Thermochemical energy storage (TCES) presents a promising method for energy storage due to its high storage density and capacity for long-term storage. A combination of TCES and district heating networks exhibits an appealing alternative to natural gas boilers, particularly through the utilisation of industrial waste heat to achieve the UK government’s target of Net Zero by 2050. The most pivotal aspects of TCES design are the selected materials, reactor configuration, and heat transfer efficiency. Among the array of potential reactors, the fluidised bed emerges as a novel solution due to its ability to bypass traditional design limitations; the fluidised nature of these reactors provides high heat transfer coefficients, improved mixing and uniformity, and greater fluid-particle contact. This research endeavours to assess the enhancement of thermochemical fluidised bed systems through material characterisation and development techniques, alongside the optimisation of heat transfer. The analysis underscores the appeal of calcium and magnesium hydroxides for TCES, particularly when providing a buffer between medium-grade waste heat supply and district heat demand. Enhancement techniques such as doping and nanomaterial/composite coating are also explored, which are found to improve agglomeration, flowability, and operating conditions of the hydroxide systems. Furthermore, the optimisation of heat transfer prompted an evaluation of heat exchanger configurations and heat transfer fluids. Helical coil heat exchangers are predominantly favoured over alternative configurations, while various heat transfer fluids are considered advantageous depending on TCES material selection. In particular, water and synthetic liquids are compared according to their thermal efficiencies and performances at elevated operating temperatures. Full article

This work presents the thermochemical analysis of a packed-bed reactor via multi-dimensional CFD modeling using FlexPDE and COMSOL Multiphysics. The temperature, concentration, and reaction rate profiles for methane production following the Fischer–Tropsch (F-T) synthesis were studied. To this end, stationary and dynamic differential equations for mass and heat transfer were solved via the finite element technique. The transport equations for 1-D and 2-D models using FlexPDE consider dispersion models, where the fluid and the catalyst can be treated as either homogeneous or heterogenous systems depending on the gradient extents. On the other hand, the 3-D model obtained in COMSOL deems the transport equations incorporated in the Porous Media module. The aim was to compare the FlexPDE and COMSOL models, and to validate them with experimental data from literature. As a result, all models were in good agreement with experimental data, especially for the 2-D and 3-D dynamic models. In terms of kinetics, the predicted reaction rate profiles from the COMSOL model and the 2-D dynamic model followed the temperature trend, thus reflecting the temperature dependence of the reaction. Based on these findings, it was demonstrated that applying different approaches for the CFD modeling of F-T processes conducts reliable results. Full article

The decarbonisation of building heating in urban areas can be achieved by heat pumps connected to district heating networks. These could be ‘third-generation’ (85/75 °C), ‘fourth-generation’ (50/40 or 50/25 °C) or ‘fifth-generation’ (near ambient) water loops. Networks using thermochemical reactions should require smaller pipe diameters than water systems and be more economic. This work investigates thermochemical transmission systems based on liquid–gas absorption intended for application in urban district heating networks where the main heat source might be a MW scale heat pump. Previous studies of absorption for heat transmission have concentrated on long distance (e.g., 50 km) transmission of heat or cold utilizing waste heat from power stations or similar but these are not directly applicable to our application which has not been investigated before. Absorbent-refrigerant pairs are modelled using water, methanol and acetone as absorbates. Thermodynamic properties are obtained from the literature and modelling carried out using thermodynamic analysis very similar to that employed for absorption heat pumps or chillers. The pairs with the best performance (efficiency and power density) both for ambient loop (fifth-generation) and high temperature (fourth-generation) networks use water pairs. The next best pairs use methanol as a refrigerant. Methanol has the advantage of being usable at ambient temperatures below 0 °C. Of the water-based pairs, water–NaOH is good for ambient temperature loops, reducing pipe size by 75%. Specifically, in an ambient loop, heat losses are typically less than 5% and the heat transferred per volume of pumped fluid can be 30 times that of a pumped water network with 10 K temperature change. For high temperature networks the heat losses can reach 30% and the power density is 4 times that of water. The limitation with water–NaOH is the low evaporating temperature when ambient air is the heat source. Other water pairs perform better but use lithium compounds which are prohibitively expensive. For high temperature networks, a few water- and methanol-based pairs may be used, but their performance is lower and may be unattractive. Full article

