The rapid advancements in optical communication and sensing technologies have significantly increased the demand for advanced tunable spectral systems. This study presents a dual-band terahertz transmission and manipulation approach by leveraging the topologically protected properties of valley-topological photonic crystal edge states. The designed structure facilitates the excitation of the K valley within the range of 0.851–0.934 THz and the K′ valley from 1.604 to 1.686 THz, while also demonstrating anomalous refraction and birefringence. The calculated emission angles, derived through momentum matching, enable transitions between single-wave and dual-wave emissions and allow for precise angle control. The introduction of the liquid crystal material NJU-LDn-4 enables continuous tuning of the dual-band spectral range under a varying electric field, broadening the operating frequency bands to the ranges of 0.757–0.996 THz and 1.426–1.798 THz, respectively. These findings suggest promising applications in tunable filter design, optical communication, photonic computing, optical sensing, and high-resolution imaging, particularly in novel optical devices requiring precise control over spectral characteristics and light propagation. Full article

A new approach to the dynamic polarimetric method is proposed, which allows for the decoupling of electro-optical Kerr effect measurements from the electro-absorption effect in partially transparent liquids. The method is illustrated by using the results of engine oil measurements as a function of temperature and modulating field frequency. It was shown that the birefringence induced in the sample, the modulation of the ordinary wave transmission, and the modulation of the extraordinary wave transmission in the sample can be shifted in phase with respect to the square of the applied alternating modulating field. Each of these three phase shifts can depend differently on the temperature and frequency. Neglecting the influence of electro-absorption on electro-optical measurements in liquids or considering electro-absorption as an effect correlated in phase with induced birefringence may lead to significant measurement errors. This indicates that the Kerr constant and the electro-absorption coefficients for an alternating electric field should be considered as complex quantities instead of real values, as they have been traditionally. The proposed approach fills an important gap in measurement techniques described in the literature, which may provide erroneous results for measurements of the Kerr constant in partially transparent liquids including many industrially important liquids. Full article

Nanostructured polymer-dispersed liquid crystals (nano-PDLCs) are transparent and optically isotropic materials in which submicron-sized liquid crystal (LC) domains are dispersed within a polymer matrix. Nano-PDLCs can induce birefringence by applying an electric field (E-field) based on the reorientation of the LC molecules. If nano-PDLCs are utilized as light-scattering-less birefringence memory materials, it is necessary to suppress the relaxation of the LC molecule orientation after the removal of the E-field. We focused on the ferroelectric smectic A (SmA) phase to suppress the relaxation of LC molecules, owing to its layered structure and high viscosity. Although nano-PDLCs require a strong E-field to reorient their LC molecules because of the anchoring effect at the LC/polymer interface, the required field strength can be reduced using a ferroelectric smectic A (SmA_F) LC with a large dielectric constant. In this study, we fabricated a nano-PDLC by shining an ultraviolet light on a mixture comprised an SmA_F LC, photocurable monomers, and a photo-initiator. The electro-birefringence effect was evaluated using polarizing optical microscopy. After the removal of the E-field, an enhanced memory effect was observed in the sample using SmA_F LC compared with nematic LC-based nano-PDLCs. Full article

In this paper, the refractive index and extinction coefficient of ferroelectric liquid crystals have been examined by the terahertz time-domain spectroscopy system. Two modes of ferroelectric liquid crystal materials, deformed helix ferroelectric liquid crystal (DHFLC), and electric suppressed helix ferroelectric liquid crystal (ESHFLC) are tested as experimental samples. Nematic liquid crystal (NLC) was also investigated for comparison. The birefringence of DHFLC 587 slowly increases with the growth of frequency, and it averages at 0.115. Its extinction coefficients gradually incline to their stable states at 0.06 for o-wave and 0.04 for e-wave. The birefringence of ESHFLC FD4004N remains between around 0.165 and 0.175, and both of its e-wave and o-wave extinction coefficients are under 0.1, ranging from 0.05 to 0.09. These results of FLC will facilitate the examination and improve the response performance of THz devices using fast liquid crystal materials. Full article

Symmetry-deficient two-dimensional (2D) layered materials induce a highly anisotropic optical response due to the anisotropy in their crystal structure, facilitating their application in polarized nanodevices. Intercalation is a new way to tune the optoelectronic properties of materials by inserting guest atoms into layered host materials, and 2D layered structures stacked with van der Waals gaps are a prerequisite for this phase of the technique. In this paper, 2D tellurium nanosheets were synthesized with a hydrothermal method, and copper atoms were inserted with a wet chemical method. The widening of the crystal plane spacing proves the introduction of copper atoms, and polarization−related second-harmonic-generation (SHG) studies reveal the intrinsic anisotropic modes of the two samples, and birefringent properties are found with polarizing light microscopy. We further investigated the electrical properties of the samples, and the embedding of the copper atoms caused the samples to exhibit higher currents, but their devices lost the gate control effect. Full article

