Search Results (25)

Grazing incidence small- and wide-angle X-ray scattering (GISAXS, GIWAXS) has been widely applied for the study of functional thin films, be it for the characterization of nanostructured morphologies in block copolymers, nanocomposites, and nanoparticle assemblies, or for the packing and orientation of aromatic molecules or conjugated polymers. Solution-processed thin films are typically uniaxial powders, with a specific crystallographic plane oriented parallel to the substrate surface while ordered domains assume random orientations laterally. The convenient GISAXS/GIWAXS scattering geometry facilitates obtaining complete information about thin film structure as well as the ability to study samples in well-defined sample environments, as controlled by temperature, exposure to solvent vapor and drying, or coating processes. Moreover, with suitable X-ray sources and detectors, information about the ordering kinetics and phase transitions can be obtained down to the millisecond scale. The scattering geometry and an interactive graphical tool to index such scattering patterns will be discussed here. Furthermore, it will be demonstrated that proper indexing of the X-ray scattering patterns can provide deep insight into thin film structure–property relationships and the kinetics of structure formation. Recent examples of nanostructures and molecular organization in thin films will be discussed, as well as self-assembly processes leading to such structures. Full article

The annealing process is one of the most common methods used to study the thermal stability of multilayers. To study the effect of the annealing process on the microstructural variation in NiV/B₄C multilayers, different annealing experiments were performed on NiV/B₄C multilayers with a d-spacing of 8 nm. This work provides a foundation for the fabrication of non-periodic NiV/B₄C multilayers. The NiV/B₄C multilayers were investigated by grazing-incidence X-ray reflectometry (GIXR), X-ray diffuse scattering (XRS), atomic force microscopy (AFM), X-ray diffraction (XRD), grazing-incidence small-angle X-ray scattering (GISAXS) and transmission electron microscopy (TEM). The temperature-dependent experiments showed that annealing at 70–290 °C slightly increased the period thickness and interface width. Annealing at higher temperatures resulted in significant structural changes and thickness ratio (Г = d_NiV/d) changes from 0.4 to 1/3 at 340 °C. The time-dependent results showed that the microstructural variations primarily occurred after 60 min. The XRD, XRS, GISAXS and TEM were further used to study microstructural changes. It was found that the NiV/B₄C multilayers exhibited a microcrystal structure after annealing, and that enhanced crystallinity and an increase in interface roughness were the main reasons for the microstructural changes. Full article

Grazing incidence small angle X-ray scattering (GISAXS) was used to study the structure and interparticle spacing of monolayers of organic ligand-stabilized iron oxide nanocrystals floating at the air–water interface on a Langmuir trough, and after transfer to a solid support via the Langmuir–Blodgett technique. GISAXS measurements of the nanocrystal arrangement at the air–water interface showed that lateral compression decreased the interparticle spacing of continuous films. GISAXS also revealed that Langmuir–Blodgett transfer of the nanocrystal layers to a silicon substrate led to a stretching of the film, with a significant increase in interparticle spacing. Full article

Femtosecond high-intensity laser pulses at intensities surpassing 10¹⁴ W/cm² can generate a diverse range of functional surface nanostructures. Achieving precise control over the production of these functional structures necessitates a thorough understanding of the surface morphology dynamics with nanometer-scale spatial resolution and picosecond-scale temporal resolution. In this study, we show that single XFEL pulses can elucidate structural changes on surfaces induced by laser-generated plasmas using grazing-incidence small-angle X-ray scattering (GISAXS). Using aluminium-coated multilayer samples we distinguish between sub-picosecond (ps) surface morphology dynamics and subsequent multi-ps subsurface density dynamics with nanometer-depth sensitivity. The observed subsurface density dynamics serve to validate advanced simulation models representing matter under extreme conditions. Our findings promise to open new avenues for laser material-nanoprocessing and high-energy-density science. Full article

