Carbonate fracture–cavity reservoirs are significant oil and gas reservoirs globally, and their efficient development is influenced by the connectivity between fracture–cavity units within the reservoir. These reservoirs primarily consist of large caves, dissolution holes, and natural fractures, which serve as the primary storage and flow spaces. The S91 unit of the Tarim Oilfield is a karstic fracture–cavity reservoir with shallow coverage. It exhibits significant heterogeneity in the fracture–cavity reservoirs and presents complex connectivity between the fracture–cavity bodies. The integration of static and dynamic data, including geology, well logging, seismic, and production dynamics, resulted in the development of a set of static and dynamic connectivity evaluation processes designed for highly heterogeneous fracture–cavity reservoirs. Methods include using structural gradient tensors and stratigraphic continuity attributes to delineate the boundaries of caves and holes; performing RGB fusion analysis of coherence, curvature, and variance attributes to characterize large-scale fault development features; applying ant-tracking algorithms and fracture simulation techniques to identify the distribution and density characteristics of fracture zones; utilizing 3D visualization technology to describe the spatial relationship between fracture–cavity units and large-scale faults and fracture development zones; and combining dynamic data to verify interwell connectivity. This process will provide a key geological basis for optimizing well network deployment, improving water and gas injection efficiency, predicting residual oil distribution, and formulating adjustment measures, thereby improving the development efficiency of such complex reservoirs. Full article

Dolomitization is a critical diagenetic alteration that impacts the formation of carbonate hydrocarbon reservoirs. In the offshore Bohai Bay Basin, the Lower Paleozoic carbonate reservoirs in buried hill traps, and the basement highs unconformably overlain by younger rock units, are emerging as a prospective target and predominantly occur in dolomite layers. Meanwhile, the formation mechanisms of the dolomite are not clear, which affects the understanding of the occurrence of deep dolomite reservoirs and hinders oil and gas exploration. Based on comprehensive observations of the thin sections of the carbonate samples, the dolomite types were meticulously categorized into micritic dolostone, fine-crystalline dolostone, and saddle dolomite. Then, carbon, oxygen, and strontium isotope and trace elements were examined to elucidate the dolomitization fluids and propose diagenetic models for the three kinds of dolomite formation. The mineralogical and geochemical evidence reveals that there were two kinds of dolomitization fluids, including penecontemporaneous seawater, and hydrothermal fluid. The diagenetic fluid of the micritic dolostone and fine-crystalline dolostone both involved penecontemporaneous seawater, but fine-crystalline dolostone is also affected by later burial dolomitization processes. The saddle dolomite, filling in pre-existing fractures or dissolution pore cavities, is attributed to a hydrothermal fluid associated with magmatic activities. Notably, the extensive layered fine-crystalline dolostone was the predominant reservoir rock. The initial mechanism for its formation involves penecontemporaneous seepage reflux dolomitization, which is superimposed by later burial dolomitization. The burial dolomitization enhanced porosity, subsequently facilitating the formation of a fracture-related dissolution pore cavity system, and partly filled by saddle dolomite during the Cenozoic hydrothermal events. The findings highlight that the layered fine-crystalline dolostone that underwent multiphase dolomitization is the most potential target for hydrocarbon exploration. Full article

