thermography. The estimated local heat transfer quantities are therefore processed to quantify the fluid oscillatory behavior in every device branch during the intermittent flow and full activation regimes, thus providing a deeper insight into the heat transfer modes. After dealing with a further validation of the inverse approach in terms of oscillation frequency restoration capability, the wall-to-fluid heat fluxes referred to each channel are processed by means of the wavelet method. Scalograms and power spectra of the considered signals are presented for a time-based analysis of the working fluid oscillations, as well as for the identification of dominant oscillation frequencies. Fluid motion is then quantified in terms of the continuity of fluid oscillations and activity of channels by applying a scalogram denoising technique named K-means clustering method. Moreover, a statistical reduction of the channel-wise dominant oscillation frequencies is performed to provide useful references for the interpretation of the overall oscillatory behavior. The link between oscillations and transverse interactions is finally investigated. The vertical bottom-heated mode exhibits stronger fluid oscillations with respect to the horizontal mode, with fluid oscillation frequencies ranging from 0.78 up to 1 Hz. Nonetheless, the fluid motion is more stable in terms of oscillation frequency between channels when the device operates in the horizontal orientation probably due to negligible buoyancy effects. Moreover, thermal interactions between adjacent channels are found to be stronger when the oscillatory behavior presents similar features from channel to channel in horizontal orientation. The proposed method for fluid oscillation analyses in fully metallic flat-plate pulsating heat pipes can be effectively adopted to other flat-plate layouts without any need for transparent windows, thus reducing the overall complexity of experimental set-ups and providing, at the same time, a good insight into the inner fluid dynamics. Full article

In order to successfully study the condensation and separation of a steam–CO₂ mixture, a boundary layer model was applied to the mixture condensation of steam and CO₂ on horizontal and vertical plates. The modified condensation boundary layer model of steam and CO₂, given the CO₂ solubility in the condensate, was established, numerically solved, and verified with existing experimental data. Different condensation data of steam–air and steam–CO₂ mixtures were compared, and the effect of CO₂ solubility on the mixed gas condensation was analyzed under multiple pressure conditions (1 atm–10 MPa). The simulation data show that the presence of CO₂ will deteriorate the condensation heat transfer, just like air. Given that CO₂ is slightly soluble, some CO₂ can pass through the gas–liquid interface to enter the condensate film and reduce the accumulated CO₂ on the gas–liquid interface, which improves the condensation. However, the solubility of CO₂ is only significant under high-pressure conditions, inducing its effects on condensation. A comparison of the condensation coefficients of the steam–CO₂ mixture shows the lower impact of CO₂ condensation on the horizontal plate compared to that on the vertical plate. For most conditions, the steam–CO₂ mixture gas condensation heat transfer coefficient on the vertical plate surface is still larger than that on the horizontal plate surface, and the improvement in the condensation heat transfer coefficient caused by low CO₂ solubility (2 or 10%) at 10 MPa on the vertical plate is also larger than that of the horizontal plate. Full article

Various external-recycle configurations of multi-pass flat-plate solar air collectors were studied theoretically to examine the optimal thermal performance under the same working dimension and operation conditions. An absorber plate and insulation sheet were implemented horizontally and vertically, respectively, into an open rectangular conduit to conduct a recycling four-pass operation, which the device lengthens the air flow channel and increases the air mass flow rate within the collector, and thus, a more heat transfer efficiency is obtained. Four recycling types with different external-recycle patterns were introduced and expected to augment the heat transfer rate due to the turbulent convective intensity through four subchannels in the present study. Coupling energy balances into one-dimensional modeling equations were derived by making the energy-flow diagram within a finite element, which the longitudinal temperature distributions for each subchannel were obtained. The theoretical predictions show that the improved four-pass device is accomplished due to the multiple heating pathways over and under the absorber plate, from which the turbulence intensity augmentation results in the heat transfer rate as compared to that in the device without inserting the absorber plate and insulation sheet (say a downward-type single-pass solar air collector). The theoretical results also show that the external-recycle configuration (say Type C in the present study) acts as an optimal collector thermal efficiency and leading to a beneficial design in multi-pass solar air collectors for improving heat-transfer rate and increasing resident time under the same operation conditions. Theoretical predictions show a higher heat-transfer efficiency for the present recycling configurations up to a maximum 115% device enhancement in comparison to that of a single-pass device. Examination of implementing the absorber plate and insulation sheet on the heat-transfer efficiency enhancement as well as the hydraulic dissipated power increment were also delineated, and deliberated the suitable external-recycle configuration with respect to an economic consideration. Full article