The functionality and reliability of nanoscale multilayer devices and components are influenced by changes in stress and microstructure throughout fabrication, processing, and operation. NiV/B₄C multilayers with a d-spacing of 3 nm were prepared by magnetron sputtering, and two groups of annealing experiments were performed. The stress, microstructure, and interface changes in NiV/B₄C after annealing were investigated by grazing-incidence X-ray reflectometry (GIXR), grazing-incidence X-ray diffraction (GIXRD), X-ray diffuse scattering, and grazing-incidence small-angle X-ray scattering (GISAXS). The temperature dependence experiments revealed a gradual shift in the multilayer stress from compression to tension during annealing from 70 °C to 340 °C, with the stress approaching near-zero levels between 70 °C and 140 °C. The time-dependent experiments indicated that most of the stress changes occurred within the initial 10 min, which showed that prolonged annealing was unnecessary. Combining the X-ray diffraction and X-ray scattering measurements, it was found that the changes in the thickness, interface roughness, and lateral correlation length, primarily due to crystallization, drove the changes in stress and microstructure. Full article

Granular films SiO₂(Co) exhibit unusual magnetic and magnetotransport properties which are strongly dependent on the composition of the film and material of a substrate. For example, the injection magnetoresistance (IMR) coefficient reaches a giant (GIMR) value of 10⁵% at room temperature in SiO₂(Co) films on an n-GaAs substrate. However, the IMR effect is negligible in the case of a similar granular film deposited on the n-Si substrate. In this report, the structural and magnetic properties of granular film SiO₂(Co) on Si substrate are studied with the aim to understand the cause of the difference in IMR coefficients for SiO₂(Co) thin film deposited on n-GaAs and on n-Si substrates. Investigations were carried out using complementary methods of Polarized Neutron Reflectometry, Grazing Incidence Small-Angle X-ray Scattering, X-ray Reflectometry, Scanning Electron Microscope, and SQUID magnetometry. It is shown that the interface layer between the granular film and Si substrate exhibits metallic rather than magnetic properties and eliminates the GIMR effect. This interface layer is associated with the Si diffusion to Co nanoparticles and the formation of the metallic cobalt silicides. Full article

Grazing-incidence small-angle X-ray scattering (GISAXS) is a powerful method for the structural analysis of ordered arrays of nanoparticles, quantum dots, or similar objects. However, for the correct interpretation of the measured GISAXS intensity distributions, a proper data analysis, including a suitable model, is required. Here, we demonstrate a software platform, GisaxStudio, aimed at the analysis and simulation of 2D GISAXS intensity distributions from ordered lattices of different nanoparticles. It contains several models that satisfactorily describe the GISAXS from 3D lattices or crystals of nanoparticles prepared by the self-assembly processes, pre-pattering, or ion-beam interaction with the material within their tracks. It also supports different shapes of nanoparticles, including core-shell structure with the center of core possibly displaced from the center of the shell. The software is very useful for fast and accurate GISAXS data analysis. Full article

Fluorine-doped tin oxide thin films (SnO₂:F) are widely used as transparent conductive oxide electrodes in thin-film solar cells because of their appropriate electrical and optical properties. The surface morphology of these films influences their optical properties and therefore plays an important role in the overall efficiencies of the solar cells in which they are implemented. At rough surfaces light is diffusely scattered, extending the optical path of light inside the active layer of the solar cell, which in term improves light absorption and solar cell conversion efficiency. In this work, we investigated the surface morphology of undoped and doped SnO₂ thin films and their influence on the optical properties of the films. We have compared and analysed the results obtained by several complementary methods for thin-film surface morphology investigation: atomic force microscopy (AFM), transmission electron microscopy (TEM), and grazing-incidence small-angle X-ray scattering (GISAXS). Based on the AFM and TEM results we propose a theoretical model that reproduces well the GISAXS scattering patterns. Full article

