Air switchgear is an important power equipment in the transmission, transformation, and distribution process of the power system. Insulation defects can lead to partial discharge, which is one of the primary causes of air switchgear failure. Current monitoring methods primarily rely on detecting ultra-high frequency or ultrasonic signals generated by partial discharge to identify insulation defects. However, these methods are prone to external signal interference, resulting in substantial detection errors. Based on gas discharge theory and engineering practice, this paper uses three typical defects to represent the main insulation defects of air switchgear, namely metal protrusion defects, insulation layer air gap defects, and metal particle defects. After that, the validity of the numerical model to describe the partial discharge process of air switchgear insulation defects is verified by the volt-ampere characteristic curve. The discharge process of three typical defect models was investigated by using the numerical model, and the variation curves of the volume fractions of CO, NO₂, and O₃ gases at different voltage levels and different discharge durations were obtained. After analysis, the volume fractions of the three characteristic gases are unique under different defect models and partial discharge quantities. Finally, this paper designed a partial discharge inversion method based on characteristic gases, and fitted time-domain regression equations and partial discharge inversion regression equations based on the changes in volume fractions of the three characteristic gases measured. The research results of this paper provide a theoretical basis for online detection of partial discharge in high-voltage air switchgear through characteristic gases. The method proposed in this paper can also be applied to other gas-insulated equipment, such as GIS, metal-enclosed switchgear, and vacuum circuit breakers. Full article

The mechanical reliability of the gas-insulated metal-enclosed switchgear (GIS) is critical to the safe and stable operation of a power system. The internal stress induced in GIS insulators, which typically lead to cracking, can degrade the mechanical properties and compromise the reliability of the GIS. In this work, ultrasonic nondestructive measurements of the internal stress in a GIS 126 kV epoxy composite with the transverse waves are demonstrated for the first time. Our results show that the velocities of ultrasonic transverse waves increase linearly with the compressive stress and decrease linearly with the tensile stress. The acoustoelastic coefficients are −1.18 × 10⁻⁴/MPa and −1.96 × 10⁻⁴/MPa for measurements with transverse waves polarized vertically and parallelly to stress, respectively. Based on these acoustoelastic coefficients, the internal stresses are calculated, and the maximum absolute values of relative errors are 35.4% and 26.3% for measurements with the transverse wave polarized vertically and parallelly to stress, respectively. Full article

Internal stress in basin insulators of gas-insulated metal-enclosed switchgear (GIS) can lead to cracks, which affects the safe operation of these apparatuses. In this research, we proposed a subsurface internal stress measurement method for GIS epoxy composites. This method is based on an ultrasonic longitudinal critically refracted (LCR) wave technique. In this study, some epoxy composite specimens were synthesized with similar materials and manufacturing processes to those of 252 kV GIS basin insulators. An ultrasonic stress measurement system that utilized the LCR wave technique was set-up to investigate the relationship between stress and LCR wave propagation time, as well as to measure the compressive stress of the epoxy specimen within 0–50 MPa. The results show that LCR wave propagation time linearly decreased when stress increased in the subsurface zone and the acoustoelastic coefficient was −4.95. We found the relative errors of stress measurements to be less than 13%. Full article

Conductive particles are one of the most important defects which can greatly degrade the performance of gas-insulated metal-enclosed switchgear (GIS). Many efforts have been made to clarify the influence on the withstand voltage, understand the flashover mechanism, and build a comprehensive model to describe the particle-initiated flashover. In this study, a partial discharge (PD) signal detected through a photomultiplier (PMT) and recorded by a high-speed data acquisition (DAQ) system was used to analyze the discharge development of a conductive particle-contaminated GIS insulator under constant high AC voltage. An additional PMT was used as a reference to eliminate the dark count of the PMT and the data collection method of a DAQ system was optimized to capture the pulse waveform of each PD to obtain detailed physical information. Spectra of the PD pulse amplitude over pulse width, PD counts within various amplitude ranges over time and phase resolved partial discharge (PRPD) patterns of the PDs in different stages are obtained through the captured PD waveforms. Characteristics of the PDs from the application of the high AC voltage up to the flashover of the insulator were then analyzed, and it was found that the features of the PDs in the near-flashover stage were significantly different to the previous stages. Full article