Deep carbonate rocks are characterized by strong heterogeneity and fracture and cavity development, which have important influence on the storage and seepage capacity of reservoirs. To comprehensively characterize the developmental characteristics of the reservoir body in the intra–platform reservoir of the fourth member of the Dengying Formation in the Anyue gas field, this study employed a multiscale pore–throat structure characterization method that combines physical property analysis, core surface observation, cast thin section observation, a nuclear magnetic resonance (NMR) test, and CT scanning analysis. The results reveal that the primary storage spaces in the intra–platform reservoirs consist of inter–crystalline pores and small cavities (<2 mm), with thick throats and fractures serving as the primary flow channels. The rock density is lower in areas where solution fractures and cavities are developed, and the fractures and cavities are generally distributed in clusters. Notably, the intra–platform reservoir of the fourth member of the Dengying Formation is characterized by low asphaltene content. The presence of fractures in fracture–cavity type cores can reduce seepage resistance in the near–fracture area and enhance the drainage efficiency of small pores, as observed in the NMR test combined with centrifugation. In the centrifugal experiments, the increase in centrifugal force had the most significant impact on drainage efficiency, with the highest efficiency being 25.82% for cavity–type cores and the lowest being 6.39% for pore–type cores. Furthermore, by integrating the results of cast thin section and NMR test, the cavity–type reservoirs were further classified into two categories: dissolved cavity storage type and dissolved pore storage type. This study clarifies the storage and seepage characteristics of dissolved–pore storage reservoirs, which are challenging to develop but have high development potential. With reasonable surface operation measures, these reservoirs can provide important support for stable production in the middle and late stages of intra–platform reservoir development. Full article

Controlling the extent of water invasion in the reservoir and mitigating its detrimental effects on gas well production and natural gas recovery have long been a challenging task in the efficient development of strongly heterogeneous edge water gas reservoirs. To elucidate the edge water invasion mechanism of strongly heterogeneous carbonate gas reservoirs, this study investigates the pore throat characteristics and fluid mobility from both qualitative and quantitative aspects, leveraging natural core observations, cast thin sections, scanning electron microscopy (SEM), and nuclear magnetic resonance (NMR) tests with centrifuge experiments. A core-scale edge water invasion simulation experiment was conducted under online NMR monitoring to examine the dynamic gas production characteristics of the three types of reservoirs during the water invasion process and to elucidate the formation mechanism and distribution pattern of water-sealed gas. Research findings indicate that carbonate reservoirs typically exhibit a diverse range of pore types, including various types of fractures and cavities. Fractures significantly enhance reservoir connectivity, thereby increasing fluid mobility, but also lead to strong non-uniform water invasion. In contrast, cavities substantially improve the storage capacity of the reservoir and can retard the advancement of the water invasion front, thereby alleviating the adverse effects of water invasion. The ultimate recovery rates of fracture-type, cavity-type, and fracture-cavity cores in the water invasion simulation experiment were 29.81%, 64.87%, and 53.03%, respectively. Premature water breakthroughs in the reservoir can result in a large number of gases in matrix pores and even cavities being sealed by formation water, rendering them unrecoverable, which seriously impacts the gas recovery rate of the reservoir. Full article

Fracture–cavity carbonate reservoirs account for a considerable proportion of oil and gas resources. Because of the complicated relationships between cavities, fractures and pores in these reservoirs, which are defined as cavity clusters, fracturing technology is employed to enhance their hydrocarbon productivity. However, almost all previous studies have just considered the effect of a single natural cavity or fracture on the propagation of a hydraulic fracture; therefore, the mechanism by which a hydraulic fracture interacts with a cavity cluster needs to be clarified. In this study, cavity clusters with different distributions were accurately prefabricated in synthetically made samples, and large-scale simulation equipment was employed to systematically perform fracturing experiments considering different horizontal differential stress levels. Meanwhile, the hydraulic fracture propagation behaviors were comprehensively analyzed through fracture morphology, fracturing curves, the complexity of the fracture network and acoustic emission monitoring. It was found that a natural fracture with a smaller approach angle is favorable in guiding a hydraulic fracture to a cavity. The fracturing curves were divided into the following four types: frequent fluctuations with “step-like” shapes, great fluctuations with slightly lower closure pressure, fluctuations with obviously lower closure pressure, and little fluctuations with obviously lower closure pressure. And different cavity cluster distributions play a dominant role in the complexity of generated hydraulic fracture networks. In addition, AE energy was used to judge the ease of crossing the cavity. The above findings indicated that for the actual exploration and exploitation of carbonate reservoirs, the geological exploration of different fracture–cavity structures in reservoirs would be required, and targeted fracturing engineering designs need to be carried out for different fracture–cavity carbonate reservoirs. Full article

