19 pages, 8251 KiB
Technical Note
Modified Auto-Focusing Algorithm for High Squint Diving SAR Imaging Based on the Back-Projection Algorithm with Spectrum Alignment and Truncation
by Anqi Gao, Bing Sun, Mengyuan Yan, Chen Xue and Jingwen Li
Remote Sens. 2023, 15(12), 2976; https://doi.org/10.3390/rs15122976 - 7 Jun 2023
Cited by 4 | Viewed by 2059
Abstract
The study focuses on addressing the image defocusing issue caused by motion errors in highly squinted Synthetic Aperture Radar (SAR). The traditional auto-focusing algorithm, Phase Gradient Autofocus (PGA), is not effective in this mode due to difficulties in estimating the phase gradient accurately [...] Read more.
The study focuses on addressing the image defocusing issue caused by motion errors in highly squinted Synthetic Aperture Radar (SAR). The traditional auto-focusing algorithm, Phase Gradient Autofocus (PGA), is not effective in this mode due to difficulties in estimating the phase gradient accurately from strong point targets. Two main reasons contribute to this problem. Firstly, the direction of the energy-distributed lines in the Point Spread Function (PSF) does not align with the image’s azimuth direction in highly squinted mode. Secondly, the wavenumber spectrum of high squint SAR images obtained using the Back-Projection Algorithm (BPA) varies spatially, causing aliasing in the azimuth spectrum of all targets. In this paper, a new auto-focusing method is proposed for highly squinted SAR imaging. The modifications to the BP imaging grids have been implemented to address the first problem, while a novel wavenumber spectrum shifting and truncation method is proposed to accurately extract the phase gradient and tackle the spatial variation issue. The feasibility of the proposed algorithm is verified through simulations with point targets and processing of real data. The evaluation of the image shows an average improvement of four times in PSLR (Peak-Sidelobe-to-Noise Ratio). Full article
Show Figures

Figure 1

14 pages, 4811 KiB
Technical Note
Extended Polar Format Algorithm (EPFA) for High-Resolution Highly Squinted SAR
by Ping Guo, Fuen Wu and Anyi Wang
Remote Sens. 2023, 15(2), 456; https://doi.org/10.3390/rs15020456 - 12 Jan 2023
Cited by 2 | Viewed by 2556
Abstract
The conventional polar format algorithm (CPFA) is widely used for synthetic aperture radar (SAR) because of its simple and efficient operations. However, due to its wavefront curvature assumption, the CPFA’s depth-of-focus (DOF) is extremely small, which greatly limits the scene size, especially for [...] Read more.
The conventional polar format algorithm (CPFA) is widely used for synthetic aperture radar (SAR) because of its simple and efficient operations. However, due to its wavefront curvature assumption, the CPFA’s depth-of-focus (DOF) is extremely small, which greatly limits the scene size, especially for high-resolution and highly squinted (HRHS) SAR. To solve this problem, an extended PFA (EPFA) is proposed in this study, re-deriving mapping functions by expanding the range history into slant- and cross-range components according to the forms of real data storage. This allows the full use of storage data, which the CPFA cannot achieve due to the large approximations introduced by the projection of echo data onto the ground. The wavefront curvature error is then analyzed and eliminated using a space-variant phase compensation function. Due to the high accuracy of expansion in the slant range plane and the space-variant correction processing, the EPFA has a larger DOF than the CPFA. The EPFA is also more suitable for undulating terrains since it avoids the projection of real data onto the ground plane performed in the CPFA. Using comparative analyses of simulated data and real-world images, the results suggest that the proposed EPFA achieves better focusing effects than the CPFA and is particularly useful for HRHS SAR. Full article
(This article belongs to the Special Issue Radar Techniques and Imaging Applications)
Show Figures