Various types of 2D organic–inorganic perovskite solar cells have been developed and investigated due to better electron transport behavior and environmental stability. Controlling the formation of phases in the 2D perovskite films has been considered to play an important role in influencing the stability of perovskite materials and their performance in optoelectronic applications. In this work, Lewis base urea was used as an effective additive for the formation of 2D Ruddlesden—Popper (RP) perovskite (BA)₂(MA)_n−1Pb_nI_3n+1 thin film with mixed phases (n = 2~4). The detailed structural morphology of the 2D perovskite thin film was investigated by in situ X-ray diffraction (XRD), grazing-incidence small-angle X-ray scattering (GISAXS) and photoluminescence mapping. The results indicated that the urea additive could facilitate the formation of 2D RP perovskite thin film with larger grain size and high crystallinity. The 2D RP perovskite thin films for solar cells exhibited a power conversion efficiency (PCE) of 7.9% under AM 1.5G illumination at 100 mW/cm². Full article

We reported on the interaction between poly(3,4-ethylenedioxythiophene):polystyrene sulfonate (PEDOT:PSS) and high-boiling-point additives in PEDOT:PSS aqueous dispersions and in the final polymer films with the aim of stablishing correlations between the structure of both inks and solid thin films. By Small-Angle X-ray Scattering (SAXS) using synchrotron radiation, it was found that the structural changes of dispersions of PEDOT:PSS with high-boiling-point additives can be explained as a two-step mechanism depending on the additive concentration. A compaction of PEDOT:PSS grains was observed at low concentrations while a swelling of the grains together with a phase segregation between PEDOT and PSS segments was evidenced at larger concentrations. Thin films’ morphology and structure were investigated by atomic force microscopy (AFM) and synchrotron Grazing Incidence Wide-Angle X-ray Scattering (GIWAXS) respectively. Our two-step model provides an explanation for the small and sharp domains of PEDOT:PSS thin films observed for low-additive concentrations (first step) and larger domains and roughness found for higher-additive concentrations (second step). A reduction of the ratio of PSS in PEDOT:PSS thin films upon the presence of additives was also observed. This can be related to a thinning of the PSS shells of PEDOT:PSS grains in the dispersion. The results discussed in this work provide the basis for a controlled tuning of PEDOT:PSS thin films structure and the subsequent electrical properties. Full article

The impact of several solvent processing additives (1-chloronaphthalene, methylnaphthalene, hexadecane, 1-phenyloctane, and p-anisaldehyde), 3% v/v in o-dichlorobenzene, on the performance and morphology of poly[(5,6-difluoro-2,1,3-benzothiadiazol-4,7-diyl)-alt-(3,3‴-di(2-octyldodecyl)-2,2′,5′,22033,5″,2‴-quaterthiophen-5,5‴-diyl)] (PffBT4T-2OD):[6,6]-phenyl-C71-butyric acid methyl ester (PC₇₁BM)-based polymer solar cells was investigated. Some additives were shown to enhance the power conversion efficiency (PCE) by ~6%, while others decreased the PCE by ~17–25% and a subset of the additives tested completely eliminated any power conversion efficiency and the operation as a photovoltaic device. Grazing-Incidence Wide Angle X-ray Scattering (GIWAXS) revealed a clear stepwise variation in the crystallinity of the systems when changing the additive between the two extreme situations of maximum PCE (1-chloronaphthalene) and null PCE (hexadecane). Small-Angle Neutron Scattering (SANS) revealed that the morphology of devices with PCE ~0% was composed of large domains with correlation lengths of ~30 nm, i.e., much larger than the typical exciton diffusion length (~12 nm) in organic semiconductors. The graded variations in crystallinity and in nano-domain size observed between the two extreme situations (1-chloronaphthalene and hexadecane) were responsible for the observed graded variations in device performance. Full article