With the rapid development of electronic technologies towards high integration, high power and miniaturization, thermal management has become an increasingly important issue to guarantee the reliability and service life of electronic devices. The oscillating heat pipe (OHP), which was governed by thermally excited oscillating motion, was considered as a promising technology to dissipate high-density heat and had excellent application prospects in many important industrial processes. A flat-plate OHP, however, was fabricated by traditional welding methods, which were difficult and inefficient, resulting in increasing the cost and wasting the production time. In this work, we adopted a new metal 3D printing technology to develop an aluminum flat-plate OHP, which made it facile to build complex inner channels with high-precision molding at one time. AlSi₁₀Mg powders, as raw materials, were selectively melted and solidified to form the container of the flat-plate OHP. The sintered inner surface presented excellent wettability to the working fluid, which facilitated the evaporation of the working fluid. Acetone was chosen as the working fluid, and the filling ratios with a range of 40–70% were loaded into the flat-plate oscillating heat pipe to analyze its effect on heat transfer performance. It was found that the 3D-printed flat-plate OHP with a 60% filling ratio had a better heat transfer performance and a lower thermal resistance, and it was able to work properly in both vertical and horizontal operation modes. The 3D-printed flat-plate OHP had been successfully applied for the thermal management of high-power LEDs, and the results showed that the temperature of LEDs was maintained within 60 °C, and its service life was prolonged. Full article

The aim of this paper is to estimate the influence of the dimensions of the torsion box (height and width), of a 2400 TEU feeder-class container ship, on local stress distribution and assessment of local fatigue strength by using a numerical approach based on the fatigue limit-state and ultimate limit-state in the midship region. In terms of the fatigue limit-state, the effect of the dimensions of the torsion box is obtained by geometrical modifications, in the connection between the side shell longitudinal stiffeners with the transverse web frame for nine structural details, referring to different arrangements of strengthening elements (brackets and flat bars). The process of comparing the different elements determines the most effective combination. This structural influence on the local stress distribution is assessed, along the longitudinal plates between ordinary stiffeners bounding the perimeter of the torsion box, by calculating the hull girder stresses, local buckling stresses and shear stress distribution induced by vertical and horizontal shear forces, Saint Venant and warping torques, and finally the shear stresses induced by a warping moment. Scantling criteria are obtained allowing for a better design of this very important region in container ships. Full article

This paper reports the design, fabrication, and performance of a hybrid piezoelectric planar micro-conveyor based on Micro-Electromechanical Systems (MEMS) bridge resonators and featuring 3D-printed vertical legs. The device includes two cooperating silicon plate resonators with an area of 5 × 1 mm², actuated by an integrated aluminum-nitride (AlN) piezoelectric thin film. An optimally designed array of 3D-printed projection legs was attached to the plates, to convert the standing-wave (SW) vertical vibrations into horizontal rotations or translations of the supported slider. An open-loop control strategy based on burst-type driving signals, with different numbers of sinusoidal cycles applied on each of the resonators, allowed the cooperation of the two bridges to set up prescribed trajectories of small flat objects, up to 100 mg, with positional accuracy below 100 nm and speeds up to 20 mm/s, by differential drive actuation. The effect of the leg tip and sliders’ surface finish on the conveyor performance was investigated, suggesting that further optimizations may be possible by modifying the tribological properties. Finally, the application of the micro-conveyor as a reconfigurable electronic system, driven by a preprogrammed sequence of signals, was demonstrated by delivering some surface-mount technology (SMD) parts lying on a 65 mg glass slider. Full article

