Search Results (54)

Concrete dams are prone to various hidden dangers after long-term operation and may lead to significant risk if failed to be detected in time. However, the existing hollowing detection techniques are few as well as inefficient when facing the demands of comprehensive coverage and intelligent management for regular inspections. Hence, we proposed an innovative, non-destructive infrared inspection method via constructed dataset and proposed deep learning algorithms. We first modeled the surface temperature field variation of concrete dams as a one-dimensional, non-stationary partial differential equation with Robin boundary. We also designed physics-informed neural networks (PINNs) with multi-subnets to compute the temperature value automatically. Secondly, we obtained the time-domain features in one-dimensional space and used the diffusion techniques to obtain the synthetic infrared images with dam hollowing by converting the one-dimensional temperatures into two-dimensional ones. Finally, we employed adaptive joint learning to obtain the spatio-temporal features. We designed the experiments on the dataset we constructed, and we demonstrated that the method proposed in this paper can handle the low-data (few shots real images) issue. Our method achieved 94.7% of recognition accuracy based on few shots real images, which is 17.9% and 5.8% higher than maximum entropy and classical OTSU methods, respectively. Furthermore, it attained a sub-10% cross-sectional calculation error for hollowing dimensions, outperforming maximum entropy (70.5% error reduction) and OTSU (7.4% error reduction) methods, which shows our method being one novel method for automated intelligent hollowing detection. Full article

Circular hollow sections (CHSs) are widely used in offshore jacket structures due to their excellent compressive strength, torsional resistance, and direction-independent stiffness. However, CHS joints are prone to fatigue-induced cracking caused by complex geometries, environmental loading, and aging. Fatigue crack propagation, governed by the stress intensity factor (SIF), threatens structural integrity if the SIF exceeds fracture toughness. Composite reinforcement has emerged as a promising solution for mitigating crack propagation and enhancing joint performance. This study presents a numerical parametric investigation of fatigue-cracked tubular T-joints, focusing on the effects of crack size, crack location, and composite reinforcement on the SIF under various loading conditions. The highest SIF was consistently observed at the saddle point in T-joints under axial and out-of-plane bending (OPB) loads. However, in T-joints subjected to in-plane bending (IPB) loads, the highest SIF was found between the crown and saddle points. The SIF increased with the size and diameter of the cracks. The application of CFRP wrapping was found to reduce the SIF by more than 50% across all loading conditions, with the most significant reductions observed when the reinforcement was oriented along the chord axis. Full article

Tubular structures are critical in renewable energy and offshore industries but face significant loads over time, leading to joint degradation. Carbon fiber-reinforced polymers (CFRPs) offer promising rehabilitation solutions, yet existing studies often overlook stress concentration factors (SCFs) along the weld toe. This study examines SCFs at 24 weld toe positions in CFRP-reinforced KT-joints under axial compression. Using 5429 simulations and artificial neural networks, precise estimations of CFRPs’ impact on SCFs were achieved, with <10% error. These findings demonstrate CFRPs’ potential to reduce SCFs and improve fatigue life prediction for tubular joints under axial compression. Full article

A CHS-to-CFRHS Y-joint that consists of a circular hollow section (CHS) brace and a concrete-filled rectangular hollow section (CFRHS) chord by welding has a simple and smooth weld profile that saves time and cost for the fabrication of CHS-to-CFRHS Y-joints and leads to a superior fatigue performance, compared with other welded tubular joints. This investigation presented an analysis of the stress concentration factors (SCFs) of CHS-to-CFRHS Y-joints subjected to axial tension loading of the brace. First, a finite element (FE) modelling method, which was validated with the experimental results cited in the reference, was utilised to establish the FE models of CHS-to-CFRHS Y-joints. Then, a parametric analysis was conducted to investigate the influences of the significant non-dimensional geometric parameters on the SCFs of CHS-to-CFRHS Y-joints. It is found that the intersection angle of the brace and chord has an important influence on the magnitudes of the SCF values. An increase in the intersection angle of the brace and chord will increase the values of the SCFs at the 60° location and saddle. The values of the SCFs at the 60° location and saddle reach the maximum value when the intersection angle of the brace and chord reaches 90°. Furthermore, on the basis of the large database of the SCF results, empirical design equations were established to calculate the SCFs at the crown toe, 60° location and saddle via multiple regression analysis. A safety factor was applied to the empirical design equations to ensure safe and reliable results of SCF calculations for the fatigue design of CHS-to-CFRHS Y-joints in a composite truss structure. Ultimately, a comparative analysis of SCFs was conducted with the FE models of welded tubular joints with rectangular hollow section (RHS) chords and CFRHS chords. The results reveal that infilling concrete in the chord leads to a reduction in SCFs along the weld profile of more than 11% on average, and the peak SCF decreases by more than 15%. Full article

