Search Results (35)

Search Parameters:
Keywords = dual-PWM converter

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
19 pages, 5580 KiB
Article
Stand-Alone Operation of Multi-Phase Doubly-Fed Induction Generator Supplied by SiC-Based Current Source Converter
by Łukasz Sienkiewicz, Filip Wilczyński and Szymon Racewicz
Energies 2025, 18(11), 2753; https://doi.org/10.3390/en18112753 - 26 May 2025
Cited by 1 | Viewed by 399
Abstract
This paper investigates the performance of a five-phase silicon carbide (SiC)-based current-source converter (CSC) integrated with a Doubly Fed Induction Generator (DFIG) for wind energy applications. The study explores both healthy and faulty operation, focusing on system behavior under transient conditions and various [...] Read more.
This paper investigates the performance of a five-phase silicon carbide (SiC)-based current-source converter (CSC) integrated with a Doubly Fed Induction Generator (DFIG) for wind energy applications. The study explores both healthy and faulty operation, focusing on system behavior under transient conditions and various load scenarios in stand-alone mode. A novel five-phase space vector PWM strategy in dual coordinate planes is introduced, which enables stable control during normal and open-phase fault conditions. Experimental results demonstrate improved stator voltage and current quality, particularly in terms of reduced Total Harmonic Distortion (THD), compared to traditional voltage-source converter-based systems. Furthermore, the system maintains operational stability under a single-phase open fault, despite increased oscillations in stator quantities. The results highlight the potential of five-phase CSC-DFIG systems as a robust and efficient alternative for wind power plants, particularly in configurations involving long cable connections and requiring low generator losses. Future work will focus on enhancing fault-tolerant capabilities and expanding control strategies for improved performance under different operating conditions. Full article
(This article belongs to the Special Issue Modeling, Control and Optimization of Wind Power Systems)
Show Figures

Figure 1

25 pages, 4440 KiB
Article
PWM–PFM Hybrid Control of Three-Port LLC Resonant Converter for DC Microgrids
by Yi Zhang, Xiangjie Liu, Jiamian Wang, Baojiang Wu, Feilong Liu and Junfeng Xie
Energies 2025, 18(10), 2615; https://doi.org/10.3390/en18102615 - 19 May 2025
Viewed by 526
Abstract
This article proposes a high-efficiency isolated three-port resonant converter for DC microgrids, combining a dual active bridge (DAB)–LLC topology with hybrid Pulse Width Modulat-Pulse Frequency Modulation (PWM-PFM) phase shift control. Specifically, the integration of a dual active bridge and LLC resonant structure with [...] Read more.
This article proposes a high-efficiency isolated three-port resonant converter for DC microgrids, combining a dual active bridge (DAB)–LLC topology with hybrid Pulse Width Modulat-Pulse Frequency Modulation (PWM-PFM) phase shift control. Specifically, the integration of a dual active bridge and LLC resonant structure with interleaved buck/boost stages eliminates cascaded conversion losses. Energy flows bidirectionally between ports via zero-voltage switching, achieving a 97.2% efficiency across 150–300 V input ranges, which is a 15% improvement over conventional cascaded designs. Also, an improved PWM-PFM shift control scheme dynamically allocates power between ports without altering switching frequency. By decoupling power regulation and leveraging resonant tank optimization, this strategy reduces control complexity while maintaining a ±2.5% voltage ripple under 20% load transients. Additionally, a switch-controlled capacitor network and frequency tuning enable resonant parameter adjustment, achieving a 1:2 voltage gain range without auxiliary circuits. It reduces cost penalties compared to dual-transformer solutions, making the topology viable for heterogeneous DC microgrids. Based on a detailed theoretical analysis, simulation and experimental results verify the effectiveness of the proposed concept. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