Thermochemical energy storage systems from carbonates, mainly those based on calcium carbonate, have been gaining momentum in the last few years. However, despite the considerable interest in the process, the Technology Readiness Level (TRL) is still low. Therefore, facing the progressive development of the technology at different scales is essential to carry out a comprehensive risk assessment and a Failure Mode Effect and Analysis (FMEA) process to guarantee the safety and operation of the technology systems. In this study, the methodology was applied to a first-of-its-kind prototype, and it is a valuable tool for assessing safe design and operation and potential scaling up. The present work describes the methodology for carrying out these analyses to construct a kW-scale prototype of an energy storage system based on calcium carbonate. The main potential risks occur during the testing and operation stages (>50% of identified risks), being derived mainly from potential overheating in the reactors, failures in the control of the solar shape at the receiver, and potential failures of the control system. Through the assessment of Risk Priority Numbers (RPNs), it was identified that the issues requiring more attention are related to hot fluid path to avoid loss of heat transfer and potential damages (personal and on the facilities), mainly due to their probability to occur (>8 on a scale of 10). The results derived from the FMEA analysis show the need for specific control measures in reactors, especially in the calciner, with high operation temperatures (1000 °C) and potential effects of overheating and corrosion. Full article

Recent contributions to thermochemical heat storage (TCHS) technology have been reviewed and have revealed that there are four main branches whose mastery could significantly contribute to the field. These are the control of the processes to store or release heat, a perfect understanding and designing of the materials used for each storage process, the good sizing of the reactor, and the mastery of the whole system connected to design an efficient system. The above-mentioned fields constitute a very complex area of investigation, and most of the works focus on one of the branches to deepen their research. For this purpose, significant contributions have been and continue to be made. However, the technology is still not mature, and, up to now, no definitive, efficient, autonomous, practical, and commercial TCHS device is available. This paper highlights several issues that impede the maturity of the technology. These are the limited number of research works dedicated to the topic, the simulation results that are too illusory and impossible to implement in real prototypes, the incomplete analysis of the proposed works (simulation works without experimentation or experimentations without prior simulation study), and the endless problem of heat and mass transfer limitation. This paper provides insights and recommendations to better analyze and solve the problems that still challenge the technology. Full article

Calcium oxide/Calcium hydroxide can be utilized as a reaction system for thermochemical heat storage. It features a high storage capacity, is cheap, and does not involve major environmental concerns. Operationally, different fixed-bed reactor concepts can be distinguished; direct reactor are characterized by gas flow through the reactive bulk material, while in indirect reactors, the heat-carrying gas flow is separated from the bulk material. This study puts a focus on the indirectly operated fixed-bed reactor setup. The fluxes of the reaction fluid and the heat-carrying flow are decoupled in order to overcome limitations due to heat conduction in the reactive bulk material. The fixed bed represents a porous medium where Darcy-type flow conditions can be assumed. Here, a numerical model for such a reactor concept is presented, which has been implemented in the software DuMu${}^{\mathrm{x}}$. An attempt to calibrate and validate it with experimental results from the literature is discussed in detail. This allows for the identification of a deficient insulation of the experimental setup. Accordingly, heat-loss mechanisms are included in the model. However, it can be shown that heat losses alone are not sufficient to explain the experimental results. It is evident that another effect plays a role here. Using Bayesian inference, this effect is identified as the reaction rate decreasing with progressing conversion of reactive material. The calibrated model reveals that more heat is lost over the reactor surface than transported in the heat transfer channel, which causes a considerable speed-up of the discharge reaction. An observed deceleration of the reaction rate at progressed conversion is attributed to the presence of agglomerates of the bulk material in the fixed bed. This retardation is represented phenomenologically by mofifying the reaction kinetics. After the calibration, the model is validated with a second set of experimental results. To speed up the calculations for the calibration, the numerical model is replaced by a surrogate model based on Polynomial Chaos Expansion and Principal Component Analysis. Full article