Fractured-vuggy carbonate reservoirs are tectonically complex; their reservoirs are dominated by holes and fractures, which are extremely nonhomogeneous and are difficultly exploited. Conventional water injection can lead to water flooding, and the recovery effect is poor. This paper takes the injection of foam and solid particles to control bottom water as the research direction. Firstly, the rheological properties of foam were studied under different foam qualities and the presence of particles. The ability of foam to carry particles was tested. By designing a microcosmic model of a fractured-vuggy reservoir, we investigated the remaining oil types and the distribution caused by bottom water. Additionally, we analyzed the mechanisms of remaining oil mobilization and bottom water plugging during foam flooding and foam–particle co-injection. The experimental results showed that foam was a typical power-law fluid. Foam with a quality of 80% had good stability and apparent viscosity. During foam flooding, foam floated at the top of the dissolution cavities, effectively driving attic oil. Additionally, the gas cap is released when the foam collapses, which can provide pressure energy to supplement the energy of the reservoir. Collaborative injection of foam and solid particles into the reservoir possessed several advantages. On one hand, it inherited the benefits of foam flooding. On the other hand, the foam transported particles deep into the reservoir. Under the influence of gravity, particles settled and accumulated in the fractures or cavities, forming bridge plugs at the connection points, effectively controlling bottom water channeling. The co-injection of foam and solid particles holds significant potential for applications. Full article

The Middle Permian Maokou Formation in the Sichuan Basin has huge resources and is an important target for natural gas exploration. In recent years, significant exploration breakthroughs have been made in the dolomite field of member Mao-2 in central Sichuan, and the gas production of several wells has exceeded 1 × 10⁶ m³/d, indicating promising prospects for exploration. However, the origin of the dolomite reservoir in member Mao-2 remains ambiguous, which restricts the accurate prediction of favorable reservoirs. This study focuses on drilling in the Hechuan area as its research object, by using a detailed description of the cores from member Mao-2 of seven wells; samples were selected for tests of the degree of dolomite cation ordering, stable carbon and oxygen isotopic compositions, strontium isotopic composition, rare earth elements, LA-ICP-MS element mapping and U-Pb dating. It is clarified that: (1) The crystalline dolomite of member Mao-2 in the Hechuan area is the main reservoir rock, and the heterogeneous vugs and fractures are the main reservoir space. The dolomite in member Mao-2 has been characterized by a low degree of cation ordering value (avg. 0.59), with values of δ¹³C (avg. 3.87‰), δ¹⁸O (avg. −7.15‰) and ⁸⁷Sr/⁸⁶Sr (avg. 0.707474) having similar geochemical characteristics to Middle Permian seawater; the REEs normalized distribution patterns have similar characteristics to limestone; and the U-Pb age (261.0~262.0 Ma) corresponds to the age in the Capitanian stage of the Permian Guadalupian Series. (2) Petrological studies show that member Mao-2 has vertical karstification zonation characteristics; syngenetic karstification controls the formation of a large-scale fracture-cave system in the phreatic zone; the dolomitization of sediment in the fracture-cave system occurred during the penecontemporaneous period with locally restricted seawater. (3) The main controlling factors of the reservoir were syngenetic karstification, early dolomitization and hydrothermal dissolution related to Emei taphrogenesis. The research results are of great significance for dolomite reservoir prediction; the highlands of paleogeomorphology with syndepositional faults are favorable areas for dolomite reservoirs. Full article

