Recent advancements in head-up-displays have increased the number of instances where the visual system may face a different accommodative demand for each eye. A limited number of studies on aniso-accommodation exist, reporting contradictory results. We tested the natural capacity of observers to aniso-accommodate anisometropic stimuli. A dichoptic task allowed us to account for certain confounds, including high-level accommodation control. A 2AFC visual task was used, where participants judged if two overlapping sinusoidal gratings, presented dichoptically, had the same orientation. The gratings’ spatial frequency could be 1, 4 or 10 c/deg. The accommodative demand for each eye could be independently set to 2D or 4D. The accommodative response for each eye was recorded using an autorefractometer. Higher spatial frequencies and anisometropy had a negative impact on task accuracy. Contrary to expectations, spatial frequencies had no significant impact on accommodation response. The accommodation response to anisometropic stimuli was equal in the two eyes and leaned toward the lower of two demands. Our results confirm that when presented with asymmetrical accommodation demand, the two eyes tend to keep the same refractive power even in a dichoptic-requiring task. They also contradict the guidance of accommodation by spatial frequency in sinusoidal gratings. The visual task provided an objective measure of subjects’ performance, allowing for these conclusions to be drawn. Full article

This work aims at the determination of the coefficient of thermal expansion (CTE) of parts manufactured through the Fused Deposition Modeling process, employing fiber Bragg grating (FBG) sensors. Pure thermoplastic and composite specimens were built using different commercially available filament materials, including acrylonitrile butadiene styrene, polylactic acid, polyamide, polyether-block-amide (PEBA) and chopped carbon fiber-reinforced polyamide (CF-PA) composite. During the building process, the FBGs were embedded into the middle-plane of the test specimens, featuring 0° and 90° raster printing orientations. The samples were then subjected to thermal loading for measuring the thermally induced strains as a function of applied temperature and, consequently, the test samples’ CTE and glass transition temperature (T_g) based on the recorded FBG wavelengths. Additionally, the integrated FBGs were used for the characterization of the residual strain magnitudes both at the end of the 3D printing process and at the end of each of the two consecutively applied thermal cycles. The results indicate that, among all tested materials, the CF-PA/0° specimens exhibited the lowest CTE value of 14 × 10⁻⁶/°C. The PEBA material was proven to have the most isotropic thermal response for both examined raster orientations, 0° and 90°, with CTE values of 117 × 10⁻⁶/°C and 108 × 10⁻⁶/°C, respectively, while similar residual strains were also calculated in both printing orientations. It is presented that the followed FBG-based methodology is proven to be an excellent alternative experimental technique for the CTE characterization of materials used in 3D printing. Full article

This study used scanning electron microscopy via 3D dissection coupled with synchrotron radiation with microfocal beams of both small-angle X-ray scattering and wide-angle X-ray diffraction to analyze the periodic crystal aggregates of unusual poly(p-dioxanone) (PPDO) dendritic cactus-arm-like ring bands upon crystallization with a diluent poly(vinyl alcohol) (PVA) that is capable of hydrogen bonding interactions with PPDO. Three-dimensional microscopy interior dissection clearly expounds that the banded periodic architectures are packed by alternately normal-oriented flat-on crystals underneath the valley, periodically interfaced/branched with horizontal-oriented edge-on fibrils underneath the ridge. The oblique angles between the valley’s flat-on crystals with the branches are ca. 25–45° (depending on gradient inclines and bending), which is also proved by the azimuthal angle in microbeam X-ray diffraction. The grating-like strut-rib assembly in the PPDO cactus-arm-like ring bands is further proved by novel iridescence tests. Full article

