Search Results (10)

Blade tip leakage vortex (TLV) is a critical phenomenon in hydraulic machinery, which can significantly affect the internal flow characteristics and deteriorate the hydraulic performance. In this paper, the blade tip leakage flow and TLV characteristics in a novel dishwasher pump were investigated. The correlation between the vorticity distribution in various directions and the leakage vortices was established within a rotating coordinate system. The results show that the TLV in a composite impeller can be categorized into initial and secondary leakage vortices. The initial leakage vortex originates from the evolution of two corner vortices that initially form at different locations within the blade tip clearance. This vortex induces pressure fluctuations at the impeller inlet; its shedding is identified as the primary contributor to localized energy loss within the flow passage. These findings provide insights into TLVs in complex pump geometries and provide solutions for future pump optimization strategies. Full article

Double-suction centrifugal pumps are extensively employed in industrial applications owing to their high efficiency, low vibration, superior cavitation resistance, and operational durability. This study analyzes how impeller oblique cutting angles (0°, 6°, 9°, 12°) affect a double-suction pump at a fixed 4% trimming ratio and constant average post-trim diameter. Numerical simulations and tests reveal that under low-flow (0.7Q_d) and design-flow conditions, the flat-cut (0°) minimizes reflux ratio and maximizes efficiency by aligning blade outlet flow with the mainstream. Increasing oblique cutting angles disrupts this alignment, elevating reflux and reducing efficiency. Conversely, at high flow (1.3Q_d), the 12° bevel optimizes outlet flow, achieving peak efficiency. Pressure pulsation at the volute tongue (P11) peaks at the blade-passing frequency, with amplitudes significantly higher for 9°/12° bevels than for 0°/6°. The flat-cut suppresses wake vortices and static–rotor interaction, but oblique cutting angle choice critically influences shaft-frequency pulsation. Entropy analysis identifies the volute as the primary loss source. Larger oblique cutting angles intensify wall effects, increasing total entropy; pump chamber losses rise most sharply due to worsened outlet velocity non-uniformity and turbulent dissipation. The flat-cut yields minimal entropy at Q_d. These findings provide a basis for tailoring impeller trimming to specific operational requirements. Furthermore, the systematic analysis provides critical guidance for impeller trimming strategies in other double-suction pumps and pumps as turbines in micro hydropower plants. Full article

Cavitation is a complex multiphase flow phenomenon, and the generation of transient phase transitions between liquid and vapor during cavitation development leads to multi-scale vortex motion. The transient cavitation dynamics and centrifugal pump’s rotor–stator interaction will induce pressure fluctuations in the impeller and the volute fluid of the centrifugal pump, resulting in a complex flow field structure. Based on the Schnerr–Sauer cavitation model and SST k-ω turbulence model, this paper studies the transient characteristics of the cavitation-induced unsteady flow in the centrifugal pump and the excitation response to the pressure pulsation in the volute under different flow conditions, taking the large vertical double-volute centrifugal pump as the research object. The results indicate the following: As the impeller rotates, in the external excitation response, the jet-wake flow structure at the centrifugal pump blade outlet shows an increase in the blade frequency signal. This is evident near the measurement points of the volute tongue and separator. When severe cavitation occurs, the maximum amplitude at the blade frequency in the volute shifts from the pump tongue (30°) to the downstream of the tongue (45°). The value of f_pmax is 3.1 times that when NPSHa = 8.88 m. By applying the Omega vortex identification method, it can be seen that the interaction between the vortices at the blade trailing edge and the stable vortex in the volute tongue undergoes a process of elongation, fusion, separation, and recovery. This represents the downstream influence of the impeller on the volute. When Q = 0.9Q_d, the process of the blade passage vortex tail detaching and dissipating in the impeller flow path can be observed, demonstrating the upstream influence of the volute on the impeller. Full article

