The escalating heat flux densities in high-performance electronics necessitate superior thermal management. This study enhanced pool-boiling heat transfer, a method offering high heat removal capacity, by leveraging Binder Jetting 3D Printing (BJ3DP) to create complex porous copper structures without the need for chemical treatments. This approach enables a reliable utilization of phenomena like capillarity for improved performance. Three types of porous copper structures, namely Large Lattice, Small Lattice, and Staggered, were fabricated on pure copper substrates and tested via pool boiling of de-ionized and de-gassed water at atmospheric pressure. Compared to a plain polished copper surface, which exhibited a critical heat flux (CHF) of 782 kW/m² at a wall superheat of 18 K, the 3D-printed porous copper surfaces showed significantly improved heat transfer performance. The Staggered surface achieved a conventional CHF of 2342.4 kW/m² (a 199.7% enhancement) at a wall superheat of 24.6 K. Notably, the Large Lattice and Small Lattice structures demonstrated exceptionally stable boiling without reaching the typical catastrophic CHF within the experimental parameters. These geometries continued to increase in heat flux, reaching maximums of 2397.7 kW/m² (206.8% higher at a wall superheat of 55.6 K) and 2577.2 kW/m² (229.7% higher at a wall superheat of 39.5 K), respectively. Subsequently, a gradual decline in heat flux was observed with an increasing wall superheat, demonstrating an outstanding resistance to the boiling crisis. These improvements are attributed to the formation of distinct vapor–liquid pathways within the porous structures, which promotes the efficient rewetting of the heated surface through capillary action. This mechanism supports a highly efficient, self-sustaining boiling configuration, emphasizing the superior rewetting and vapor management capabilities of these 3D-printed porous structures, which extend the boundaries of sustained high heat flux performance. The porous surfaces also demonstrated a higher heat transfer coefficient (HTC), particularly at lower heat fluxes (≤750 kW/m²). High-speed digital camera visualization provided further insight into the boiling phenomenon. Overall, the findings demonstrate that these BJ3DP structured surfaces produce optimized vapor–liquid pathways and capillary-enhanced rewetting, offering significantly superior heat transfer performance compared to smooth surfaces and highlighting their potential for advanced thermal management. Full article

This work presents the implementation of a dual-extended Kalman filter (DEKF) in a double pipe counter-current heat exchanger. The DEKF aims to estimate online the heat transfer coefficient (HTC) to monitor the process. Some investigations estimate parameters in heat exchangers to detect fouling. However, there is limited research on online estimation using DEKF. The tests were performed at two operating conditions: in the first condition, the inlet temperatures were without perturbation; meanwhile, in the second operating condition, the cold-water inlet temperature was perturbed by the environmental heat. The experimental tests were carried out at different cold mass flow rates, which impact the temperatures and vary the heat transfer coefficient of the heat exchanger. The results showed adequate agreement between the estimated values of the heat transfer coefficients and those calculated with algebraic equations. This adequate agreement indicates that the DEKF method is conducive to detecting some problems in heat exchanger applications, such as poor heat transfer performance caused by fouling. Full article

The heat transfer coefficient, or the HTC, is an industry-standard indicator of building energy performance. It is predicated on an assumption that it is of a constant value, and several different methods have been developed to measure and calculate the HTC as a constant. Whilst there are limited variations in the results obtained from these different methods, none of these methods consider a possibility that the HTC could be dynamically variable. Our experimental work shows that the HTC is not a constant. The experimental evidence based on our environmental chambers, which contain detached houses and in which the ambient air temperature can be controlled between −24 °C and +51 °C, with additional relative humidity control and with weather rigs that can introduce solar radiation, rain, and snow, shows that the HTC is dynamically variable. The analysis of data from the fully instrumented and monitored houses in combination with calibrated simulation models and data processing scripts based on genetic algorithm optimization provide experimental evidence of the dynamic variability of the HTC. This research increases the understanding of buildings physics properties and has the potential to change the way the heat transfer coefficient is used in building performance analysis. Full article

This study investigates the thermal performance of heat pipes using nanofluids based on silver (Ag), aluminum oxide (Al₂O₃), and multi-walled carbon nanotubes (MWCNTs) at varying concentrations. Heat pipes, recognized for their efficiency in passive thermal management, face limitations with traditional fluids. Nanofluids, engineered by dispersing nanoparticles in base fluids, were explored as alternatives due to their superior thermal conductivity and convective properties. Nanofluids were prepared using ultrasonication, and their thermal conductivity, viscosity, and stability were evaluated. Experimental tests were conducted under controlled conditions to assess the impact of nanoparticle type, concentration, inclination angle, and fluid filling ratio on performance metrics, including thermal resistance (TR) and heat transfer coefficients (HTCs). The results demonstrated that Ag-based nanofluids outperformed others, achieving a 150% increase in thermal conductivity and an 83% reduction in TR compared to deionized water. HTCs increased by 300% for Ag nanofluids at a 0.5% concentration. Inclination angles and filling ratios also significantly affected performance, with optimal conditions identified at a 70% filling ratio and a 30° inclination angle. The findings highlight the potential of nanofluids in optimizing heat transfer systems and provide a framework for selecting suitable parameters in industrial applications. Full article