Binocular rivalry is the perceptual dominance of one visual stimulus over another. Conventionally, binocular rivalry is induced using a mirror-stereoscope—a setup involving mirrors oriented at an angle to a display. The respective mirror planes fuse competing visual stimuli in the observer’s visual field by projecting the stimuli through the stereoscope to the observed visual field. Since virtual-reality head-mounted displays fuse dichoptic vision in a similar way, and since virtual-reality head-mounted displays are more versatile and more readily available than mirror stereoscopes, this study investigated the efficacy of using a virtual-reality headset (Oculus Rift-S) as an alternative to using a mirror stereoscope to study binocular rivalry. To evaluate the validity of using virtual-reality headsets to induce visual dominance/suppression, two identical experimental sequences—one using a conventional mirror stereoscope and one using a virtual-reality headset—were compared and evaluated. The study used Gabor patches at different orientations to induce binocular rivalry and to evaluate the efficacy of the two experiments. Participants were asked to record all instances of perceptual dominance (complete suppression) and non-dominance (incomplete suppression). Independent sample t-tests confirmed that binocular rivalry with stable vergence was successfully induced for the mirror-stereoscope experiment (t = −4.86; p ≤ 0.0001) and the virtual-reality experiment (t = −9.41; p ≤ 0.0001). Using ANOVA to compare Gabor patch pairs of gratings at +45°/−45° orientations presented in both visual fields, gratings at 0°/90° orientations presented in both visual fields, and mixed gratings (i.e., unconventional grating pairs) presented in both visual fields, the performance of the two experiments was evaluated by comparing observation duration in seconds (F = 0.12; p = 0.91) and the alternation rate per trial (F = 8.1; p = 0.0005). The differences between the stimulus groups were not statistically significant for the observation duration but were significantly different based on the alternation rates per trial. Moreover, ANOVA also showed that the dominance durations (F = 114.1; p < 0.0001) and the alternation rates (F = 91.6; p < 0.0001) per trial were significantly different between the mirror-stereoscope and the virtual-reality experiments, with the virtual-reality experiment showing an increase in alternation rate and a decrease in observation duration. The study was able to show that a virtual-reality head-mounted display can be used as an effective and novel alternative to induce binocular rivalry, but there were some differences in visual bi-stability between the two methods. This paper discusses the experimental measures taken to minimise piecemeal rivalry and to evaluate perceptual dominance between the two experimental designs. Full article

The array position and orientation system (array POS), composed of one main POS and multiple sub-inertial measurement units (sub-IMUs), is key equipment in the aerial remote-sensing system, especially the multi-load system, which can provide motion compensation for the multi-load remote-sensing system to improve imaging quality. Nevertheless, the measurement information of each sub-IMU can only realize the motion information of the corresponding remote-sensing load. Ideally, each remote-sensing load should be equipped with a sub-IMU for motion compensation, which is impossible in actual engineering considering the volume, weight and cost. To solve this problem, a multi-node motion estimation method based on the B-spline of the array POS is proposed to realize the motion compensation of remote-sensing loads without sub-IMUs. Firstly, the transfer alignment method based on fiber-grating multi-dimensional deformation measurement was adopted. Motion parameters of the remote-sensing payload equipped with sub-IMUs at different times can be obtained by observing and correcting the errors between the main POS and sub-IMUs. In this way, the space-time characteristics of each interpolation point are fully utilized. Additionally, the motion information of the main POS and all sub-IMUs is fitted through the estimation method based on the B-spline, during which wing deformation is considered to obtain the motion parameters of the remote-sensing payload equipped without a sub-IMU. In this way, the spatial correlation between the information of each node is fully utilized. Due to the full utilization of the spatiotemporal correlation of the motion information of each sub node, high-precision and highly reliable motion information of the remote-sensing loads not equipped with sub-IMUs is obtained. Furthermore, the proposed method can be modified locally without affecting other nodes, and has the advantages of a simple algorithm and easy engineering implementation. Finally, a semi-physical simulation based on ground-loading test was conducted. The results show that the baseline in the X-axis, Y-axis and Z-axis direction is improved by 0.484 mm, 0.137 mm and 1.225 mm, respectively, and that the measurement accuracy of roll angle is improved by 0.011°. Full article