Figure 1

14 pages, 1226 KiB
Technical Note
Analysis and Correction of Antenna Pattern Effects in AMAO Spaceborne SAR Images
by Jianjun Huang, Jie Chen, Yanan Guo and Pengbo Wang
Remote Sens. 2022, 14(9), 2141; https://doi.org/10.3390/rs14092141 - 29 Apr 2022
Cited by 2 | Viewed by 2614
Abstract
Azimuthal multi-angle observation (AMAO) is a novel spaceborne synthetic aperture radar (SAR) technique proposed recently, which significantly improves the acquisition performance of target information. It has highly flexible antenna beams with powerful beam-steering capability while affecting the consistency of radiometric measurements, especially in [...] Read more.
Azimuthal multi-angle observation (AMAO) is a novel spaceborne synthetic aperture radar (SAR) technique proposed recently, which significantly improves the acquisition performance of target information. It has highly flexible antenna beams with powerful beam-steering capability while affecting the consistency of radiometric measurements, especially in the high-squint case. This paper mainly focuses on the antenna pattern effect analysis and correction method of AMAO spaceborne SAR. The antenna pattern characteristics of the squint steering beam are first analyzed. On this basis, an analytical model is developed to quantify the antenna pattern effects in AMAO SAR images. Different from the conventional approach that corrects the elevation antenna pattern, an improved antenna pattern correction method, which accounts for the spatial variation in the two-dimensional antenna pattern, is then proposed for AMAO spaceborne SAR. Finally, experiments are conducted to verify the proposed correction method. The results show that the newly proposed method considering the spatial-variant antenna pattern has higher performance than the conventional approach using a reference elevation pattern. Full article
(This article belongs to the Special Issue Radar Imaging Theory, Techniques, and Applications II)
Show Figures

Graphical abstract

21 pages, 10375 KiB
Article
An Improved Equivalent Squint Range Model and Imaging Approach for Sliding Spotlight SAR Based on Highly Elliptical Orbit
by Xinchang Hu, Pengbo Wang, Hongcheng Zeng and Yanan Guo
Remote Sens. 2021, 13(23), 4883; https://doi.org/10.3390/rs13234883 - 1 Dec 2021
Cited by 6 | Viewed by 3379
Abstract
As an emerging orbital system with flexibility and brand application prospects, the highly elliptical orbit synthetic aperture radar (HEO SAR) can achieve both a low orbit detailed survey and continuous earth surface observation in high orbit, which could be applied to marine reconnaissance [...] Read more.
As an emerging orbital system with flexibility and brand application prospects, the highly elliptical orbit synthetic aperture radar (HEO SAR) can achieve both a low orbit detailed survey and continuous earth surface observation in high orbit, which could be applied to marine reconnaissance and surveillance. However, due to its large eccentricity, two challenges have been faced in the signal processing of HEO SAR at present. The first challenge is that the traditional equivalent squint range model (ESRM) fails to accurately describe the entire range for the whole orbit period including the perigee, the apogee, and the squint subduction section. The second one is to exploit an efficient HEO SAR imaging algorithm in the squinted case which solves the problem that traditional imaging algorithm fails to achieve the focused imaging processing of HEO SAR during the entire orbit period. In this paper, a novel imaging algorithm for HEO SAR is presented. Firstly, the signal model based on the geometric configuration of the large elliptical orbit is established and the Doppler parameter characteristics of SAR are analyzed. Secondly, due to the particularity of Doppler parameters variation in the whole period of HEO, the equivalent velocity and equivalent squint angle used in MESRM can no longer be applied, a refined fourth-order equivalent squint range model(R4-ESRM) that is suitable for HEO SAR is developed by introducing fourth-order Doppler parameter into Modified ESRM (MESRM), which accurately reconstructs the range history of HEO SAR. Finally, a novel imaging algorithm combining azimuth resampling and time-frequency domain hybrid correlation based on R4-ESRM is derived. Simulation is performed to demonstrate the feasibility and validity of the presented algorithm and range model, showing that it achieves the precise phase compensation and well focusing. Full article
Show Figures

