Search Results (103)

This study investigates the effectiveness of combining helical piles (HPs) with geogrid reinforcement compared to conventional piles in improving pullout performance in dense sand, addressing a key challenge in reinforced foundation design. A comprehensive experimental program was conducted to evaluate the pullout behavior of HPs embedded in Shahriyar sand reinforced with geogrid layers. The research focused on quantifying the effects of critical parameters—pile configuration, helix pitch, and geogrid placement depth—on ultimate pullout capacity and displacement response to better understand hybrid reinforcement mechanisms. Pullout tests were performed using a Zwick/Roell Z150 universal testing machine with automated data acquisition via TestXpert11 V3.2 software. The experimental program assessed the following influences: (1) pile configurations—plain, single-helix, and double-helix; (2) helix pitch ratios of 1.00, 1.54, and 1.92 (pitch-to-shaft diameter); and (3) geogrid placement depths of 7.69, 11.54, and 15.38 (depth-to-shaft diameter) on pullout behavior. Results demonstrate that geogrid reinforcement substantially enhances pullout resistance, with single-helix HPs achieving up to a 518% increase over plain piles. Pullout resistance is highly sensitive to geogrid spacing, with optimal performance at a non-dimensional distance of 0.47 from the pile–soil interface. Additionally, double-blade HPs with geogrid placed at 0.35 exhibit a 62% reduction in displacement ratio, underscoring the role of geogrid in improving pile stiffness and load-bearing capacity. These findings provide new insights into the synergistic effects of helical pile geometry and geogrid placement for designing efficient reinforced granular foundations. Full article

This study presents the results of axial tension (uplift) and compression tests evaluating the capacity of helical piles installed in Shahriyar dense sand using the UTM apparatus. Thirteen pile load experiments involving single-, double-, or triple-helix piles with shaft diameters of 13 mm were performed, including six compression tests and seven tension tests with different pitches (D_h =13, 20, and 25 mm). The tested helical piles with a helix diameter of 51 mm were considered, and the interhelix spacing approximately ranged between two and four times the helix diameter. Through laboratory testing techniques, the Shahriyar dense sand properties were identified. Alongside theoretical analyses of helical piles, the tensile and compressive pile load tests outcomes in dense sand with a relative density of 70% are presented. It was found that the maximum capacities of the compressive and tensile helical piles were up to six and eleven times that of the shaft capacity, respectively. With an increasing number of helices, the settlement reduced, and the bearing capacity increased. Consequently, helical piles can be manufactured in smaller sizes compared to steel piles. Overall, the compressive capacities of helical piles were higher than the tensile capacities under similar conditions. Single-helices piles with a pitch of 20 mm and double-helices piles with a pitch of 13 mm were more effective than others. Therefore, placing helices at the shallower depths and using smaller pitches result in better performance. In this study, when compared to values from the L1–L2 method, the theoretical method slightly underestimates the ultimate compression capacity and both overestimates and underestimates the uplift capacity for single- and double-helical piles, respectively, due to the individual bearing mode and cylindrical shear mode. Full article

Ferroelectric liquid crystals (FLCs) are key materials for high-speed electro-optical applications, yet achieving optimal properties over a broad temperature range down below room temperature remains a challenge. This study presents a novel series of systematically designed FLC mixtures, incorporating components with three degrees of chirality—achiral systems, with one center of chirality and with two centers of chirality—to optimize the mesomorphic stability, electro-optical response, and physicochemical properties. The strategic doping by chiral components up to a 0.2 weight fraction extends the temperature range of the ferroelectric phase while lowering the melting temperature. Notably, mixtures containing two chiral centers exhibit shorter helical pitches, while increasing chirality enhances the tilt angle of the director and spontaneous polarization. However, in a mixture containing all three types of chirality (CchM), spontaneous polarization decreases due to opposing vector contributions. Switching time analysis reveals that a system with achiral components and those with two centers of chirality (A-BchM) exhibits the fastest response, while CchM demonstrates only intermediary behavior, caused by its high rotational viscosity. Among all formulations, those containing compounds with two centers of chirality display the most favorable balance of functional properties for deformed helix ferroelectric liquid crystal (DHFLC) applications. One such mixture achieves the lowest melting temperature reported for DHFLC-compatible FLCs, enabling operation at sub-zero temperatures. These findings pave the way for next-generation electro-optical devices with enhanced performance and appropriate environmental stability. Full article

