In the earthquakes that occurred in the Pazarcık (Mw = 7.7) and Elbistan (Mw = 7.6) districts of Kahramanmaraş Province on 6 February 2023, many buildings collapsed in the Hayrullah neighborhood of the Onikişubat district. In this study, we investigated whether there was a soil amplification effect on the damage occurring in the Hayrullah neighborhood of the Onikişubat district of Kahramanmaraş Province. Firstly, borehole, SPT, MASW (multi-channel surface wave analysis), microtremor, electrical resistivity tomography (ERT), and vertical electrical sounding (VES) tests were carried out in the field to determine the engineering properties and behavior of soil. Laboratory tests were also conducted using samples obtained from bore holes and field tests. Then, an idealized soil profile was created using the laboratory and field test results, and site dynamic soil behavior analyses were performed on the extracted profile. According to The Turkish Building Code (TBC 2018), the earthquake level DD-2 design spectra of the project site were determined and the average design spectrum was created. Considering the seismicity of the project site and TBC (2018) criteria (according to site-specific faulting, distance, and average shear wave velocity), 11 earthquake ground motion sets were selected and harmonized with DD-2 spectra in short, medium, and long periods. Using scaled motions, the soil profile was excited with 22 different earthquake scenarios and the results were obtained for the equivalent and non-linear models. The analysis showed that the soft soil conditions in the area amplified ground shaking by up to 2.8 times, especially for longer periods (1.0–2.5 s). This level of amplification was consistent with the damage observed in mid- to high-rise buildings, highlighting the important role of local site effects in the structural losses seen during the Kahramanmaraş earthquakes. Full article

Large storage tanks situated in coastal areas are vulnerable to environmental hazards, with earthquakes being one of the most destructive forces threatening their structural safety. Additionally, differential settlement can significantly alter conditions in the tank, including the inclination, thereby changing the direction of external applied excitation forces and affecting the liquid sloshing response. To investigate the coupled effects of structural settlement and external excitation, model tests were conducted in series to analyze liquid sloshing behavior in a tilted tank subjected to harmonic excitation. The results revealed that the liquid response under combined environmental loads displayed distinct characteristics compared with that under single excitation. While the inclination angle had minimal influence during the unstable sloshing stage, it became crucial during the stable stage, particularly for third-order resonant responses, leading to intensified sloshing. More specifically, as the tilt angle of the storage tank from 0° to 8°, the steady-state wave height at third-order resonance increased by approximately 69%. This highlights the amplified risks to the structural stability and safety posed by differential settlement. Furthermore, variations in steady-state wave heights due to differential settlement conditions were investigated. The water level elevation along the tank walls varies as the inclination angles increase, which leads to potential risks to the stability of liquid storage under forced motion, especially under symmetric structural designs, and increases the likelihood of structural instability, oil spills, and other coastal disasters. These results provide valuable insights into the safety risks and sustainable utilization of coastal infrastructure, serving a basis for assessing and mitigating the risks associated with structural settlement and seismic excitations. Full article

A nonlinear energy sink (NES) has such advantages as controlling broader band responses and better robustness than conventional control devices like tuned mass dampers (TMDs). In this research, a cubic stiffness NES mitigating the dynamic responses of a multi-degree-of-freedom structure under white noise, harmonic and seismic excitations was tested using a shake table, and the influences of the parameters of the NES on vibration mitigation effects were investigated. The test results indicate that the NES has the same vibration mitigation effects on the acceleration responses under the white noise and harmonic excitations as TMDs, even though the mass ratio of the NES is less than that of a TMD. The average control effects of the NES on the acceleration responses of the structure under the effect of 100 seismic waves are better than those of a TMD, which indicates that an NES has better robustness than a TMD. Full article