27 pages, 15914 KiB
Article
Enhanced Voltage Sensorless Control for a PWM Converter with DSOGI-FLL Under Grid Disturbances
by Seung-Pyo Kang, Dong-Youn Kim and Jang-Mok Kim
Energies 2025, 18(9), 2199; https://doi.org/10.3390/en18092199 - 25 Apr 2025
Viewed by 320
Abstract
This paper presents Enhanced Voltage Sensorless Control for PWM converter with DSOGI-FLL under grid disturbances. Even without grid voltage sensors, the proposed method accurately estimates the grid angle and voltage, which are necessary for power transfer between the DC link of the PWM [...] Read more.
This paper presents Enhanced Voltage Sensorless Control for PWM converter with DSOGI-FLL under grid disturbances. Even without grid voltage sensors, the proposed method accurately estimates the grid angle and voltage, which are necessary for power transfer between the DC link of the PWM converter and the grid. The estimated grid voltage obtained through observer design is separated into positive and negative sequence components, and the grid frequency is estimated using the Dual Second-Order Generalized Integrator Quadrature Signal Generator (DSOGI-QSG) and Dual Second-Order Generalized Integrator Frequency-Locked Loop (DSOGI-FLL). The estimated positive and negative sequence voltages were effectively controlled using a dual current controller. The method operates effectively under normal, balanced AC source conditions and in various grid fault scenarios, including unbalanced voltage, harmonic distortion, voltage sag, and frequency step changes. The validity of the proposed method was evaluated through experimental results by using a grid simulator to implement the fault condition. Full article
Show Figures

Figure 1

19 pages, 3061 KiB
Article
Improved Control Strategy for Dual-PWM Converter Based on Equivalent Input Disturbance
by Zixin Huang, Wei Wang, Chengsong Yu and Junjie Lu
Electronics 2024, 13(18), 3777; https://doi.org/10.3390/electronics13183777 - 23 Sep 2024
Cited by 1 | Viewed by 1217
Abstract
Aiming at the problems of jittering waveforms and poor power quality caused by external disturbances during the operation of a dual-pulse-width-modulation (PWM) converter, an improved terminal sliding mode control and an improved active disturbance rejection control (ADRC) are investigated. The method is based [...] Read more.
Aiming at the problems of jittering waveforms and poor power quality caused by external disturbances during the operation of a dual-pulse-width-modulation (PWM) converter, an improved terminal sliding mode control and an improved active disturbance rejection control (ADRC) are investigated. The method is based on mathematical models of grid-side and machine-side converters to design the controllers separately, and the balance between the two sides is maintained by the capacitor voltage. An improved terminal fuzzy sliding mode control and equivalent input disturbance (EID)-error-estimation-based active disturbance rejection control are presented on the grid side to improve the voltage response rate, and an improved support vector modulation (SVM)–direct torque control (DTC)–ADRC method is developed on the motor side to improve the robustness against disturbances. Finally, theoretical simulation experiments are built in MATLAB R2023a/Simulink to verify the effectiveness and superiority of this method. Full article
(This article belongs to the Special Issue Advanced Control Strategies and Applications of Multi-Agent Systems)
Show Figures

Figure 1

29 pages, 7577 KiB
Review
Overview of Isolated Bidirectional DC–DC Converter Topology and Switching Strategies for Electric Vehicle Applications
by Zhenkun Wang, Xianjin Su, Nianyin Zeng and Jiahui Jiang
Energies 2024, 17(10), 2434; https://doi.org/10.3390/en17102434 - 20 May 2024
Cited by 16 | Viewed by 4445
Abstract
Isolated bidirectional DC–DC converters are becoming increasingly important in various applications, particularly in the electric vehicle sector, due to their ability to achieve bidirectional power flow and their safety features. This paper aims to review the switch strategies and topologies of isolated bidirectional [...] Read more.
Isolated bidirectional DC–DC converters are becoming increasingly important in various applications, particularly in the electric vehicle sector, due to their ability to achieve bidirectional power flow and their safety features. This paper aims to review the switch strategies and topologies of isolated bidirectional DC–DC converters, with a specific focus on their applications in the field of electric vehicles. From the perspective of topology, PWM-type isolated bidirectional DC–DC converters, dual active bridge converters, and resonant-type isolated bidirectional DC–DC converters constitute the three main categories of these converters. The paper further examines the traditional switch strategies of these converters and discusses how specific switch technologies, such as single-phase shift, expanding-phase shift, double-phase shift, and triple-phase shift, can enhance the overall performance of isolated bidirectional DC–DC converters. The paper meticulously examines the characteristics of each topology and control scheme, as well as their typical use cases in practical applications. Particularly, the paper delves into the applications of isolated bidirectional DC–DC converters in the electric vehicle sector and draws conclusions regarding their potential and trends in future electric vehicle technology. Full article
Show Figures