In this paper, we propose that thermally induced Knudsen forces in a rarefied gas can be exploited to achieve a tweezer-like mechanism that can be used to trap and grasp a micro-object without physical contact. Using the direct simulation Monte Carlo (DSMC) method, we showed that the proposed mechanism is achieved when a heated thin plate, mounted perpendicularly on a flat substrate, is placed close to a colder object; in this case, a beam. This mechanism is mainly due to the pressure differences induced by the thermal edge flows at the corners of the beam and the thermal edge flow at the tip of the thin plate. Specifically, the pressure on the top surface of the beam is smaller than that on its bottom surface when the thin plate is above the beam, while the pressure on the right side of the beam is smaller than that on its left side when the thin plate is located near the right side of the beam. These differences in pressure generate a force, which attracts the beam to the plate horizontally and vertically. Furthermore, this phenomenon is enhanced when the height of the beam is shorter, such that the horizontal and vertical net forces, which attract the beam to the plate, become stronger. The mechanism proposed here was also found to depend significantly on the height of the beam, the temperature difference between the thin plate and the beam, and the Knudsen number. Full article

This paper aims to present the design and prototype of an inspection robot that can perform both horizontal and vertical locomotion in ferromagnetic pipelines. The proposed robot applies to a range from 5-inch (127 mm) diameter pipes to flat plates. The train-like robot is mainly composed of three sealed modules with omnidirectional driving wheels for longitudinal and transverse movements. Permanent magnets were designed to provide sufficient magnetic adhesion between the robot and the ferromagnetic surface of the pipes. The internal condition of the pipe can be monitored visually through cameras and sensors. Specific experimental conditions have been carried out to validate the robot’s capabilities, including maximum speed, payload capacity, and vertical climbing distance. The experimental results also show that the robot is capable of passing through a straight pipe and elbow fitting in both upward and downward directions. Full article

Multiple competing factors are forcing aircraft designers to reconsider the underwing engine pod configuration typically seen on most modern commercial aircraft. One notable concern is increasing environmental regulations on noise emitted by aircraft. In an attempt to satisfy these constraints while maintaining or improving vehicle performance, engineers have been experimenting with some innovative aircraft designs which place the engines above the wings or embedded in the fuselage. In one configuration, a blended wing concept vehicle utilizes rectangular jet exhaust ports exiting from above the wing ahead of the trailing edge. While intuitively one would think that this design would reduce the noise levels transmitted to the ground due to the shielding provided by the wing, experimental studies have shown that this design can actually increase noise levels due to interactions of the jet exhaust with the aft wing surface and flat trailing edge. In this work, we take another look at this rectangular exhaust port configuration with some notional modifications to the geometry of the trailing edge to determine if the emitted noise levels due to jet interactions can be reduced with respect to a baseline configuration. We consider various horizontal and vertical offsets of the jet exit with respect to a flat plate standing in for the aft wing surface. We then introduce a series of sinusoidal deformations to the trailing edge of the plate of varying amplitude and wave number. Our results show that the emitted sound levels due to the jet–surface interactions can be significantly altered by the proposed geometry modifications. While sound levels remained fairly consistent over many configurations, there were some that showed both increased and decreased sound levels in specific directions. We present results here for the simulated configurations which showed the greatest decrease in overall sound levels with respect to the baseline. These results provide strong indications that such geometry modifications can potentially be tailored to optimize for further reductions in sound levels. Full article