Graphical abstract

23 pages, 1485 KiB
Article
Robust GMTI Scheme for Highly Squinted Hypersonic Vehicle-Borne Multichannel SAR in Dive Mode
by Jiusheng Han, Yunhe Cao, Wenhua Wu, Yang Wang, Tat-Soon Yeo, Shuai Liu and Fengfei Wang
Remote Sens. 2021, 13(21), 4431; https://doi.org/10.3390/rs13214431 - 3 Nov 2021
Cited by 9 | Viewed by 2041
Abstract
While there are recent researches on hypersonic vehicle-borne multichannel synthetic aperture radar in ground moving target indication (HSV-MC-SAR/GMTI), this article, which specifically explores a robust GMTI scheme for the highly squinted HSV-MC-SAR in dive mode, is novel. First, an improved equivalent range model [...] Read more.
While there are recent researches on hypersonic vehicle-borne multichannel synthetic aperture radar in ground moving target indication (HSV-MC-SAR/GMTI), this article, which specifically explores a robust GMTI scheme for the highly squinted HSV-MC-SAR in dive mode, is novel. First, an improved equivalent range model (IERM) for stationary targets and GMTs is explored, which enjoys a concise expression and therefore offers the potential to simplify the GMTI process. Then, based on the proposed model, a robust GMTI scheme is derived in detail, paying particular attention to Doppler ambiguity arising from the high-speed and high-resolution wide-swath. Furthermore, it retrieves the accurate two-dimensional speeds of GMTs and realizes the satisfactory performance of clutter rejection and GMT imaging, generating the matched beamforming and enhancing the GMT energy. Finally, it applies the inverse projection to revise the geometry shift induced by the vertical speed. Simulation examples are used to verify the proposed GMTI scheme. Full article
Show Figures

Graphical abstract

19 pages, 3092 KiB
Article
Ground Moving Target Imaging for Highly Squint SAR by Modified Minimum Entropy Algorithm and Spectrum Rotation
by Shichao Xiong, Jiacheng Ni, Qun Zhang, Ying Luo and Longqiang Yu
Remote Sens. 2021, 13(21), 4373; https://doi.org/10.3390/rs13214373 - 30 Oct 2021
Cited by 3 | Viewed by 2364
Abstract
Ground moving target (GMT) is displaced and defocused in conventional synthetic aperture radar (SAR) image due to the residual phase error of non-cooperative GMT motion. In this study, a GMT imaging (GMTIm) method is proposed for highly squint SAR. As the squint angle [...] Read more.
Ground moving target (GMT) is displaced and defocused in conventional synthetic aperture radar (SAR) image due to the residual phase error of non-cooperative GMT motion. In this study, a GMT imaging (GMTIm) method is proposed for highly squint SAR. As the squint angle become large, the displace and defocus effect of the GMT image become severe and the geometry distortion of the GMT image cannot be ignored. The proposed method first deduced the two-dimensional (2-D) frequency domain signal of the GMT and the bulk compression function of the Range Migration Algorithm (RMA) in highly squint SAR. Then GMT ROI data are extracted and a modified minimum entropy algorithm (MMEA) is proposed to refocus the GMT image. MMEA introduces the idea of bisection into the iteration process to converge more efficiently than the previous minimum entropy method. To overcome the geometry distortion of the GMT image, an equivalent squint angle spectrum rotation method is proposed. Finally, to suppress the GMT image sidelobe, the sparse characteristic of GMT is considered and a sparse enhancement method is adopted. The proposed method can realize GMTIm in highly squint SAR where the squint angle reaches to 75 degrees. The PSNR and ISLR of point target in highly squint SAR is close to that in side-looking SAR. The simulated point target data and ship data are used to validate the effectiveness of the proposed method. Full article
Show Figures

Graphical abstract

20 pages, 1550 KiB
Article
Processing Missile-Borne SAR Data by Using Cartesian Factorized Back Projection Algorithm Integrated with Data-Driven Motion Compensation
by Min Bao, Song Zhou and Mengdao Xing
Remote Sens. 2021, 13(8), 1462; https://doi.org/10.3390/rs13081462 - 10 Apr 2021
Cited by 7 | Viewed by 2836
Abstract
Due to the independence of azimuth-invariant assumption of an echo signal, time-domain algorithms have significant performance advantages for missile-borne synthetic aperture radar (SAR) focusing with curve moving trajectory. The Cartesian factorized back projection (CFBP) algorithm is a newly proposed fast time-domain implementation which [...] Read more.
Due to the independence of azimuth-invariant assumption of an echo signal, time-domain algorithms have significant performance advantages for missile-borne synthetic aperture radar (SAR) focusing with curve moving trajectory. The Cartesian factorized back projection (CFBP) algorithm is a newly proposed fast time-domain implementation which can avoid massive interpolations to improve the computational efficiency. However, it is difficult to combine effective and efficient data-driven motion compensation (MOCO) for achieving high focusing performance. In this paper, a new data-driven MOCO algorithm is developed under the CFBP framework to deal with the motion error problem for missile-borne SAR application. In the algorithm, spectrum compression is implemented after a CFBP process, and the SAR images are transformed into the spectrum-compressed domain. Then, the analytical image spectrum is obtained by utilizing wavenumber decomposition based on which the property of motion induced error is carefully investigated. With the analytical image spectrum, it is revealed that the echoes from different scattering points are aligned in the same spectrum range and the phase error becomes a spatial invariant component after spectrum compression. Based on the spectrum-compressed domain, an effective and efficient data-driven MOCO algorithm is accordingly developed for accurate error estimation and compensation. Both simulations of missile-borne SAR and raw data experiment from maneuvering highly-squint airborne SAR are provided and analyzed, which show high focusing performance of the proposed algorithm. Full article
Show Figures

