The applicability of similar materials is a key factor affecting the results of geomechanical model tests. In order to investigate the multi-physical field evolution mechanism of surrounding rocks during water inrush disasters in tunnels crossing fault zones, based on the similarity theory of geomechanical model tests, the physical–mechanical parameters of a prototype rock’s mass were first analyzed for similarity, and the target values of similar materials were determined. Secondly, using sand as coarse aggregate, talcum powder as fine aggregate, gypsum and clay as binders, and Vaseline as a regulator, a fault-simulating material suitable for model tests was developed through extensive laboratory experiments. Finally, with material deformation characteristics and strength failure characteristics as key control indicators, parameters such as uniaxial compressive strength, permeability coefficient, unit weight, and elastic modulus are synergistically regulated to determine the influence of different component ratios on material properties. The experimental results show that the uniaxial compressive strength and permeability coefficient of similar materials are mainly controlled by gypsum and Vaseline. Cohesion is mainly controlled by clay and Vaseline. The application of this similar material in the model test of the tunnel fault water inrush disaster successfully reproduced the disaster evolution process of fault water inrush, meeting the requirements of the model test for similar materials of faults. Furthermore, it provides valuable guidance for the selection of similar materials and the optimization of mix proportions for fault disaster model tests involving similar characteristics. Full article

The existence of fault zones in high-intensity earthquake areas has a serious impact on engineering structures, and the longitudinal response of tunnels crossing faults needs further in-depth research. To analyze the tangential contact effect between the surrounding rock and the tunnel lining, and the axial deformation characteristics of the tunnel structure, tangential foundation springs were introduced and a theoretical model for the longitudinal response of the tunnel under fault dislocation was established. Firstly, the tunnel was simplified as a finite-length beam. The normal and tangential springs were taken to represent the interaction between the soil and the lining. The fault’s free-field displacement was applied at the end of the normal foundation spring to simulate fault dislocation, and the differential equation for the longitudinal response of the tunnel structure was obtained. The analytical solution of the structural response was obtained using the Green’s function method. Then, the three-dimensional finite difference method was used to verify the effectiveness of the analytical model in this paper. The results show that the tangential contact effect between the surrounding rock and the lining has a significant impact on the longitudinal response of the tunnel structure. Ignoring this effect leads to an error of up to 35.33% in the peak value of the structural bending moment. Finally, the influences of the width of the fault zone, the soil stiffness of the fault zone, and the stiffness of the tunnel lining on the longitudinal response of the tunnel were explored. As the fault width increases, the internal force of the tunnel structure decreases. Increasing the lining concrete grade leads to an increase in the internal force of the structure. The increase in the elastic modulus of the surrounding rock in the fault area reduces the bending moment and shear force of the structure and increases the axial force. The research results can provide a theoretical basis for the anti-dislocation design of tunnels crossing faults. Full article

Existing risk assessment approaches for soft rock tunnels in fault-fractured zones typically employ single weighting schemes, inadequately integrate subjective and objective weights, and fail to define clear risk. This study proposes a risk-grading methodology that integrates an enhanced game theoretic weight-balancing algorithm with an optimized cloud entropy extension cloud model. Initially, a comprehensive indicator system encompassing geological (surrounding rock grade, groundwater conditions, fault thickness, dip, and strike), design (excavation cross-section shape, excavation span, and tunnel cross-sectional area), and support (support stiffness, support installation timing, and construction step length) parameters is established. Subjective weights obtained via the analytic hierarchy process (AHP) are combined with objective weights calculated using the entropy, coefficient of variation, and CRITIC methods and subsequently balanced through a game theoretic approach to mitigate bias and reconcile expert judgment with data objectivity. Subsequently, the optimized cloud entropy extension cloud algorithm quantifies the fuzzy relationships between indicators and risk levels, yielding a cloud association evaluation matrix for precise classification. A case study of a representative soft rock tunnel in a fault-fractured zone validates this method’s enhanced accuracy, stability, and rationality, offering a robust tool for risk management and design decision making in complex geological settings. Full article