Aiming at the problem of high vibration and high wear of centrifugal pump tongue, this paper proposes a double-tongue volute structure. Under the condition of ensuring the reliability of CFD results, the influence of various combinations of tongue and volute base circle on the turbulent kinetic energy of centrifugal pump and the radial force of impeller is explored. The traditional single-tongue volute centrifugal pump is compared with various characteristic indexes, and the unsteady numerical calculation is carried out based on different working conditions. It is concluded that the double-tongue volute structure can improve the pressure fluctuation at the monitoring points near the tongue. The results show that the double-tongue volute structure can improve the static pressure gradient and velocity gradient of the middle section of the centrifugal pump and reduce the maximum turbulent kinetic energy value at the tongue under small flow conditions. When the working condition is 1.0 Q, the radial force of the impeller of the C-type double-tongue volute reaches the minimum value of 3.03 N, which can effectively balance part of the radial force. Full article

In order to analyze the inner flow in a multi-stage double-suction centrifugal pump, which is regarded as a common way of knowing the current characteristics of the pump and as the basis of optimization for better performance, a numerical simulation considering the velocity field distribution characteristics and pressure fluctuation propagation law using the detached eddy simulation method was conducted. Additionally, the principle of entropy generation was put to use to quantify and compare the energy loss of different components. The results reveal that the existence of unstable flow structures in the first-stage impeller and a large number of vortical structures in the back-channel result in reduced operational efficiency of the pump. Furthermore, the pressure fluctuation intensity reaches its maximum with 0.15 at the blade trailing edge, which propagates to the tongue region of the forward flow channel and the double-volute under the low rates condition. Additionally, the main frequency of the monitoring points in the inter-stage flow channel and volute is basically located at a frequency of 198.667 Hz, which is twice the blade frequency. Consequently, the wall entropy production accounting for nearly 25% cannot be ignored and that the loss mainly occurs in the double-volute and the inter-stage flow channel due to the occurrence of irregular flow in the above components with more than 50%. The outcomes of this research present a valuable point of reference for the optimization of structural design in multistage turbomachines with various applications. Full article

Stall usually occurs in the hump area of the head curve, which will block the channel and aggravate the pump vibration. For centrifugal pumps with guide vanes usually have a clocking effect, the stall characteristic at different clocking positions should be focused. In this paper, the flow field of the centrifugal pump under stall conditions is numerically simulated, and the rotor–stator interaction effects of the centrifugal pump under stall conditions are studied. The double-hump characteristic is found in the head curve by using SAS (Scale Adaptive Simulation) model. The hump area close to the optimal working condition is caused by hydraulic loss, while the hump area far away from the optimal working condition point is caused by the combined action of Euler’s head and hydraulic loss. The SAS model can accurately calculate the wall friction loss, thus predicting the double-hump phenomenon. The pressure fluctuation and head characteristics at different clocking positions under stall conditions are obtained. It is found that when the guide vanes outlet in line with the volute tongue, the corresponding head is the highest, and the pressure fluctuation is the lowest. The mechanism of the clocking effect in the centrifugal pump with guide vanes is obtained by simplifying the hydrofoil. It is found that when the downstream hydrofoil leading edge is always interfered with by the upstream hydrofoil wake, the wake with low energy mixes the boundary layer with low energy, which causes small-pressure pulsation. The results could be used for the operation of centrifugal pumps with guide vanes. Full article

In order to improve the operation performance of the multi-stage double-suction centrifugal pump and reduce the internal energy loss of the pump, this paper proposes a single-objective optimization design method based on the non-hierarchical response surface methodology (RSM) and the multi-island genetic algorithm (MIGA). Nine parameters, such as the blade outlet width and blade wrap angle, were used as design variables, and the optimization objective was efficiency under design conditions. In total, 149 sets of valid data were obtained under the Latin hypercube sampling method (LHS), the corresponding thresholds were set for efficiency and head, and 99 sets of valid data were obtained. A cross-validation analysis of the sieved data was carried out based on non-hierarchical RSM, global optimization of the efficiency was carried out using MIGA, and numerical verification was carried out via CFD. The research results show that compared with hierarchical RSM, non-hierarchical RSM can approximate the nonlinear relationship between the objective function and the design variables with higher accuracy, and the model fitting R² value was 0.919. The efficiency was improved by 3.717% after optimization. The overall prewhirl of the impeller inlet after optimization decreased, the internal speed of the volute significantly improved, the large-area vortex at the volute and the outlet pipe was eliminated, the impact loss at the volute separating tongue disappeared, and the overall hydraulic performance of the pump was improved. The total entropy output value of the optimized pump was reduced by 4.79 (W/K), mainly concentrated on the reduction in the entropy output value of the double volute, and the overall energy dissipation of the pump was reduced. Full article