Collagenous tissues exhibit anisotropic optical properties such as birefringence and linear dichroism (LD) as a result of their structurally oriented supraorganization from the nanometer level to the collagen bundle scale. Changes in macromolecular order and in aggregational states can be evaluated in tendon collagen bundles using polarization microscopy. Because there are no reports on the status of the macromolecular organization in tendon explants, the objective of this work was to evaluate the birefringence and LD characteristics of collagen bundles in rat calcaneal tendons cultivated in vitro on substrates that differ in their mechanical stiffness (plastic vs. glass) while accompanying the expected occurrence of cell migration from these structures. Tendon explants from adult male Wistar rats were cultivated for 8 and 12 days on borosilicate glass coverslips (n = 3) and on nonpyrogenic polystyrene plastic dishes (n = 4) and were compared with tendons not cultivated in vitro (n = 3). Birefringence was investigated in unstained tendon sections using high-performance polarization microscopy and image analysis. LD was studied under polarized light in tendon sections stained with the dichroic dyes Ponceau SS and toluidine blue at pH 4.0 to evaluate the orientation of proteins and acid glycosaminoglycans (GAG) macromolecules, respectively. Structural remodeling characterized by the reduction in the macromolecular orientation, aggregation and alignment of collagen bundles, based on decreased average gray values concerned with birefringence intensity, LD and morphological changes, was detected especially in the tendon explants cultivated on the plastic substrate. These changes may have facilitated cell migration from the lateral regions of the explants to the substrates, an event that was observed earlier and more intensely upon tissue cultivation on the plastic substrate. The axial alignment of the migrating cells relative to the explant, which occurred with increased cultivation times, may be due to the mechanosensitive nature of the tenocytes. Collagen fibers possibly played a role as a signal source to cells, a hypothesis that requires further investigation, including studies on the dynamics of cell membrane receptors and cytoskeletal organization, and collagen shearing electrical properties. Full article

Transparent organic light emitting diode (OLED) display is one of the most promising devices among next-generation information displays because of beneficial characteristics, such as self-emissive and optically clear properties. Nevertheless, in conventional transparent OLED display devices, there are serious intrinsic problems in terms of the transmittance in the dark state because of empty windows in the cell, so the contrast ratio of the transparent OLED display would be deteriorated even though it can exhibit excellent bright state. In general, the transparent mode using the OLED device applies an empty area in each pixel because an emitting device could never reveal the background image, so the transparent OLED should contain the empty area in the pixel for transparent images. This may cause the optical degradation in the dark state. To solve this problem, we propose hybrid-type transparent OLED display modes that apply a liquid crystal (LC) to the transparent window part of the empty space. In this paper, we applied two dichroic LC modes— which use an electrically controlled birefringence (ECB) mode (Heilmeier type) for the polarized mode and a cholesteric LC mode (Guest-Host mode) for the non-polarized mode—to the empty area. In each hybrid mode, we have observed optical performance, including the transmittance in the dark/bright state, contrast ratio and response time as a function of cell parameters. As a result, we confirmed that the dark state and the contrast ratio could be improved by applying the proposed modes without serious decay of the transmittance in the bright state. Full article

Electro-optical sampling of Terahertz fields with ultrashort pulsed probes is a well-established approach for directly measuring the electric field of THz radiation. This technique usually relies on balanced detection to record the optical phase shift brought by THz-induced birefringence. The sensitivity of electro-optical sampling is, therefore, limited by the shot noise of the probe pulse, and improvements could be achieved using quantum metrology approaches using, e.g., NOON states for Heisenberg-limited phase estimation. We report on our experiments on THz electro-optical sampling using single-photon detectors and a weak squeezed vacuum field as the optical probe. Our approach achieves field sensitivity limited by the probe state statistical properties using phase-locked single-photon detectors and paves the way for further studies targeting quantum-enhanced THz sensing. Full article

Agarose gels containing and not bacteriorhodopsin purple membranes (incorporated before gelling) manifest spontaneous optical anisotropy. The dependencies of the anisotropy on the agarose concentration and time have been studied. The rise in the anisotropy is explained by the predominant orientation of the agarose fibers during the gelling and subsequent deformation of the gel net. In the electric field, additional optical anisotropy rises, which is caused by the orientation of the membranes. A procedure has been developed to separate electrically induced and spontaneous anisotropy in composite gels. The isoelectric points and surface electric potential of bacteriorhodopsin trimer and purple membranes are calculated by the method of protein electrostatics to explain their electric asymmetry, which leads to perpendicular orientation in the direct electric field and longitudinal in the kilohertz sinusoidal field. The results allow for an increase in the separation capability of composite gels of electrophoresis for macromolecules with different sizes by applying an appropriate electric field to modulate the effective pore size. Full article