The massive integration of renewable electricity places significant regulatory pressure on urban power grids. This has also promoted the development of virtual power plant technology. The air conditioning systems of public buildings, as one of the main cores of virtual power plants, have flexible regulation capability that is difficult to quantify accurately, leading to slow development in practical engineering applications. This study proposes quantifying the flexible regulation capability of public building air conditioning systems based on heat and light transfer coefficient (HTC and LTC). Taking a public building in Shanghai as an example, this study combines 3D modeling and simulation and sliding window and correlation analysis techniques to investigate changes in influencing factors under different time periods, levels of insulation performance, and window-to-wall ratios. Drawing an analogy with energy storage batteries, two quantification indicators, response time (RT) and response energy loss (RL), are proposed and combined with heat and light transmission systems for nonlinear fitting. Finally, a sensitivity analysis of the impact of external environment and building performance is conducted. The results of sliding window and correlation analysis show that surface irradiance has the highest correlation with air conditioning energy consumption (over 0.8). However, through linear and nonlinear fitting, it was found that HTC can better characterize the two key indicators of RT and RL in air conditioning flexible adjustment, with fitting degrees (R²) of 80% and 72%, respectively. The results obtained from this study can provide a quantitative reference for quantification and response control research into the flexible regulation capability of public building air conditioning systems. Full article

In this study, the efficiency of an immersion cooling system for controlling the temperature of 5S7P battery modules at high charge and discharge C-rates was experimentally evaluated. The study was conducted in three main stages including the evaluation of different coolant oils followed by the proposition of an optimal volume flow rate (VFR) and cooling performance evaluation under high charging/discharging C-rates. In the first stage, three coolant oils, including Therminol D-12, Pitherm 150B, and BOT 2100, were compared. The Therminol D-12 achieved superior cooling performance, with the highest heat transfer coefficient (HTC) of 2171.93 W/m²⋅K and the ability to maintain the maximum temperature (T_max) and temperature difference (∆T) of the battery module within the safe range. In the next stage, VFR was varied between 0.4 LPM and 1.0 LPM for the selected best coolant oil of Therminol D-12. The 0.8 LPM VFR was determined to be optimal with the highest HTC of 2445.73 W/m²⋅K and an acceptable pressure drop of 12,650 Pa, ensuring a balance between cooling performance and energy consumption. Finally, the cooling performance was evaluated at high charging/discharging C-rates from 1.5C to 3.0C for the proposed best coolant oil and VFR. The immersion cooling system with Therminol D-12 and a VFR of 0.8 LPM is an effective combination to achieve the desired performance of the battery module under extreme C-rate working conditions. The immersion cooling system with the proposed effective combination maintains the T_max and ∆T at 38.6 °C and 4.3 °C under a charging rate of 3.0C and to 43.0 °C and 5.5 °C under a discharging rate of 3.0C. Full article

Flow boiling heat transfer in micro-channels under hypergravity conditions is a crucial research area for developing efficient cooling systems in aerospace applications. This experimental study investigated the flow boiling heat transfer characteristics of deionized water in a tube with a 2 mm diameter under various gravitational conditions ranging from normal gravity (1 g) to hypergravity (up to 5.1 g) by employing a centrifugal rotating platform. The study systematically analyzes the effects of gravity level, vapor quality, mass flux, and heat flux on the flow boiling heat transfer coefficient (HTC) of deionized water. Experimental results reveal that hypergravity significantly influenced the HTC at a higher vapor quality with up to a 40% deviation and was less pronounced at lower values with an approximately 10% deviation. This deterioration is attributed to the complex interplay of centrifugal force, the Coriolis force, buoyancy, and the specific properties of water, leading to vapor–liquid stratification and hindering effective heat transfer. Meanwhile, critical heat flux was found to increase with increasing gravity acceleration at high vapor qualities. This enhancement is attributed to improved buoyancy effects, liquid replenishment, and altered flow patterns under hypergravity conditions. Furthermore, five existing correlations for predicting flow boiling HTCs were evaluated against the experimental data, and all the correlations showed overestimated results. The consistent over-prediction by these correlations highlights the need for modifications to better capture heat transfer mechanisms under hypergravity conditions. Full article