Wind energy’s crucial role in global sustainability necessitates efficient wind turbine maintenance, traditionally hindered by labor-intensive, risky manual inspections. UAV-based inspections offer improvements yet often lack adaptability to dynamic conditions like blade pitch and wind. To overcome these limitations and enhance inspection efficacy, we introduce the Dynamic Trajectory Adaptation Method (DyTAM), a novel approach for automated wind turbine inspections using UAVs. Within the proposed DyTAM, real-time image segmentation identifies key turbine components—blades, tower, and nacelle—from the initial viewpoint. Subsequently, the system dynamically computes blade pitch angles, classifying them into acute, vertical, and horizontal tilts. Based on this classification, DyTAM employs specialized, parameterized trajectory models—spiral, helical, and offset-line paths—tailored for each component and blade orientation. DyTAM allows for cutting total inspection time by 78% over manual approaches, decreasing path length by 17%, and boosting blade coverage by 6%. Field trials at a commercial site under challenging wind conditions show that deviations from planned trajectories are lowered by 68%. By integrating advanced path models (spiral, helical, and offset-line) with robust optical sensing, the DyTAM-based system streamlines the inspection process and ensures high-quality data capture. The dynamic adaptation is achieved through a closed-loop control system where real-time visual data from the UAV’s camera is continuously processed to update the flight trajectory on the fly, ensuring optimal inspection angles and distances are maintained regardless of blade position or external disturbances. The proposed method is scalable and can be extended to multi-UAV scenarios, laying a foundation for future efforts in real-time, large-scale wind infrastructure monitoring. Full article

This paper presents a comprehensive three-dimensional (3D) finite-element (FE) study of skin and proximity losses in a five-segment, helically twisted underground power cable. Unlike conventional two-dimensional (2D) analyses—which assume parallel conductors and consequently overestimate eddy current losses—our 3D approach accurately captures the effects of varying lay lengths ($\lambda$). Simulations are performed from 0 Hz (DC) to 50 Hz, showing that while the per-unit-length DC resistance remains unaffected by twisting, the AC resistance can increase significantly depending on the pitch. At 50 Hz, the ratio of AC to DC resistance ($R_{\mathrm{AC}}$/$R_{\mathrm{DC}}$) ranges from about 1.32 for very tight twists ($\lambda =0.1\mathrm{m}$) to nearly 1.72 for gentle pitches ($\lambda =5.0\mathrm{m}$). Further analysis reveals that short lay lengths enhance magnetic field coupling, improving current distribution and partially mitigating losses. To quantify these findings, an exponential-saturation model is proposed to describe $R_{\mathrm{AC}}$/$R_{\mathrm{DC}}$ as a function of lay length, achieving excellent agreement ($R^2\approx 0.996$) with the 3D FE data. These results underscore the importance of considering full 3D geometry in cable design, offering a practical tool for optimizing both mechanical reliability and electromagnetic performance in high-voltage underground applications. Full article

Within the realm of industrial energy conservation, the optimization of heat exchanger performance is paramount for the augmentation of energy utilization efficiency. This investigation employs computational fluid dynamics (CFD) simulations to elucidate the effects of an innovative DNA-Inspired Slotted Insert (DSI) on the convective heat transfer and pressure drop characteristics within heat exchange tubes. The study provides a thorough analysis of fully turbulent flow (Re = 6600–17,200), examining the effects of various DSI pitches, key lengths, and geometries. The findings reveal that the DSI instigates a three-dimensional spiral flow pattern, which is accompanied by an escalation in the Nusselt number (Nu) and friction factor (f) with increasing Reynolds numbers. An inverse relationship between Nu and both pitch and key length is observed; conversely, f exhibits a direct correlation with these parameters. The study identifies an optimal configuration characterized by a pitch of 10 mm and a key length of 1.5 mm, with square keys demonstrating superior heat transfer performance relative to other geometrical configurations. This research contributes significant design and application insights for double-helical inserts, which are pivotal for the enhancement of heat exchanger efficiency. Full article

Helical carbon nanotubes (HCNTs) with different geometrical properties were constructed and incorporated into nanocomposites for the investigation of the anti-crack mechanism. The interfacial mechanical properties of the nanocomposites reinforced with straight carbon nanotubes and various types of HCNTs were investigated through the pullout of HCNTs in the crack propagation using molecular dynamics (MD). The results show that the pullout force of HCNTs is much higher than that of CNTs because the physical interlock between HCNTs and matrices is much stronger than the van der Waals (vdW) interactions between CNTs and matrices. Remarkably, HCNTs with a large pitch length can not only effectively prevent the initiation of breakages but also hinder the growth of cracks, while HCNTs with a small diameter and tube radius cannot even effectively prevent the initiation of cracks, which is similar to straight CNTs. Moreover, the shear resistance of HCNTs increases with the increase in the helix angle, which remains at a high level when the helix angle reaches the critical value. However, HCNTs with a small helix angle and large diameter can carry out more polymer chains, while snake-like HCNTs and HCNTs with a small diameter and helix angle can hardly carry out any polymer chain during the pullout process and show similar interfacial properties to the straight CNTs. Full article