Figure 1

17 pages, 1201 KiB
Article
A Single-Output-Filter Double Dual Ćuk Converter
by Hector R. Robles-Campos, Julio C. Rosas-Caro, Antonio Valderrabano-Gonzalez and Johnny Posada
Electronics 2024, 13(10), 1838; https://doi.org/10.3390/electronics13101838 - 9 May 2024
Cited by 2 | Viewed by 1245
Abstract
This study introduces an innovative version of a recently studied converter. A Double Dual Ćuk Converter was recently studied with advantages like the possibility of designing it for achieving a low-input current ripple. The proposed converter, called the Improved Double Dual Ćuk Converter, [...] Read more.
This study introduces an innovative version of a recently studied converter. A Double Dual Ćuk Converter was recently studied with advantages like the possibility of designing it for achieving a low-input current ripple. The proposed converter, called the Improved Double Dual Ćuk Converter, maintains the advantages of the former one, and it is characterized by requiring one less capacitor and inductor than its predecessor. This allows addressing the challenge of optimizing the topology to reduce component count without compromising the operation; this work proposes an efficient design methodology based on theoretical analysis and experimental validation. Results demonstrate that the improved topology not only retains the advantages of the previous version, including high efficiency and robustness, but also enhances power density by reducing the number of components. These advancements open new possibilities for applications requiring compact and efficient power converters, such as renewable energy systems, electric vehicles, and portable power supply systems. This work underscores the importance of continuous innovation in power converter design and lays the groundwork for future research aimed at optimizing converter topologies. A detailed discussion of the operating principles and modeling of the converter is provided. Furthermore, simulation outcomes highlighting differences in steady-state duration, output voltage, input current ripple, and operational efficiency are shared. The results from an experimental test bench are also presented to corroborate the efficacy of the improved converter. Full article
(This article belongs to the Special Issue Advanced Technologies in Power Electronics and Electric Drives)
Show Figures

Figure 1

17 pages, 42940 KiB
Article
Enhancing Electric Vehicle Charger Performance with Synchronous Boost and Model Predictive Control for Vehicle-to-Grid Integration
by Youness Hakam, Ahmed Gaga, Mohamed Tabaa and Benachir El hadadi
Energies 2024, 17(7), 1787; https://doi.org/10.3390/en17071787 - 8 Apr 2024
Cited by 9 | Viewed by 1818
Abstract
This paper investigates optimizing the power exchange between electric vehicles (EVs) and the grid, with a specific focus on the DC-DC converters utilized in vehicle-to-grid (V2G) systems. It specifically explores using model predictive control (MPC) in synchronous boost converters to enhance efficiency and [...] Read more.
This paper investigates optimizing the power exchange between electric vehicles (EVs) and the grid, with a specific focus on the DC-DC converters utilized in vehicle-to-grid (V2G) systems. It specifically explores using model predictive control (MPC) in synchronous boost converters to enhance efficiency and performance. Through experiments and simulations, this paper shows that replacing diodes with SIC MOSFETs in boost converters significantly improves efficiency, particularly in synchronous mode, by minimizing the deadtime of SIC MOSFETs during switching. Additionally, this study evaluates MPC’s effectiveness in controlling boost converters, highlighting its advantages over traditional control methods. Real-world validations further validate the robustness and applicability of MPC in V2G systems. This study utilizes TMS320F28379D, one of Texas Instruments’ leading digital signal processors, enabling the implementation of MPC with a high PWM frequency of up to 200 MHz. This processor features dual 32-bit CPUs and a 16-bit ADC, allowing for high-resolution readings from sensors. Leveraging digital signal processing technologies and advanced electronic circuits, this study advances the development of high-performance boost converters, achieving power outputs of up to 48 watts and output voltages of 24 volts. Electronic circuits (PCB boards) have been devised, implemented, and evaluated to showcase their significance in advancing efficient V2G integration. Full article
Show Figures

