Search Results (12)

Electronic speckle pattern interferometry (ESPI) is widely used in fields such as materials science, biomedical research, surface morphology analysis, and optical component inspection because of its high measurement accuracy, broad frequency range, and ease of measurement. Phase extraction is a critical stage in ESPI. However, conventional phase extraction methods exhibit problems such as low accuracy, slow processing speed, and poor generalization. With the continuous development of deep learning in image processing, the application of deep learning in phase extraction from electronic speckle interferometry images has become a critical topic of research. This paper reviews the principles and characteristics of ESPI and comprehensively analyzes the phase extraction processes for fringe patterns and wrapped phase maps. The application, advantages, and limitations of deep learning techniques in filtering, fringe skeleton line extraction, and phase unwrapping algorithms are discussed based on the representation of measurement results. Finally, this paper provides a perspective on future trends, such as the construction of physical models for electronic speckle interferometry, improvement and optimization of deep learning models, and quantitative evaluation of phase extraction quality, in this field. Full article

The mechanical properties of the dental filling material (DFMs) strongly influence the lifetime and durability of the tooth reparation performed. Among the most significant mechanical characteristics, one has to mention the Poisson’s ratio and the elastic modulus (Young’s modulus). They, during the cyclic mastication load, can prevent or aid in the prevention of secondary dental decays by provoking micro-cracks, the de-bonding of the filling material from the natural dental tissue, as well as fatigue at the level of their interface. The authors performed a scoping analysis of the nowadays-involved experimental methods, together with a critical review, putting in evidence of their advantages and limits. Based on the developments, they propose a new approach in this sense by involving the electronic speckle pattern interferometry (ESPI)/shearography high-accuracy optical method. They illustrate the advantages of this method in establishment of the elastic modulus, but they also propose a high-accuracy methodology in the estimation of Poisson’s ratio. Based on the briefly-illustrated experimental results, one can conclude that ESPI/shearography can become a very useful tool for research, even though it is not a common (nowadays widely applied) method, such as three-point bending or strain gauge methods. Full article

An integrated method, which combines Electronic Speckle Pattern Interferometry, impulse response measurements, finite element method simulations, and psychoacoustic tests, is proposed to evaluate the vibroacoustic behavior of a carbon fiber bouzouki. Three of the carbon fiber instruments are manufactured, and one is qualified via interferometric experimental measurements with reference to a traditional wooden bouzouki, which was evaluated for its sound and playability by the proposed method. Psychoacoustic tests were used to evaluate the sound and playability of the newly qualified carbon fiber bouzouki, which was further modeled by the finite element method and simulated. The simulation results agreed well with the experimental measurements. Furthermore, finite element simulation results of the qualified carbon fiber bouzouki were demonstrated with reference to the traditional wooden bouzouki experimental results, providing new findings crucial for the optimization of the manufacturing and the vibroacoustic behavior of the carbon fiber instrument. The proposed integrated method can be applied to a variety of carbon fiber stringed musical instruments. Full article

The deformation and fracture mechanism in 7075 aluminum alloy is discussed based on a field theoretical approach. A pair of peak-aged and overaged plate specimens are prepared under the respective precipitation conditions, and their plastic deformation behaviors are visualized with two-dimensional electronic speckle pattern interferometry (ESPI). The in-plane velocity field caused by monotonic tensile loading is monitored continuously via the contour analysis method of ESPI. In the plastic regime, the peak-aged specimen exhibits a macroscopically uniform deformation behavior, while the annealed specimen exhibits non-uniform deformation characterized by a localized shear band. The occurrence of the shear band is explained by the transition of the material’s elastic resistive mechanism from the longitudinal force dominant to shear force dominant mode. The shear force is interpreted as the frictional force that drives mobile dislocations along the shear band. The dynamic behavior of the shear band is explained as representing the motion of a solitary wave. The observed decrease in the solitary wave’s velocity is accounted for by the change in the acoustic impedance with the advancement of plastic deformation. Full article