For the Tahe Oilfield, there are multiple sets of karst reservoirs with different genesis developed in carbonate fracture-vuggy reservoirs and the varying karst reservoir type has a considerable influence on the distribution of residual oil. The complex characteristics of different karst reservoirs and the difficulty in producing the remaining oil in the middle and lower part of the reservoir greatly restrict the recovery effects. This work managed to comprehensively investigate the action mechanism of nitrogen-assisted gravity drainage (NAGD) on remaining oil in reservoirs with different karst genesis through modeling and experiments. Based on geological characteristics and modeling results, a reservoir-profile model considering reservoir type, fracture distribution, and the fracture–cave combination was established, the displacement experiments of main reservoirs such as the epikarst zone, underground river, and fault karst were carried out, and the oil–gas–water multiphase flow was visually analyzed. The remaining oil state before and after NAGD was studied, and the difference in recovery enhancement in different genetic karst reservoirs was quantitatively compared. The results show that NAGD was helpful in enhancing oil recovery (EOR) for reservoirs with different karst genesis. NAGD technique has the greatest increasing effect on the sweep efficiency of the fault-karst reservoir, followed by the epikarst zone reservoir, and the smallest in the underground river reservoir. The results of this research will facilitate an understanding of the EOR effect of karst-reservoir types on NAGD and provide theory and technical support for the high-efficiency development in varying karst reservoirs in the Tahe Oilfield. Full article

The largest marine carbonate oilfield and gas condensate field in China have been found in the Ordovician limestones in the central Tarim Basin. They are defined as large “layered” reef-shoal and karstic reservoirs. However, low and/or unstable oil/gas production has been a big challenge for effective exploitation in ultra-deep (>6000 m) reservoirs for more than 20 years. Together with the static and dynamic reservoir data, we have a review of the unconventional characteristics of the oil/gas fields in that: (1) the large area tight matrix reservoir (porosity less than 5%, permeability less than 0.2 mD) superimposed with localized fracture-cave reservoir (porosity > 5%, permeability > 2 mD); (2) complicated fluid distribution and unstable production without uniform oil/gas/water interface in an oil/gas field; (3) about 30% wells in fractured reservoirs support more than 80% production; (4) high production decline rate is over 20% per year with low recovery ratio. These data suggest that the “sweet spot” of the fractured reservoir rather than the matrix reservoir is the major drilling target for ultra-deep reservoir development. In the ultra-deep pre-Mesozoic reservoirs, further advances in horizontal drilling and large multiple fracturing techniques are needed for the economic exploitation of the matrix reservoirs, and seismic quantitative descriptions and horizontal drilling techniques across the fault zones are needed for oil/gas efficient development from the deeply fractured reservoirs. Full article

The largest ultra-deep (>6000 m) strike-slip fault-controlled oilfield in the world is found in the Tarim Basin of Northwestern China. The localized fractured reservoirs are the major production targets along the strike-slip fault zones. Different from its use in the primary porous-type reservoirs, however, the conventional technology is not favorable for use in oil/gas development in Ordovician carbonate reservoirs. For this reason, high-density seismic acquisition and high-resolution seismic processing were carried out to provide high-precision data for fault and fractured reservoir identification. In addition, the multi-filtering process and the maximum likelihood method are typically used to identify small faults and fault segments along a strike-slip fault zone. Further, seismic facies-constrained inversion and amplitude attributes are favorable for large fracture-cave reservoir description. With the advancements in seismic technology, the high and stable production well ratio has been doubled in the “sweet spots” of fractured reservoir optimization, and the first ultra-deep strike-slip fault-controlled oilfield with an annual oil production of over 1 million tons has been realized, achieving economic development in the ultra-deep fractured reservoirs. However, unstable production and high rates of production decline are still significant challenges in the economic exploitation of the ultra-deep fractured reservoirs. Seismic technology requires further improvement for the description of small fractured reservoirs and matrix reservoirs, as well as reservoir connectivity prediction and hydrocarbon detection in the deep subsurface. Full article

