High concrete gravity dams, particularly Roller-Compacted Concrete (RCC) types, face long-term safety challenges due to weak interlayer formation and crack propagation. This study presented a comprehensive evaluation of safety monitoring indexes for the Guxian high RCC dam (currently under construction) using both numerical and mathematical models. A finite element method (FEM) is employed with a strength reduction approach to assess dam stability considering weak layers. In parallel, a fracture mechanical model is used to investigate the safety of the Guxian dam based on failure assessment diagrams (FADs) for calculating the safety factor and the residual strength curve for calculating critical crack depth for two different crack locations, single-edge and center-through crack, to investigate the high possible risk associated with crack location on the dam safety. Additionally, the Guxian dam’s resistance to hydraulic fracture is assessed under two fracture mechanic failure modes, Mode I (open type) and Mode II (in-plane shear), by computing the ultimate overload coefficient using a proposed novel derived formula. The results show that weak layers reduce the dam’s safety index by approximately 20%, especially in lower sections with extensive interfaces. Single-edge cracks pose greater risk, decreasing the safety factor by 10% and reducing critical crack depth by 40% compared to center cracks. Mode II demonstrates higher resistance to hydraulic fracture due to greater shear strength and fracture energy, whereas Mode I represents the most critical failure scenario. The findings highlight the urgent need to incorporate weak layer behavior and hydraulic fracture mechanisms into dam safety monitoring, and to design regulations for high RCC gravity dams. Full article

For the safety assessment of concrete dam–foundation systems, this study used an explicit time-stepping small-displacement algorithm, which simulates the hydromechanical interaction and considers the discrete representation of the foundation discontinuities. The proposed innovative methodology allows for the definition of more reliable safety factors and the identification of more realistic failure modes by integrating (i) softening-based constitutive laws that are closer to the real behavior identified experimentally in concrete–concrete and concrete–rock interfaces; (ii) a water height increase that can be considered in both hydraulic and mechanical models; and (iii) fracture propagation along the dam–foundation interface. Parametric studies were conducted to assess the impact of the mechanical properties on the global safety factors of three gravity dams with different heights. The results obtained using a coupled/fracture propagation model were compared with those from the strength reduction method and the overtopping scenario not considering the hydraulic pressure increase. The results show that the safety assessment should be conducted using the proposed methodology. It is shown that the concrete–rock interface should preferably have a high value of fracture energy or, ideally, higher tensile and cohesion strengths and high associated fracture energy. The results also indicate that with a brittle concrete–rock model, the predicted safety factors are always conservative when compared with those that consider the fracture energy. Full article

Seismic isolation and damping technologies, though extensively used in buildings, are less common in large hydraulic structures, underscoring the importance of researching seismic mitigation methods for these constructions. This research first establishes that saturated sandy soil can act as a damping material through experimental and theoretical analysis. Subsequently, a novel hollow concrete gravity dam containing saturated sandy soil is proposed, utilizing the EOS (equation of state) subroutine for viscous fluids to model the liquefied sand. The findings indicate that the new-type dam exhibits a reduction in displacement of approximately 20% along the flow direction under an 8-degree seismic event compared to conventional gravity dams. This decrease correlates inversely with the characteristic wave speed of the saturated sandy soil, while the energy dissipation capacity of the saturated sandy soil is directly proportional to the soil layer’s thickness. Finally, a small-scale shaking table test revealed that saturated sandy soil effectively reduces displacement and acceleration at the dam crest. These findings were corroborated by numerical simulations, which further substantiated the reliability of both the experimental and simulated data. Utilizing saturated sandy soil for energy dissipation and seismic damping in dams offers cost benefits, high durability, and significant effectiveness, representing a promising direction for the advancement of seismic mitigation in concrete gravity dams. Full article

Asphalt concrete impervious facings, widely adopted as the impervious structures for rockfill dams and upper reservoirs in pumped storage power stations, typically have a multilayer structure with a thin sealing layer, a thick impervious layer, and a thick leveling bonding layer. The properties of the interfaces between these layers are crucial for the overall performance of the facings. This paper develops a model to investigate the complex interface damage behavior of the facing under static water pressure and gravity. The model considers two damage origins: one is the interface adhesion–decohesion damage, which is described by the cohesive zone model (CZM) combined with the Weibull-type random interface strength distribution, and the other is the bulk damage of each layer, described by Mazars’ model. Primarily, a comparison between numerical simulation and indoor direct shear tests validates the reliability of the CZM for the asphalt concrete layer interface. Then, the damage distribution of the two interfaces is simulated, and the characteristics of the interface stress are analyzed in detail. The interface shear stresses of the ogee sections, which have different curvatures, all show an interesting oscillation between the thin sealing layer and the impervious layer, and the interface damage at this interface exhibits high heterogeneity. Furthermore, tension stress exists in the local zones of the ogee section, and the damage in this section is significantly greater than in other parts of the facings. Full article

