For the guide vane adjusting mechanism, precision represents the primary design requirement. Meanwhile, due to the presence of aerodynamic loads under actual operating conditions, stagnation forces emerge that affect the mechanism motion characteristics, including the response speed and precision. This paper establishes kinematic and static analysis models of the guide vane adjusting mechanism through analytical modeling methods, investigates analytical approaches for mechanism adjustment precision and stagnation force, and conducts error and sensitivity analyses of the mechanism parameters based on these analytical models. Building upon this foundation, an optimization design method integrating adjustment precision and force transmission performance is proposed using a multi-objective genetic algorithm. Optimizing the critical design parameters, such as the mechanism dimensions and positions, can enhance both the adjustment precision and force transmission performance. Through case studies, significant reductions in motion precision errors and the peak stagnation force and maximum differences in stagnation force were achieved, validating the feasibility of this optimization design approach. Full article

This article provides a comprehensive review of key approaches to suppressing stall flow in pumps, offering insights to enhance pump performance and reliability. It begins by outlining the formation mechanisms and characteristics of stalls, followed by an in-depth analysis of various stall types. The discussion highlights passive and active flow control methods, emphasizing their roles in suppressing stall phenomena. Passive flow-control strategies, including surface roughness, grooves, obstacles, fixed guide vanes, and vortex generators, are examined with a focus on their mechanisms and effectiveness in suppressing stall. Similarly, active flow-control techniques, such as jets and adjustable guide vanes, are explored for their capacity to regulate the flow field and suppress stall. The novelty of this review lies in its exploration of the effectiveness of passive and active flow-control methods in suppressing pump stall, with a focus on their mechanisms of action and the underlying principles of stall formation. The findings reveal that appropriate flow-control measures can mitigate laminar flow separation and reduce performance losses associated with stall. However, careful attention must be given to the optimal arrangement of control devices. Finally, the article highlights the limitations of current implementations of combined active and passive flow-control methods while offering insights into the future potential of advanced flow-control technologies in regard to suppressing stall. Full article

Based on the transient-performance calculation model of a dual-spool mixed-flow turbofan engine, this article improves the dynamic algorithm of geometric adjustment mechanisms and establishes a transient-performance calculation model suitable for a three-stream adaptive cycle engine (three-stream ACE). Using this model, the transient characteristics of a three-stream ACE were analyzed. The results indicate that the delay in the area of the fan nozzle significantly reduces the surge margin of the front fan during deceleration, while the delay in the angle of the front-fan and aft-fan guide vanes significantly reduces the surge margin of the front fan during acceleration, therefore becoming a limitation of the transient performance of the engine. At the same time, to meet the demand for equal-thrust mode switching, this article also proposes a mode-switching control scheme that solves the problem of engine state oscillation during the mode-conversion process and achieves a smooth conversion with thrust fluctuations within 1%. The research results of this article can guide the optimization design of three-stream ACE transition-state control laws and the design of control system architecture, which has important engineering significance. Full article

In recent years, more and more attention has been paid to research on variable geometry turbine engines with the increasing requirement of engine performance. Variable geometry turbine technology can significantly improve the operating performance of aero engines. Adjusting the working angle of the turbine guide vane can change the thermodynamic cycle of the engine operation, so that the turbine can respond to different engine operating conditions. Variable geometry turbines work in harsh environments. Therefore, the design of the variable geometry turbine needs to consider the effect of thermal deformations of the mechanism on operational stability. There are few research studies on variable geometry turbine adjusting mechanisms. This paper established the numerical calculation models of two adjusting mechanisms by integrating fluid mechanics, heat transfer, and dynamic theories, which are paddle and push–pull rod mechanisms. The models were applied to study the effects of components’ thermal deformations and flexible bodies on the motion characteristics of the adjusting mechanism. Furthermore, the performance of the two adjusting mechanisms was compared. The calculation results show that the paddle rod adjusting mechanism can accurately adjust the angles of guide vanes. The paddle rod adjusting mechanism has a larger driving stroke and smaller driving force than the push–pull rod adjusting mechanism. The paddle adjustment mechanism was better suited to the operational requirements of the variable geometry turbine. The research results of this paper are relevant to the design of variable geometry turbine regulation structures. Full article

In the present work, numerical simulation and optimization was carried out to analyze the mechanism of the variable guide vanes (VGVs) of a transonic compressor. A seven-stage transonic compressor including three-stage VGVs was studied. The VGVs were adjusted individually and jointly under different IGV opening degrees. Changes in performance and shock wave were analyzed, and the coupling effect of the VGV joint adjustment was summarized. Aiming at the maximum efficiency, the joint turning angles were optimized. A novel phenomenon was found wherein the VGV adjustment can affect not only its own performance and that of adjacent downstream blades, but also that of upstream blades. Incidence and performance of upstream blades are improved, but those of the VGV and its adjacent downstream blades are deteriorated. VGV adjustment weakens the shock wave and shock-induced boundary layer separation. The optimal solution for VGV joint adjustment is the combination of the optimal solutions for single VGV adjustments. The joint adjustment optimization improves the efficiency by 0.2–1.93% under different IGV opening degrees. Full article