Figure 1

20 pages, 3913 KiB
Article
Modulation Techniques and Coordinated Voltage Vector Distribution: Effects on Efficiency in Dual-Inverter Topology-Based Electric Drives
by Jakub Kucera, Petr Zakopal, Filip Baum and Ondrej Lipcak
Energies 2024, 17(5), 986; https://doi.org/10.3390/en17050986 - 20 Feb 2024
Cited by 1 | Viewed by 1710
Abstract
The increasing popularity of electric drives employing an isolated dual-inverter (DI) topology is motivated by their superior DC-link voltage and power utilization, fault-tolerant operation, and potential for multilevel operation. These attributes are significant in battery-powered transportation, such as electric vehicles and aviation. Given [...] Read more.
The increasing popularity of electric drives employing an isolated dual-inverter (DI) topology is motivated by their superior DC-link voltage and power utilization, fault-tolerant operation, and potential for multilevel operation. These attributes are significant in battery-powered transportation, such as electric vehicles and aviation. Given the considerable freedom in modulation and control of the DI topology, this paper researches the impact of reference voltage vector distribution between the two individual inverters. The study also evaluates the influence of two well-established asynchronous modulation strategies—Space Vector PWM (SVPWM) and Depenbrock’s Discontinuous Modulation (DPWM1). Since simulation tools nowadays play a crucial role in power electronics design and concept verification, the results are based on extensive and detailed models in Matlab/Simulink. Employing the basic field-oriented control of a 12 kW induction motor with precisely parameterized SiC switching devices for accurate loss calculation, this research reveals the possibility of significant energy savings at multiple operating points. Notably, optimal efficiency is achieved when one inverter operates up to half of the nominal speed while the other solely establishes a neutral point for the winding. Moreover, the results highlight DPWM1 as a superior strategy for the DI topology, showcasing reduced converter losses. Overall, it is shown that the system’s losses can be significantly reduced just by the design of the voltage vector distribution in the drive’s operating range and the modulation strategy selection. Full article
(This article belongs to the Special Issue Modeling, Control and Design of Power Electronics Converters)
Show Figures

Figure 1

19 pages, 12055 KiB
Article
A Wide-Range Negative Output DC-DC Converter with Adaptive Drive Technique for Active-Matrix OLED Microdisplays
by Yue Liu, Hong Cai and Bohua Zhao
Electronics 2024, 13(3), 564; https://doi.org/10.3390/electronics13030564 - 30 Jan 2024
Cited by 1 | Viewed by 1720
Abstract
This paper presents a DC-DC converter with wide-range negative output for active-matrix organic light-emitting diode (AMOLED). The generated negative voltage Vout is connected to the negative terminal of the organic light-emitting diode (OLED), and the luminous brightness is adjusted by [...] Read more.
This paper presents a DC-DC converter with wide-range negative output for active-matrix organic light-emitting diode (AMOLED). The generated negative voltage Vout is connected to the negative terminal of the organic light-emitting diode (OLED), and the luminous brightness is adjusted by changing the value of Vout. The negative output voltage of the DC-DC converter is regulated by a Buck–Boost topology structure with a dual-loop control (DLC) system composed of a voltage loop and a current loop. The proposed compensatory peak-current-sensing technique (PCST) and switch MOSFETs adaptive drive technique (ADT) successfully support the implementation of the converter topology and enable the converter to work in continuous conduction mode (CCM). In addition, with the DLC system, the converter can guarantee a negative output voltage that enables both a fast transient response such as excellent load/line regulation, and a small output voltage ripple of the pulse width modulation (PWM) control. The proposed chip is implemented in a 0.18 μm CMOS process that operates at an operating frequency of 2 MHz with a maximum efficiency of 85.82%. The output voltage ripple is 1.5 mV at typical loading of Vout=4 V and Iout=100 mA. Full article
Show Figures

Figure 1

13 pages, 4955 KiB
Article
A Fast Transient Adaptive On-Time Controlled BUCK Converter with Dual Modulation
by Mengyuan Sun, Chufan Chen, Leiyi Wang, Xinling Xie, Yuhang Wang and Min Xu
Micromachines 2023, 14(10), 1868; https://doi.org/10.3390/mi14101868 - 29 Sep 2023
Cited by 2 | Viewed by 2941
Abstract
This paper proposed a fully integrated adaptive on-time (AOT) controlled buck converter with fast load transient. An adaptive on-time generator is presented to stabilize the output frequency. To enhance the light load efficiency, the converter could transfer from the pulse width modulation (PWM) [...] Read more.
This paper proposed a fully integrated adaptive on-time (AOT) controlled buck converter with fast load transient. An adaptive on-time generator is presented to stabilize the output frequency. To enhance the light load efficiency, the converter could transfer from the pulse width modulation (PWM) to pulse skip modulation (PSM) as the load current decreases. The buck converter can switch between these two modulation modes adaptively with the assistance of a zero current detection circuit. Implemented in the TSMC 0.18 µm BCD (BiCMOS/DMOS) process, the proposed buck converter works with an input voltage ranging from 5.5 to 15 V, an output voltage ranging from 0.5 to 5 V, and an output load ranging up to 5 A. The experimental results show that based on the dual modulation adaptive on-time controlled mode, the transient recovery time from light to heavy load and from heavy load to light load is 13 µs and 15 µs, respectively. An overshot voltage of 57 mV and an undershot voltage of 53 mV are also achieved. Full article
(This article belongs to the Special Issue Advanced Micro- and Nano-Manufacturing Technologies)
Show Figures

