In the realm of electric machines, there has been an increasing interest in multiphase (greater than three-phase) and hybrid excited machines. The benefits of multiphase machines include improved power density, efficiency, reliability, and fault tolerance, while for hybrid electric machines, the literature offers a variety of topologies, each with its own advantages and disadvantages. In essence, the term hybrid for electric machines is used when there is more than one source of excitation, e.g., permanent magnet (PM) excitation combined with or assisted by wound field (WF) excitation. This paper presents an extensive review of the latest topologies in hybrid machines. It explores fundamental principles, multiphase winding, and the advantage of multiphase over three-phase, as well as a comparison of ripple in the DC link for different numbers of phase winding. Additionally, this review discusses applications across industries, including automotive, aerospace, marine, and renewable energy systems. This paper later studies the motoric and generator modes of hybrid machines while considering the machine characteristics in both of these modes. Full article

The electric urban air mobility sector has gained significant attraction in public debates, particularly with the proliferation of announcements demonstrating new aerial vehicles and the infrastructure that goes with them. In this context, the development of new methodologies for the design and sizing of actuation systems, ensuring high performances of these aerial vehicles, remains an important task in this process. This will allow for better integration within this transport sector. In this paper, a robust design optimisation approach of multiphase fault-tolerant (FT) outer rotor (OR) permanent magnets (PM) for multirotor aerial vehicle applications is proposed. In order to show the effectiveness and the robustness of the proposed design methodology, the number of stator winding phases, with a fractional slot concentrated winding (FSCW) configuration, as well as the PM configuration are considered as variables. Thus, four cases for the number of phases are considered, namely 3, 5, 6 and 7 phases, where for each number of phases case, the PM takes 3 configurations, namely surface PM, interior V-shape PM and interior spoke PM. First, a pre-sizing step is carried out, consisting of selecting the optimal combinations slot/pole, designing the multiphase FSCW layout, and estimating the electric motor (EM) geometry using analytical computations to obtain a preliminary validation of the design specifications. Second, constrained multiobjective optimisation is considered in order to optimise the EM performances, such as motor efficiency and weight, under constraints where the FEMM/Matlab based Finite Element Analysis (FEA) tool is used to perform this optimisation. Finally, results analysis and performance comparisons of different EM configurations are carried out in order to assess the design parameters, such as phases number, PM position, and harmonic currents in the EM design and consequently to select the best configuration for the considered application. Full article

This paper presents a speed sensorless control of a five-phase PMSM in healthy operation and under the Open-Phase Fault on any phase of the machine. The solution is recommended for mission-critical applications requiring high reliability capacities, such as Aerospace applications. An adapted Active Fault Tolerant Control is proposed with the aim of obtaining electromechanical torque as close as possible to that normally developed by a machine working in healthy condition. In instances of a loss of power to one phase of the machine, a reconfiguration of the control law is performed to ensure the continuity of service and to maintain acceptable control performances without requiring a hardware rearrangement of the power architecture. The motor rotation speed and position, required for the Field Oriented Control (FOC) of the stator currents, are estimated using a Back-Electromotive Forces (Back-EMF) observer based on a mathematical model of the motor and implemented in the stator diphase reference frame. Different electrical models that describe the behavior of the five-phase machine in the normal and degraded operations are given. Experimental results on a 1.25 kW synchronous PM machine are shown to confirm the effectiveness of the motor control. Full article

This paper proposes a simplified lumped parameter thermal network (LPTN) model for thermal analysis under the inter-turn short-circuit (SC) faults of a five-phase fault-tolerant permanent magnet (PM) motor for electric vehicles. The proposed model can consider circumferential heat transfer, variable copper loss, and uneven loss distribution. Firstly, an analytical calculation formula of inter-turn SC current is proposed to separate the copper loss of SC turns from electromagnetic simulation, and the accuracy of the formula is verified by finite element analysis (FEA). Secondly, a simplified LPTN model is proposed, the calculation formulas of the thermal resistance are given, and the simplified principle is explained. By comparing the results of different simplifications, it is found that the error between the simplified model and the original model is small. Finally, the proposed model is verified by experiments. The results show that the simplified model can achieve not only a high calculation speed but also a high accuracy. Moreover, the proposed model is applicable to all cases of asymmetrical temperature distribution. Full article