Several methods for the measurement of tactile acuity have been devised previously, but unexpected nonspatial cues and intensive manual skill requirements compromise measurement accuracy. Therefore, we must urgently develop an automated, accurate, and noninvasive method for assessing tactile acuity. The present study develops a novel method applying a robotic tactile stimulator to automatically measure tactile acuity that comprises eye-opened, eye-closed training, and testing sessions. Healthy participants judge the orientation of a rotating grating ball presented on their index fingerpads in a two-alternative forced-choice task. A variable rotation speed of 5, 10, 40, or 160 mm/s was used for the tactile measurement at a variety of difficulties. All participants met the passing criteria for the training experiment. Performance in orientation identification, quantified by the proportion of trials with correct answers, differed across scanning directions, with the highest rotation speed (160 mm/s) having the worst performance. Accuracy did not differ between vertical and horizontal orientations. Our results demonstrated the utility of the pre-test training protocol and the functionality of the developed procedure for tactile acuity assessment. The novel protocol performed well when applied to the participants. Future studies will be conducted to apply this method to patients with impairment of light touch. Full article

Optofluidics is a constantly developing research area that combines known technologies from chemistry and photonics. Various systems have been created, which are used in biology and chemistry as well as in other subjects. The combination of materials such as polydimethylsiloxane (PDMS) and liquid crystal (LC) provides a number of possibilities to create functional structures. The properties of LC allow systems to be developed in PDMS, e.g., lenses with different focal lengths depending on the polarization of light or multiplexers have been proposed. Appropriately controlling LC molecule orientation is a crucial element in creating tunable systems. The motivation of this research is to determine the proper arrangement of an electrode array to control the orientation of liquid crystal molecules and thus the refractive index. The performed tests allowed the initial parameters to be determined to produce LC:PDMS structures with a periodic orientation of LC molecules. As the channel sizes have to be micrometer-scale, a proper electrode arrangement has to be developed. The materials from which electrodes can be created are also limited due to PDMS properties as well as the size of the channels. The plan is to create a tunable LC:PDMS structure with LC molecules in a periodic reorientation, which would allow the system to function as a tunable Bragg grating. It would be the first achievement of this kind, and it would open up new possibilities for the combination of liquid crystal and PDMS in photonic systems. Full article

We report on the calibration and testing of a fiber Bragg grating (FBG)-based 2D-shape sensing strip for real-time monitoring of the position and orientation of the human spine during gait. The strip is evaluated for its use as an input for control of an exoskeleton for patients with spinal cord injury. By measuring the torsion and bending of the back, walking movements can be reconstructed. The 3D-printed strip has nine embedded fiber Bragg gratings that are located at specific places with respect to the vertebral column. Three FBGs are placed opposite to the thoracic vertebrae T6–T9, these FBGs are sensitive for measuring the bending of the spine during the gait cycle. Torsion is measured at two locations: at thoracic vertebra, T3 and at lumbar vertebra, L3. At these locations, the width of the strip is reduced to have a larger sensitivity for torsion. The strain at each FBG is measured using an interrogator. This leads to the radius of curvature and torsion as a function of time. The Frenet-Serret formulae are used to calculate the shape of the strip during the gait cycle. We have calibrated this FBG strip for curvature by bending it at known radius of different curvatures. We found a linear dependence between the strain and curvature. For torsion calibration we have rotated the strip with a stepper motor at different angles and monitored the strain. We, again, found a linear dependence with a small hysteresis. We mounted the strip on a healthy test subject and monitored their gait cycle. The FBG strip shows similar results when compared to a motion capture system based on multiple cameras. Although the fixation of the strip to a garment or on the back directly strongly influences the measured response, it does show a periodic and reproducible signal during the gait cycle. Full article