One of the most interesting perspectives for the development of concentrated solar power (CSP) is the storage of solar energy on a seasonal basis, intending to exploit the summer solar radiation in excess and use it in the winter months, thus stabilizing the yearly production and increasing the capacity factor of the plant. By using materials subject to reversible chemical reactions, and thus storing the thermal energy in the form of chemical energy, thermochemical storage systems can potentially serve to this purpose. The present work focuses on the identification of possible integration solutions between CSP plants and thermochemical systems for long-term energy storage, particularly for high-temperature systems such as central receiver plants. The analysis is restricted to storage systems potentially compatible with temperatures ranging from 700 to 1000 °C and using gases as heat transfer fluids. On the basis of the solar plant specifications, suitable reactive systems are identified and the process interfaces for the integration of solar plant/storage system/power block are discussed. The main operating conditions of the storage unit are defined for each considered case through process simulation. Full article

The design elements considered during the construction of a thermochemical reactor determine its thermal performance. This current study investigated the effect of design elements, such as boundary layer thickness, insulating materials for the outlet tube design and fluid inlet locations of the frustum, on the thermal performance of a proposed syngas production reactor with incident radiation heat transfer through quartz glass. The P₁ radiation approximation model and fluid flow in the shallow path were integrated into a proposed radiation model. The result indicated that inlet mass flow rates from 5 × 10⁻⁴ to 14 × 10⁻⁴ kg/s increased the temperature in the cavity and the outlet. The fluid inlet located at the top of the quartz glass edges was found to have better thermal performance and maximum average outlet temperature. Insulation for fluid inlets tube above the quartz glass edges of the frustum was very important for the prevention of radiation loss through quartz glass and sedimentation of fluid particles around the quartz glass edge, and the facilitation of fast heat transfer towards the internal part of the reactor. The outlet that was a tube designed using an aluminum oxide-type insulator with a 50 mm boundary layer thickness was found to increase the average outlet temperature of the reactor. This study revealed that fluid entry and exit locations on the frustum and proper fluid outlet design were critical for the thermal performance analysis of the solar thermochemical reactor for heat transfer with quartz glass. Findings from this study will be of relevance to chemical and power engineering sectors, as well as academia. Full article

Increasing energy prices make space heating more expensive every year in The Organisation for Economic Co-operation and Development (OECD) member countries. Thermochemical heat storage systems (THSS) can be used to reduce residential energy consumption for space heating and to control humidity. Utilizing compressed thermochemical pellets as heat storage materials is a way to increase volumetric energy storage capacity and to improve the performance of the THSS. In this work, expanded natural graphite (ENG), activated carbon (AC), strontium bromide, and magnesium sulphate were mixed in different mass ratios and compressed under applied pressures in a range of 0.77 to 5.2 kN⋅mm⁻² to form composite pellets with a diameter of 12 and 25 mm, respectively, and a thickness from 1.5 to 25 mm. These pellets were characterized using thermogravimetric analysis and differential scanning calorimetry. Cyclic tests of hydration at 20 °C and dehydration at 85 °C were conducted to investigate changes in the surface morphology and the heat and mass transfer characteristics of the composite pellets. The permeability and thermal conductivity of the composite pellets were also measured. It was found that the structural stability of the pellets was enhanced by increasing the compression pressure. Utilizing AC and ENG in the composite mixture enhanced the porosity, thermal conductivity, and the permeability of the pellets. Full article

Different kinds of explosions are driven by the internal energy accumulated in compressed gas or superheated liquid. A well-known example of such an explosion is the burst of a vessel with pressure-liquefied substance, known as Boiling Liquid Expanding Vapor Explosion (BLEVE). Hot BLEVE accident is caused mainly by direct heating (pool fire or jet fire) of the steel casing at the vapor side of the tank to temperatures in excess of 400 °C. Thermal insulation around the tank can significantly reduce and retard the excessive heating of the tank casings in a fire. This will allow fire fighters enough time to reach the accident location and to cool the LPG (Liquid Petroleum Gas) tank to avoid the BLEVE, to extinguish the fire or to evacuate the people in the vicinity of the accident. The proposed algorithm addresses several aspects of the BLEVE accident and its mitigation: Computational Fluid Dynamic (CFD) Simulation of jet fire by using fire dynamics simulator (FDS) software by using large eddy simulation (LES); calculation of the convective and radiative heat fluxes by using the impinging jet fire theory; performing thermochemical and heat transfer analysis on the glass-woven vinyl ester coating of the vessel by using FDS software (version 5); and COMSOL Multiphysics (version 4.3b) during the heating phase of composite and calculation of the time period required to evaporate the liquefied propane by using the first and second laws of thermodynamics. Full article