A pressure pulsation experiment of a dishwasher pump with a passive rotation double-tongue volute was carried out and compared with the pressure pulsation of a single-tongue volute and a static double-tongue volute. The pressure pulsation of the three volute models was compared and analyzed from two aspects of different impeller speeds and different monitoring points. The frequency domain and time–frequency domain of pressure pulsation were obtained by a Fourier transform and short-time Fourier transform, respectively. The results showed that the average pressure of each monitoring point on the rotating double-tongue volute was the smallest and that on the single-tongue volute was the largest. When the impeller rotates at 3000 rpm, there were eight peaks and valleys in the pressure pulsation time domain curve of the single-tongue volute, while the double-tongue volute was twice that of the single-tongue volute. Under different impeller speeds, the changing trends of pressure pulsation time and frequency domain curves of static and rotating double-tongue volutes at monitoring point p1 are basically the same. Therefore, a volute reference scheme with passive rotation speed is proposed in this study, which can effectively improve the flow pattern and reduce pressure inside the dishwasher pump, and also provide a new idea for rotor–rotor interference to guide the innovation of dishwashers. Full article

The flow instability of a double-blade centrifugal pump is more serious due to its special design feature with two blades and large flow passages. The dynamic instabilities and pressure pulsations can affect the pump performance and operating lifetime. In the present study, a numerical investigation of unsteady flow and time variation of pressure within a complete double-blade centrifugal pump was carried out. The time domain and frequency domain of pressure pulsations were extracted at 16 monitoring locations covering the important regions to analyze the internal flow instabilities of the pump model. The frequency spectra of pressure pulsations were decomposed into Strouhal number dependent functions. This led to the conclusion that the blade passing frequency (BPF) related vibrations are exclusively flow-induced. Large vortices were observed in the flow passages of the pump at low flow rate. It is noted that high vorticity magnitude occurred in the vicinities of the blade trailing edge and tongue of the volute, due to the rotor-stator interaction between impeller and volute. Full article

The steady and unsteady flow characteristics of internal flow in a backward centrifugal fan of double inlet at low flow-rate condition are investigated by computational fluid dynamics in this paper. The investigation aims to reveal insights into generation mechanisms and our physical understanding of the rotating stall and surge. The numerical results mainly demonstrate that, with decreasing flow rate, a large number of vortex flows almost increasingly occupy the internal flow of the impeller. The reverse flow and separation vortices increasingly appear near the outlet of volute, and the internal flow of the impeller is completely blocked by the separated vortex flow at low flow-rate conditions. Results indicate that, due to a synchronization of the impeller rotation and separation vortex, these separated vortices act intensely on the pressure surface of the blade with time evolution, and the interaction between the separated vortices and surface of blade increasingly yields small-scale eddies. It is further found that the amplitude of pressure and velocity fluctuations gradually increase with the decrease of flow rate in a certain range. The unsteady characteristics acting on the volute tongue gradually increase in a range of Q_d to 0.3 Q_d (Q_d is the design volume flow rate) with the decrease of flow rate, and the unsteady characteristics acting on the volute tongue are weakened at the working condition of 0.15 Q_d. These insights clearly explain the unsteady nature of the rotating stall and surge phenomenon in the double inlet backward centrifugal fan. Full article