Sustainable energy consumption in cement production involves practises and strategies aimed at reducing energy use and minimising environmental impact. The efficiency of a cement kiln is dependent on the kiln design, fuel type, and operating temperature. In this study, a dynamic simulation analysis is used to investigate heat losses and distribution within kilns with the aim of improving energy efficiency in cement production. This study used Computational Fluid Dynamics (CFD) with Conjugate Heat Transfer, Turbulent Flow, and the Realisable k−ϵ turbulence model to simulate heat transfer within the refractory and wall systems of the kiln, evaluate the effectiveness of these systems in managing heat losses, and establish the relationship between the heat transfer coefficient (HTC) and the velocities of solid and gas phases. The simulation results indicate that a temperature gradient from the kiln’s interior to its exterior is highly dependent on the effectiveness of refractory lining in absorbing and reducing heat transfer to the outer walls. The results also confirm that different thermal profiles exist for clinker and fuel gases, with clinker temperatures consistently peaking at approximately 1450 °C, an essential condition for optimal cement-phase formation. The results also indicate that phase velocities significantly influence heat absorption and transfer. Lower velocities, such as 0.2 m/s, lead to increased heat absorption, but also elevate heat losses due to prolonged exposure. The relationship between the heat transfer coefficient (HTC) and the velocities of solid and gas phases also indicates that higher velocities improve HTC and enhance overall heat transfer efficiency, reducing energy demand. Full article

In this study, we systematically explored how changing groove surfaces of iron oxide/water nanofluid could affect the pool boiling heat transfer. We aimed to investigate the effect of three types of grooves, namely rectangular, circular, and triangular, on the boiling heat transfer. The goal was to improve heat transfer performance by consciously changing surface structure. Comparative analyses were conducted with deionized water to provide valuable insights. Notably, the heat transfer coefficient (HTC) exhibited a significant increase in the presence of grooves. For deionized water, the HTC rose by 91.7% and 48.7% on circular and rectangular grooved surfaces, respectively. Surprisingly, the triangular-grooved surface showed a decrease of 32.9% in HTC compared to the flat surface. On the other hand, the performance of the nanofluid displayed intriguing trends. The HTC for the nanofluid diminished by 89.2% and 22.3% on rectangular and triangular grooved surfaces, while the circular-grooved surface exhibited a notable 41.2% increase in HTC. These results underscore the complex interplay between groove geometry, fluid properties, and heat transfer enhancement in nanofluid-based boiling. Hence, we thoroughly examine the underlying mechanisms and elements influencing these observed patterns in this research. The results provide important insights for further developments in this area by shedding light on how surface changes and groove geometry may greatly affect heat transfer in nanofluid-based pool boiling systems. Full article

The technology for obtaining sorbite by isothermal quenching of high-temperature molten salt has been used by more and more factories to produce wires with high tensile strength. In this paper, the controlling cap and bottom pipeline of the original salt bath are redesigned. The mathematical model previously proposed is used to simulate the redesigned salt bath model, and the flow field is analyzed in detail. The redesigned and original controlling cap are compared in detail by applying third-generation vortex identification technology. Then, by using the inverse heat transfer method, the heat transfer coefficient (HTC) during the boiling heat transfer stage of the wire rod in molten salt is calculated by taking advantage of quenching experimental data, on the basis of which the original model is corrected. Finally, a new salt bath design is proposed, which divides the salt bath into two parts. The first salt bath at 515 °C is used to cool the austenitized wire and complete the initial phase transformation. The second salt bath at 560 °C is used to prevent the transformation from retained austenite to bainite, and to induce its transformation from retained austenite to sorbite. Full article

Utilizing pool boiling as a cooling method holds significant importance within power plant industries due to its ability to effectively manage temperature differentials amidst high heat flux conditions. This study delves into the impact of surface modifications on the pool boiling process by conducting experiments on four distinct boiling surfaces under various conditions. An experimental setup tailored for this investigation is meticulously designed and implemented. The primary objective is to discern the optimal surface configuration capable of efficiently absorbing maximum heat flux while minimizing temperature differentials. In addition, this study scrutinizes bubble dynamics, pivotal in nucleation processes. Notably, surfaces polished unidirectionally (ROD), exhibiting lower roughness, demonstrate superior performance in critical heat flux (CHF) compared to surfaces with circular roughness (RCD). Moreover, the integration of bubble liquid separation methodology along with the introduction of a bubble micro-layer yields a microchannel surface. Remarkably, this modification results in a noteworthy enhancement of 131% in CHF and a substantial 211% increase in the heat transfer coefficient (HTC) without resorting to particle incorporation onto the surface. This indicates promising avenues for enhancing cooling efficiency through surface engineering without additional additives. Full article