The widespread adoption of high concrete gravity dams in China and globally underscores the necessity for enhancing design processes to address potential risks, notably hydraulic fracture. This study delves into this urgency by scrutinizing common design regulations and investigating the impact of hydraulic fracture on high concrete gravity dams. A comparative analysis of design specifications from China, the USA, and Switzerland, employing the gravity method, elucidates distinctions, focusing on the Guxian dam. In addition, evaluation of standards with higher resistance to hydraulic fracture was conducted using the Finite Element Method (FEM) with XFEM (eXtended Finite Element Method), employing initial cracks with different depths at the dam heel ranging from 0.2 to 2 m. The vulnerability of the Guxian dam’s cross-section to safety risks prompts further inquiry into the dam’s resistance to hydraulic fracture. Therefore, high-pressure water splitting risks to the ultimate bearing capacity were examined through FEM simulation and theoretical calculations. FEM simulations assessed the dam’s ultimate bearing capacity with and without automatic crack propagation combining the XFEM and overloading methods, particularly considering weak layers in the RCC (Roller-Compacted Concrete) dams. Theoretical calculations utilized a fracture mechanical evaluation model. This model derived mechanism formulas to assess the dam’s resistance to hydraulic fracture. Additionally, the investigation explored the effect of the uplift pressure on the ultimate overload coefficient. Findings indicated that the Guxian dam’s current cross-sectional area was insufficiently safe against hydraulic fracture, necessitating an increase to its cross-sectional area to 18,888.1 m². Notably, the USA’s and Switzerland’s criteria exhibited greater resistance to hydraulic fracture than the Chinese criteria, especially without considering uplift pressure. Also, the Chinese regulations tended to calculate a lower dam cross-sectional area compared with the other regulations. Numerical calculations revealed a substantial decrease in overall dam safety (up to 48%) when considering automatic crack propagation and the dam’s weak layers. The fracture mechanical evaluation model showed that the Guxian dam had the lowest resistance, with an overloading coefficient of 1.05 considering the uplift pressure. In the case of not considering the uplift pressure, the dam resistance to hydraulic fracture increased and the overloading coefficient rose to 1.27. The results highlighted the risk of hydraulic fracture in concrete dams. Hence, it is recommended that design specifications of high concrete gravity dams incorporate safety analyses of hydraulic fracture in the design process. Reducing uplift pressure plays a crucial role in enhancing the dam’s resistance to hydraulic fractures, emphasizing the need for this consideration in safety evaluations. The differences between the three design specifications were particularly pronounced for dams higher than 200 m. In contrast, dams of 50 m yielded similar results across these regulations. Full article

This paper examines the influence of monolith length on the temperature field of concrete gravity dams built using the block method. The developed 3D model is capable of conducting a thermal analysis of a 95.0 m high concrete gravity dam built using the block method, where each newly cast block represents a new analysis phase. The calculation accounts for the period of construction, the filling of the reservoir, and the service for a total duration of about 5 years. The thermal properties of the material, the influence of cement hydration heat, the temperature of the surrounding rock mass, the temperature of the fresh concrete mixture, and the corresponding boundary conditions defining a heat transfer were taken into account. The height and width of the blocks, as well as the sequence of concreting, were considered invariable, while the length of the blocks (dimension in the direction of the dam’s axis equal to the monolith length) varied, with values of 10.0, 12.5, 15.0, and 20.0 m. The obtained calculation results for the control nodes showed that the maximum reduction in the monolith length (from 20.0 m to 10.0 m) caused a decrease in the maximum temperature values of the concrete (from 1.6 to 3.4 °C, depending on the control node). Also, the results showed that, by reducing the length of the monolith, there was a delay in the moment at which the maximum temperature values of the concrete appeared in the selected control node. The delay in reaching the maximum, in relation to the 10.0 m long monolith, was from 7 days (for points on the crest dam) to 49 days (for points in the central zone of the monolith) for the other considered monolith lengths. The above indicates the importance of concrete temperature control for longer monoliths, especially during construction in extreme air temperatures. The main contribution of the conducted analysis is the development of insight into temperature field changes depending on monolith length, which can help engineers during the design and construction of new, as well as the maintenance of existing, dams. Full article

Investigating the dynamic response patterns and failure modes of concrete gravity dams subjected to strong earthquakes is a pivotal area of research for addressing seismic safety concerns associated with gravity dam structures. Dynamic shaking table testing has proven to be a robust methodology for exploring the dynamic characteristics and failure modes of gravity dams. This paper details the dynamic test conducted on a gravity dam model on a shaking table. The emulation concrete material, featuring high density, low dynamic elastic modulus, and appropriate strength, was meticulously designed and fabricated. Integrating the shaking table conditions with the model material, a comprehensive gravity dam shaking table model test was devised to capture the dynamic response of the model under various dynamic loads. Multiple operational conditions were carefully selected for in-depth analysis. Leveraging the dynamic strain responses, the progression of damage in the gravity dam model under these diverse conditions was thoroughly examined. Subsequently, the recorded acceleration responses were utilized for identifying dynamic characteristic parameters, including the acceleration amplification factor in the time domain, acceleration response spectrum characteristics in the frequency domain, and modal parameters reflecting the inherent characteristics of the structure. To gain a comprehensive understanding, a comparative analysis was performed by aligning the observed damage development with the identified dynamic characteristic parameters, and the sensitivity of these identified parameters to different levels of damage was discussed. The findings of this study not only offer valuable insights for conducting and scrutinizing shaking table experiments on gravity dams but also serve as crucial supporting material for identifying structural dynamic characteristic parameters and validating damage diagnosis methods for gravity dam structures. Full article

