This study investigates the influence of variable electrode positions on image reconstruction in capacitively coupled electrical impedance tomography (CC-EIT) of the human thorax. Images were reconstructed by an adversarial neural network trained on a synthetic dataset generated using a tomographic model that included a wearable elastic band with 32 electrodes attached. Dataset generation was conducted using a previously developed numerical phantom of the thorax, combined with a newly developed algorithm for random selection of electrode positions based on physical limitations resulting from the elasticity of the band and possible position inaccuracies while putting the band on the patient’s chest. The thorax phantom included the heart, lungs, aorta, and spine. Four training and four testing datasets were generated using four different levels of electrode displacement. Reconstruction was conducted using four versions of neural networks trained on the datasets, with random ellipses included and noise added to achieve an SNR of 30 dB. The quality was assessed using pixel-to-pixel metrics such as the root-mean-square error, structural similarity index, 2D correlation coefficient, and peak signal-to-noise ratio. The results showed a strong negative influence of electrode displacement on reconstruction quality when no samples with displaced electrodes were present in the training dataset. Training the network on the dataset containing samples with electrode displacement allowed us to significantly improve the quality of the reconstructed images. Introducing samples with misplaced electrodes increased neural network robustness to electrode displacement while testing. Full article

The Electrical Capacitance Tomography (ECT) imaging pipeline relies on accurate estimation of electric field distributions to compute electrode capacitances and reconstruct permittivity maps. Traditional ECT forward model methods based on the Finite Element Method (FEM) offer high accuracy but are computationally intensive, limiting their use in real-time applications. In this proof-of-concept study, we investigate the use of Graph Convolutional Networks (GCNs) for direct, one-step prediction of electric field distributions associated with a circular ECT sensor numerical model. The network is trained on FEM-simulated data and outputs of full 2D electric field maps for all excitation patterns. To evaluate physical fidelity, we compute capacitance matrices using both GCN-predicted and FEM-based fields. Our results show strong agreement in both direct field prediction and derived quantities, demonstrating the feasibility of replacing traditional solvers with fast, learned approximators. This approach has significant implications for further real-time ECT imaging and control applications. Full article

Electrical capacitance tomography holds significant potential for multiphase flow parameter measurements, but its application has been limited by the challenge of reconstructing high-quality images, especially under complex and uncertain conditions. We propose an innovative multi-objective robust optimization model to alleviate this limitation. This model integrates advanced optimization methods, multimodal learning, and measurement physics, structured as a nested upper-level optimization problem and lower-level optimization problem to tackle the challenges of complex image reconstruction. By integrating supervised learning methodologies with optimization principles, our framework synchronously achieves parameter tuning and performance enhancement. Utilizing the regularization theory, the multimodal learning prior image, sparsity prior, and measurement physics are incorporated into a novel lower-level optimization problem. To enhance the inference accuracy of the prior image, a new multimodal neural network leveraging multimodal data is developed. An innovative nested algorithm that mitigates computational difficulties arising from the interactions between the upper- and lower-level optimization problems is proposed to solve the proposed multi-objective robust optimization model. Qualitative and quantitative evaluation results demonstrate that the proposed method surpasses mainstream imaging algorithms, enhancing the automation level of the reconstruction process and image quality while exhibiting exceptional robustness. This study pioneers a novel imaging framework for enhancing overall reconstruction performance. Full article

As the interface between frozen and unfrozen soil, the ice front is not only a spatial location concept, but also a potentially dangerous interface where the mechanical properties of soil could change abruptly. Accurately identifying its spatial position is essential for the safe and efficient execution of large-scale frozen soil engineering projects. Electrical capacitance tomography (ECT) is a promising method for the visualization of frozen soil due to its non-invasive nature, low cast, and rapid response. This paper presents the design and optimization of a mobile circular capacitance sensor (MCCS). The MCCS was used to measure frozen soil samples along the depth direction to obtain moisture distribution and three-dimensional images of the ice front. Finally, the experimental results were compared with the simulation results from COMSOL Multiphysics to analyze the deviations. It was found that the fuzzy optimization design based on multi-criteria orthogonal experiments makes the MCCS meet various performance requirements. The average permittivity distribution was proposed to reflect moisture distribution along the depth direction and showed good correlation. Three-dimensional reconstructed images could provide the precise position of the ice front. The simulation results indicate that the MCCS has a low deviation margin in identifying the position of the ice front. Full article

This paper proposes a novel approach to assessing the quality of 3D Electrical Capacitance Tomography (ECT) images. Such images are typically represented as irregular graphs. Thus, image quality metrics typically used with raster images do not straightforwardly apply to them. However, given the recent advancements in Graph Convolutional Neural Networks (GCNs) for improving ECT image reconstruction, reliable Quality Assessment methods are essential for comparing the performance of different GCN models. To address this need, this paper applied some existing image quality and similarity assessment methods designed for raster images to the graph-based representation of 3D ECT images. Specifically, attention was paid to the Peak Signal-to-Noise Ratio (PSNR), the Structural Similarity Index Measure (SSIM), and measures based on image histograms. The proposed adaptations resulted in the development of tailored Graph Quality Assessment (GQA) techniques specifically designed for the graph-based nature of ECT images. The proposed GQA techniques were validated on 1042 phantoms and their corresponding Low-Quality (LQ) and High-Quality (HQ) reconstructions through a robust GQA benchmarking system, enabling a systematic comparison of various GQA methods. The evaluation of the proposed methods’ performances across this diverse dataset, by analyzing overall trends and specific case studies, is presented and discussed. Finally, we present our conclusions regarding the effectiveness of the proposed GQA methods, and we identify the most promising approach for assessing the quality of graph-based ECT images. Full article