To address the challenge of dynamic monitoring during grouting operations in coal mine fault zones under pressurized mining, this study proposes the Borehole–Tunnel Joint Resistivity Method (BTJRM). By integrating three-dimensional (3D) electrode arrays in both tunnels and boreholes with 3D resistivity inversion technology, this approach enables fully automated underground data acquisition and real-time processing, facilitating comprehensive dynamic monitoring of grout propagation. A case study was conducted on a coal mine fault grouting project, where tunnel and borehole survey lines were deployed to construct a 3D cross-monitoring network, overcoming the limitations of traditional 2D data acquisition. Finite volume method and quasi-Gauss–Newton inversion algorithms were employed to analyze dynamic resistivity variations, enhancing spatial resolution for detailed characterization of grout migration. Key findings include: (1) Grout diffusion reduced resistivity by 10%, aligning with electrical response patterns during fracture-filling stages; (2) 3D inversion reveals that grout propagates along the principal stress axis, forming a “Y”-shaped low-resistivity anomaly zone that penetrates the fault structural block and extends into roadway areas. The maximum planar and vertical displacements of grout reach 100 m and 40 m, respectively. Thirty days post-grouting, resistivity recovers by up to 22%, reflecting the electrical signature of grout consolidation; (3) This method enables 3D reconstruction of grout diffusion pathways, extends the time window for early warning of water-conducting channel development, and enhances pre-warning capabilities for grout migration. It provides a robust framework for real-time sealing control of fault strata, offering a novel dynamic monitoring technology for mine water inrush prevention. The technology can provide reliable grouting evaluation for mine disaster control engineering. Full article

The dislocation of the active fault zone altered the stress distribution and geometry of the track structure in the tunnel, which in turn affected the safety and stability of the train operation. Polyurethane-solidified track bed (PSTB) is suitable for sections crossing through active fault zones due to its excellent serviceability and adaptability to deformation. In this study, the stress and deformation response induced by active fault dislocation are investigated for this novel track structure. The corresponding deformation of track structure is subsequently introduced into a vehicle-track dynamics model to calculate the train operation safety index. The study examines the impact of fault displacement on railway track structures, revealing significant vertical deformation in rails that corresponds to the displacement magnitude. The effects are mainly confined to the active fault zone and its immediate surroundings, with variations depending on the fault zone’s structural characteristics. Key factors such as larger displacements, steeper fault angles, and narrower fault zones increase stress on track components, particularly the wide sleeper, which is prone to cracking and represents a structural vulnerability. Higher fault displacement, narrower zones, steeper angles, and increased train speeds elevate derailment risks and wheel load reduction rates, potentially exceeding safety limits. To ensure safety under typical fault conditions, train speeds should not exceed 250 km/h for PSTB with a 40 mm displacement and a 60° fault angle. These findings provide critical guidance for railway construction in fault-prone areas. Full article

Permanent displacements caused by active faults can lead to the severe deformation of tunnel liners. To investigate the effect of fault fracture deformation patterns on the deformation of tunnel liners under fault dislocation, this paper categorized three fault-zone fracture deformation patterns and conducted numerical simulations for tunnel’s surrounding rock-liner systems under different fracture deformation patterns. Furthermore, the longitudinal displacement, relative deformation, axial stress, and shear stress of the tunnel liner were measured to characterize the mechanical response of the tunnel, and the effects of fault geometric parameters on the mechanical response of the tunnel liner were explored. The results showed that fracture deformation patterns were broadly categorized into uniform fracture deformation, linear fracture deformation, and nonlinear fracture deformation patterns. The distribution patterns of tunnel liner stress and deformation under these fracture deformation patterns were similar, but the magnitude of the peaks and the intensity of their effects differed. Under reverse fault dislocation, the peak values of tunnel liner deformation and shear stress occurred at the rupture plane. In contrast, the maximum axial stress was observed at the interface between soft and hard rock masses. When the core width of the fault zone decreased and the fault dip direction increased, the intensity of the mechanical response of the tunnel liner increased. With the fault dip decreased, the axial stress in the tunnel liner transitions from tensile-compressive stress to compressive stress, the shear stress decreases, and the intensity of the relative deformation of the tunnel liner increases. These research results can provide significant guidelines for tunnel design crossing the reverse fault. Full article