Figure 1

18 pages, 11197 KiB
Article
A Study on the Distributed-Control Architecture of a DSP-Based Solid-State Transformer System with Implementation
by Jiho Ju, Dongho Choi and June-Seok Lee
Energies 2023, 16(16), 6095; https://doi.org/10.3390/en16166095 - 21 Aug 2023
Cited by 1 | Viewed by 1295
Abstract
This article proposes a Distributed-control Architecture (D-CA) and an operation sequence with start-up strategies for a Digital Signal Processor (DSP)-based Solid-State Transformer (SST). Although various control techniques for SSTs have been reported in earlier studies, there is still a lack of research covering [...] Read more.
This article proposes a Distributed-control Architecture (D-CA) and an operation sequence with start-up strategies for a Digital Signal Processor (DSP)-based Solid-State Transformer (SST). Although various control techniques for SSTs have been reported in earlier studies, there is still a lack of research covering comprehensive content, including hierarchical control architectures and operation sequences with start-ups considering the implementation of DSPs. Therefore, this article addresses the following factors of SST. First, the D-CA is described for the design of the hierarchy between control boards. With the D-CA, because sub-boards are in charge of their corresponding DC-link voltage balancing control individually, the computational burden on the master board can be reduced. Second, the operation sequence of the SST system is explained based on the SST with D-CA. The step of DC-link voltage balance is considered throughout the entire operation sequence for safe driving. Furthermore, the PWM start-up strategies for a Cascade H-bridge Multilevel (CHM) converter and Dual Active Bridge (DAB) converter are proposed to prevent switching pulse errors caused by DSP operating characteristics. These start-up strategies reduce the current surges. The validity of the proposed D-CA and operation sequence with start-up strategies are verified by experimental results. Full article
(This article belongs to the Section F: Electrical Engineering)
Show Figures

Graphical abstract

15 pages, 5853 KiB
Article
A Dual-Mode Step-Down Converter with Automatic Mode Switch Circuit for System-on-Chip Applications
by Yue Liu, Taishan Mo and Bin Wu
Electronics 2023, 12(13), 2999; https://doi.org/10.3390/electronics12132999 - 7 Jul 2023
Viewed by 1952
Abstract
In this paper, a dual-mode step-down DC-DC converter with an automatic mode-switching circuit is implemented in a 28 nm digital CMOS process and embedded in an RF transceiver chip to power the digital part. The proposed automatic mode-switching circuit includes a frequency-voltage conversion [...] Read more.
In this paper, a dual-mode step-down DC-DC converter with an automatic mode-switching circuit is implemented in a 28 nm digital CMOS process and embedded in an RF transceiver chip to power the digital part. The proposed automatic mode-switching circuit includes a frequency-voltage conversion circuit that is designed according to the principle of charge redistribution on capacitance. The converter can switch modes according to the load without external intervention. This converter, along with a PMU sequencer, can also provide a solution for low-power design for system-on-chip applications. The IC occupies a total die area of 0.378 mm2. The input voltage of the converter is 3.3 V, the output voltage is 1.05 V, and the maximum load current can reach 1 A. The converter shows a conversion efficiency of not less than 81% at a full load range and can achieve a peak conversion efficiency of 91% when the load current is 100 mA. The load range of the PWM mode is 1 A to 50 mA, and that of the PFM mode is 100 mA to 1 mA. The combination of zero-crossing detection circuitry and freewheel switches can reduce energy loss and eliminate additional electromagnetic interference. Full article
Show Figures

