Search Results (38)

An analytical approach is developed for calculating a phase diffraction axicon with angularly variable spatial frequency that generates a prescribed light curve without iteratively solving an inverse design problem: the axicon frequency function is obtained directly from the polar equation of the target curve. When the axicon is combined with a lens, the intended curve is formed in the focal plane (Fraunhofer region), whereas in the Fresnel zone the intensity pattern is closely related to the curve’s evolute. We systematize this correspondence for rings, ellipses, spirals and polygonal curves, and derive analytical parameter bounds associated with the appearance of inflection points that qualitatively reshape both the evolute and the diffracted field (including hybrid curve–evolute patterns and “rose”-type contours). The qualitative outcome depends on the curve class/type. For a convex curve without inflections the expected curve is formed in in the far field (or in the focal plane), whereas the Fresnel intensity envelope follows the evolute. If the curve has peculiarities, especially inflection points with unbounded evolute branches, hybrid curve–evolute structure appears, and the focal pattern may itself resemble the evolute. For ellipses and polygonal families we analytically identify parameter intervals that mark this transition. The approach is verified experimentally for polygonal axicons, with attention to fabrication tolerances and to matching camera planes with the simulated propagation distances. Measured intensity distribution patterns agree with the corresponding simulations for both convex contours and curves that contain inflection points. The results are of fundamental interest and of practical value for optical trapping and laser surface structuring, where a compact phase element should deliver a controlled bright contour at a chosen working distance. Full article

This work presents a refined theoretical and numerical framework for shaping the axial intensity of finite-energy Bessel–Gaussian beams through programmable nonlinear phase modulation. Starting from the scalar Fresnel diffraction integral, we reformulate the propagation of a Gaussian-apodized axicon beam using a dimensionally consistent stationary-phase method. This analysis directly relates the radial phase gradient to the saddle-point trajectory, phase curvature, and on-axis intensity distribution. A Gaussian phase modulation (GPM) serves as a reference design to achieve a flattop axial profile while preserving the characteristic transverse Bessel ring structure. This work is validated against beam propagation simulations and previously reported spatial light modulator (SLM) experiments, confirming its accuracy within the paraxial regime. A parametric study then clarifies the scaling of wavelength, beam waist, axicon angle, and refractive index for extended focusing. Beyond standard GPM, several alternative nonlinear phase functions are systematically compared. High-performing profiles must replicate not only the amplitude scale but, more importantly, the radial phase-gradient structure of the Gaussian reference, which governs energy redistribution from annular regions to the axis. The results identify smooth, localized nonlinear functions as promising candidates for stable flattop Bessel beam generation. The proposed framework offers a flexible optical design for applications such as through-glass via (TGV) micromachining and light-sheet illumination, while prospective high-intensity laser plasma uses remain beyond the present linear model. Full article

A vector vortex beam (VVB) combines the phase singularity of a vortex beam (VB) with the anisotropic polarization of a vector beam, enabling the transmission of complex optical information and offering broad application prospects in optical sensing, high-capacity communication, and high-resolution imaging. In this work, we present a detailed theoretical analysis of the generation and detection of VVBs with Laguerre–Gaussian (LG) and Bessel–Gaussian (BG) forms. Particular emphasis is placed on the polarization characteristics of VVBs, the evolution of beam profiles after passing through polarizers with different orientations, and the interference features arising from the coaxial superposition of a VVB with a circularly polarized divergent spherical wave. To validate the theoretical analysis, LGVVBs were experimentally generated using a Mach–Zehnder interferometer by superposing two vortex beams with opposite topological charges and orthogonal circular polarizations. Furthermore, the introduction of an axicon enabled the direct conversion of LGVVBs into BGVVBs. The excellent agreement between theoretical predictions and experimental observations lays a solid foundation for beginners to systematically understand VVB characteristics and advance future research. Full article

To design novel imaging devices, we use masks coded with numerical sequences. These masks work in conjunction with varifocal systems that implement zero-throw tunable magnification. Some masks control field depth, even when the size of the pupil aperture remains fixed. Pairs of vortex masks are used to implement tunable phase radial profiles, like axicons and lenses. The autocorrelation properties of the Barker sequences are applied to the generation of narrow passband windows on the OTF. For this application, we apply Barker matrices in rectangular coordinates. A similar procedure, but now in polar coordinates, is useful for sensing in-plane rotations. We implement geometrical transformations by using zero-throw, tunable, anamorphic magnifications. Full article

Vector beams (VBs) with longitudinally varying polarization states provide a new dimension for light field manipulation, and promote the advancements of related areas such as optical metrology, longitudinal depth detection, and classical and quantum communications. In this study, we propose a half-wave plate dielectric metasurface based on a spatial partitioning method, realizing the longitudinal manipulation of the polarization states of higher-order Poincaré (HOP) beams by changing the elliptical polarization state of the incident light and selecting the appropriate propagation distances. The metasurface is composed of two sub-metasurfaces, and the two sets of a-Si:H meta-atoms are uniformly arranged on concentric rings of different radii with an equal interval. The propagation and Pancharatnam–Berry phases are utilized to construct the axicon and helical phase profiles. As a result, two sub-metasurfaces, respectively, generate the first- and second-order VBs with longitudinally varying polarization states. The polarization states of generated VBs correspond to points on different meridians of nth-order HOP spheres from the south pole to the north pole. The consistency between the theoretical and simulated results demonstrates the feasibility and practicability of the proposed method. This study provides an innovative strategy to extend the modulation of light fields from two-dimensional to three-dimensional space. Full article