Graphical abstract

17 pages, 5010 KiB
Article
Spatial-Variant SAR Range Cell Migration Correction Using Subaperture Strategy
by Liping Hu, Guanyong Wang and Lin Hou
Sensors 2021, 21(7), 2444; https://doi.org/10.3390/s21072444 - 1 Apr 2021
Cited by 2 | Viewed by 3115
Abstract
The coupling between range and azimuth dimensions is the main obstacle for highly squinted synthetic aperture radar (SAR) data focusing. Range walk correction (RWC) processing is effective to remove the linear coupling term, but the residual high order range cell migration (RCM) parts [...] Read more.
The coupling between range and azimuth dimensions is the main obstacle for highly squinted synthetic aperture radar (SAR) data focusing. Range walk correction (RWC) processing is effective to remove the linear coupling term, but the residual high order range cell migration (RCM) parts are spatial-variant in both range and azimuth dimensions. In this paper, we propose a precise spatial-variant range cell migration correction (RCMC) method with subaperture processing. The method contains two stages. Firstly, the main component of range-variant RCM is corrected in the coarse RCMC stage. Secondly, data are derived into azimuth subapertures (SAs), an SA-image-domain RCMC is developed by interp correction, where the SA image is obtained using a modified spectrum analysis (SPECAN) algorithm by establishing the relationship between Doppler frequency and residual spatial-variant RCM. In the proposed algorithm, precise compensation of space-variant RCM is implemented by SA processing, which is designed for a better practicality in real-time processing system. Simulated and real measured data experiments are designed to validate the effectiveness of the proposed approach for highly squinted SAR imaging. Full article
(This article belongs to the Section Radar Sensors)
Show Figures

Figure 1

21 pages, 8974 KiB
Article
Squinted Airborne Synthetic Aperture Radar Imaging with Unknown Curved Trajectory
by Wei Pu, Junjie Wu, Yulin Huang and Jianyu Yang
Sensors 2020, 20(21), 6026; https://doi.org/10.3390/s20216026 - 23 Oct 2020
Cited by 5 | Viewed by 2819
Abstract
The imagery of airborne highly squinted synthetic aperture radar (SAR) with curved trajectory is a challenging task due to the translational-variant range cell migration (RCM) and azimuth modulation. However, in most cases of practical application, the curved trajectory cannot be accurately known, which [...] Read more.
The imagery of airborne highly squinted synthetic aperture radar (SAR) with curved trajectory is a challenging task due to the translational-variant range cell migration (RCM) and azimuth modulation. However, in most cases of practical application, the curved trajectory cannot be accurately known, which brings greater difficulties to the imaging problem. To accommodate these issues, we propose a novel motion modelling and optimisation based imaging algorithm for the highly squinted SAR with unknown curved trajectory. First, to correct the translational-variant RCM, a coarse-to-fine RCM correction scheme as well as a range perturbation approach is applied. Afterwards, an optimisation model of motion information under the criterion of minimum entropy is built during the azimuth processing by nonlinear chirp scaling (NLCS). Correspondingly, a differential evolution (DE) optimisation strategy is proposed to estimate the motion information in an iterative manner. We empirically compare the proposed algorithms with several state-of-the-art highly squinted curved SAR imaging algorithms. Numerical results show the effectiveness of the proposed method in the case without any prior information of the curved trajectory. Full article
(This article belongs to the Section Remote Sensors)
Show Figures