Displacements or deformations of materials or structures are measured with linear variable differential transducers (LVDT), fibre optic sensors, laser sensors, and confocal sensor systems, while strains are measured with electro-resistant tensometers or wire strain gauges. Measurements significantly limited to a point or a small area are the obvious disadvantage of these measurements. Such disadvantages are eliminated by performing measurements with optical techniques, such as digital image correlation (DIC) or electronic speckle pattern interferometry (ESPI). Many devices applied to optical measurements only record test results and do not cooperate with the system that exerts and controls load. This paper describes the procedure for preparing a test stand involving the Digital Image Correlation system ARAMIS 6M for remote-controlled loading. The existing hydraulic power pack (ZWICK-ROELL) was adapted by installing the modern NI cRIO-9022 controller operating under its own software developed within the LABVIEW system. The application of the DIC techniques to directly control load on the real structure is the unquestionable innovation of the described solution. This led to the elimination of errors caused by the test stand susceptibility and more precise relations between load and displacements/strains which have not been possible using the previous solutions. This project is a synergistic and successful combination of civil engineering, computer science, automatic control engineering and electrical engineering that provides a new solution class. The prepared stand was tested using two two-span, statically non-determinable reinforced concrete beams loaded under different conditions (force or displacement). The method of load application was demonstrated to affect the redistribution of bending moments. The conducted tests confirmed the suitability of the applied technique for the remote controlling and recording of test results. Regardless of the load control method (with force or displacement), convergent results were obtained for the redistribution of bending moments. Force-controlled rotation of the beam section over the support was over 50% greater than rotation of the second beam controlled with an increase in the displacement. Full article

The application of a recent field theory of deformation and fracture to nondestructive testing (NDT) is discussed. Based on the principle known as the symmetry of physical laws, the present field theory formulates all stages of deformation including the fracturing stage on the same theoretical basis. The formalism derives wave equations that govern the spatiotemporal characteristics of the differential displacement field of solids under deformation. The evolution from the elastic to the plastic stage of deformation is characterized by a transition from longitudinal (compression) wave to decaying longitudinal/transverse wave characteristics. The evolution from the plastic to the fracturing stage is characterized by transition from continuous wave to solitary wave characteristics. Further, the evolution from the pre-fracturing to the final fracturing stage is characterized by transition from the traveling solitary wave to stationary solitary wave characteristics. In accordance with these transitions, the criterion for deformation stage is defined as specific spatiotemporal characteristics of the differential displacement field. The optical interferometric technique, known as Electronic Speckle-Pattern Interferometry (ESPI), is discussed as an experimental tool to visualize those wave characteristics and the associated deformation-stage criteria. The wave equations are numerically solved for the elastoplastic stages, and the resultant spatiotemporal behavior of the differential displacement field is compared with the experimental results obtained by ESPI. Agreement between the experimental and numerical results validates the present methodology at least for the elastoplastic stages. The solitary wave characteristics in the fracturing stages is discussed based on the experimental results and dislocation theory. Full article

A method to diagnose the deformation status of solid objects under loading is discussed. The present method is based on a recent field theory of deformation and fracture and optical interferometry known as the Electronic Speckle-Pattern Interferometry (ESPI). Using one of the most fundamental principles of physics referred to as symmetry in physics, this field theory formulates all stages of deformation and fracture on the same theoretical basis. In accordance with the formalism, the theory has defined the criteria for different stages of deformation (linear elastic, plastic and fracturing stages) expressed by certain spatiotemporal features of the differential displacement (the displacement occurring during a small time interval). The ESPI is used to visualize the differential displacement field of a specimen as two-dimensional, full-field interferometric fringe patterns. This paper reports experimental evidence that demonstrates the usefulness of the present method. A tensile load is applied to an aluminum-alloy plate specimen at a constant pulling rate and the resultant in-plane displacement field is visualized with a two-dimensional ESPI setup. The differential displacement field is obtained at each time step and the interferometric fringe patterns are interpreted based on the criterion for each stage of deformation. It has been found that the criteria of linear elastic deformation, plastic deformation and fracturing stage are clearly observed in the corresponding fringe patterns and that the observations are consistent with the loading characteristics. Full article

This paper describes the vibration characteristics of a dual-bimorph piezoelectric pumping element under fluid–structure coupling. Unlike the single bimorph used in most previous studies, the proposed device comprises two piezoelectric bimorphs within an acrylic housing. Amplitude-fluctuation electronic speckle pattern interferometry (AF-ESPI) was used to examine the visible displacement fringes in order to elucidate the anti-phase as well as in-phase motions associated with vibration. Analysis was also conducted using impedance analysis and laser Doppler vibrometer (LDV) based on the measurement of point-wise displacement. The experimental results of resonant frequencies and the corresponding mode shapes are in good agreement with those obtained using finite element analysis. The gain of flow rate obtained by the anti-phase motion of the dual-bimorph pumping element is larger than both those obtained by in-phase motion and the single bimorph pumping element. This work greatly enhances our understanding of the vibration characteristics of piezoelectric pumping elements with two bimorphs, and provides a valuable reference for the further development of bionic pump designs. Full article