The focus of this paper is on estimating the stress concentration factor of circular hollow section KK-joints with different geometric parameters and subsequently assessing the effectiveness of carbon fiber-reinforced polymer (CFRP) wrapping for repairing joints with cracks. Different geometric parameters, such as θ (brace inclination angle), γ (the ratio of the outer diameter to the wall thickness of the chord), and τ (the thickness ratio of the brace to the chord), were studied to investigate changes in stress concentration using numerical simulation. The results indicated that the stress concentration factor was most sensitive to changes in θ, followed by γ. Subsequently, the effect of crack length and depth was analyzed to simulate cracks in joints subjected to reciprocating load. The results showed that changing D from T/16 to T/2 (where T is the thickness of the chord) can cause more stress concentration, with an average of 8.37%. Next, damaged joints were wrapped in carbon fiber-reinforced polymer as a repair. Analysis of the effects of different layers and directions of polymer wrap revealed that even six layers of wrapping effectively reduced the stress concentration compared to the initial model. Finally, based on the results of parametric analysis and nonlinear fitting, a calculation formula for the stress concentration factor suitable for KK-joints under axial loads is proposed. Full article

This study investigates the seismic behavior of traditional and eccentric rectangular hollow section (RHS) X-joints through a comprehensive experimental program. Four X-joint specimens, including two traditional and two eccentric joints with brace-to-chord width ratios (β) of 0.83 and 1.0, were subjected to quasi-static cyclic axial loading. Test results revealed that joints with β = 0.83 primarily failed due to chord face tearing, while those with β = 1.0 exhibited failure modes, including chord face tearing and significant sidewall buckling. Eccentric joints further experienced tearing of brace wall near the intersection. Increasing β enhanced axial strength but reduced ductility, deformability, and energy dissipation capacity. Eccentric joints with β = 0.83 showed improved strength, ductility, and energy dissipation compared to traditional joints, whereas eccentric joints with β = 1.0 displayed superior ductility but comparable strength and energy dissipation. The findings that current design codes underestimate the compressive strength of traditional joints with medium β and confirm that tensile strength exceeds compressive strength for all tested joints. Additionally, cyclic compressive strength closely static compressive strength. Full article

Single-layer spatial grid joints are crucial to structural safety, with commonly used welded hollow spherical joints and cast steel joints. However, these traditional joints face limitations, including a rigid design, excessive weight, and susceptibility to stress concentration. As engineering practices advance, these joints struggle to meet modern requirements. This paper introduces a generative method for designing rigid joints in single-layer spatial grid structures, based on Audze space-filling criteria. The method’s mathematical formulation is presented, followed by developing novel joint configurations by exploring various cross-sectional forms, retention mass, and geometric elements, while considering bending moments. A comparative analysis of static properties between the new and traditional joints shows promising results. The generative approach demonstrates significant innovation, producing lightweight, aesthetically pleasing, and structurally efficient joints. Compared to conventional welded hollow spherical joints, the new joints exhibit a 57% reduction in self-weight, a 51% decrease in maximum equivalent stress, and a 24% reduction in maximum displacement. This method enables versatile and optimized joint design for single-layer spatial grid structures, offering enhanced strength, safety, and aesthetic appeal. Full article

Welding residual stresses significantly influence the mechanical behavior of hollow section joints, especially in the pivotal connection zones of steel structures employed in construction. The research object of this study is the Q355 steel square tube–plate Y-joint welded using Gas Metal Arc Welding (GMAW) with CO₂ Shielding. The thermodynamic sequence coupling method was employed to simulate the temperature field, microstructure distribution, and welding residual stresses in square tube–plate Y-joints. Based on the monitored temperature field data and the cross-sectional dimensions of the weld pool, this study calibrated the finite element model. Subsequently, the calibrated finite element model was employed to analyze the influence of microstructural phase transformations and welding sequences on the welding residual stresses in square tube–plate Y-joints. The research findings indicate that the peak transverse welding residual stresses in the branch pipes of the four joint zones were lower when considering the phase transformation effect than when not accounting for it in the calculations. There was no significant difference in the transverse and longitudinal welding residual stresses on the surface of branch pipes under the three welding sequences. However, there were certain differences in the microstructural content of the weld zones under the three welding sequences, with the martensite content in the third welding sequence being significantly lower than that in the other two sequences. Full article