To accommodate the next generation of adaptive/variable cycle engines and gas turbine power, the variable geometry turbine (VTG) is widely acknowledged as a most essential component. VGT consists of an adjustable vane to address the combined goals of high dry thrust and low specific fuel consumption (SFC) at subsonic cruises for aero-engines. This concept allows an engine to operate at a constant bypass ratio over a wide range of pressure ratios. To avoid scraping during rotation for guide vanes, a typical gap is deliberately left, which leads to significant leakage loss. In this research work, a novel spherical convex plat with a pivot shaft is proposed, which can be obtained by additive manufacturing. The plat is sophisticatedly designed according to the aggressive tip/hub pressure gradient. This design naturally generates a blockage for the gas from the pressure side towards the suction side. As a result, the most aggressive pressure gradient is removed, and maximum leakage flow is eliminated. The overall leakage loss is reduced. This simple rotating structure design can improve the efficiency by 0.4–3.0% within the wide range considered. Based on the understanding of the loss mechanism, a radially restacked vane is designed and another extra 0.2% improvement is achieved. This universal design philosophy is also verified on different loading blade profiles, i.e., front-, middle- and aft-loaded turbine vane. The improved aerodynamic performance is achieved with this novel idea. Full article

In order to explore the inducing factors and mechanism of the non-synchronous vibration, the flow field structure and its formation mechanism in the non-synchronous vibration state of a high speed turbocompressor are discussed in this paper, based on the fluid–structure interaction method. The predicted frequencies f_BV (4.4EO), f_AR (9.6EO) in the field have a good correspondence with the experimental data, which verify the reliability and accuracy of the numerical method. The results indicate that, under a deviation in the adjustment of inlet guide vane (IGV), the disturbances of pressure in the tip diffuse upstream and downstream, and maintain the corresponding relationship with the non-synchronous vibration frequency of the blade. An instability flow that developed at the tip region of 90% span emerged due to interactions among the incoming main flow, the axial separation backflow, and the tip leakage vortices. The separation vortices in the blade passage mixed up with the tip leakage flow reverse at the trailing edge of blade tip, presenting a spiral vortex structure which flows upstream to the leading edge of the adjacent blade. The disturbances of the spiral vortexes emerge to rotate at 54.5% of the rotor speed in the same rotating direction as a modal oscillation. The blade vibration in the turbocompressor is found to be related to the unsteadiness of the tip flow. The large pressure oscillation caused by the movement of the spiral vortex is regarded as the one of the main drivers for the non-synchronous vibration for the present turbocompressor, besides the deviation in the adjustment of IGV. Full article

The variable guide vanes (VGV) of gas turbine engines are commonly utilized to expand operating range and to improve efficiency of the compressor. Guiding air flow using the VGVs in the compressor prevents aerodynamic instability by making proper incidence angle to the blades. In this study, we dealt with rig-type three-stages VGVs for developed engine tests. The three link mechanism of VGVs are linked to each other with two hydraulic actuators, and inevitably, induced hysteresis exists between vane rotations and actuators strokes, due to links with non-fully constrained degree of freedoms for easy installation and instrumentation, as well. Therefore, the adjustment of each VGVs link mechanism is required to satisfy vane angle demands. To adjust coupled three-stages VGVs link mechanism, an analytical VGV-link kinematic model was derived, and effects of two adjusting parameters (lengths of bell cranks and vertical links) were discovered. Lastly, we obtained two vane angle schedule curves from the experiments according to link moving directions, and applied them to the engine controller to minimize hysteresis of the variable inlet guide vane (VIGV). The proposed VGV adjusting and controlling method can be simply applied to the pre-designed or pre-manufactured VGVs system without mechanical compensation or additional cost. Full article

To obtain the flow mechanism of the transient characteristics of a Kaplan turbine, a three-dimensional (3-D) unsteady, incompressible flow simulation during load rejection was conducted using a computational fluid dynamics (CFD) method in this paper. The dynamic mesh and re-meshing methods were performed to simulate the closing process of the guide vanes and runner blades. The evolution of inner flow patterns and varying regularities of some parameters, such as the runner rotation speed, unit flow rate, unit torque, axial force, and static pressure of the monitored points were revealed, and the results were consistent with the experimental data. During the load rejection process, the guide vane closing behavior played a decisive role in changing the external characteristics and inner flow configurations. In this paper, the runner blades underwent a linear needle closure law and guide vanes operated according to a stage-closing law of “first fast, then slow,” where the inflection point was t = 2.3 s. At the segment point of the guide vane closing curve, a water hammer occurs between guide vanes and a large quantity of vortices emerged in the runner and the draft tube. The pressure at the measurement points changes dramatically and the axial thrust rises sharply, marking a unique time in the transient process. Thus, the quality of a transient process could be effectively improved by properly setting the location of segmented point. This study conducted a dynamic simulation of co-adjustment of the guide vanes and the blades, and the results could be used in fault diagnosis of transient operations at hydropower plants. Full article