The largest carbonate condensate field has been found in the Tarim Basin, NW China. Different from sandstone condensate gas reservoirs, however, the conventional gas injection for pressure maintenance development is not favorable for Ordovician fracture-cave reservoirs. Based on this, in this paper, 21 sets of displacement experiments in full-diameter cores and a pilot test in 11 boreholes were carried out to study enhanced oil recovery (EOR) in complicated carbonate reservoirs. The experimental results show that the seepage channels of the gas condensate reservoirs are fractures, which are quite different from sandstone pore-throat structures. Condensate oil recovery using water injection was up to 57–88% in unfilled fractured caves and at ca. 52–80% in sand-filled fractured caves. These values are much higher than the 14–46% and 17–58% values obtained from the depletion and gas injection experiments, respectively. The water injection in 11 wells showed that the condensate oil recovery increased by 0–17.7% (avg. 3.1%). The effective EOR for residual oil replacement using water injection may be attributed to fractures, as the gas channel leads to an ineffective gas circulation and pipe flow in fracture-cave reservoirs, which is favorable for waterflood development. The complicated fracture network in the deep subsurface may be the key element in the varied and lower oil recovery rates obtained from the wells than from the experiments. This case study provides new insights for the exploitation of similar condensate gas reservoirs. Full article

Karst cavities and caves are often present along fractures in limestone reservoirs and are of significance for oil and gas exploration. Understanding the formation and evolution of caves in fractured carbonate rocks will enhance oil and gas exploration and development. Herein, a reactive transport model was established considering both the matrix and fractures. Different factors affecting the dissolution along fractures were considered in the simulation of matrix–fracture carbonate rocks, including the magnitude and characteristic length of the matrix porosity heterogeneity, intersecting fractures, and complex fracture network. The results show that a strong heterogeneity of the matrix porosity significantly affects the cave formation along the fracture and the existence of fractures increases the heterogeneity due to the high permeability as well as the dissolution area. The characteristic length of the matrix porosity heterogeneity affects the cave location and shape. The larger permeability of intersecting fractures or the matrix greatly increases the cave size, leading to the formation of large, connected cave areas. A complex fracture network leads to more developed karst dissolution caves. The topology of the fracture network and preferential flow dominate the distribution of caves and alleviate the effect of the matrix heterogeneity. Full article

It is difficult to investigate the formation process and occurrence states of water in multi-type reservoirs, due to the strong heterogeneity and complex microstructure of the fracture–cavity carbonate gas reservoirs. To date, there is no systematic study on the occurrence characteristics of multi-type formation water, especially through visual observation experiments. In this paper, a new creation method for visual micromodels based on CT scan images and microelectronic photolithography techniques was described. Subsequently, a gas–drive–water visual experiment was conducted to intuitively study the formation mechanism and the occurrence states of formation water. Then, the ImageJ gray analysis method was utilized to quantitatively investigate the gas-water saturation and the proportion of residual water film. Finally, the occurrence characteristics of formation water and its effects on gas seepage flow were comprehensively analyzed. Visual experimental results showed that: the migration processes of natural gas in different types of reservoirs are different; the water in multiple media consists of native movable water and residual water, and residual water is composed of secondary movable water and irreducible water; the residual water mainly occurs in different locations of different reservoirs with the forms of “water film”, “water mass”, “water column” and “water droplets”; the main influencing factors are capillary force, surface tension, displacement pressure and channel connectivity. Quantitative results reflect that the saturation of movable water and residual water are the parameters related directly to reservoir physical properties, pore structure and displacement pressure—the smaller the size of flow channel, the larger the space occupied by water film; the thickness proportion of water film is increasing exponentially with the channel size; the thickness proportion of water film decreases as the increase of displacement pressure; the thickness proportion of water film is essentially constant when the displacement pressure increases to a certain extent. The conducted visual investigation not only improves our intuitive understanding of the occurrence characteristics of formation water, but also provides a theoretical basis for the efficient development of fracture-cavity gas reservoirs. Full article