Tunnels crossing active faults frequently experience simultaneous exposure to fault dislocation and seismic action during operation. To study the damage behavior of tunnels under the combined effects of fault dislocation and seismic action, a three-dimensional nonlinear finite element model was established. This model simulates fault dislocation superimposed on seismic action in the context of tunnel engineering through active faults. The main conclusions are as follows: (1) The acceleration amplification phenomenon occurs in the tunnels after the superposition of seismic action; at the same time, the degree and scope of tunnel damage increase significantly, in which the increase in tensile damage is more significant. (2) The initial damage from fault dislocation worsens tunnel damage under seismic action, as evidenced by the energy dissipation characteristics. (3) As the initial fault displacement and peak seismic acceleration increase, the extent of lining damage also increases. Notably, compressive damage to the lining is symmetrically distributed along the fault plane, whereas tensile damage is significantly more severe within the fault rupture zone. (4) Even moderate earthquakes can cause severe damage to tunnels crossing active faults. Therefore, tunnel construction in these areas must include disaster prevention and mitigation strategies. Full article

Taking the tunnels crossing active faults in China’s Sichuan–Tibet Railway as the research background, experimental studies were conducted using a custom-developed split model box. The research focused on the cracking characteristics of the surrounding rock surface under the action of strike-slip faults, the progressive failure process of the tunnel model, and the mechanical response of the tunnel lining. In-depth analyses were performed on the tunnel damage mechanism under strike-slip fault action and the mitigation effects of combined anti-dislocation measures. The results indicate the following: Damage to the upper surface of the surrounding rock primarily occurs within the fault fracture zone. The split model box enables the graded transfer of fault displacement within this zone, improving the boundary conditions for the model test. Under a 50 mm fault displacement, the continuous tunnel experiences severe damage, leading to a complete loss of function. The damage is mainly characterized by circumferential shear and is concentrated within the fault fracture zone. The zone 20 cm to 30 cm on both sides of the fault plane is the primary area influenced by tunnel forces. The force distribution on the left and right sidewalls of the lining exhibits an anti-symmetric pattern across the fault plane. The left side wall is extruded by surrounding rock in the moving block, while the right side wall experiences extrusion from the surrounding rock in the fracture zone, and there is a phenomenon of dehollowing and loosening of the surrounding rock on both sides of the fault plane; the combination of anti-dislocation measures significantly enhances the tunnel’s stress state, reducing peak axial strain by 93% compared to a continuous tunnel. Furthermore, the extent and severity of tunnel damage are greatly diminished. The primary cause of lining segment damage is circumferential stress, with the main damage characterized by tensile cracking on both the inner and outer surfaces of the lining along the tunnel’s axial direction. Full article

