Electric vehicles (EVs) have fundamentally changed the noise, vibration, and harshness (NVH) landscape of automotive powertrains. In the absence of masking internal-combustion-engine noise, harmonic components such as gear whine, electric-motor orders, and inverter-related tones become more perceptible and more critical to vehicle refinement. This review synthesizes the current state of the art in harmonic NVH engineering for electric drivetrains, focusing on the interactions between gear geometry, manufacturing variability, electromechanical coupling, structural transfer, and human sound perception. Classical mechanisms of gear-mesh excitation are revisited together with emerging EV-specific challenges, including long-wavelength flank deviations, ghost orders, lightweight housing dynamics, and psychoacoustic sound-quality requirements. The review further examines recent progress in predictive and data-driven approaches, including machine-learning-based gear-noise modeling, digital-twin concepts, and virtual NVH assessment workflows. Overall, the literature shows that harmonic NVH engineering in EVs is evolving from a conventional gear-noise problem into a multidisciplinary system-level task integrating gear dynamics, manufacturing science, structural acoustics, electric-drive control, psychoacoustics, and data-driven optimization. This review provides a structured synthesis of these developments and identifies key research gaps and future directions for the next generation of refined electric drivetrains. Full article

Quiet drivetrains have become a central requirement in modern electric vehicles, where the absence of engine masking makes even subtle gear tones clearly audible. As a result, manufacturers are looking for more reliable ways to understand how design choices, manufacturing variability, and operating conditions shape gear noise and vibration. Digital Twin (DT) approaches—linking high-fidelity models with measured data throughout the product lifecycle—offer a potential route to achieve this, but their use in gear NVH is still emerging. This review examines recent work from the past decade on DT concepts applied to gears and drivetrain NVH, drawing together advances in simulation, metrology, sensing, and data exchange standards. The survey shows that several building blocks of an NVH-oriented twin already exist, yet they are rarely combined into an end-to-end workflow. Clear gaps remain. Current models still struggle with high-frequency behavior. Real-time operation is also limited. Manufacturing and test data are often disconnected from simulations. Validation practices lack consistent NVH metrics. Hybrid and surrogate modeling methods are used only to a limited extent. The sustainability benefits of reducing prototypes are rarely quantified. These gaps define the research directions needed to make DTs a practical tool for future gear NVH development. A research Gap Map is presented, categorizing these gaps and their impact. For each gap, we propose actionable future directions—from multiscale “hybrid twins” that merge test data with simulations, to benchmark datasets and standards for DT NVH validation. Closing these gaps will enable more reliable gear DTs that reduce development costs, improve acoustic quality, and support sustainable, data-driven NVH optimization. Full article

Electric vehicle (EV) drivetrains operate at high rotational speeds, which makes the noise, vibration, and harshness (NVH) performance of gear transmissions a critical design factor. Without the masking effect of an internal combustion engine, gear whine can become a prominent source of passenger discomfort. This paper provides the first comprehensive review focused specifically on gear tooth surface waviness, a subtle manufacturing-induced deviation that can excite tonal noise. Periodic, micron-scale undulations caused by finishing processes such as grinding may generate non-meshing frequency “ghost orders,” leading to tonal complaints even in high-quality gears. The article compares finishing technologies including honing and superfinishing, showing their influence on waviness and acoustic behavior. It also summarizes modern waviness detection techniques, from single-flank rolling tests to optical scanning systems, and highlights data-driven predictive approaches using machine learning. Industrial case studies illustrate the practical challenges of managing waviness, while recent proposals such as controlled surface texturing are also discussed. The review identifies gaps in current research: (i) the lack of standardized waviness metrics for consistent comparison across studies; (ii) the limited validation of digital twin approaches against measured data; and (iii) the insufficient integration of machine learning with physics-based models. Addressing these gaps will be essential for linking surface finish specifications with NVH performance, reducing development costs, and improving passenger comfort in EV transmissions. Full article

Gear whine noise is governed not only by intentional microgeometry modifications but also by unavoidable pitch (indexing) deviation. This study presents a workflow that couples a tooth-resolved surface scan with a calibrated pitch-deviation table, both imported into a multibody dynamics (MBD) model built in MSC Adams View. Three operating scenarios were evaluated—ideal geometry, measured microgeometry without pitch error, and measured microgeometry with pitch error—at a nominal speed of 1000 r min⁻¹. Time domain analysis shows that integrating the pitch table increases the mean transmission error (TE) by almost an order of magnitude and introduces a distinct 16.66 Hz shaft order tone. When the measured tooth topologies are added, peak-to-peak TE nearly doubles, revealing a non-linear interaction between spacing deviation and local flank shape. Frequency domain results reproduce the expected mesh-frequency side bands, validating the mapping of the pitch table into the solver. The combined method therefore provides a more faithful digital twin for predicting tonal noise and demonstrates why indexing tolerances must be considered alongside profile relief during gear design optimization. Full article

As the demand for agricultural electric vehicles increases, it is becoming important to conduct noise reduction in consideration of the characteristics of an electric powertrain. This study was conducted to optimize the shape design of gearbox housing for radiated noise reduction of an agricultural electric vehicle gearbox. The noise and vibration of the gearbox were measured considering the noise characteristics of the electric vehicle gearbox, which radiates high-frequency pure tone noise. The main noise source radiated by the structural vibration of the gearbox housing was identified and considered when modeling the loading conditions in the numerical analysis. To improve the reliability, the finite element (FE) model was updated and validated. Internal machine elements were modeled as a substructure through a reduced-order modeling method to reduce the computing time and apply a constant gear excitation force. The weak areas of structure were determined and it was used as the design area for optimization. The topology optimization technique was used to reduce the equivalent radiated power (ERP) which was used as an indicator of radiated noise level. The maximum value of the ERP decreased under all operating conditions at the rated speed. Full article