Figure 1

20 pages, 9780 KiB
Article
Focusing High-Resolution Highly-Squinted Airborne SAR Data with Maneuvers
by Shiyang Tang, Linrang Zhang and Hing Cheung So
Remote Sens. 2018, 10(6), 862; https://doi.org/10.3390/rs10060862 - 1 Jun 2018
Cited by 19 | Viewed by 5171
Abstract
Maneuvers provide flexibility for high-resolution highly-squinted (HRHS) airborne synthetic aperture radar (SAR) imaging and also mean complex signal properties in the echoes. In this paper, considering the curved path described by the fifth-order motion parameter model, effects of the third- and higher-order motion [...] Read more.
Maneuvers provide flexibility for high-resolution highly-squinted (HRHS) airborne synthetic aperture radar (SAR) imaging and also mean complex signal properties in the echoes. In this paper, considering the curved path described by the fifth-order motion parameter model, effects of the third- and higher-order motion parameters on imaging are analyzed. The results indicate that the spatial variations distributed in range, azimuth, and height directions, have great impacts on imaging qualities, and they should be eliminated when designing the focusing approach. In order to deal with this problem, the spatial variations are decomposed into three main parts: range, azimuth, and cross-coupling terms. The cross-coupling variations are corrected by polynomial phase filter, whereas the range and azimuth terms are removed via Stolt mapping. Different from the traditional focusing methods, the cross-coupling variations can be removed greatly by the proposed approach. Implementation considerations are also included. Simulation results prove the effectiveness of the proposed approach. Full article
Show Figures

Figure 1

15 pages, 4119 KiB
Article
A Novel Sidelobe Reduction Algorithm Based on Two-Dimensional Sidelobe Correction Using D-SVA for Squint SAR Images
by Min Liu, Zhou Li and Lu Liu
Sensors 2018, 18(3), 783; https://doi.org/10.3390/s18030783 - 5 Mar 2018
Cited by 8 | Viewed by 6084
Abstract
Sidelobe reduction is a very primary task for synthetic aperture radar (SAR) images. Various methods have been proposed for broadside SAR, which can suppress the sidelobes effectively while maintaining high image resolution at the same time. Alternatively, squint SAR, especially highly squint SAR, [...] Read more.
Sidelobe reduction is a very primary task for synthetic aperture radar (SAR) images. Various methods have been proposed for broadside SAR, which can suppress the sidelobes effectively while maintaining high image resolution at the same time. Alternatively, squint SAR, especially highly squint SAR, has emerged as an important tool that provides more mobility and flexibility and has become a focus of recent research studies. One of the research challenges for squint SAR is how to resolve the severe range-azimuth coupling of echo signals. Unlike broadside SAR images, the range and azimuth sidelobes of the squint SAR images no longer locate on the principal axes with high probability. Thus the spatially variant apodization (SVA) filters could hardly get all the sidelobe information, and hence the sidelobe reduction process is not optimal. In this paper, we present an improved algorithm called double spatially variant apodization (D-SVA) for better sidelobe suppression. Satisfactory sidelobe reduction results are achieved with the proposed algorithm by comparing the squint SAR images to the broadside SAR images. Simulation results also demonstrate the reliability and efficiency of the proposed method. Full article
Show Figures

Figure 1

15 pages, 2754 KiB
Article
Generalized Nonlinear Chirp Scaling Algorithm for High-Resolution Highly Squint SAR Imaging
by Tianzhu Yi, Zhihua He, Feng He, Zhen Dong and Manqing Wu
Sensors 2017, 17(11), 2568; https://doi.org/10.3390/s17112568 - 7 Nov 2017
Cited by 9 | Viewed by 4544
Abstract
This paper presents a modified approach for high-resolution, highly squint synthetic aperture radar (SAR) data processing. Several nonlinear chirp scaling (NLCS) algorithms have been proposed to solve the azimuth variance of the frequency modulation rates that are caused by the linear range walk [...] Read more.
This paper presents a modified approach for high-resolution, highly squint synthetic aperture radar (SAR) data processing. Several nonlinear chirp scaling (NLCS) algorithms have been proposed to solve the azimuth variance of the frequency modulation rates that are caused by the linear range walk correction (LRWC). However, the azimuth depth of focusing (ADOF) is not handled well by these algorithms. The generalized nonlinear chirp scaling (GNLCS) algorithm that is proposed in this paper uses the method of series reverse (MSR) to improve the ADOF and focusing precision. It also introduces a high order processing kernel to avoid the range block processing. Simulation results show that the GNLCS algorithm can enlarge the ADOF and focusing precision for high-resolution highly squint SAR data. Full article
(This article belongs to the Section Remote Sensors)
Show Figures

Figure 1