This study investigated the potential of the generative adversarial neural network (cGAN) image reconstruction in industrial electrical capacitance tomography. The image reconstruction quality was examined using image patterns typical for a two-phase flow. The training dataset was prepared by generating images of random test objects and simulating the corresponding capacitance measurements. Numerical simulations were performed using the ECTsim toolkit for MATLAB. A cylindrical sixteen-electrode ECT sensor was used in the experiments. Real measurements were obtained using the EVT4 data acquisition system. The reconstructed images were evaluated using selected image quality metrics. The results obtained using cGAN are better than those obtained using the Landweber iteration and simplified Levenberg–Marquardt algorithm. The suggested method offers a promising solution for a fast reconstruction algorithm suitable for real-time monitoring and the control of a two-phase flow using ECT. Full article

This work presents an experimental study on oil–water flow downstream of a restriction. The flow pattern, volumetric phase distribution, and their impacts on pressure drop are discussed. We employed two techniques to visualize the oil–water flow patterns, a high-speed camera and an Electrical Capacitance Volume Tomography (ECVT) system. The ECVT system is a non-intrusive device that measures the volumetric phase distribution at the pipe cross-section with time, which plays a critical role in determining the continuous phase in the oil–water flow, and therefore the oil–water flow pattern. In this study, we delved into the oil–water flow pattern and volumetric phase distribution for different valve openings, flow rates, and water cuts, and how they impact the pressure drop. The experimental results have demonstrated a strong relationship between the oil–water flow pattern and the pressure gradient, while the oil–water flow pattern is significantly influenced by the flowing conditions and the valve openings. The impacts of water cuts on the oil–water flow pattern are more obvious for smaller valve openings. For large valve openings, the oil and water phases tend to be more separated. This results in a moderate variation in the pressure gradient as a function of water cuts. However, it becomes more complex as the valve opening decreases. The pressure gradient generally increases with decreasing valve openings until the flow pattern becomes an oil-in-water dispersed flow. The impact of the valve on the pressure gradient is more pronounced in water-dominated flow when the water cut is above the inversion point, while it seems to be most obvious for medium water cut conditions. Full article

The reconstruction of the spatial complex conductivity $\sigma +j\omega {\epsilon }_0{\epsilon }_{\mathrm{r}}$ from complex valued impedance measurements forms the inverse problem of complex electrical impedance tomography or complex electrical capacitance tomography. Regularized Gauß-Newton schemes have been proposed for their solution. However, the necessary computation of the Jacobian is known to be computationally expensive, as standard techniques such as adjoint field methods require additional simulations. In this work, we show a more efficient way to computationally access the Jacobian matrix. In particular, the presented techniques do not require additional simulations, making the use of the Jacobian, free of additional computational costs. Full article

This study investigated the potential of machine-learning-based stroke image reconstruction in capacitively coupled electrical impedance tomography. The quality of brain images reconstructed using the adversarial neural network (cGAN) was examined. The big data required for supervised network training were generated using a two-dimensional numerical simulation. The phantom of an axial cross-section of the head without and with impact lesions was an average of a three-centimeter-thick layer corresponding to the height of the sensing electrodes. Stroke was modeled using regions with characteristic electrical parameters for tissues with reduced perfusion. The head phantom included skin, skull bone, white matter, gray matter, and cerebrospinal fluid. The coupling capacitance was taken into account in the 16-electrode capacitive sensor model. A dedicated ECTsim toolkit for Matlab was used to solve the forward problem and simulate measurements. A conditional generative adversarial network (cGAN) was trained using a numerically generated dataset containing samples corresponding to healthy patients and patients affected by either hemorrhagic or ischemic stroke. The validation showed that the quality of images obtained using supervised learning and cGAN was promising. It is possible to visually distinguish when the image corresponds to the patient affected by stroke, and changes caused by hemorrhagic stroke are the most visible. The continuation of work towards image reconstruction for measurements of physical phantoms is justified. Full article

