Accurate fetal R-peak detection from low-SNR fetal electrocardiogram (FECG) signals remains a critical challenge as current NI-FECG methods struggle to extract high SNR FECG signals and conventional algorithms fail when signal quality deteriorates. We proposed a U-Net-based method that enables robust R-peak detection directly from low-SNR FECG signals (0–12 dB), bypassing the need for high-SNR inputs that are clinically difficult to acquire. The method was evaluated on both real (A&D FECG) and synthetic (FECGSYN) databases, comparing against ten state-of-the-art detectors. The proposed method significantly reduces false predictions compared to commonly used detection algorithms, achieving a PPV of 99.81%, an SEN of 100.00%, and an F1-score of 99.91% on the A&D FECG database and a PPV of 99.96%, an SEN of 99.93%, and an F1-score of 99.94% on the FECGSYN database. Further investigation of robustness in low-SNR conditions (0 dB, 5 dB, and 10 dB) achieved 87.38% F1-score at 0 dB SNR on real signals, surpassing the best-performing algorithm implemented in Neurokit by 13.58%. In addition, the algorithm showed ≤2.65% performance variation across tolerance windows (50 reduced to 20 ms), further underscoring its detection accuracy. Overall, this work reduces the reliance on high-SNR FECG signals by reliably extracting R-peaks from suboptimal signals, providing implications for the reliability of fetal heart rate variability analysis in real-world noisy environments. Full article

Background: Early identification of left ventricular ejection fraction (LVEF) levels during the progression of hypertension is essential to prevent cardiac deterioration. However, achieving a non-invasive, cost-effective, and definitive assessment is challenging. It has prompted us to develop a comprehensive machine learning framework for the automatic quantitative estimation of LVEF levels from electrocardiography (ECG) signals. Methods: We enrolled 200 hypertensive patients from Zhongshan City, Guangdong Province, China, from 1 November 2022 to 1 January 2025. Participants underwent 24 h Holter monitoring and echocardiography for LVEF estimation. We developed a comprehensive machine learning framework that initiated with preprocessed ECG signal in one-hour intervals to extract CMSE-based heart rate variability (HRV) features, then utilized machine learning models such as linear regression (LR), Support Vector Machines (SVMs), and random forests (RFs) with recursive feature elimination for optimal LVEF estimation. Results: The LR model, notably during early night interval (20:00–21:00), achieved a RMSE of 4.61% and a MAE of 3.74%, highlighting its superiority. Compared with other similar studies, key CMSE parameters (Scales 1, 5, Slope 1–5, and Area 1–5) can effectively enhance regression models’ estimation performance. Conclusion: Our findings suggest that CMSE-derived circadian HRV features from Holter ECG could serve as a non-invasive, cost-effective, and interpretable solution for LVEF assessment in community settings. From a machine learning interpretable perspective, the proposed method emphasized CMSE’s clinical potential in capturing autonomic dynamics and cardiac function fluctuations. Full article

Chronic kidney disease (CKD) is a progressive pathology characterized by gradual function loss. It is accompanied by complications including cardiovascular disorders. This study involves 4-h electrocardiographic records from the Telemetric and Holter ECG Warehouse (THEW) project database to analyze the dynamics in heart rate variability (HRV) indices of 51 patients with CKD. It proposes three algorithms to process long-term electrocardiography records: QRS complex and R-wave detection, premature ventricular contraction (PVC) identification, and tachograms. PVCs were analyzed with the consideration of the changes occurring before, during, and after hemodialysis, especially during the interdialytic period. The hour with the highest PVCs occurrence was identified and used to assess HRV fluctuations and segmented into 5 min blocks with a 0.77 min overlap, yielding a dynamic HRV vector, one for each of seven HRV indices selected to evaluate autonomic nervous system balance. R-wave and PVC identification resulted in 97.53% and 85.83% positive predictive values, respectively. PVCs’ prevalence and HRV changes’ relationship in 48 h records could relate to cardiovascular risk. The stratification of hemodialysis patients into three distinct PVC patterns (p < 0.001) identified two clinically significant high-risk subgroups: Class 1, indicative of electrical instability, and Class 3, of advanced autonomic dysfunction, demonstrating divergent arrhythmogenic mechanisms with direct implications for risk stratification. Full article

