Search Results (26)

Slamming load is characterized by a high peak and short duration. Severe slamming phenomena are extremely detrimental to the navigation safety of high-speed vessels, thereby constraining the development and application of high-performance ships. Studies on slamming mechanisms, load distribution, prediction, and mitigation methods are particularly essential. This paper provides a comprehensive review of the theoretical, numerical, and experimental research progress on water-entry slamming for high-performance ships. First, the theoretical foundations and numerical simulation methods of slamming are elaborated. Then, existing research findings are summarized from two perspectives: segmented water entry and full-scale wave loads. Finally, unresolved issues and future research directions are identified. The aim is to offer valuable insights for further advancements in high-performance ship slamming studies. Full article

Hydrodynamic slamming loads during water landing are one of the main concerns for the structural design and wave resistance performance of large amphibious aircraft. However, current existing sensors are not used for full-scale hydrodynamic load flight tests on complex models due to their large size, fragility, intrusiveness, limited range, frequency response limitations, accuracy issues, and low sampling frequency. Fibre-optic sensors’ small size, immunity to electromagnetic interference, and reduced susceptibility to environmental disturbances have led to their progressive development in maritime and aeronautic fields. This research proposes a novel hydrodynamic profile encapsulation method using ultra-thin surface-mounted micro-electromechanical system (MEMS) fibre-optic Fabry–Pérot pressure sensors (total thickness of 1 mm). The proposed sensor exhibits an exceptional linear response and low-temperature sensitivity in hydrostatic calibration tests and shows superior response and detection accuracy in water-entry tests of wedge-shaped bodies. This work exhibits significant potential for the in situ monitoring of hydrodynamic loads during water landing, contributing to the research of large amphibious aircraft. Furthermore, this research demonstrates, for the first time, the proposed surface-mounted pressure sensor in conjunction with a high-speed acquisition system for the in situ monitoring of hydrodynamic pressure on the hull of a large amphibious prototype. Following flight tests, the sensors remained intact throughout multiple high-speed hydrodynamic taxiing events and 12 full water landings, successfully acquiring the complete dataset. The flight test results show that this proposed pressure sensor exhibits superior robustness in extreme environments compared to traditional invasive electrical sensors and can be used for full-scale hydrodynamic load flight tests. Full article

During high-speed navigation, boat propellers often become partially exposed due to elevated sailing speeds. This condition results in a unique operational scenario where propellers are only partially submerged. Conducting computational studies on the excitation of propellers under such circumstances is essential for optimizing the dynamic performance of the shafting system. A theoretical calculation method for propeller performance was developed based on the principles of fluid dynamics relevant to water entry, leading to a computational method for determining excitation forces in this specific operational condition. This method was subsequently refined through appropriate adjustments using ANSYS Fluent software to simulate the behavior of partially submerged propellers. The findings highlighted the accuracy of the proposed model in predicting the pulsation of six force components across three distinct directions: along the propeller shaft, vertical, and lateral. Specifically, for a single blade (Blade 1), the pulsation amplitude of the vertical force (Fx) constituted 82.1% of its maximum peak magnitude and equated to 57.5% of the blade’s mean thrust. Analogously, the lateral force (Fz) pulsation amplitude represented 53.3% of its maximum peak magnitude and 40.0% of the mean thrust. These findings indicate the presence of significant unsteady hydrodynamic loads. Furthermore, a visualization approach was presented to analyze blade load phasing, offering insights relevant to the arrangement of blades on partially submerged propellers. Full article