Embedding stacked HTS tapes into twisted slots is one design approach for constructing fusion conductors. This paper adopts a Cable-in-Conduit Conductor (CICC) structure, utilizing commercially REBCO coated conductors. The cable framework is made of copper and features six helically twisted slots filled with 2G HTS tapes. Two 1 m long samples with twist pitches of 200 mm and 300 mm, respectively, were fabricated. In one slot, copper and superconducting tapes were alternated, while the remaining grooves were filled with copper tapes. The 90 µm thick copper-plated bare tapes provided by Shanghai Superconductor were used for testing. By measuring the critical current of tapes positioned at different locations within the grooves at 77 K, the characteristics of each tape in the stacked arrangement were individually characterized. The study obtained the current degradation patterns of tapes located at different positions within the grooves under various bending radii. This paper will present and discuss the preliminary results of the bending measurements conducted at 77 K under a self-field. Full article

Heat transfer enhancement is always pursued in the industry to achieve high-performance and low-energy-consumption heat exchange devices and systems. For decades, various types of heat transfer-enhancing tubes with differing geometries and wall configurations have been developed. In this paper, the heat transfer and pressure drop characteristics of air inside an innovative heat transfer tube with regular wall dimples, namely a vortex-enhanced tube, which has a great application prospect in the gas–gas heat exchanger, are numerically studied with an experimentally validated model. The effects of the depth, axial pitch, and radial rotation angle of the dimple in the tube wall on the convective heat transfer coefficient and friction drag coefficient are comprehensively analyzed. Based on the Performance Evaluation Criteria (PEC) of the tubes, the optimal parameters of the vortex-enhanced tube are obtained. When Re ranges from 10,000 to 40,000, the comprehensive evaluation factor of the vortex-enhanced tube is 1.29 times higher than the smooth tube. Dimple pacing, dimple depth, and dimple helical angle of the optimal tube type are 8 mm, 6 mm, and 83°, respectively. Full article

In response to the issue of the size effect of helical anchors in deep-sea areas on their uplift bearing capacity, this study was proposed based on the ratio of the anchor shaft diameter to the anchor helix diameter and the ratio of the pitch to the anchor helix diameter. Eight sets of small-scale anchors were designed for laboratory model tests to study the impact of different anchor shaft diameters to anchor helix diameter ratios and the ratio of the pitch to the anchor helix diameter on uplift bearing capacity. The results indicate that smaller ratios of the anchor shaft diameter to the anchor helix diameter and the pitch to the anchor helix diameter can improve the uplift bearing capacity of helical anchors. In addition, this study found that the uplift bearing capacity of helical anchors decreased with the increase in the ratio of the anchor diameter to the anchor helix diameter and the ratio of the pitch to the anchor helix diameter. Based on this, a prediction equation for the uplift bearing capacity of helical anchors was proposed. Full article

Computer modelling of technical constructions is increasingly carried out using software that includes more detailed knowledge, which requires an increase in the level as well as an expansion of the scope of the geometric knowledge. A significant part of motion transmission mechanisms are worm drive pairs, for which the separation of the parts dealing with the theoretical and practical problems found in the literature can be experienced in numerous instances. Due to the different technical features, in many cases the helical surfaces are not designed and manufactured in a geometrically correct way, or the best solution is not the compulsory chosen. The geometric model describing the production process of the worm surfaces provides the basis for examining the deviation between the surface mathematically determined by the designer and the surface produced. An integrated mathematical kinematic model was developed for the production geometrical analysis of the elements of cylindrical and conical worm gear drive pairs for machining with a traditional thread grinding machine, which causes a serious pitch fluctuating error among several other problems in the case of machining the conical worm. Modelling of the production process of surfaces and the simultaneous study of the manufacturing errors is basically performed with the toolbox of descriptive geometry, including the use of the projective invariants. Knowing the inheritance of the invariants of projective geometry, the aim was the mathematical generalization of the integrated model and the creation of a projective relationship between the reference surfaces of conical and cylindrical spiral surfaces. As a result, the improved constructive geometric model was created, in which the method of analytically creating the projective geometric relationship between the reference surfaces of conical and cylindrical helicoid surfaces has been described for the first time in this article. This procedure is considered the most important result of the present article. Another significance of the further development presented is that during production of the conical helicoid surface, the thread pitch fluctuation has been eliminated. The results obtained, consisting of an improved geometric model, lead to a new geometry of the technological environment regarding the relative position of the cutting tool and the workpiece as well as the relative motion between them. Full article