Background and Objectives: Preeclampsia, a pregnancy-induced hypertensive disorder, shares cardiovascular characteristics in etiology, prognosis, and fetomaternal risks. Electrocardiography plays a pivotal role in assessing cardiovascular risks. Beyond conventional predictors, identifying easily obtainable and reproducible electrocardiographic markers may significantly contribute to the early identification of individuals at risk of preeclampsia. In this study, we aimed to investigate the value of the Frontal QRS-T angle and other electrocardiographic parameters in predicting the development of preeclampsia. Materials and Methods: A total of 62 pregnant patients diagnosed with preeclampsia and 50 healthy pregnant patients as the control group were included in this study. The first- and third-trimester electrocardiographic parameters were compared within groups and between groups. Results: The Frontal QRS-T angle was significantly elevated in patients with preeclampsia compared to the controls (55.0 ± 40.8 vs. 19.5 ± 15.1; p = 0.002). The first-trimester Frontal QRS-T angles in the patients with preeclampsia were higher than those of the controls (29.5 ± 25.0 vs. 15.3 ± 11.5; p = 0.015). A high Frontal QRS-T angle independently marked preeclampsia development in antenatal and late pregnancy (p = 0.003 and p = 0.042, respectively). The diagnostic accuracy of the Frontal QRS-T angle in predicting preeclampsia surpassed other electrocardiographic parameters. Conclusions: This study shows that the Frontal QRS-T angle may be a candidate to be an independent predictor for the development of preeclampsia. In this context, the Frontal QRS-T angle, which is an electrocardiographic parameter, seems promising. Full article

Electrocardiography (ECG) has emerged as a ubiquitous diagnostic tool for the identification and characterization of diverse cardiovascular pathologies. Wearable health monitoring devices, equipped with on-device biomedical artificial intelligence (AI) processors, have revolutionized the acquisition, analysis, and interpretation of ECG data. However, these systems necessitate AI processors that exhibit flexible configuration, facilitate portability, and demonstrate optimal performance in terms of power consumption and latency for the realization of various functionalities. To address these challenges, this study proposes an instruction-driven convolutional neural network (CNN) processor. This processor incorporates three key features: (1) An instruction-driven CNN processor to support versatile ECG-based application. (2) A Processing element (PE) array design that simultaneously considers parallelism and data reuse. (3) An activation unit based on the CORDIC algorithm, supporting both Tanh and Sigmoid computations. The design has been implemented using 110 nm CMOS process technology, occupying a die area of 1.35 mm² with 12.94 µW power consumption. It has been demonstrated with two typical ECG AI applications, including two-class (i.e., normal/abnormal) classification and five-class classification. The proposed 1-D CNN algorithm performs with a 97.95% accuracy for the two-class classification and 97.9% for the five-class classification, respectively. Full article

Electrocardiography (ECG) is a simple and safe tool for detecting heart conditions. Despite the diaspora of existing heartbeat classifiers, improvements such as real-time heartbeat identification and patient-independent classification persist. Reservoir computing (RC) based heartbeat classifiers are an emerging computational efficiency solution that is potentially recommended for real-time concerns. However, multiclass patient-independent heartbeat classification using RC-based classifiers has not been considered and constitutes a challenge. This study investigates patient-independent heartbeat classification by leveraging traditional RC and next-generation reservoir computing (NG-RC) solely or in a cascade. Three RCs were investigated for classification tasks: a linear RC featuring linear internal nodes, a nonlinear RC with a nonlinear internal node, and an NG-RC. Each of these has been evaluated independently using either linear ridge regression or multilayer perceptron (MLP) as readout models. Only three classes were considered for classification: the N, V, and S categories. Techniques to deal with the imbalanced nature of the data, such as the synthetic minority oversampling technique (SMOTE) and oversampling by replacement, were used. The MIT-BIH dataset was used to evaluate classification performance. The area under the curve (AUC) criterion was used as an evaluation metric. The NG-RC-based model improves classification performance and mitigates the overfitting issue. It has improved classification performance by 4.18% and 2.31% for the intra-patient and inter-patient paradigms, respectively. By cascading RC and NG-RC, the identification performance of the three heartbeat categories is further enhanced. AUCs of 97.80% and 92.09% were reported for intra- and inter-patient scenarios, respectively. These results suggest promising opportunities to leverage RC technology for multiclass, patient-independent heartbeat recognition. Full article