With its unique environment and strategic value, the near space (NS) has become the focus of global scientific and technological, military, and commercial fields. Aiming at the problem of communication interruption when the aircraft re-enters the atmosphere, to ensure the needs of communication, navigation, and telemetry, tracking, and command (TT&C), this paper proposes an overall integration of communication, navigation, and TT&C (ICNT) signals scheme based on the K/Ka frequency band. Firstly, the K/Ka frequency band is selected according to the ITU frequency division, high-speed communication requirements, advantages of space-based over-the-horizon relay, overcoming the blackout problem, and the development trend of high frequencies. Secondly, the influence of the physical characteristics of the NS on ICNT is analyzed through simulation. The results show that when the K/Ka signal is transmitted in the NS, the path loss changes significantly with the elevation angle. The bottom layer loss at an elevation angle of 90° is between 143.5 and 150.5 dB, and the top layer loss is between 157.5 and 164.4 dB; the maximum attenuation of the bottom layer and the top layer at an elevation angle of 0° is close to 180 dB and 187 dB, respectively. In terms of rainfall attenuation, when a 30 GHz signal passes through a 100 km rain area under moderate rain conditions, the horizontal and vertical polarization losses reach 225 dB and 185 dB, respectively, and the rainfall attenuation increases with the increase in frequency. For gas absorption, the loss of water vapor is higher than that of oxygen molecules; when a 30 GHz signal is transmitted for 100 km, the loss of water vapor is 17 dB, while that of oxygen is 2 dB. The loss of clouds and fog is relatively small, less than 1 dB. Increasing the frequency and the antenna elevation angle can reduce the atmospheric scintillation. In addition, factors such as the plasma sheath and multipath also affect the signal propagation. In terms of modulation technology, the constant envelope signal shows an advantage in spectral efficiency; the new integrated signal obtained by integrating communication, navigation, and TT&C signals into a single K/Ka frequency point has excellent characteristics in the simulation of power spectral density (PSD) and autocorrelation function (ACF), verifying the feasibility of the scheme. The proposed ICNT scheme is expected to provide an innovative solution example for the communication, navigation, and TT&C requirements of NS vehicles during the re-entry phase. Full article

The cross-media water entry problem widely exists in fields such as ocean engineering and aerospace. The highly non-stationary characteristics of the cross-media water entry process significantly influence the structural strength and ballistic stability of vehicles. This paper selects air-dropped torpedoes, supercavitating vehicles, and high-speed projectiles as three typical types of cross-media vehicles for study. Based on their unique structural characteristics and typical water entry conditions, this paper focuses on the current status of their respective impact load and load reduction challenges, as well as water entry ballistic stability issues. At the research methodological level, this paper systematically reviews the progress of current research in three directions: theory, experiments, and numerical simulations, and introduces the application of artificial intelligence in solving cross-media problems. Finally, this paper looks forward to future development trends in cross-media water entry research, aiming to provide a reference for structural optimization design, motion stability control, and other related studies of cross-media vehicles. Full article

Liquid–liquid mass transfer is crucial in chemical processes like extraction and desulfurization. Traditional tube-in-tube millireactors often overlook internal flow dynamics, focusing instead on entry modifications. This study explores mass transfer enhancement through structured inserts (twisted tapes, multi-blades) and inlet designs (multi-hole injectors, T-mixers). Using high-speed imaging and water–succinic acid–butanol experiments, flow patterns and mass transfer rates were analyzed. Results show annular and dispersion flows dominate under tested conditions with structured inserts lowering the threshold for dispersion flow. Multi-hole injectors improved mass transfer by over 40% compared to T-mixers in plain tubes, while C-tape inserts achieved the highest volumetric mass transfer coefficient (2.43 s⁻¹) due to increased interfacial area and droplet breakup from energy dissipation. This approach offers scalable solutions to enhance tube-in-tube millireactor performance for industrial applications. Full article

Based on the RNG k-ε turbulence model and VOF multiphase flow model, a numerical model of horizontal water-entry of the vehicle was established, and the numerical method was verified by experimental results. The cavitation characteristics, fluid resistance, and motion of the vehicle under different conditions were studied during the vehicle’s water-entry process. The results show that the cavitation process can be divided into the cavity development stage, saturation stage, and collapse stage. With the increase in initial velocity and mass of the vehicle, more water vapor will be generated during the water-entry process. The initial velocity of the vehicle had a limited effect on the resistance coefficient. The resistance coefficient in the stable stage remained almost unchanged for vehicles with different masses. Nevertheless, the time interval of the stable stage was shortened, and the resistance coefficient was greater in the gradually increasing stage for the vehicle with a smaller mass. For vehicles with higher initial velocity or smaller mass, the instantaneous velocity decreased faster after it entered the water. The vehicle with a streamlined design was able to reduce the generation of water vapor and decrease fluid resistance and its coefficient, and the vehicle can run farther during the water-entry process. Full article