Clarifying the origins of fractures and adopting acceptable repair plans are crucial for the design, maintenance, and safe operation of concrete gravity dams. In this research, numerical simulation is largely utilized to investigate the reasons for fractures in the anti-arc portion of the concrete gravity dam and the top of a substation tunnel in Guangdong Province, China. The calculation parameters are chosen based on the design information and engineering expertise to model the temperature field and stress field distribution of the dam during both normal operation and severe weather. The study demonstrates that under the effect of severe structural restraints and high temperatures, the tensile stress at the top of the substation tunnel would be 2.64 MPa in the summer, which is more than the tensile strength by 1.5 MPa and causes deep cracks. The tensile stress reaches 3.0 MPa in the summer under the effect of severe weather near the top of the substation tunnel. When a cold wave strikes in the winter, the concrete’s tensile stress on the overflow dam surface rises from 1.6 MPa to 4.0 MPa, exceeding the tensile strength by 1.9 MPa, resulting in the formation of a connection fracture in the reverse arc section. Both the actual observed crack location and the monitoring findings of the crack opening, as determined by the crack gauge, agree with the modeling results. The technique to lessen the structural restrictions of a comparable powerhouse hydropower station is pointed out based on engineering expertise, and various and practical repair strategies are proposed to guarantee the structure’s safe operation. Full article

Ethiopia began constructing the Grand Ethiopian Renaissance Dam (GERD) in 2011 on the Blue Nile near the borders of Sudan for electricity production. The dam was constructed as a roller-compacted concrete (RCC) gravity-type dam, comprising two power stations, three spillways, and the Saddle Dam. The main dam is expected to be 145 m high and 1780 m long. After filling of the dam, the estimated volume of Nile water to be bounded is about 74 billion m³. The first filling of the dam reservoir started in July 2020. It is crucial to monitor the newly impounded lake and its size for the water security balance for the Nile countries. We used remote sensing techniques and a geographic information system to analyze different satellite images, including multi-looking Sentinel-2, Landsat-9, and Sentinel-1 (SAR), to monitor the changes in the volume of water from 21 July 2020 to 28 August 2022. The volume of Nile water during and after the first, second, and third filling was estimated for the Grand Ethiopian Renaissance Dam (GERD) Reservoir Lake and compared for future hazards and environmental impacts. The proposed monitoring and early warning system of the Nile Basin lakes is essential to act as a confidence-building measure and provide an opportunity for cooperation between the Nile Basin countries. Full article

A novel damage model for concrete has been developed, which can reflect the complex hysteresis phenomena of concrete under cyclic loading, as well as other nonlinear behaviors such as stress softening, stiffness degradation, and irreversible deformation. The model cleverly transforms the complex multiaxial stress state into a uniaxial state by equivalent strain, with few computational parameters and simple mathematical expression. The uniaxial tensile and compressive stress–strain curves matching the actual characteristics are used to accommodate the high asymmetry of concrete in tension and compression, respectively. Meanwhile, an unloading path and a reloading path that can reflect the hysteresis effect under cyclic loading of concrete are established, in which the adopted expressions for the loading and unloading characteristic points do not depend on the shape of the curve. The proposed model has a concise form that can be easily implemented and also shows strong generality and flexibility. Finally, the reliability and correctness of the model are verified by comparing the numerical results with the three-point bending beam test, cyclic loading test, and a seismic damage simulation of the Koyna gravity dam. Full article

The seismic design and dynamic analysis of high concrete gravity dams is a challenge due to the dams’ high levels of designed seismic intensity, dam height, and water pressure. In this study, the rigid, massless, and viscoelastic artificial boundary foundation models were established to consider the effect of dam–foundation dynamic interaction on the dynamic responses of the dam. Three reservoir water simulation methods, namely, the Westergaard added mass method, and incompressible and compressible potential fluid methods, were used to account for the effect of hydrodynamic pressure on the dynamic characteristics and seismic responses of the dam. The ranges of the truncation boundary of the foundation and reservoir in numerical analysis were further investigated. The research results showed that the viscoelastic artificial boundary foundation was more efficient than the massless foundation in the simulation of the radiation damping effect of the far-field foundation. It was found that a foundation size of 3 times the dam height was the most reasonable range of the truncation boundary of the foundation. The dynamic interaction of the reservoir foundation had a significant influence on the dam stress. Full article