The research aimed to investigate the effect of pulsed electric field (PEF) treatment on cassava flour at mild intensities (1, 2, and 4 kV/cm) combined with elevated levels of specific energy input (250–500 kJ/kg). Influences on starch digestibility, morphological characteristics, birefringence, short-range order and thermal properties were evaluated. Application of PEF at energy input no greater than 250 kJ/kg had negligible influence on the different starch digestion fractions of cassava flour but raised the rapidly digestible starch fraction at a combined electric field strength >1 kV/cm and energy input >350 kJ/kg. Morphological evaluation revealed that at this PEF combination, cassava starch’s external structure was consistently altered with swelling and disintegration, albeit some granules remained intact. Consequently, this led to disruption in the internal crystalline structure, supported by progressive loss of birefringence and significantly lower absorbance ratio at 1047/1022 cm⁻¹. These physical and microstructural changes of the inherent starch promoted the shift in gelatinization temperatures to a higher temperature and reduced the gelatinization enthalpy. The study demonstrated that PEF can be utilized to change the starch fraction of cassava flour, which is driven by electric field strength and specific energy input, causing changes in the starch-related properties leading to increased digestibility. Full article

This paper presents the design and process of two highly sensitive sensors working in the terahertz band. The sensors comprise the quartz substrate, medium, reflection plate, and metal resonant layer with a symmetrical single-slot patch array. The devices help study the electrically induced permittivity of two liquid crystals in different frequency bands and at different voltages, and the experimental data verify that both liquid crystals have a large birefringence. Based on experimental results, the sensitivity of the fabricated sensor is 47.03 GHz/RIU in the frequency range 90–140 GHz. Similarly, the other fabricated sensor has a sensitivity of 112.47 GHz/RIU in the frequency range 325–500 GHz. The results show that both sensors have superior sensing properties and potential applications in biological and chemical liquid sensing. Full article

The laser-assisted melt electrospinning (LES) method was utilized for the preparation of poly(L-lactide-co-ε-caprolactone) (PLCL) fibers. During the process, a carbon dioxide laser was irradiated, and voltage was applied to the raw fiber of PLCL. In situ observation of fiber formation behavior revealed that only a single jet was formed from the swelling region under the conditions of low laser power and applied voltage and feeding rate, whereas multiple jets and shots were produced with increases in these parameters. The formation of multiple jets resulted in the preparation of thinner fibers, and under the optimum condition, an average fiber diameter of 0.77 μm and its coefficient of variation of 17% was achieved without the formation of shots. The estimation of tension and stress profiles in the spin-line was also carried out based on the result of in situ observation and the consideration that the forces originated from surface tension, electricity, air friction, and inertia. The higher peak values of tension and stress appearing near the apex of the swelling region corresponded to the formation of thinner fibers for the condition of single-jet ejection. Analyses of the molecular orientation and crystallization of as-spun fibers revealed the formation of a wide variation of higher order structure depending on the spinning conditions. Full article

In order to achieve collinear phase-matched nonlinear optical frequency conversion in cubic crystals, a novel method to induce and modulate the birefringence based on the linear electro-optic effect was studied. Taking terahertz generation with ZnTe and CdTe crystals of the $\overline{4}3\mathrm{m}$ point group as an example, an external electric field provided the freedom to realize perfect phase matching (PM) in a wide bandwidth up to 2 THz for difference frequency generation, with monochromatic optical waves at around 800 nm and 1010 nm, respectively. Theoretical simulations showed that such a method helps to extend the terahertz frequency, enhance the conversion efficiency, and alleviate the limitation on the pump wavelength, which is highly favorable for nonlinear optical uses of cubic crystals. Simultaneous wideband terahertz generation pumped by ultrashort laser pulses via optical rectification or difference frequency mixing was also discussed, indicating that an electric field can be used to modulate the PM characteristics without changing the group velocity-matching condition. Tuning the nonlinear interaction by an applied voltage is fast, robust, and convenient compared to other approaches. In addition, the linear electro-optic effect can make the nonlinear crystal a compact and high-speed terahertz amplitude modulator, which has great potential in radar, communication, imaging, etc. Full article

We report the design, fabrication and experimental validation of a THz all-dielectric multi-mode q-plate having a fixed rate of change of the optical axis. The device consists of space-variant birefringent slabs manufactured by 3D printing using melt-extruded Acrylonitrile Butadiene Styrene (ABS). The desired form birefringence is analytically evaluated and experimentally measured by the THz time domain spectroscopy technique. The manufactured q-plate design is characterized using a polarization-sensitive imaging setup. The full electric field spatial maps are acquired from the beam propagating through the q-plate. The device enables the realization of both radial and azimuthal vector beams at discrete frequency intervals by controlling the space-dependent orientation of the ordinary and extraordinary axes in the transverse plane with a multi-mode sequence. Full article

Femtosecond optical measurements of photoexcitable molecular crystals carry ultrafast dynamics information with structural sensitivity. The creation and detection of transient dynamics depend on the optical parameters, as well as the explicit molecular structure, crystal symmetry, crystal orientation, polarisation of the photoexciting beam, and interaction geometry. In order to retrieve the linear and non-linear population transfer in photoexcited crystals, excitation theory is combined here with the calculation of birefringence decomposition and is shown for both the generalised uniaxial and biaxial systems. A computational tool was constructed based on this treatment to allow modelling of electric field decomposition, dipole projections, and non-linear excitation population levels. This is available open source and with a GUI for ease of use. Such work has applications in two areas of ultrafast science: multidimensional optical crystallography and femtosecond time-resolved X-ray crystallography. Full article