We propose and demonstrate a novel high-temperature-resistant vector accelerometer, consisting of a ring cavity laser and sensing probe (i.e., fiber Bragg gratings (FBGs)) inscribed in a seven-core fiber (SCF) by using the femtosecond laser direct writing technique. A ring cavity laser serves as a light source. Three FBGs in the outer cores of SCF, which are not aligned in a straight line, are employed to test the vibration. These three FBGs have 120° angular separation in the SCF, and hence, vibration orientation and acceleration can be measured simultaneously. Moreover, the FBG in the central core was used as a reflector in the ring cavity laser, benefiting to resist external interference factors, such as temperature and strain fluctuation. Such a proposed accelerometer exhibits a working frequency bandwidth ranging from 4 to 68 Hz, a maximum sensitivity of 54.2 mV/g, and the best azimuthal angle accuracy of 0.21° over a range of 0–360°. Furthermore, we investigated the effect of strain and temperature on the performance of this sensor. The signal-to-noise ratio (SNR) only exhibits a fluctuation of ~1 dB in the range (0, 2289 με) and (50 °C, 1050 °C). Hence, such a vector accelerometer can operate in harsh environments, such as in aerospace and a nuclear reactor. Full article

It is increasingly being understood that perceptual learning involves different types of plasticity. Thus, whereas the practice-based improvement in the ability to perform specific tasks is believed to rely on top-down plasticity, the capacity of sensory systems to passively adapt to the stimuli they are exposed to is believed to rely on bottom-up plasticity. However, top-down and bottom-up plasticity have never been investigated concurrently, and hence their relationship is not well understood. To examine whether passive exposure influences perceptual performance, we asked subjects to test their orientation discrimination performance around and orthogonal to the exposed orientation axes, at an exposed and an unexposed location while oriented sine-wave gratings were presented in a fixed position. Here we report that repetitive passive exposure to oriented sequences that are not linked to a specific task induces a persistent, bottom-up form of learning that is stronger than top-down practice learning and generalizes across complex stimulus dimensions. Importantly, orientation-specific exposure learning led to a robust improvement in the discrimination of complex stimuli (shapes and natural scenes). Our results indicate that long-term sensory adaptation by passive exposure should be viewed as a form of perceptual learning that is complementary to practice learning in that it reduces constraints on speed and generalization. Full article

In this paper, the application of a fiber Bragg grating written in a highly birefringent side-hole elliptical core optical fiber for two-axial strain measurement is presented. Hybrid optical fiber structures achieved by combining large side-holes and elliptical core result in a very high birefringence of 1 × 10⁻³ and thus high initial Bragg peak spectral separation of 1.16 nm, as well as a very high transverse force sensitivity, of up to 650 pm/(N/mm) or even −1150 pm/(N/mm), depending on the fiber orientation with respect to the applied force. Due to the ~22 %m/m GeO₂ concentration in the core the fiber being highly photosensitive, which significantly simplifies FBG fabrication by UV illumination without the need for prior hydrogen loading, which worsens thermal stability. Finally, the developed FBGs written in the highly birefringent side-hole elliptical core optical fiber were embedded in the square composite plates and applied for strain measurements. Tests of two-directional four-point bending have shown usability of such FBG for two-axial in-plane strain measurement with a single FBG in iso-thermal conditions. Full article

In a specific biosensing application, a nanoplasmonic sensor chip has been tested by an experimental setup based on an aluminum holder and two plastic optical fibers used to illuminate and collect the transmitted light. The studied plasmonic probe is based on gold nanograting, realized on the top of a Poly(methyl methacrylate) (PMMA) chip. The PMMA substrate could be considered as a transparent substrate and, in such a way, it has been already used in previous work. Alternatively, here it is regarded as a slab waveguide. In particular, we have deposited upon the slab surface, covered with a nanograting, a synthetic receptor specific for bovine serum albumin (BSA), to test the proposed biosensing approach. Exploiting this different experimental configuration, we have determined how the orientation of the nanostripes forming the grating pattern, with respect to the direction of the input light (longitudinal or orthogonal), influences the biosensing performances. For example, the best limit of detection (LOD) in the BSA detection that has been obtained is equal to 23 pM. Specifically, the longitudinal configuration is characterized by two observable plasmonic phenomena, each sensitive to a different BSA concentration range, ranging from pM to µM. This aspect plays a key role in several biochemical sensing applications, where a wide working range is required. Full article