Based on the two-fluid model, a three-zone drag model was developed, and the kinetic theory of granular flows and the Schneiderbauer solids wall boundary model were modified to establish a new three-dimensional (3D) unsteady mathematical model for high-pressure dense-phase pneumatic conveying in horizontal pipe. With this mathematical model, the influence of the three frictional stress models, namely Dartevelle frictional stress model, Srivastava and Sundaresan frictional stress model, and the modified Berzi frictional stress model, on the simulation result was explored. The simulation results showed that the three frictional stress models accurately predicted the pressure drop and its variations with supplementary gas in the horizontal pipe, with relative errors ranging from −4.91% to +7.60%. Moreover, the predicted solids volume fraction distribution in the cross-section of the horizontal pipe using these frictional stress models exhibited good agreement with the electrical capacitance tomography (ECT) images. Notably, the influence of the three frictional stress models on the simulation results was predominantly observed in the transition region and deposited region. In the deposited region, stronger frictional stress resulting in lower solids volume fraction and a higher pressure drop in the horizontal pipe were observed. Among the three frictional stress models, the simulation results with the modified Berzi frictional stress model aligned better with the experimental data. Therefore, the modified Berzi frictional stress model is deemed more suitable for simulating high-pressure dense-phase pneumatic conveying in horizontal pipe. Full article

Electrical capacitance volume tomography (ECVT) is an experimental technique capable of reconstructing 3D solid volume fraction distribution inside a sensing region. This technique has been used in fluidized beds as it allows for accessing data that are very difficult to obtain using other experimental devices. Recently, artificial neural networks have been proposed as a new type of reconstruction algorithm for ECVT devices. One of the main drawbacks of neural networks is that they need a database containing previously reconstructed images to learn from. Previous works have used databases with very simple or limited configurations that might not be well adapted to the complex dynamics of fluidized bed configurations. In this work, we study two different approaches: a supervised learning approach that uses simulated data as a training database and a reinforcement learning approach that relies only on experimental data. Our results show that both techniques can perform as well as the classical algorithms. However, once the neural networks are trained, the reconstruction process is much faster than the classical algorithms. Full article

High-precision images enable electrical capacitance tomography (ECT) to obtain more reliable measurement results, meaning that the reconstruction algorithm is particularly important. Some excellent numerical algorithms have successfully solved the inverse problem for ECT imaging, but their imaging quality is relatively low. To solve this problem, this paper proposes a new reconstruction algorithm based on regularized extreme learning machines (RELMs). The implementation of the algorithm is mainly divided into two steps: (1) according to a large number of training samples, the RELM model can be obtained by the iterative split Bregman (ISB) algorithm, which can describe the mapping relationship between the capacitance correlation coefficient and the imaging target well, and (2) the capacitance correlation coefficient is calculated, which is then used as input to the RELM model to predict the final imaging. Both simulation and experimental results show that the RELM algorithm achieves greater improvement in imaging quality and robustness, and provides new development ideas for the ECT. Full article

The electric capacitance tomography (ECT) technique has been widely used in phase distribution reconstruction, while the practical application raised nonideal noise and other errors for cryogenic conditions, requiring a more accurate algorithm. This paper develops a new image reconstruction algorithm for ECT by coupling the traditional Landweber algorithm with the least square support vector regression (LSSVR) for cryogenic fluids. The performance of the algorithm is quantitatively evaluated by comparing the inversion images with the experimental results for both the room temperature working medium with the dielectric constant ratio close to cryogenic fluid and the cryogenic fluid of liquid nitrogen/nitrogen vapor (LN₂-VN₂). The inversion images based on the conventional LBP and Landweber algorithms are also presented for comparison. The benefits and drawbacks of the developed algorithms are revealed and discussed, according to the results. It is demonstrated that the correlated coefficients of the images based on the developed algorithm reach more than 0.88 and a maximum of 0.975. In addition, the minimum void fraction error of the algorithm is reduced to 0.534%, which indicates the significant optimization of the LSSVR coupled method over the Landweber algorithm. Full article

Gigantic aufeis fields serve as indicators of water exchange processes within the permafrost zone and are important in assessing the state of the cryosphere in a changing climate. The Anmangynda aufeis, located in the upstream of the Kolyma River basin, is present in the mountainous regions of Northeast Eurasia. Recent decades have witnessed significant changes in aufeis formation patterns, necessitating a comprehensive understanding of cryospheric processes. The objective of the study, conducted in 2021–2022, was to examine the structure of the Anmangynda aufeis and its glade, aiming to understand its genesis and formation processes. The tasks included identifying above- and intra-frozen taliks, mapping groundwater (GW) discharge channels, determining permafrost base depth, and assessing ice thickness distribution. Soundings using ground-penetrating radar (GPR), capacitively coupled electrical resistivity tomography (CCERT), and the transient electromagnetic (TEM) method were employed. GW discharge channels originating from alluvial deposits and extending to the aufeis surface within river channels were identified through GPR and verified through drilling. Deep-seated sources of GW within the bedrock were inferred. CCERT data allowed us to identify large and localized frozen river taliks, from which water is forced onto the ice surface. According to the TEM data, the places of GW outlets spatially coincide with the zones interpreted as faults. Full article

Propellant mass gauging under micro-gravity conditions is a challenging task due to the unpredictable position and shape of the fuel body inside the tank. Micro-gravity conditions are common for orbiting satellites and rockets that operate on limited fuel supplies. Capacitance sensors have been investigated for this task in recent years; however, the effect of various positions and shapes of the fuel body is not analyzed in detail. In this paper, we investigate this with various fill types, such as annular, core-annular, and stratified fills at different positions. We compare the performance among several curve-fitting-based approaches and a machine-learning-based approach, the latter of which offers superior performance in estimating the fuel content. Full article