Objective: This work presents an implementation of a stable algorithm that recovers sources located at the boundary separating two homogeneous media in field-programmable gate arrays. Two loop unrolling architectures were developed and analyzed for this purpose. This inverse source problem is ill-posed due to numerical instability, i.e., small errors in the measurement can produce significant changes in the source location. Methodology: To handle the numerical instability when recovering these sources, the Tikhonov regularization method in combination with the Fourier series truncation method are applied in the stable algorithm. This stable algorithm is implemented in two different architectures developed in this work: The first architecture (Mode 1) allows for different operating speeds, which is an advantage depending on whether we work with fast or slow signals. The second one (Mode 2) reduces resource consumption by exploiting the characteristics of the source identification algorithm, which is an advantage for multichannel problems such as inverse electrocardiography or electroencephalography. Results: The architectures were tested on four devices of the 7 Series of Xilinx: Spartan-7 xc7s100fgga484, Virtex-7 xc7v585tffg1157, Kintex-7 xc7k70tfbg484, and Artix-7 xc7a35tcpg236. The two hardware implementations of the stable algorithm were validated using synthetic examples implemented in MATLAB, which shows the advantages of each architecture. Contributions: We developed two efficient architectures based on a loop unrolling design for source identification problems. These are effective strategies to divide and assign tasks to the configurable hardware, and they appear as an appropriate technique for implementing the algorithm. The first one is simple and allows for different operating speeds. The second one uses a control system based on multiplexors that reduce resource consumption and complexity of the design and can be used for multichannel problems. From the numerical test, we found the regularization parameters. The synthetic examples developed here can be considered for similar problems and can be extended to concentric spheres. Full article

The healthcare industry has made significant progress in the diagnosis of heart conditions due to the use of intelligent detection systems such as electrocardiograms, cardiac ultrasounds, and abnormal sound diagnostics that use artificial intelligence (AI) technology, such as convolutional neural networks (CNNs). Over the past few decades, methods for automated segmentation and classification of heart sounds have been widely studied. In many cases, both experimental and clinical data require electrocardiography (ECG)-labeled phonocardiograms (PCGs) or several feature extraction techniques from the mel-scale frequency cepstral coefficient (MFCC) spectrum of heart sounds to achieve better identification results with AI methods. Without good feature extraction techniques, the CNN may face challenges in classifying the MFCC spectrum of heart sounds. To overcome these limitations, we propose a capsule neural network (CapsNet), which can utilize iterative dynamic routing methods to obtain good combinations for layers in the translational equivariance of MFCC spectrum features, thereby improving the prediction accuracy of heart murmur classification. The 2016 PhysioNet heart sound database was used for training and validating the prediction performance of CapsNet and other CNNs. Then, we collected our own dataset of clinical auscultation scenarios for fine-tuning hyperparameters and testing results. CapsNet demonstrated its feasibility by achieving validation accuracies of 90.29% and 91.67% on the test dataset. Full article