This paper presents a novel numerical investigation into the air cushion effect and impact loads during the water entry of notched discs, utilizing the Structured Arbitrary Lagrangian–Eulerian (S-ALE) algorithm in LS-DYNA. Unlike prior studies that focused on smooth or unnotched geometries, the present study explores how varying notch parameters influence the fluid–solid coupling process during high-speed water entry. The reliability and accuracy of the computational method are validated through grid independence verification and comparisons with experimental data and empirical formulas. Systematic analysis of the effects of notch size, water entry velocity, and entry angle on the evolution of the free surface, impact loads, and structural responses uncovers several novel findings. Notably, increasing the notch diameter significantly enhances the formation and stability of the air cushion, leading to a considerable reduction in peak impact loads—a phenomenon not previously quantified. Additionally, higher water entry Froude numbers are shown to accelerate air cushion compression and formation, markedly affecting free surface morphology and force distribution. The results also reveal that varying the water entry angle alters the air cushion’s morphological characteristics, where larger angles induce a more pronounced but less stable air cushion, influencing the internal structural response differently across regions. Full article

Firmly, the bearing capacity test of 1:1 equal ratio pillar under different constraint forms and different filling medium conditions was carried out. The results show that the binding pillar-forming effect is relatively good. The constraint ability of unconstrained, metal mesh, polyester mesh, hooked iron flat-hoop bushing, bellows, and spiral iron pipe is enhanced, in turn, and the carrying capacity is improved successfully. The homogeneity of high-water materials is better than concrete, and they have better compressibility, but their carrying capacity is relatively weak. The carrying capacity of concrete pillars is generously higher than that of high-water materials, but the compressibility is poor. Second, the migration characteristics of the surrounding rock structure of the gob-side entry retaining and the rule of side support are analyzed, the requirements of the side support are pointed out, and the side-support technology of the binding pillar is proposed. Taking Hijiata Mine’s 50108 working face gob-side entry retaining as an example, the bellows pump-filled concrete pillar is used as the side support body, supplemented by handling steel mesh and air-duct cloth, and toughness material is sprayed between the pillars to seal the goaf, meeting the requirements of side support and road stability. The pillar has the characteristics of high early strength, strong final consolidation carrying capacity, good crimping effect, high mechanism degree, fast construction speed, less concrete consumption, low comprehensive cost, etc., and it has a good application prospect in the gob-side entry retaining or rapid advanced working face. Full article

A three-dimensional model is established to investigate the effect of argon injection mode, argon flow rate and casting speed on the gas–liquid two-phase flow behavior inside a slab continuous casting mold. The Eulerian–Eulerian model is employed to simulate the gas–liquid flow, and the population balance model is applied to describe the bubble breakage and coalescence process in the mold. The numerical simulation results of the bubble size distribution are verified using the water model experiment. The results show that the flow field and bubble distribution are similar between the argon injection at the upper submerged entry nozzle (SEN) and tundish upper nozzle (TUN), while the number density is larger for the argon injection of TUN. The coalescence rate of bubbles and the bubble size inside the mold increase with increasing argon flow rate. When the argon flow rate exceeds 4 L/min, the flow pattern of liquid steel changes from double-roll flow to complex flow, with aggravation of the level fluctuation of the top surface near the SEN. When the casting speed increases, the bubble breakup rate increases and results in a decrease in the size of bubbles inside the mold. At a high casting speed, the flow pattern tends to form double-roll flow, and the liquid level at the narrow face of the top surface increases. Full article

In recent years, trimarans have been used in high-speed transport and in warships, but studies of them have made little progress. We designed a trimaran model and used it to perform a water-entry experiment to find a way to reduce the slamming pressure. The process of the model entering the water was divided into several steps, and different theoretical models were designed for each step, together with their force analysis. Relying on our experimental platform, we designed three flexible coating thicknesses and six drop heights as the different working conditions. With an analysis of the results under these experimental conditions, the experiment clearly indicates that the flexible cladding on the model can decrease the impact force when the model slams into water. Furthermore, the theoretical models and their corresponding force analyses are validated by the experimental results. Full article