The conventional method of cutting quartz glass with a knife often leads to undesirable effects, such as chipping, debris generation, and an inconsistent cut quality. Additionally, implementing the current methods of laser ablation cutting and crack control cutting presents challenges in ensuring both the quality of the cut and the efficiency of the process. Previous reports have documented a single direct cut of thin quartz glass, albeit at a thickness of only 200 μm. In this study, we utilized a pulse-width-tunable Gaussian beam, in combination with an axicon and a beam-reducing mirror, to generate a high-quality Bessel beam. This process endows the quartz glass with a nano-porous structure with a thickness of 1 mm, enabling high-quality cutting in a single pass. The effects of laser-cutting speed and pulse width on the cutting cross-section and cut surface were investigated. The results of the experiments show that using the optimal cutting speed and pulse width significantly improved cutting quality, reduced surface damage and sputtering, enabled the penetration of the modified cutting cross-section throughout the material, and decreased cutting cross-section roughness to 607 nm Ra. This technique holds promise for the laser-processing industry, enhancing both the quality and efficiency of cutting 1 mm thick quartz glass. Full article

The best focus point of a focused Gaussian beam subject to a phase aberration is generally shifted with respect to the focal plane of the focusing lens. This focus shift is attributed to a lensing effect that belongs to the phase aberration, which mean focal length can be determined from the aberration coefficients determined in the framework of a Zernike polynomial decomposition. In this paper, we have checked the validity of this procedure, already available in literature, applied to three aberration types: a pure primary spherical aberration, the Kerr effect induced by a Gaussian beam, and an axicon illuminated by a Gaussian beam. Note that usually, the mean focal length of an aberrated lens is based on the relation between the effective radius of curvature of the wavefront before and after the lens. However, in this paper, the focal length associated with the phase aberration under study is defined from the point of the best focus, where the diffracted intensity on the axis is the maximum. Full article

In this work, we demonstrate a Watt-level, high-quality Laguerre–Gaussian (LG) LG_0±1 vortex mode directly output from an end-pumped Nd:YVO₄ laser by using an axicon-based annular pump beam. A theoretical model for the annular beam end-pumped solid-state laser with an LG vortex mode output was established. Chirality control of the vortex laser was achieved by carefully tilting the output coupler. Watt-level 1064 nm lasers with pure LG_0,1/LG_0,−1 vortex mode, and the incoherent superposition mode of LG_0,1 odd and even petal modes, were achieved successively in our experiments. The intensity profile of the generated pure LG_0,1 vortex laser was measured, and it can be well fitted by using the standard expression of the LG_0,1 vortex mode. The beam quality of the pure LG_0,1 mode is M_x² = 2.01 and M_y² = 2.00 along the x-axis and y-axis, respectively. Our study demonstrates that that axicon-based annular pumping has great potential in developing high-power vortex solid-state lasers with simple and compact structures. Full article

The generation of optical beam arrays with prospective uses within the realms of microscopy, photonics, non-linear optics, and material processing often requires Dammann gratings. Here, we report the direct fabrication of one- and two-dimensional Dammann grating-like structures on soda lime glass using a nanosecond pulsed laser beam with a 1064 nm wavelength. Using the fabricated grating, an axicon lens, and an optical magnification system, we propose a scheme of generation of a diverging array of zero-order Bessel beams with a sub-micron-size central core, extending longitudinally over several hundred microns. Two different grating fabrication strategies are also proposed to control the number of Bessel beams in an array. It was demonstrated that Bessel beams of 12 degrees conical half-angle in an array of up to [5 × 5] dimensions can be generated using a suitable combination of Dammann grating, axicon lens and focusing optics. Full article

Tunable circular devices made of liquid crystals or other materials, like lenses, axicons, or phase plates, are often constrained by limitations in size, tunability, power, and other parameters. These constraints restrict their use and limit their applicability. In this review, a thorough study of the use of light’s orbital angular momentum in the manufacturing of liquid crystal (LC) devices is presented. Twisted light fosters the simultaneous optimization of most critical parameters. Experimental demonstrations of the unmatched performance of tunable LC lenses, axicons, and other elements in parameters such as lens diameter (>1″), power and tunability (>±6 diopters), fill factor (>98%), and time response have been achieved by reversible vortex generation created by azimuthal phase delay. This phase delay can eventually be removed within the optical system so that lens performance is not affected. Full article