The time-averaged electronic speckle pattern interferometry (ESPI) is employed to measure the frequencies and mode shapes of thin, cantilevered plates with root-slit. The first 12 order linear resonance frequency and mode shape of an intact cantilevered plate is determined by using FEM calculation. The dynamic response of the intact specimen forced by a PZT actuator is measured and its super-harmonic resonance of forced response is investigated experimentally. The results show that the principal mode shape of super-harmonic vibration is similar to its natural modal. In contrast to linear forcing vibration, the threshold of force for super-harmonic resonance is much higher than that of the former. In addition, linear free response of four cantilevered root-slit plates with variation length of slit are analyzed by applying the FEM calculation, and their responses of forcing vibration were measured by using the ESPI method. The validity and accuracy of the numerical prediction are confirmed through experimental studies. The present work shows that the ESPI technique can provide whole-field and real-time measurement for vibration analysis and can also be employed for validation of the FEM calculation. Full article

This study reports the application of an optoacoustic method for evaluating the bonding strength of ultrasonically bonded joints in a non-destructive and non-contact fashion. It is proposed that the bonding strength is correlated with the resonant frequency of bonded joints. The bonding strength measured with a destructive tensile test roughly increased with the vibration time, however, it varied, causing the transitional and dispersed formation of micro-bonds at the bonding interface. Scanning Electron Microscopic observation of the fractured surface suggested that the bonding strength depends on the total bonded area of micro-bonds. Frequency response of the bonded joint was examined with a non-destructive method using a piezo-electric vibrator. The experiment revealed that the resonant frequency exponentially increased with the bonding strength. In addition, this vibration behavior was dynamically visualized with electronic speckle pattern interferometry (ESPI). The correlation between the bonded area and the resonant frequency is discussed based on finite element analysis. The results indicate the possibility for in-situ evaluation of the ultrasonic bonding strength. Full article

Engineering techniques used to evaluate strain-stress fields, materials’ mechanical properties, and load transfer mechanisms, among others, are useful tools in the study of biomechanical applications. These engineering tools, as experimental and numerical ones, were imported to biomechanics, in particular in dental biomechanics, a few decades ago. Several experimental techniques have been used in dental biomechanics, like photoelasticity, ESPI (Electronic Speckle Pattern Interferometry), strain gages, and other kinds of transducers. However, these techniques have some limitations. For instance, photoelasticity and ESPI give the overall field pattern of the strain, showing the stress-strain concentration points. These methods cannot give an accurate measurement at all points. On the contrary, strain gages can be used to perform local measurements. However, as they use electrical resistances, their use is limited to perform in vivo measurements. Optical fiber sensors have already been used in dentistry, for diagnostic and therapeutic purposes, and in dental biomechanics studies. Lasers have also been used in clinical dentistry for a few decades. Other optical technologies, like optical coherence tomography (OCT), became suitable for dental practice and nowadays it is perhaps one that has had more development in dentristry, along with lasers. Full article

In this work, a fiber Bragg grating (FBG) sensing system which can measure the transient response of out-of-plane point-wise displacement responses is set up on a smart cantilever beam and the feasibility of its use as a feedback sensor in an active structural control system is studied experimentally. An FBG filter is employed in the proposed fiber sensing system to dynamically demodulate the responses obtained by the FBG displacement sensor with high sensitivity. For comparison, a laser Doppler vibrometer (LDV) is utilized simultaneously to verify displacement detection ability of the FBG sensing system. An optical full-field measurement technique called amplitude-fluctuation electronic speckle pattern interferometry (AF-ESPI) is used to provide full-field vibration mode shapes and resonant frequencies. To verify the dynamic demodulation performance of the FBG filter, a traditional FBG strain sensor calibrated with a strain gauge is first employed to measure the dynamic strain of impact-induced vibrations. Then, system identification of the smart cantilever beam is performed by FBG strain and displacement sensors. Finally, by employing a velocity feedback control algorithm, the feasibility of integrating the proposed FBG displacement sensing system in a collocated feedback system is investigated and excellent dynamic feedback performance is demonstrated. In conclusion, our experiments show that the FBG sensor is capable of performing dynamic displacement feedback and/or strain measurements with high sensitivity and resolution. Full article