As one of the key components, low-speed direct-drive in-wheel machines with high compact volume and high torque density are important for the traction system of electric vehicles (EVs). This paper introduces four different types of outer-rotor permanent magnet motors for EVs, including one five-phase SPM machine, one three-phase IPM machine with V-shaped PMs, one seven-phase axial flux machine (AFM) of sandwich structure and finally one hybrid flux (radial and axial) machine with a third rotor with V-shaped PMs added to the AFM. Firstly, the design criteria and basic operation principle are compared and discussed. Then, the key properties are analyzed using the Finite Element Method (FEM). The electromagnetic properties of the four fractional slot tooth concentrated winding in-wheel motors with similar dimensions are quantitatively compared, including air-gap flux density, electromotive force, field weakening capability, torque density, losses, and fault tolerant capability. The results show that the multi-phase motors have high torque density and high fault tolerance and are suitable for direct drive applications in EVs. Full article

Demagnetization in permanent magnet synchronous motor (PMSM), caused by high temperature or inverse magnetic field, may increase loss and torque ripple, and even degrade the system stability in severe cases. On-line detection can identify the incipient demagnetization of permanent magnets (PMs), as well as providing reference for subsequent fault-tolerant control, so as to avoid further demagnetization. Therefore, an on-line demagnetization detection method is proposed in this paper by using flux observer. First, an observer is established in the three-phase stationary reference frame by taking the stator currents and the amplitudes of the fundamental and harmonic components of flux as state variables. Then, three demagnetization indexes are presented to evaluate the properties of PMs based on the observed flux information. The proposed method can directly track the amplitude of harmonic flux and evaluate the severity of the demagnetization more comprehensively. Simulation and experimental results demonstrate the effectiveness of the proposed method. Full article

This paper analyzes the harmonics and vibration under different fault-tolerant current control when one-phase winding of dual three-phase permanent magnet synchronous motor (PMSM) is an open circuit fault. Firstly, the dual three-phase load condition subdomain model of breadloaf surface-mounted permanent magnet (PM) PMSM is established. Secondly, the working conditions of an open circuit fault of one-phase winding are set from the perspectives of no fault-tolerant (NFT) control, maximum torque (MT) control, minimum copper loss (MCL) control and single three-phase mode (STPM) control. The torque harmonics and electromagnetic force harmonics of the four working conditions are analyzed. Then, considering the multi-physical field of electromagnetic and structural coupling, the electromagnetic force in the motor air gap acts on the stator core, and the vibration under four different working conditions is calculated and analyzed. Through the comparison between the analytical method and finite element method, the accuracy of the established model is verified. The calculation method is effective and accurate, it can quickly predict the motor performance in case of one-phase open circuit fault of dual three-phase PMSM. Full article

Recently, a dual inverter motor drive feeding an open-end winding permanent magnet (PM) motor has been studied, aiming for the improvement of total efficiency and a fault tolerant function of hybrid and electric vehicles. The authors have studied the fault tolerant operation of the DC-bus battery, where the failed inverter is operated only with a capacitor across the DC-bus and a space vector modulation (SVM) is employed to regulate the capacitor voltage. In our previous research, the SVM techniques for the fault tolerant operation in a low-modulation-index have been proposed. However, it was difficult to have fault tolerance in a high-modulation-index case. The voltage margin in the fault situation is limited because the failed inverter is operated with the capacitor. In this paper, the SVM technique to achieve the fault tolerant operation in the high-modulation-index state is investigated. The novel point of this paper is that the proposed technique introduces a field-weakening control in order to reduce the command voltage vector within the controllable voltage region. The proposed technique was verified through experimental tests and its operational characteristics were compared with the normal operation, from the viewpoints of the total harmonic distortion (THD) and the efficiencies of the inverters and the motor. Full article