We have experimentally created perfect vortex beams (PVBs) by Fourier transformation of Bessel–Gaussian vortex beams, which are generated by modulating the fundamental Gaussian beam with the spiral phase plates and the axicons, respectively. Although the method has been used many times by other authors, as far as we know, few people pay attention to the quantitative relationship between the control parameters of the PVB and ring width. The effects of the waist radius of the fundamental Gaussian beam w_g, base angle of the axicon γ, and focal length of the lens f on the spot parameters (ring radius ρ, and ring half-width Δ) of PVB are systematically studied. The beam pattern of the generated Bessel–Gaussian beam for different propagation distances behind the axicon and the fundamental Gaussian beam w_g is presented. We showed experimentally that the ring radius ρ increases linearly with the increase of the base angle γ and focal length f, while the ring half-width Δ decreases with the increase of the fundamental beam waist radius w_g, and increases with enlarging the focal length f. We confirmed the topological charge (TC) of the PVB by the interferogram between the PVB and the reference fundamental Gaussian beam. We also studied experimentally that the size of the generated PVB in the Fourier plane is independent of the TCs. Our approach to generate the PVB has the advantages of high-power tolerance and high efficiency. Full article

Concentric circular gratings are diffractive optical elements useful for polarization-independent applications in photonics and plasmonics. They are usually fabricated using a low-throughput and expensive electron beam lithography technique. In this paper, concentric circular gratings with selectable pitch values were successfully manufactured on thin films of azobenzene molecular glass using a novel laser interference lithography technique utilizing Bessel beams generated by a combined lens–axicon configuration. This innovative approach offers enhanced scalability and a simplified manufacturing process on larger surface areas compared to the previously reported techniques. Furthermore, the plasmonic characteristics of these concentric circular gratings were investigated using conventional spectrometric techniques after transferring the nanostructured patterns from azobenzene to transparent gold/epoxy thin films. In addition, the real-time imaging of surface plasmon resonance colors transmitted from the concentric circular gratings was obtained using a 45-megapixel digital camera. The results demonstrated a strong correlation between the real-time photographic technique and the spectroscopy measurements, validating the efficacy and accuracy of this approach for the colorimetric studying of surface plasmon resonance responses in thin film photonics. Full article

We report, for the first time, the generation of a 1173 nm acousto-optic Q-switched self-Raman vortex laser with an axicon-based annular pump system. A 20 mm long Nd:GdVO₄ crystal was used as the self-Raman crystal. Both the fundamental field and the first-Stokes field were investigated using the respective output couplers. In comparison with both vortex fields, a noticeable beam cleaning-up effect and pulse compression were observed from the 1063 nm fundamental field to the 1173 nm first-Stokes field. A Stokes field carrying a unitary topological charge was achieved. Finally, the average output power of the first-Stokes vortex emission reached 454 mW under an incident pump power of 19.5 W, corresponding to a pulse width of 45.7 ns. It was beneficial to apply a high peak power from the Q-switched laser and self-Raman conversion to expand the applications of the vortex laser beam. Full article

Optical metasurfaces have been widely investigated for their versatile ability to manipulate wavefront and miniaturize traditional optical components into ultrathin planar devices. The integration of metasurfaces with multifunctionality and tunability has fundamentally transformed optics with unprecedented control over light propagation and manipulation. This study introduces a pioneering framework for the development of tunable metasurfaces with multifunctionality, and an example of a tunable metasurface of dual functionalities is proposed and numerically verified as one of the tunable meta-axicon for generating Bessel beams with a variable depth of focus (DOF) and a continuous-zoom metalens. Specifically, this design achieves dual-functional phase modulation by helicity-multiplexing from the combination of the geometric phase as well as the propagation phase and realizes tunability for both functionalities through rotational actuation between double metasurface layers. As a result, dual functionalities with continuous tunability of the proposed TiO₂ metasurface are enabled independently for the left and right circularly polarized (LCP and RCP) incidences at 532 nm. Specifically, LCP light triggers the metasurface to function as a tunable axicon, generating non-diffracting Bessel beams with variable numerical apertures (NA) and DOFs. Conversely, the RCP incidence induces it to operate as a continuous-zoom metalens and generates variable spherical wavefront focusing on diverse focal lengths. This study not only initially implements the design of tunable meta-axicon, but also achieves the integration of such a tunable meta-axicon and continuous-zoom metalens within a single metasurface configuration. The proposed device could find potential applications in biological imaging, microscopic measurement, laser fabrication, optical manipulation, multi-plane imaging, depth estimation, optical data storage, etc. Full article

Various methods have been employed to produce Bessel beams (BBs), with axicon-based techniques remaining the most efficient. Among the limitations of axicons are manufacturing defects such as oblate tips and difficulty in tuning the generated BBs. In this work, we combine the effect of a blunt-tip axicon with refraction using various combinations of liquid media to generate variable BB intensity profiles. The output BBs from the axicon are made to pass through a custom-built fluid chamber and magnified using a telescope system. When traversing an empty chamber, the Bessel beam core diameter is measured to be 773.8 µm at propagation distance z’ = 30 cm. The core diameter increases as the beam passes through a chamber containing different liquids as a result of an effective axicon–telescope distance produced by the indices of refraction of the pertinent fluids. Bessel beams modified by the fluid chamber maintain the properties of non-diffraction and self-healing. Full article