The seismic beacon is a new instrument that allows for the measurement of changes in a rock massif with high sensitivity. It is based on effects, which affect the propagation of harmonic seismic waves generated continuously with stable and precise frequency and amplitude. These seismic waves are registered by a system of seismic stations. The amplitude of the seismic signal is very small, and it is normally hidden in a seismic noise. Special techniques are applied to increase the signal-to-noise ratio. In 2020, the first prototype of the seismic beacon was constructed in a laboratory, and field tests were performed in 2022 and 2023. During the tests, the changes in spectral amplitude and phase of seismic waves were detected, which is interpreted as the changes in material properties. These measurements testified the basic functionality of the device. The seismic beacon has been developed primarily for the detection of critical stress before an earthquake, which is manifested by non-linear effects such as higher harmonics generation. In addition, it could be used, for example, in the detection of magma movements, groundwater level changes, changes in hydrocarbon saturation in rocks during the extraction of oil and natural gas, or the penetration of gases and liquids into the earth’s crust. Full article

It is known that the low frequencies of seismic surface waves have a destructive effect. The main purpose of seismic metamaterials is to protect structures from seismic waves at low frequencies, especially in a wide band. In this study, the effects of seismic metamaterials formed using circular array concrete piles on surface waves were investigated. Each concrete pile has been selected due to symmetric properties to investigate the band diagram. Therefore, the direction independence can also be determined with respect to frequency. This study was conducted both numerically and experimentally in the low-frequency range of 5–15 Hz. Two fields, with and without metamaterials, have been designed and compared. In numerical analysis, transmission loss graphs were drawn using the finite element method (FEM), and wave propagation at frequencies where the loss happened was simulated. In numerical analysis, optimum dimensions such as radius and depth were determined, and these dimensions were applied exactly in the experimental field. The results obtained from the experiment using a harmonic vibration device are mapped. In this numerical and experimental study, it has been revealed that the proposed structure prevents the propagation of seismic surface waves. Full article

Road traffic noise is a special kind of high amplitude noise in seismic or acoustic data acquisition around a road network. It is a mixture of several surface waves with different dispersion and harmonic waves. Road traffic noise is mainly generated by passing vehicles on a road. The geophones near the road will record the noise while receiving the seismic signal. The amplitude of the traffic noise is much larger than the signal, which masks the effective information and degrades the quality of acquired data. At the same time, the traffic noise is coupled with the effective signal, which makes it difficult to separate them. Therefore, attenuating traffic noise is the key to improving the quality of the final processing results. In recent years, denoising methods based on convolution neural networks (CNN) have shown good performance in noise attenuation. These denoising methods can learn the potential characteristics of acquired data, thus establishing the mapping relationship between the original data and the effective signal or noise. Here, we introduce a method combining UNet networks with asymmetric convolution blocks (ACBs) for traffic noise attenuation, and the network is called the ACB-UNet. The ACB-UNet is a supervised deep learning method, which can obtain the distribution characteristics of noise and effective signal through learning the training data and then effectively separate the two to achieve noise removal. To validate the performance of the proposed method, we apply it to synthetic and real data. The data tests show that the ACB-UNet can obtain good results for high amplitude noise attenuation and is practical and efficient. Full article

Seismic velocities and elastic moduli of rocks are known to vary significantly with applied stress, which indicates that these materials exhibit nonlinear elasticity. Monochromatic waves in nonlinear elastic media are known to generate higher harmonics and combinational frequencies. Such effects have the potential to be used for broadening the frequency band of seismic sources, characterization of the subsurface, and safety monitoring of civil engineering infrastructure. However, knowledge on nonlinear seismic effects is still scarce, which impedes the development of their practical applications. To explore the potential of nonlinear seismology, we performed three experiments: two in the field and one in the laboratory. The first field experiment used two vibroseis sources generating signals with two different monochromatic frequencies. The second field experiment used a surface orbital vibrator with two eccentric motors working at different frequencies. In both experiments, the generated wavefield was recorded in a borehole using a fiber-optic distributed acoustic sensing cable. Both experiments showed combinational frequencies, harmonics, and other intermodulation products of the fundamental frequencies both on the surface and at depth. Laboratory experiments replicated the setup of the field test with vibroseis sources and showed similar nonlinear combinations of fundamental frequencies. Amplitudes of the nonlinear signals observed in the laboratory showed variation with the saturating fluid. These results confirm that nonlinear components of the wavefield propagate as body waves, are likely to generate within rock formations, and can be potentially used for reservoir fluid characterization. Full article