Hydraulic tunnels are prone to pass through faults and high-intensity earthquake areas, which will cause serious damage under fault dislocation and earthquake action. Fault dislocation and seismic excitation are often considered separately in previous studies. For tectonic earthquakes with higher frequency in seismic phenomena, fault dislocation and ground motion are often associated, and fault dislocation is usually the cause of earthquake occurrence, so it is limiting to consider the two separately. Moreover, strong earthquake records show that there will be significant differences in the mainland vibration within 50 m. The uniform ground motion inputs in previous studies are not suitable for long hydraulic tunnels. This paper begins with the simulation of non-uniform stochastic seismic excitations that consider spatial correlation. Based on stochastic vibration theory, multiple multi-point acceleration time-history curves that can reflect traveling wave effects, coherence effects, attenuation effects, and non-stationary characteristics are synthesized. Furthermore, a fault velocity function is introduced to account for the velocity effect of fault dislocation. Finally, numerical analyses of the response patterns of the tunnel lining under four different conditions are conducted based on an actual engineering project. The results indicate the following: (a) the maximum lining response values occur under the combined effects of fault dislocation and non-uniform seismic excitation, indicating its importance in the seismic resistance of the tunnel. (b) Compared to uniform seismic excitation, the peak displacement of the tunnel under non-uniform seismic excitation increases by up to 6.42%, and the peak maximum principal stress increases by up to 28%. Additionally, longer tunnels exhibit a noticeable delay effect in axial deformation during an earthquake. (c) Under non-uniform seismic excitation, the larger the fault dislocation magnitude, the greater the peak displacement and peak maximum principal stress at the monitoring points of the lining. The simulation results show that the extreme response values primarily occur at the crown and haunches of the tunnel, which require special attention. The research can provide valuable references for the seismic design of cross-fault tunnels. Full article

This paper investigated the response of a cross-fault water conveyance tunnel under the combined action of faulting dislocation and seismic loading. The current work studied the mechanical properties of the wall rock–lining contact surface. Finite difference method (FDM) code was used for the numerical simulation test to reproduce the shear test and calibrate the parameters. In the analysis of the combined faulting dislocation and strong earthquake impact on the cross-fault tunnel, the FDM was used with special consideration of the wall rock–lining interaction. The result showed that the Coulomb contact model in the FDM code could satisfactorily simulate the shear behavior of wall rock–lining contact surface. In the mechanical response calculation of the cross-fault tunnel under the faulting dislocation–seismic loading action, the magnitude of the initial faulting distance had a significant effect on the seismic relative deformation of the tunnel. The permanent deformation caused by the seismic loading increased with the initial faulting dislocation. The position of the maximum shear stress on the contact interface was related to the faulting dislocation mode, and it was distributed on the side of the tunnel squeezed by the active plate. In the high seismic risk regions with extensive development of active faults, it was necessary to consider the initial crack caused by the faulting dislocation in the stability evaluation of the cross-fault tunnel. Then, the seismic resistance study of the tunnel was followed. Full article

Maseve Mine is located in the western limb of the Bushveld Complex, recognized as the largest layered igneous intrusion in the world. The study shows results from surface (SP1, SP2, and SP3) and tunnel (T3a, T3b, and TP4b) reflection seismic profiles, totaling 4150 m. Tunnel seismic data were acquired using a seismic landstreamer and spiked geophones with 5 m receiver and shot spacing, as well as a sledgehammer for shots due to space constraints and safety. The profiles, 10–50 m above mineral deposits, crossed major geological structures. Surface seismic profiles used cabled systems and wireless sensors with 5 m and 10 m receiver spacing, respectively, and a 500 kg drop hammer as a source with 10 m shot spacing. Despite high noise levels from mine infrastructure and power cables, a careful processing workflow enhanced target reflections. Interpretation was constrained using borehole data, geological models, and 2D/3D seismic modeling. The processed data exhibit gently dipping reflections associated with faults and dykes, imaging the target mineralization (Merensky Reef and Upper Group 2) and a possible extension. Tunnel seismic experiments demonstrated the application of seismic methods using in-mine infrastructure, while surface experiments proved efficient, illustrating small-scale seismic surveys’ capability to image the subsurface, adding value in active mining environments for exploration with cost-effective seismic equipment. Full article

