Supersonic flow over a half-angle wedge (θ = 15°) with an upstream Mach number of 2.0 was investigated using 2D Euler equations where sea level conditions were considered. The investigation employed the Steger–Warming flux vector splitting (FVS) method executed in MATLAB 9.13.0 (R2022b) software. The study involved a meticulous comparison between theoretical calculations and numerical results. Particularly, the research emphasized the angle of oblique shock and downstream flow properties. A substantial iteration count of 2000 iteratively refined the outcomes, underscoring the role of advanced computational resources. Validation and comparative assessment were conducted to elucidate the superiority of the Steger–Warming flux vector splitting (FVS) scheme over existing methodologies. This research serves as a link between theoretical rigor and practical applications in high-speed aerospace design, enhancing the efficiency of aircraft components. Full article

We explore, both theoretically and experimentally, the potential of semiconductor materials for the Cherenkov scheme of terahertz generation on the example of GaP crystal pumped by femtosecond laser pulses of 1.54 $\mathrm{\mu }$m wavelength. We use a convenient scheme with a focused-to-a-line laser beam which is introduced into the crystal by oblique incidence at the Brewster angle on the crystal front face and propagates in the crystal at the Cherenkov angle to its normal. A half of the generated Cherenkov wedge impinges normally the rear face of the crystal and generates an output terahertz beam with a plane wavefront. The whole generation process is simulated by FDTD method. In experiments, the laser pulses of 140 fs duration and 10 $\mathrm{\mu }$J energy were converted to wideband (~2.5 THz bandwidth) terahertz radiation with the efficiency of ~3 × 10${}^{-5}$, which exceeds the efficiency of the standard collinear scheme by at least an order of magnitude. Full article

In this study, we conducted small-scale physical modeling tests to consider the impact of the infiltration of rainfall in order to investigate the processes involved in wedge slope deformation and failure. The experiments were conducted under controlled conditions of the intersection angle and half-wedge angle. The observations obtained during each stage of deformation and failure were used to explain how gravity deformation varies on wedge slopes and infer how rainfall influences slope failure. The results indicated that half-wedge angle is a crucial factor in the deformation failure of slopes. The failure mechanisms of small-intersection angle slopes (sliding model) differ considerably from those of large-intersection angle slopes (free falling or toppling model). The infiltration of surface water can have a significant influence on rock layer deformation and the speed of failure. Details of the failure characteristics of wedge slope models were discussed in this paper. Full article

In this paper, a transonic compressor cascade was optimized to improve its aerodynamic performance. A new blade parameterization method with 16 control variables was first proposed to fit the shapes of the suction and the pressure side, as well as the leading edge. Then, the Kriging surrogate-model-based genetic algorithm (GA) was used to optimize the performance of the transonic cascade. The optimization algorithm is effective in reducing the total pressure loss while extending the working range of the cascade. The results show that the total pressure loss coefficient could be reduced by 11% at the best airflow angle and the working range could be extended by 6.9% for the optimized cascade in two-dimensional simulations. Similar improvement results could also be obtained in the simulations of their linear cascade cases. Detailed analyses show that the relative maximum thickness positions of the optimized blades move forward by about 10% to the leading edge, and the radii of curvature of the front half of the suction and pressure surfaces increase, compared with the initial blade. This makes the front half of the optimized blades look more closely like a wedge. Consequently, the passage shock strength is reduced and the shock changes from the passage normal shock to oblique shock. The weakened shock strength leads to the disappearance of the flow separation caused by the shock boundary layer interaction on the suction surfaces of the optimized blades, and results in a narrowed wake width at the outlet section. Full article

The Finite-element method (FEM) and experiments were used to investigate the geometric factors and material parameter on the strain distribution during tube high-pressure shearing (t-HPS). The results show that t-HPS could be realized successfully either by pressurizing on both ends of the tube, or by pressurizing using the wedge effect; and in both cases, the “dead metal zone” could be found at both ends of the tube. The grain size distribution from the experiment confirmed this strain distribution feature. In the case of t-HPS pressurized using the wedge effect, the half cone angle has little effect on the strain distribution. Decreasing the strain-hardening exponent leads to increased deformation inhomogeneity in both the ideal t-HPS described by theoretical equations and the close to practical t-HPS described by FEM. This feature of t-HPS stands out from other SPD processes like HPT, and makes practical t-HPS behavior more predictable using the analytical formation than any other SPD processes, and places it an advantageous position in understanding the basics of deformation physics through the coupling between practical experiments and theoretical approaches. Full article

In order to study the effect of the angle of wedged indenters during nanoindentation, indenters with half vertex angles of 60°, 70° and 80° are used for the simulations of nanoindentation on FCC aluminum (Al) bulk material by the multiscale quasicontinuum method (QC). The load-displacement responses, the strain energy-displacement responses, and hardness of Al bulk material are obtained. Besides, atomic configurations for each loading situation are presented. We analyze the drop points in the load-displacement responses, which correspond to the changes of microstructure in the bulk material. From the atom images, the generation of partial dislocations as well as the nucleation and the emission of perfect dislocations have been observed with wedged indenters of half vertex angles of 60° and 70°, but not 80°. The stacking faults move beneath the indenter along the direction $[1\overline{1}0]$ . The microstructures of residual displacements are also discussed. In addition, hardness of the Al bulk material is different in simulations with wedged indenters of half vertex angles of 60° and 70°, and critical hardness in the simulation with the 70° indenter is bigger than that with the 60° indenter. The size effect of hardness in plastic wedged nanoindentation is observed. There are fewer abrupt drops in the strain energy-displacement response than in the load-displacement response, and the abrupt drops in strain energy-displacement response reflect the nucleation of perfect dislocations or extended dislocations rather than partial dislocations. The wedged indenter with half vertex angle of 70° is recommended for investigating dislocations during nanoindentation. Full article