Fracture seismic is the method for recording and analyzing passive seismic data for mapping the fractures in the subsurface. Fracture seismic is able to map the fractures because of two types of mechanical actions in the fractures. First, in cohesive rock, fractures can emit short duration energy pulses when growing at their tips through opening and shearing. The industrial practice of recording and analyzing these short duration events is commonly called micro-seismic. Second, coupled rock–fracture–fluid interactions take place during earth deformations and this generates signals unique to the fracture’s physical characteristics. This signal appears as harmonic resonance of the entire, fluid-filled fracture. These signals can be initiated by both external and internal changes in local pressure, e.g., a passing seismic wave, tectonic deformations, and injection during a hydraulic well treatment. Fracture seismic is used to map the location, spatial extent, and physical characteristics of fractures. The strongest fracture seismic signals come from connected fluid-pathways. Fracture seismic observations recorded before, during, and after hydraulic stimulations show that such treatments primarily open pre-existing fractures and weak zones in the rocks. Time-lapse fracture seismic methods map the flow of fluids in the rocks and reveal how the reservoir connectivity changes over time. We present examples that support these findings and suggest that the fracture seismic method should become an important exploration, reservoir management, production, and civil safety tool for the subsurface energy industry. Full article

In this article, we suggest a new type of seismic source for surveying both structure state and foundation soil conditions regardless of the level of seismic noise. In our opinion, powerful industrial equipment can be treated as seismic sources. We describe the results of a survey conducted on the Song Tranh-2 hydropower dam located in Central Vietnam. After a М = 4.7 earthquake, the dam visual inspection revealed zones of the excessive durability loss: cracks and areas with an elevated infiltration of water into the dam galleries. Powerful industrial equipment generates continuous quasi-harmonic mechanical oscillations (seismic waves) that travel through layers of rocks. These seismic oscillations are recorded by receivers in different measurement points such as the dam body, abutments, and the foundation soils. Anomalous amplitudes of these oscillations indicate the presence of weakened zones in the structure or in foundation soil. We coupled passive and active seismic methods to more precisely find such zones. In this case, active seismic methods allowed us to investigate dam abutment zones, and passive seismic methods were used to localize weakened zones in the dam-foundation soil system. We assumed that the joint contribution of two factors was the cause of the dam weakening. One of them was caused by increased water infiltration through the rock mass and its contact zones, and the other was reservoir-induced seismicity contributing to the deterioration of the foundation soils, which was possibly the reason for a shift in the dam in the contact zone with the rock mass foundation. It is necessary to perform computer modelling, which was not included in our research. The developed method can be used for the safety control of the hydropower station dams. Full article

In this paper, a new time-frequency analysis method—Synchrosqueezing Generalized S-transform (SSGST)—is proposed to meet the needs of high-resolution seismic signal processing and interpretation. The basic wavelet of the generalized S-transform (GST) in the paper is a modulated harmonic wave with four undetermined parameters that can be constructed by adjusting the four parameters to make the GST more suitable for seismic signals processing. The SSGST method squeezes and reconstructs the complex coefficient spectra of GST results along the frequency direction so that the energy distributions on the time-frequency spectra are concentrated around the real instantaneous frequency of the signal; thus, the time-frequency resolution can be improved. Based on mathematical theory, the basic principle of the new transformation method is given, and the mathematical expressions of the positive transformation and lossless inverse transformation of the method are strictly deduced. The experimental results of numerical signals illustrate that the proposed method can correctly decompose signals with different spectral characteristics into a high time-frequency resolution spectrum and can recovery the original signal from the time-frequency spectrum with satisfying reconstructing accuracy. Application on field seismic data shows the superiority of the new method in seismic time-frequency analysis for hydrocarbon detection. Full article