Situations of internal stress in basin insulators inside gas-insulated metal-enclosed switchgear (GIS) can lead to cracks, which can influence the safety and stability of apparatus. However, there is currently no research on internal stress measurements for composites of GIS basin insulators, and only measurements for surface stress. In this paper, an internal stress measurement method for GIS epoxy composite is proposed using an ultrasonic longitudinal through-transmission technique based on the acoustoelastic effect. An internal stress measurement system is developed to investigate the relationship between the uniaxial compressive internal stress and the velocity of the ultrasonic wave vertical to the stress in epoxy composite within a range of 0–70 MPa, and to calculate the acoustoelastic coefficient of epoxy composite. The effects of system delay are eliminated in measuring the propagation time. Some epoxy composite cuboid specimens with similar materials and using a manufacturing process similar to those of 252 kV GIS basin insulators are synthesized, and the uniformity of the internal stress in cuboid specimens is verified by finite element simulation. The results reveal a linear increase of the ultrasonic longitudinal wave velocity with increasing stress. It has been shown that the average acoustoelastic coefficient of GIS epoxy composites, using the longitudinal waves vertical to the stress, is 4.556 × 10⁻⁵/MPa. Additionally, the absolute errors of the internal stress measurements are less than 12.397 MPa. This research shows that the ultrasonic method based on the acoustoelastic effect for measuring the internal stress in GIS epoxy composites is feasible. Full article

Voids or cracks in basin insulators inside a GIS (gas-insulated metal-enclosed switchgear) could trigger partial discharges or surface flashover under electrical stresses, threatening safe GIS operation. For this paper, some epoxy composite specimens were made from similar materials and manufacturing processes to make 252 kV GIS basin insulators. Some voids with different diameters or cracks with different diameters and orientations were artificially made in the specimens with different thicknesses. An ultrasonic pulse-echo system was set up, and ultrasonic tests were carried out on the specimens with voids or cracks. A method to calculate the depth of a defect was proposed by the propagation time of defect reflected waves. The results showed that a depth of 50 mm, a diameter φ of 2 mm void, and a diameter φ of 1 mm crack in epoxy composite insulation were detected by the ultrasonic system using a 1 MHz transducer. Full article

The large diameter metal shell component (LDMSC) is an important part of gas insulated (metal-enclosed) switchgear (GIS). The LDMSC with multi branches is filled with gas under certain pressure. The plastic forming process is an efficient approach to manufacturing the high reliability LDMSC. The warm flanging process has been widely used to form LDMSC using aluminum alloy. The forming process is characterized by local heating, and the distribution of temperature is strongly inhomogeneous. Although the wall thickness of the shell is 10 mm to 20 mm, the ratio of outer diameter to thickness is more than 40. These present some difficulties in the flanging process and result in some forming defects. Detailed forming characteristics are hard to obtain by analytical and experimental methods. Thus, the through-process finite element (FE) modeling considering heating, forming, unloading, and cooling is one of the key problems to research the manufacturing process of LDMSC. In this study, the through-process FE modeling of the warm flanging process of LDMSC using aluminum alloy was carried out based on the FORGE. The thermo-mechanical coupled finite element method was adopted in the modeling, and the deformation of the workpiece and the die stress were considered together in the modeling. A full three-dimensional (3D) geometry was modeled due to inhomogeneous distribution in all directions for the temperature field. The simulation data of local flame heating could be transferred seamlessly to the simulations of the deforming process, the unloading process, and the cooling process in the through-process FE model. The model was validated by comparison with geometric shapes and forming defects obtained from the experiment. The developed FE model could describe the inhomogeneous temperature field along circumferential, radial, and axial directions for the formed branch as well as the deformation characteristic and the unloading behavior during the warm flanging process. By using the FE model, the forming defects during the flanging process and their controlling characteristics were explored, the evolution of the temperature field through the whole process was studied, and deformation and springback characteristics were analyzed. The results of this study provide a basis for investigating deformation mechanisms, optimizing processes, and determining parameters in the warm flanging process of a large-diameter aluminum alloy shell component. Full article

Identification of insulation defects in gas insulated metal-enclosed switchgear (GIS) is important for partial discharge (PD) evaluation. This article proposes a polar coordinate pattern approach to characterize the different kinds of defect types. These defect types include floating electrodes, a fixed protrusion on the enclosure, surface contamination on the spacer, metallic prominence on the high voltage electrode, a void in the insulator, and free metal particles on the enclosure. First, the physical models for the insulation defects in the established GIS model are designed. Second, the phase resolved pulse sequence (PRPS) data sets are obtained using ultra-high frequency (UHF) measurement. Then, the polar coordinate patterns are proposed to characterize the defects. Nine discharge parameters combined with the parameters based on quadrant statistical theory constitute the input feature vector to identify the PD types. The experimental results show that these new parameters could produce a clear, quantitative description of the characteristics of the defect types and could be used to distinguish between the different kinds of defect types. Full article