Background: The hospital-at-home (HAH) model is a viable alternative for conventional in-hospital stays worldwide. Serum electrolyte abnormalities are common in acute patients, especially in those with many comorbidities. Pathologic changes in cardiac electrophysiology pose a potential risk during HAH stays. Periodical electrocardiogram (ECG) tracing is therefore advised, but few studies have evaluated the accuracy and efficiency of compact, self-activated ECG devices in HAH settings. This study aimed to evaluate the reliability of such a device in comparison with a standard 12-lead ECG. Methods: We prospectively recruited consecutive patients admitted to the Sheba Beyond Virtual Hospital, in the HAH department, during a 3-month duration. Each patient underwent a 12-lead ECG recording using the legacy device and a consecutive recording by a compact six-lead device. Baseline patient characteristics during hospitalization were collected. The level of agreement between devices was measured by Cohen’s kappa coefficient for inter-rater reliability (Ϗ). Results: Fifty patients were included in the study (median age 80 years, IQR 14). In total, 26 (52%) had electrolyte disturbances. Abnormal D-dimer values were observed in 33 (66%) patients, and 12 (24%) patients had elevated troponin values. We found a level of 94.5% raw agreement between devices with regards to nine of the options included in the automatic read-out of the legacy device. The calculated Ϗ was 0.72, classified as a substantial consensus. The rate of raw consensus regarding the ECG intervals’ measurement (PR, RR, and QT) was 78.5%, and the calculated Ϗ was 0.42, corresponding to a moderate level of agreement. Conclusion: This is the first report to our knowledge regarding the feasibility of using a compact, six-lead ECG device in the setting of an HAH to be safe and bearing satisfying agreement level with a legacy, 12-lead ECG device, enabling quick, accessible arrythmia detection in this setting. Our findings bear a promise to the future development of telemedicine-based hospital-at-home methodology. Full article

In recent years, deep learning has been applied in numerous fields and has yielded excellent results. Convolutional neural networks (CNNs) have been used to analyze electrocardiography (ECG) data in biomedical engineering. This study combines the Taguchi method and CNNs for classifying ECG images from single heartbeats without feature extraction or signal conversion. All of the fifteen types (five classes) in the MIT-BIH Arrhythmia Dataset were included in this study. The classification accuracy achieved 96.79%, which is comparable to the state-of-the-art literature. The proposed model demonstrates effective and efficient performance in the identification of heartbeat diseases while minimizing misdiagnosis. Full article

Driving safely is crucial to avoid death, injuries, or financial losses that can be sustained in an accident. Thus, a driver’s physical state should be monitored to prevent accidents, rather than vehicle-based or behavioral measurements, and provide reliable information in this regard. Electrocardiography (ECG), electroencephalography (EEG), electrooculography (EOG), and surface electromyography (sEMG) signals are used to monitor a driver’s physical state during a drive. The purpose of this study was to detect driver hypovigilance (drowsiness, fatigue, as well as visual and cognitive inattention) using signals collected from 10 drivers while they were driving. EOG signals from the driver were preprocessed to remove noise, and 17 features were extracted. ANOVA (analysis of variance) was used to select statistically significant features that were then loaded into a machine learning algorithm. We then reduced the features by using principal component analysis (PCA) and trained three classifiers: support vector machine (SVM), k-nearest neighbor (KNN), and ensemble. A maximum accuracy of 98.7% was obtained for the classification of normal and cognitive classes under the category of two-class detection. Upon considering hypovigilance states as five-class, a maximum accuracy of 90.9% was achieved. In this case, the number of detection classes increased, resulting in a reduction in the accuracy of detecting more driver states. However, with the possibility of incorrect identification and the presence of issues, the ensemble classifier’s performance produced an enhanced accuracy when compared to others. Full article

Heart rate variability (HRV) features support several clinical applications, including sleep staging, and ballistocardiograms (BCGs) can be used to unobtrusively estimate these features. Electrocardiography is the traditional clinical standard for HRV estimation, but BCGs and electrocardiograms (ECGs) yield different estimates for heartbeat intervals (HBIs), leading to differences in calculated HRV parameters. This study examines the viability of using BCG-based HRV features for sleep staging by quantifying the impact of these timing differences on the resulting parameters of interest. We introduced a range of synthetic time offsets to simulate the differences between BCG- and ECG-based heartbeat intervals, and the resulting HRV features are used to perform sleep staging. Subsequently, we draw a relationship between the mean absolute error in HBIs and the resulting sleep-staging performances. We also extend our previous work in heartbeat interval identification algorithms to demonstrate that our simulated timing jitters are close representatives of errors between heartbeat interval measurements. This work indicates that BCG-based sleep staging can produce accuracies comparable to ECG-based techniques such that at an HBI error range of up to 60 ms, the sleep-scoring error could increase from 17% to 25% based on one of the scenarios we examined. Full article