The axinite-bearing Gukjeon Pb–Zn deposit is hosted by the limestone, a member of the Jeonggaksan Formation, which, in turn, forms the part of the Jusasan subgroup of the Yucheon Group in the Gyeongsang Basin in the southeastern part of the Korean Peninsula. In this study, we attempted to interpret the spatial and temporal relationships among geologic events, including the mineralization of this deposit. We constructed a new 3D orebody model and suggested a relationship between skarn alteration and related mineralization. Mineralization timing was constrained using SHRIMP zircon age dating results combined with boron geochemistry on coeval intrusive rocks. Skarn alterations are restrictively found in several horizons of the limestone formation. The major skarn minerals are garnet (grossular), pyroxene (hedenbergite), amphibole (actinolite and ferro-actinolite), axinite (tizenite and ferro-axinite), and epidote (clinozoisite and epidote). The three stages of pre-skarn, syn-skarn, and post-skarn alteration are recognized within the deposit. The syn-skarn alteration is characterized by prograde metasomatic pyroxene and garnet, and the retrograde metasomatic amphibole, axinite, and epidote. Major skarn sulfide minerals are sphalerite, chalcopyrite, galena, and pyrite, which were predominantly precipitated during the retrograde stage and formed amphibole and axinite skarns. The skarn orebodies seem to be disc- or flat-shaped with a convex form at the central part of the orebodies. The vertical ascending and horizontal infiltration of boron-rich hydrothermal fluid probably controlled the geometry of the orebodies. Considering the whole-rock major, trace, and boron geochemical and geochronological results, the timing of Pb–Zn mineralization can be tightly constrained between the emplacement of boron-poor intrusion (fine-grained granodiorite, 82.8 Ma) and boron-rich intrusion (porphyritic andesite in Beomdori andesitic rocks, 83.8 Ma) in a back-arc basin setting. The boron for mineralization was sourced from late Cretaceous (Campanian), subduction-related magmatic rocks along the margin of the Pacific plate. Full article

A novel model is developed to evaluate the van der Waals (vdW) interactions between a capsule shaped bacterium (P. putida) and flat minerals plates in different approach profiles: Vertically and horizontally. A comparison of the approaches to the well-developed spherical particle to mineral surface (semi-infinite wall and spherical) approach has been made in this investigation. The van der Waals (vdW) interaction potentials for a capsule-shaped bacterium are found using Hamaker’s microscopic approach of sphere to plate and cylinder to plate either vertically or horizontally to the flat surface. The numerical results show that a horizontal orientated capsule shaped bacterium to mineral surface interaction was more attractive compared to a capsule shaped bacterium approaching vertically. The orientation of the bacterial approaching a surface as well as the type and topology of the mineral influence the adhesion of a bacteria to that surface. Furthermore, the density difference among each type of bacteria shape (capsule, cylinder, and sphere) require different amounts of energy to adhere to hematite and quartz surfaces. Full article

Applying a well-performing heat exchanger is an efficient way to fortify the relatively low thermal response of phase-change materials (PCMs), which have broad application prospects in the fields of thermal management and energy storage. In this study, an improved PCM melting and solidification in corrugated (zigzag) plate heat exchanger are numerically examined compared with smooth (flat) plate heat exchanger in both horizontal and vertical positions. The effects of the channel width (0.5 W, W, and 2 W) and the airflow temperature (318 K, 323 K, and 328 K) are exclusively studied and reported. The results reveal the much better performance of the horizontal corrugated configuration compared with the smooth channel during both melting and solidification modes. It is found that the melting rate is about 8% faster, and the average temperature is 4 K higher in the corrugated region compared with the smooth region because of the large heat-exchange surface area, which facilitates higher rates of heat transfer into the PCM channel. In addition to the higher performance, a more compact unit can be achieved using the corrugated system. Moreover, applying the half-width PCM channel accelerates the melting rate by eight times compared to the double-width channel. Meanwhile, applying thicker channels provides faster solidification rates. The melting rate is proportional to the airflow temperature. The PCM melts within 274 s when the airflow temperature is 328 K. However, the melting time increases to 460 s for the airflow temperature of 308 K. Moreover, the PCM solidifies in 250 s and 405 s in the cases of 318 K and 328 K airflow temperatures, respectively. Full article

We experimentally investigated the forces induced by monochromatic and solitary waves on a submerged horizontal plate in a wave flume. The experimental results of two-dimensional wave forces on the plate over a 1:10 simple slope and a flat bottom are presented. The effects of the uneven bottom on wave loads are discussed by comparing the results with those in a constant water depth. The measured nonlinear wave forces exhibited considerable discrepancies with the theoretical results from the linear wave theory. The wave forces on the plate induced by monochromatic waves over the simple slope in intermediate water showed no appreciable difference with the flat-bottom results. The solitary wave forces in terms of the downward vertical force and overturning moment significantly decreased in the existence of the simple slope. Furthermore, the dependency of the wave length, wave height and the submergence depth on the wave loads is also discussed. Full article