Recently, two new polymorphs have been added to the nematic class: the polar-twisted nematic (N_PT) in 2016 and the ferroelectric nematic (N_F) in 2020. Comprised of achiral molecules, both exhibit local polar ordering and adopt modulated structures, right- and left-handed helical organizations—form chirality—albeit on vastly different dimensional scales; modulations have a ~10 nanometer pitch in the N_PT and ~500 nm in the N_F. Here, we focus on the structure and symmetries of the N_PT phase and the ensuing physical properties. Based on an array of order parameters that fully describe the molecular ordering and the nano-modulations thereof, we present a consistent formulation of the dielectric, optical, surface anchoring, and elasticity properties of the N_PT materials. We show that these properties are distinctly different from those associated with an elastically modulated, locally uniaxial, nematic. Full article

This work reports the synthesis method and various properties of four rod-like antiferroelectric (R) laterally substituted enantiomers, with or without fluorine atoms used as substituents in the benzene ring. The influence of fluorine substitution on the mesophase temperature range was determined. The synthesized compounds are three-ring rod-like smectics with a chiral center based on (R)-(−)-2-octanol. Their chemical and optical purity was checked using high-performance liquid chromatography (HPLC). Two newly synthesized enantiomers and three previously reported (R) enantiomers were used to formulate two antiferroelectric mixtures. The mesomorphic behavior was characterized by polarizing optical microscopy, differential scanning calorimetry, and X-ray diffraction (XRD). The helical pitch and tilt angle measurements were done using the selective light reflection phenomenon and the electro-optical method, respectively. All the enantiomers exhibit a wide temperature range of the antiferroelectric phase, with a high tilt angle. Furthermore, the enantiomer with lateral fluorine substitution in the ortho position has a very long helical pitch (more than 2.0 µm), relatively low enthalpy of melting point, and a tilt angle close to 45 degrees. The designed (R) enantiomers can be useful for formulating eutectic mixtures for further use in various devices, including photonics and optoelectronics. Full article

To face the challenges in preparing hydrogel fibers with complex structures and functions, this study utilized a microfluidic coaxial co-extrusion technique to successfully form functional hydrogel fibers through rapid ionic crosslinking. Functional hydrogel fibers with complex structures, including linear fibers, core–shell structure fibers, embedded helical channels, hollow tubes, and necklaces, were generated by adjusting the composition of internal and external phases. The characteristic parameters of the hydrogel fibers (inner and outer diameter, helix generation position, pitch, etc.) were achieved by adjusting the flow rate of the internal and external phases. As biocompatible materials, hydrogel fibers were endowed with electrical conductivity, temperature sensitivity, mechanical enhancement, and freeze resistance, allowing for their use as temperature sensors for human respiratory monitoring and other biomimetic application developments. The hydrogel fibers had a conductivity of up to 22.71 S/m, a response time to respiration of 37 ms, a recovery time of 1.956 s, and could improve the strength of respiration; the tensile strength at break up to 8.081 MPa, elongation at break up to 159%, and temperature coefficient of resistance (TCR) up to −13.080% °C⁻¹ were better than the existing related research. Full article

The helical anchor foundation is driven into the soil under the combined action of torque and vertical pressure. The installation process involves a significant deformation of the soil, which is difficult to simulate numerically using the traditional finite element method. As a meshless method, Smoothed Particle Hydrodynamics (SPH) is very suitable for simulating large deformation problems. In this paper, the SPH meshless method and traditional finite element method are used to simulate the installation and pulling process of helical anchor foundations in sandy soil. The variations in installation force, installation torque, ultimate uplift capacity, and torque correlation factor under different advancement ratios were studied. The research results indicate that using a low advancement ratio for installation can significantly reduce the installation force and torque of the helical anchor and positively affect the ultimate uplift capacity. Moreover, the torque correlation factor is also influenced by the advancement ratio. Using the torque correlation factor value obtained from the “pitch matching” installation to predict the ultimate uplift capacity at other advancement ratios may result in an overestimation. Full article