Nanostructured metal assemblies on thin and ultrathin polymeric films enable state of the art technologies and have further potential in diverse fields. Rational design of the structure–function relationship is of critical importance but aggravated by the scarcity of systematic studies. Here, we studied the influence of the interplay between metal and polymer surface free energy and reactivity on the evolution of electric conductivity and the resulting morphologies. In situ resistance measurements during sputter deposition of Ag, Au, Cu and Ni films on ultrathin reticulated polymer films collectively reveal metal–insulator transitions characteristic for Volmer–Weber growth. The different onsets of percolation correlate with interfacial energy and energy of adhesion weakly but as expected from ordinary wetting theory. A more pronounced trend of lower percolation thickness for more reactive metals falls in line with reported correlations. Ex situ grazing incidence small angle X-ray scattering experiments were performed at various thicknesses to gain an insight into cluster and film morphology evolution. A novel approach to interpret the scattering data is used where simulated pair distance distributions of arbitrary shapes and arrangements can be fitted to experiments. Detailed approximations of cluster structures could be inferred and are discussed in view of the established parameters describing film growth behavior. Full article

Polyether ether ketone (PEEK) films irradiated with 170 keV protons were calculated by the stopping and ranges of ions in matter (SRIM) software. The results showed that the damage caused by 170 keV protons was only several microns of the PEEK surface, and the ionization absorbed dose and displacement absorbed dose were calculated. The surface morphology and roughness of PEEK after proton irradiation were studied by atomic force microscope (AFM). GISAXS was used to analyze the surface structural information of the pristine and irradiated PEEK. The experimental results showed that near the surface of the pristine and irradiated PEEK exists a peak, and the peak gradually disappeared with the increasing of the angles of incidence and the peak changed after irradiation, which implies the 170 keV protons have an effect on PEEK structure. The influences of PEEK irradiated with protons on the melting temperature and crystallization temperature was investigated by differential scanning calorimetry (DSC). The DSC results showed that the crystallinity of the polymer after irradiation decreased. The structure and content of free radicals of pristine and irradiated PEEK were studied by Fourier transform infrared spectroscopy (FTIR) and electron paramagnetic resonance (EPR). The stress and strain test results showed that the yield strength of the PEEK irradiated with 5 × 10¹⁵ p/cm² and 1 × 10¹⁶ p/cm² was higher than the pristine, but the elongation at break of the PEEK irradiated with 5 × 10¹⁵ p/cm² and 1 × 10¹⁶ p/cm² decreased obviously. Full article

Quantum dots are under intense research, given their amazing properties which favor their use in electronics, optoelectronics, energy, medicine and other important applications. For many of these technological applications, quantum dots are used in their ordered self-assembled form, called superlattice. Understanding the mechanism of formation of the superlattices is crucial to designing quantum dots devices with desired properties. Here we review some of the most important findings about the formation of such superlattices that have been derived using grazing incidence scattering techniques (grazing incidence small and wide angle X-ray scattering (GISAXS/GIWAXS)). Acquisition of these structural information is essential to developing some of the most important underlying theories in the field. Full article

Organic electronics became an attractive alternative for practical applications in complementary logic circuits due to the unique features of organic semiconductors such as solution processability and ease of large-area manufacturing. Bulk heterojunctions (BHJ), consisting of a blend of two organic semiconductors of different electronic affinities, allow fabrication of a broad range of devices such as light-emitting transistors, light-emitting diodes, photovoltaics, photodetectors, ambipolar transistors and sensors. In this work, the charge carrier transport of BHJ films in field-effect transistors is switched from electron to hole domination upon processing and post-treatment. Low molecular weight n-type N,N′-bis(n-octyl)-(1,7&1,6)-dicyanoperylene-3,4:9,10-bis(dicarboximide) (PDI8-CN₂) was blended with p-type poly[2,5-bis(3-tetradecylthiophene-2-yl)thieno[3,2-b]thiophene] (PBTTT-C₁₄) and deposited by spin-coating to form BHJ films. Systematic investigation of the role of rotation speed, solution temperature, and thermal annealing on thin film morphology was performed using atomic force microscopy, scanning electron microscopy, and grazing incidence wide-angle X-ray scattering. It has been determined that upon thermal annealing the BHJ morphology is modified from small interconnected PDI8-CN₂ crystals uniformly distributed in the polymer fraction to large planar PDI8-CN2 crystal domains on top of the blend film, leading to the switch from electron to hole transport in field-effect transistors. Full article