Machine learning (ML) approaches, widely used in civil engineering, have the potential to reduce computing costs and enhance predictive capabilities. However, many ML methods have yet to be applied to develop models that accurately analyze the nonlinear dynamic response of cross-fault hydraulic tunnels (CFHTs). To predict CFHT models and fragility curves effectively, we identify the most effective ML techniques and improve prediction capacity and accuracy by initially creating an integrated multivariate earthquake intensity measure (IM) from nine univariate earthquake IMs using principal component analysis. Structural reactions are then performed using incremental dynamic analysis by a multimedium-coupled interaction system. Four techniques are used to test ML–principal component analysis (PCA) feasibility. Meanwhile, mathematical statistical parameters are compared to standard probabilistic seismic demand models of expected and computed values using ML-PCA. Eventually, multiple stripe analysis–maximum likelihood estimation (MSA-MLE) is applied to assess the seismic performance of CFHTs. This study highlights that the Gaussian process regression and integrated IM can improve reliable probability and reduce uncertainties in evaluating the structural response. Thorough numerical analysis, using the suggested methodology, one can efficiently assess the seismic fragilities of the tunnel by the predicted model. ML-PCA techniques can be viewed as an alternate strategy for seismic design and CFHT performance enhancement in real-world engineering. Full article

In the fractured weak fault zone, rock mass exhibits low strength and poor self-stability. The geological conditions are complex, and when tunnels cross through fractured zones, significant deformations and collapses are prone to occur, leading to geological hazards. This paper investigates the in situ stress and deformation patterns of the Dongmachang Tunnel No. 1, proposing support solutions for addressing tunnel deformations through field experiments and numerical simulations. The on-site monitoring results indicate that despite implementing measures such as grouting reinforcement and temporary steel supports to control surrounding rock deformation, significant structural damage still occurred in the tunnel support system. The manifestations included severe sinking and cracking of the arch crown, strong inward deformation of the sidewalls, widespread cracking, crushing, and spalling of shotcrete, slight arching uplift, and severe distortion and twisting of steel arches forming a “Z” or “S” shape. To ensure tunnel safety and control the stability of excavations in weak fault zones, a comparison of tunnel deformation support schemes is conducted through field experiments and numerical simulations, indicating that replacing the upper tunnel structure and invert can effectively prevent tunnel deformations. These measures are vital for the sustainable development of tunnel. Full article

This study investigates the water pressure distribution and deformation patterns in tunnel linings within water-rich tunnels traversing fault zones, focusing on the Gudou Mountain Tunnel. The study utilized field tests and numerical simulations to assess the water pressure distribution around test sections. Following the confirmation of consistent water pressure distribution patterns from field tests and simulations, we analyzed the deformation patterns of tunnel linings at various water levels. The results showed that water pressure is highest at the tunnel’s inverted arch and arch foot, moderately high at the vault and spandrel, and lowest at the arch waist. The sections RK51 + 590 and LK51 + 640, located on opposite sides of a fault crush zone, experience high fragmentation of surrounding rock. This allows rainfall and reservoir water to seep through fractures, causing increased water pressure and significant deformation at the inverted arch of these sections. With rising groundwater levels, deformation intensifies at the inverted arch, arch foot, and vault. The appearance of macro-cracks in these critical areas leads to groundwater seepage through the cracks, severely impacting tunnel operations. Consequently, reinforcing the inverted arch, arch foot, and vault is crucial to reduce the risk of water leakage in the tunnel. Full article

The rock strength in an active fault zone is low and the surrounding rock is fractured and has poor stability, making any subsea tunnel crossing the active fault zone extremely susceptible to disasters such as tunnel collapse, sudden water ingress, and mud inrush. This poses a potential threat to the construction project, making the dynamic stability analysis of a subsea tunnel crossing an active fault zone of great significance. This study takes the second subsea tunnel crossing the Cangkou Fault in Jiaozhou Bay as the engineering background and conducts numerical simulations by employing different lining stiffnesses for tunnel excavation, as well as applying dynamic loads. The dynamic stability of the subsea tunnel crossing the active fault zone is evaluated by comparing and analyzing the lining’s displacement, peak acceleration, and stress characteristics. This study explores the disaster-causing mechanisms of active fractures, determining that the hazard of orthogonal misalignment in an active fault zone is the least severe, while the hazard of opposite misalignment is the most severe. This research provides a basis for disaster prevention and mitigation in active fracture zones. Full article