Detachable circular hollow sections (CHSs) offer an innovative solution to tackle the complexities of installation, maintenance, upgrades, and repairs in offshore monopile systems, particularly in challenging environments with limited access. As an alternative to traditional tubular joints, the PIP slip joint presents advantages in terms of ease of installation, time efficiency, and reduced susceptibility to failure. This study conducts an experimental investigation on PIP (Pile-in-Pile) slip joints under pure bending conditions, accompanied by comprehensive numerical analyses to examine the relationship between section slenderness, contact properties, and structural performance. The results highlight a strong correlation between force-displacement curves and include a comparison of compressive and tensile strain values for both experimental and numerical models. The experimental and numerical models showed strong agreement across all results, demonstrating the robustness of the findings. Additionally, numerical models were utilized to investigate various D/t ratios, revealing insights into the normalized moment, rotational capacity, and the impact of local buckling and contact mechanics. Furthermore, a comparison of these findings with established code guidelines, such as Eurocode and AISC-LRFD, has been conducted and reviewed in the context of this study. From analysis, it was found that the rise in the D/t ratio prompted a transformation in the buckling mode, which substantially altered the rotational ratio. This shift indicates the importance of understanding how these variables interact in engineering applications. These findings significantly enhance the understanding of PIP slip joints and emphasize their potential as a compelling alternative for offshore wind turbine support structures. Full article

In recent years, 3D printing technology has become very important in many fields of science, manufacturing, design, medicine, aviation, sports, etc. Furniture design and manufacturing are also not left out of this trend. In this study, the results of bending moments and stiffness of joints of thin structural elements connected by 3D printing with polylactic acid (PLA) connectors are given. The connectors are newly developed, and information on their strength characteristics is lacking in the literature. Ten joints were investigated, made with 9 and 12 mm plywood and 6 mm MDF. The tested joints constructed by 3D-printed connecting elements show a high strength under arm compression bending load, between 44.16 and 24.02 N·m. The stiffness coefficients of joints with 3D-printed connecting elements are between 348 and 145 N·m/rad and are higher than those of conventional detachable mitre joints but lower than those of glued ones. The type of filling of the hollow section of the connecting elements and the wall thickness influenced the joints’ strength and stiffness. Reducing the width of the connecting elements from 40 to 30 mm and the inner radius between the arms from 2 to 1 mm does not significantly affect the joints’ strength and stiffness coefficients. Full article

In recent years, square hollow section (SHS) joints with concrete-filled square hollow section (CFSHS) chords have increasingly been used in truss bridges where the fatigue life reliability is a critical issue. In this paper, a finite element analysis was performed to investigate the SCFs in SHS-CFSHS T-joints under in-plane bending in the brace, axial force in the chord and in-plane bending in the chord. The finite element models were developed and validated with experimental results. Then a parametric study was conducted with a reasonable range of three key non-dimensional parameters, i.e., β (width ratio between brace and chord), 2γ (width–to–wall thickness ratio of the chord) and τ (wall thickness ratio between brace and chord). Consequently, the stress concentration factor formulae for the fatigue design of SHS-CFSHS T-joints were proposed through multiple regression analysis. For in-plane bending in the brace, the maximum stress concentration factors were found at lines B and C for thick-walled chords (2γ = 25.0), while the stress concentration factors at all the lines need to be checked for thin-walled chords (2γ < 16.0). Under axial force in the chord and in-plane bending in the chord, only stress concentration factors at lines C and D needed to be considered. A comparison of stress concentration factors between SHS-SHS and SHS-CFSHS joints showed reductions of 10~26% and 14~31% in stress concentration factors in SHS-CFSHS joints under axial force in the brace and in-plane bending in the brace, respectively. In addition, it showed a general increase in stress concentration factors in SHS-CFSHS joints under axial force and in-plane bending in the chord. This reduction is attributed to the reduction in chord face deformation benefiting from the in-filled concrete. Meanwhile, the stress concentration factors caused by loads in the chord are much lower than those caused by loads in the brace. This work complements earlier studies on SHS-CFSHS T-joints under axial force. Full article