In this study, the tail-slapping behavior of an oblique water-entry projectile is investigated through high-speed photography technology. The experimental images and data are captured, extracted and processed using a digital image processing method. The experimental repeatability is verified. By examining the formation, development and collapse process of the projectile’s cavity, this study investigates the impact of the tail-slapping motion on the cavity’s evolution. Furthermore, it examines the distinctive characteristics of both the tail-slapping cavity and the original cavity at varying initial water-entry speeds. By analyzing the formation, development and collapse process of the cavity of the projectile, the influence of the tail-slapping motion on the cavity evolution is explored. Furthermore, it examines the evolution characteristics of both the tail-slapping cavity and the original cavity under different initial water-entry speeds. The results indicate that a tail-slapping cavity is formed during the reciprocating motion of the projectile. The tail-slapping cavity fits closely with the original cavity and is finally pulled off from the surface of the original cavity to collapse. In addition, as the initial water-entry speed increases, both the maximum cross-section size of the tail-slapping cavity and the length of the original cavity gradually increase. With the increase in the number of tail-slapping motions, the speed attenuation amplitude of the projectile increases during each tail-slapping motion, the time interval between two tail-slapping motions is gradually shortened, the energy loss of the projectile correspondingly enlarges, and the speed storage capacity of the projectile decreases. Full article

Aiming at the problem of high-speed entry of vehicles with a diameter of 200 mm, a numerical model of high-speed entry of vehicles is established based on the arbitrary Lagrange–Euler (ALE) algorithm, and the numerical simulation of high-speed entry of flat-nosed and round-nosed vehicles is carried out. On this basis, the experimental research on the entry of vehicle with buffer caps is carried out. The following conclusions are obtained through simulation. The peak value of the axial load of the vehicle raises with the increase of the inlet velocity and angle, while the stable value only raises with the increase of the inlet velocity. The impact load on the round-nosed vehicle is obviously smaller than that on the flat-nosed vehicle when the water entry angle is greater than 80°. The peak value of axial load can be reduced by 22% when entering water vertically at 100 m/s. The following conclusions are obtained through experiments. The buffer head cap has a significant load reduction effect. It shows compaction, cracks and breakage under the impact of water. These processes can absorb part of the impact energy, reduce the peak value of axial load and increase the pulse width. The load reduction rate grows from 4.7% to 18.5% when the length of the buffer head cap is increased from 200 mm to 300 mm while the water inlet speed is the same. The damage level of the head cap increases sharply, and the load reduction rate raises when the water entry speed is increased while the length of the buffer head cap is the same. Full article

Addressing the problem of the influence of surface properties on the cavity in the process of a moving body entering water, especially the problems of water entry speed and the cavitation evolution of the round-head, air-delivered projectile that has many practical applications, a self-designed launch platform and high-speed camera were used, and the MK46 was used as a prototype to conduct scaled model experiments with different head form types and different surface properties. This paper describes the general process of the moving body entering the water and the generation of the cavity. The relationship between the re-injection flow, the local cavity number and the cavity stability is discussed. At the same time, the effects of head shape, launch velocity and surface wettability on the cavity evolution and motion characteristics were analyzed, including 0°, 57°, 70°, 90° and 180° hemispherical angle-head projectiles with speeds of 2.2 m/s and 3.95 m/s, so as to observe the cavity development and ballistics. The results show that hydrophobic surfaces are more prone to cavities when entering water vertically at low speeds. The influencing factors of water entry ballistics are often the combined effects of head shape, water entry speed and water entry angle. The speed of the hydrophilic surface models with head hemisphere angles of 57 degrees and 70 degrees entering the water is the fastest. This provides a reference for us to design the shape of the projectile. The internal relationship between the cavity shape and the ballistic characteristics is based on the premise that the cavity will complicate the force on the model. The cavity affects the ballistic characteristics of the model by affecting the forces on the model. Full article

Aiming at a design for buffering and load reduction configuration for a large-scale (diameter greater than 500 mm) vehicle entering water at high speed (greater than 100 m/s), a numerical model for a vehicle entering water at high speed was employed based on an arbitrary Lagrange-Euler (ALE) algorithm. Combined with modal analysis and shock response spectrum, the influence of the head cap on the dynamic characteristics of the structure was analyzed. The results showed that the peak value and pulse width of the impact load on the vehicle increased with the increase in the speed of water entry. The existence of the head cap increased the complexity of the forces on the vehicle during the process of water entry. The initial formation of the cavity was greatly affected by the head cap. The head cap and the vehicle separated in the later stage of the water entry. During the process of water entry, the shell of the vehicle was mainly compressed and bent and the head cap reduced the deformation. The relevant conclusions of this paper can provide some input for the design of a new buffering structure and vehicle shell. Full article