Few methodological approaches have been developed to measure lingual tactile sensitivity, and little information exists about the comparison between children and adults. The aims of the study were to: verify the cognitive and perceptive suitability of Von Frey filaments and a gratings orientation test in children of different ages; compare lingual tactile sensitivity between children and adults; investigate the relationships between lingual tactile sensitivity, preference and consumption of foods with different textures and level of food neophobia. One hundred and forty-seven children aged 6–13 years and their parents participated in the study, in addition to a separate sample of seventy adults. Participants filled in questionnaires, and lingual tactile sensitivity was evaluated through filaments and gratings. Results showed that gratings evaluation was more difficult than filaments assessment but enabled a better separation of participants according to their performance than filaments. R-indices from filaments were not correlated with those of gratings, suggesting that the tools measure different dimensions of lingual tactile sensitivity. No differences were found in lingual tactile sensitivity between children and adults, nor between children of different ages. Food neophobia was negatively associated with preferences of hard foods in children. Although a multifactor analysis concluded that neither texture preferences nor food consumption were strongly correlated with lingual tactile sensitivity, there was a weak but significant positive correlation between lingual tactile sensitivity to the finest Von Frey filament and food neophobia in the youngest age group, indicating that children with higher levels of food neophobia are more sensitive to oral tactile stimuli. Suitable child-friendly adaptations for the assessment of lingual sensitivity in children are discussed. Full article

Fibre Bragg Grating (FBG) sensors are gaining popularity in biomedical engineering. However, specific standards for in vivo testing for their use are absolutely limited. In this study, in vitro experimental tests were performed to investigate the behaviors and applications of gratings attached to intact and fractured thighbone for a range of compression loading (<300 N) based around some usual daily activities. The wavelength shifts and the corresponding strain sensitivities of the FBG sensors were measured to determine their effectiveness in monitoring the femoral fracture healing process. Four different arrangements of FBG sensors were selected to measure strains at different critical locations on the femoral sawbones surface. Data obtained for intact and plated sawbones were compared using both embedded longitudinal and coiled FBG arrays. Strains were measured close to the fracture, posterior linea aspera and popliteal surface areas, as well as at the proximal and distal ends of the synthetic femur; their responses are discussed herein. The gratings on the longitudinally secured FBG arrays were found to provide high levels of sensitivity and precise measurements, even for relatively small loads (<100 N). Nevertheless, embedding angled FBG sensors is essential to measure the strain generated by applied torque on the femur bone. The maximum recorded strain of the plated femur was 503.97 µε for longitudinal and −274.97 µε for coiled FBG arrays, respectively. These project results are important to configure effective arrangements and orientations of FBG sensors with respect to fracture position and fixation implant for future in vivo experiments. Full article

To perform zebrafish larvae-related experiments within a microfluidic environment, the larvae need to be anesthetized and subsequently transported into respective test sections through mechanical or manual means. However, anesthetization tends to affect larval sensory perceptions, hindering their natural behaviors. Taking into account that juvenile larvae move naturally within their environment by accessing visual as well as hydromechanical cues, this work proposes an experimental framework to transport nonanesthetized larvae within a microfluidic environment by harmonically tuning both of the aforementioned cues. To provide visual cues, computer-animated moving gratings were provided through an in-house-developed control interface that drove the larval optomotor response. In the meantime, to provide hydromechanical cues, the flow rate was tuned using a syringe pump that affected the zebrafish larvae’s lateral line movement. The results obtained (corresponding to different test conditions) suggest that the magnitude of both modalities plays a crucial role in larval transportation and orientation control. For instance, with a flow rate tuning of 0.1 mL/min along with grating parameters of 1 Hz temporal frequency, the average transportation time for larvae that were 5 days postfertilization was recorded at 1.29 ± 0.49 s, which was approximately three times faster than the transportation time required only in the presence of hydromechanical cues. Full article