The rapid progress of electronic devices has necessitated efficient heat dissipation within boiling cooling systems, underscoring the need for improvements in boiling heat transfer coefficient (HTC) and critical heat flux (CHF). While different approaches for micropillar fabrication on copper or silicon substrates have been developed and have shown significant boiling performance improvements, such enhancement approaches on aluminum surfaces are not broadly investigated, despite their industrial applicability. This study introduces a scalable approach to engineering hierarchical micro-nano structures on aluminum surfaces, aiming to simultaneously increase HTC and CHF. One set of samples was produced using a combination of nanosecond laser texturing and chemical etching in hydrochloric acid, while another set underwent an additional laser texturing step. Three distinct micropillar patterns were tested under saturated pool boiling conditions using water at atmospheric pressure. Our findings reveal that microcavities created atop pillars successfully facilitate nucleation and micropillars representing nucleation site areas on a microscale, leading to an enhanced HTC up to 242 kW m⁻² K⁻¹. At the same time, the combination of the surrounding hydrophilic porous area enables increased wicking and pillar patterning, defining the vapor–liquid pathways on a macroscale, which leads to an increase in CHF of up to 2609 kW m⁻². Full article

Due to environmental concerns, natural refrigerants and their use in refrigeration and air conditioning systems are receiving more attention from manufacturers, end users and the scientific community. The study of heat transfer and pressure drop is essential for accurate design and more energy efficient cycles using natural refrigerants. The aim of this work is to provide an overview of the latest outcomes related to heat transfer and pressure drop correlations for ammonia, propane, isobutane and propylene and to investigate the current state of the art in terms of operating conditions. Available data on the existing correlations between heat transfer coefficients and pressure drops for natural refrigerants have been collected through a systematic search. Whenever possible, validity intervals are given for each correlation, and the error is quantified. It is the intention of the authors that this paper be a valuable support for researchers and an aid to design, with particular reference to heat pumps. A procedure based on the Preferred Reporting Items for Systematic Reviews and Meta-Analyses (PRISMA) statement was adopted, and the Scopus database was used to query the relevant literature. A total of 135 publications qualified for inclusion in the survey; 34 articles report experimental investigations for unusual geometric conditions. Of the 101 selected papers related to usual geometric conditions, N = 50 deal only with HTC, N = 16 deal only with pressure drop and the remainder (N = 35) analyse both HTC and pressure drop. Among the 85 HTC papers, N = 53 deal with the evaporating condition, N = 30 with condensation and only N = 2 with the heat transfer correlations under both conditions. Most of the 101 articles concern propane and isobutane. The high temperatures are less widely investigated. Full article

Highly glazed spaces are visually appealing and trendy, but effectively managing their temperature in hot arid climates remains a significant challenge. This study evaluates the effectiveness of dark-tinted double low-E glass with internal roller blinds in reducing heat gain in glazed spaces in hot arid climates and investigates architects’ perspectives on these facades. It combines field measurements and a survey to assess the balance between thermal control and aesthetics in such environments. This study reveals that the current glazing significantly attenuates solar radiation ingress, evidenced by a marked indoor-–outdoor temperature differential (ΔT) of approximately 9.2 °C. The mean radiant temperature registers at 1.5 °C above the indoor air temperature, which can be attributed to the glazing’s propensity to absorb and retain solar heat, resulting in an inner glass surface temperature of 43 °C. The implementation of adjustable blinds has a dynamic influence on the heat transfer coefficient (HTC), effectively modulating the temperature by impeding natural convection currents. With the blinds retracted, the HTC stands at an average of 7.1 W/m²K, which diminishes to 5 W/m²K when the blinds are 50% closed and further reduces to 4.2 W/m²K when the blinds are fully closed (100%). Survey results suggest that architects prioritise glazed facades for aesthetics (52%) while facing challenges in thermal and energy efficiency (44%). Future studies should concentrate on developing novel glazing systems that integrate solutions for visual appeal, lighting and thermal efficiency in glazed facades, particularly in hot arid climates. Full article

To investigate the heat transfer coefficient (HTC) of a newly developed rare-earth wrought magnesium alloy under different cooling rates, the experiment of solution treatment followed by water quenching or air cooling process was carried out for calculation by lumped capacitance method (LCM) and optimized by inverse heat transfer method (IHTM), and cooling temperature curves were simulated afterward. In water quenching, the larger the temperature difference between the sample and water, the larger the maximum HTC, and the earlier it reached the maximum value, and in air cooling the HTC became larger with the airflow speeds increased. In LCM, the peak values of the HTC were 2840 W/(m²·°C) in water quenching and 54 W/(m²·°C) in air cooling. The corresponding HTC was 2388 W/(m²·°C) in IHTM. The maximum absolute average relative error (AARE) of temperature simulation in water quenching decreased from 8.46% in LCM to 2.45% in IHTM. The residual stress(RS) of a large conical component was simulated using both non-optimized and optimized HTC, the RS in the IHTM was ~30 MPa smaller than that in the ILCM, because the corresponding HTC was smaller, and the comparison of the simulation results with the measurements revealed that the RS using HTC in the IHTM is more accurate. Full article