Considering the practical conditions, it has been observed that the support structures of wind turbines inevitably experience bending and axial compression, both during the installation phase and throughout their operational lifespan. The monopile is the most commonly utilized support structure for offshore applications and a reliable method for creating a detachable section within these structures is using a Pile-in-Pile (PIP) slip joint. Consequently, the behavior of PIP slip joints, under combined axial compression and bending, has been meticulously investigated. To facilitate a thorough analysis, overlapping lengths proportional to the pile diameters have been used, encompassing three distinct variations. This approach allows for a comprehensive understanding of structural integrity and performance under varying stress conditions, which are comprehensively understood and accounted for in design considerations. The current study builds upon assessing the pure bending characteristics of slip joints in cylindrical hollow section (CHS) structures. Additionally, two ring stoppers have been strategically employed inside the piles to withstand the axial load. Furthermore, the complexity of the pressure acting in the overlapping length, attributed to the frictional coefficient in that region, has been carefully addressed. The current research also encompasses a comprehensive overview of the P-M envelopes for the existing arrangements, with a particular focus on non-linear buckling, which is known to significantly influence the performance of tubular structures. Finally, a design equation was introduced to concisely describe the behavior of the components and compare it with other design equations provided by an established code. Full article

Tubular joints are important connecting parts of a welded steel tube structure. The S-N curves based on the hot spot stress (HSS) method are often used to evaluate the fatigue life of tubular joints in practical engineering. The stress concentration factor (SCF) is a key parameter to calculate HSS. In this paper, stress concentration tests of hollow-section and concrete-filled double-skin tubular (CFDST) K-joints were carried out, respectively, and then finite element models of K-joints considering the weld were established. The developed models were validated with the experimental results. The influence of key geometrical parameters, such as the diameter ratio of brace to chord β, the diameter to thickness ratio of chord γ, the wall thickness ratio of brace to chord τ, brace angle θ, and hollow section ratio ζ on the distribution and key position of SCFs along the weld toe, was discussed. Parametric studies were conducted to obtain the calculating equations for the SCF values of CFDST K-joints. The results demonstrate that infill concrete can effectively reduce SCFs along the weld on the chord. When the hollow section ratio was reduced to 0.317, the SCF was reduced by 77.2%. Notably, the SCF reduction rate was sensitive to γ and θ, with a decrease observed as γ increased. The hollow section ratio ζ had a less pronounced effect on SCF distribution patterns, but as ζ decreased, the chord’s stiffness improved, suggesting a potential approach to enhance joint performance. The distribution of SCFs is similar for joints of the same type but different geometric configurations. The innovatively integrated hollow section ratio in the CFDST design equation significantly simplifies and enhances the precision of SCF calculations for CFDST K-joints. Full article

Welded structural hollow sections are becoming increasingly used in contemporary civil engineering buildings. More specific design techniques are needed for connections in steel structures with welded structural hollow sections than for traditional connections made with gusset plates. At the connecting site, stress and local deformations show very complex, non-linear behaviors. The application of non-linear numerical analyses to determine the ultimate bearing capacity of “T” connections was demonstrated in this study. A non-linear material model was used in the analysis. In order to validate the applicable steel modeling method, a comparative study between experimentally obtained results and analytically and numerically computed ultimate bearing capacities was carried out. The comparison showed good agreement between the numerical and experimental results and pointed out the highly conservative design of such joints was obtained using the analytical solution. Full article

The paper concerns the numerical modelling of a new slim-floor system with innovative steel–concrete composite beams called “hybrid beams”. Hybrid beams consist of a high-strength TT inverted cross-section steel profile and a concrete core made of high-performance concrete and are jointed with prestressed hollow core slabs by infill concrete and tie reinforcement. Such systems are gaining popularity since they allow the integration of the main structural members within the ceiling depth, shorten the execution time, and reduce the use of concrete and steel. A three-dimensional finite element model is proposed with all parts of the system taken into account and detailed geometry reproduction. Advanced constitutive models are adopted for steel and concrete. Special attention is paid to the proper characterisation of interfaces. The new approach to calibration of damaged elastic traction–separation constitutive model for cohesive elements is applied to concrete-to-concrete contact zones. The model is validated with outcomes of experimental field tests and analytical calculations. A satisfactory agreement between different assessment methods is obtained. The model can be used in the development phase of a new construction system, for instance, to plan further experimental campaigns or to calibrate simplified design formulas. Full article