Background: To evaluate the association between the visit-to-visit heart rate variability and the risk of atrial fibrillation (AF) in acute ischemic stroke (AIS). Methods: We analyzed the data of 8179 patients with AIS. Patients without AF on 12-lead electrocardiography underwent further 24 h Holter monitoring. They were categorized into four subgroups according to the visit-to-visit heart rate variability expressed as the coefficient of variation in heart rate (HR-CV). Odds ratios (ORs) and 95% confidence intervals (CIs) were estimated using the HR-CV < 0.08 subgroup as a reference. Results: The adjusted OR of paroxysmal AF was 1.866 (95% CI = 1.205–2.889) for the HR-CV ≥ 0.08 and <0.10 subgroup, 1.889 (95% CI = 1.174–3.038) for the HR-CV ≥ 0.10 and <0.12 subgroup, and 5.564 (95% CI = 3.847–8.047) for the HR-CV ≥ 0.12 subgroup. The adjusted OR of persistent AF was 2.425 (95% CI = 1.921–3.062) for the HR-CV ≥ 0.08 and <0.10 subgroup, 4.312 (95% CI = 3.415–5.446) for the HR-CV ≥ 0.10 and <0.12 subgroup, and 5.651 (95% CI = 4.586–6.964) for the HR-CV ≥ 0.12 subgroup. Conclusions: HR-CV can facilitate the identification of patients with AIS at a high risk of paroxysmal AF. Full article

Cardiac diseases have increased over the years; thus, it is essential to predict their possible signs. Accurate prediction efficiently treats the patient’s medical history before the attack occurs. Sensors available in commonly used devices may strive for the proper and early identification of various cardiac diseases. The primary purpose of this review is to analyze studies related to gender discretization based on data from different sensors including electrocardiography and echocardiography. The analyzed studies were published between 2010 and 2022 in various scientific databases, including PubMed Central, Springer, ACM, IEEE Xplore, MDPI, and Elsevier, based on the analysis of different cardiovascular diseases. It was possible to verify that most of the analyzed studies measured similar parameters as traditional methods including the QRS complex and other waves that characterize the various individuals. Full article

This article proposes a new method of identity recognition in sanitary facilities based on electrocardiography (ECG) signals. Our team previously proposed a novel approach of invisible ECG at the thighs using polymeric electrodes, leading to the creation of a proof-of-concept system integrated into a toilet seat. In this work, a biometrics pipeline was devised, which tested four different classifiers, varying the population from 2 to 17 subjects and simulating a residential environment. However, for this approach to be industrially viable, further optimization is required, particularly regarding electrode materials that are compatible with industrial processes. As such, we also explore the use of a conductive silicone material as electrodes, aiming at the industrial-scale production of a toilet seat capable of recording ECG data, without the need for body-worn devices. A desirable aspect when using such a system is matching the recorded data with the monitored user, ideally using a minimal sensor set, further reinforcing the relevance of user identification through ECG signals collected at the thighs. Our approach was evaluated against a reference device for a population of 17 healthy and pathological individuals, covering a wide age range (24–70 years). With the silicone composite, we were able to acquire signals in 100% of the sessions, with a mean heart rate deviation between a reference system and our experimental device of 2.82 ± 1.99 beats per minute (BPM). In terms of ECG waveform morphology, the best cases showed a Pearson correlation coefficient of 0.91 ± 0.06. For biometric detection, the best classifier was the Binary Convolutional Neural Network (BCNN), with an accuracy of 100% for a population of up to four individuals. Full article