Figure 1

19 pages, 2377 KiB
Article
Analysis and Design of a High-Frequency Isolated Dual-Transformer DC-DC Resonant Converter
by Yinan Li, Rui Wang, Liping Zhong, Limin Mao, Chuan Sun, Xiaodong Li and Song Hu
Electronics 2023, 12(1), 103; https://doi.org/10.3390/electronics12010103 - 27 Dec 2022
Cited by 4 | Viewed by 2733
Abstract
This paper presents the operation, analysis, design, simulation, and experimental results for a proposed Dual-Transformer DC-DC Resonant Converter (DTRC). A three-arm bridge is employed on the input side and an H-type bridge is employed on the output side of the DTRC, and the [...] Read more.
This paper presents the operation, analysis, design, simulation, and experimental results for a proposed Dual-Transformer DC-DC Resonant Converter (DTRC). A three-arm bridge is employed on the input side and an H-type bridge is employed on the output side of the DTRC, and the two bridges are connected with two high-frequency (HF) transformers. By optimizing the ratio k of the two HF transformers, the proposed DTRC has a lower boundary power for losing zero-voltage switching (ZVS). That means the DTRC has a wider ZVS operation range and lower switching loss when compared with a traditional soft-switching pulse width modulation (PWM) resonant converter. The operation principle, power transfer, ZVS characteristics, and design procedures are analyzed in detail. Both simulation and experimental results prove the feasibility and superiority of the proposed Dual-Transformer DC-DC Resonant Converter. Full article
Show Figures

Figure 1

21 pages, 13120 KiB
Article
Dual-Mode Control Scheme to Improve Light Load Efficiency for Dual Active Bridge DC-DC Converters Using Single-Phase-Shift Control
by Thanh Nhat Trung Tran, Wen-Yan Chang and Jian-Min Wang
Appl. Sci. 2022, 12(23), 12356; https://doi.org/10.3390/app122312356 - 2 Dec 2022
Viewed by 2329
Abstract
In vehicle-to-grid (V2G) applications, dual active bridge (DAB) converters are commonly used as the power interface because they offer high efficiency, galvanic isolation, and bidirectional power flow. For the DAB control strategy, phase-shift control is the mainstream, especially the single-phase-shift (SPS) method because [...] Read more.
In vehicle-to-grid (V2G) applications, dual active bridge (DAB) converters are commonly used as the power interface because they offer high efficiency, galvanic isolation, and bidirectional power flow. For the DAB control strategy, phase-shift control is the mainstream, especially the single-phase-shift (SPS) method because of its ease of implementation. However, due to the phase shift, a DAB converter operated under this control method has relatively high backflow power, resulting in poor efficiency. The SPS control method has the drawback of high backflow power, especially at light loads. Thus, this paper proposes a new dual-mode control scheme to improve the light load efficiency of DAB converters by taking advantage of the pulse-width modulation (PWM) strategy in combination with the conventional SPS strategy for DAB converters based on load conditions. In other words, when the DAB converter operates under light load conditions, the PWM control strategy is used to avoid considerable backflow power. A prototype DAB converter with a power rating of 1 kW under a switching frequency of 100 kHz interfacing a DC bus (400 V) and a battery pack (50 V) is designed and implemented to verify the feasibility of this control strategy. A detailed analysis of the working principle and design parameters of the proposed converter is provided in this paper. Experimental results show that the highest efficiency of the proposed converter at light loads (10–200 W) was 96.2% for the forward power conversion and 97.3% for the backward power conversion. Full article
Show Figures

Figure 1

12 pages, 5292 KiB
Article
Dynamic Enhancement for Dual Active Bridge Converter with a Deadbeat Current Controller
by Chengfu Tian, Shusheng Wei, Jiayu Xie and Tainming Bai
Micromachines 2022, 13(12), 2048; https://doi.org/10.3390/mi13122048 - 23 Nov 2022
Cited by 1 | Viewed by 1968
Abstract
This paper investigates the deadbeat current controllers for isolated bidirectional dual-active-bridge dc-dc converter (IBDC), including the peak current mode (PCM) and middle current mode (MCM). The controller uses an enhanced single phase shift (ESPS) modulation method by exploiting pulse width as an extra [...] Read more.
This paper investigates the deadbeat current controllers for isolated bidirectional dual-active-bridge dc-dc converter (IBDC), including the peak current mode (PCM) and middle current mode (MCM). The controller uses an enhanced single phase shift (ESPS) modulation method by exploiting pulse width as an extra control variable in addition to phase shift ratio. The control variables for PCM controllers are derived in detail and the two different current controllers are compared. A double-closed-loop control method is then employed, which could directly control the high-frequency inductor current and eliminate the transient DC current bias of the transformer. Furthermore, load feedforward was introduced to further enhance the dynamic of the converter. With the proposed control method, the settling time could be reduced within several PWM cycles during load disturbance without transient DC current bias. A 5 kW IBDC converter prototype was built and the settling time of 6 PWM cycles during load change with voltage regulation mode was achieved, which verifies the superior dynamic performance of the control method. Full article
(This article belongs to the Special Issue Advanced Interconnect and Packaging)
Show Figures

Figure 1
