Search Results (19)

Solar air heating systems offer an effective alternative for reducing greenhouse gas emissions at a profitable cost. This work details the design, construction, and experimental evaluation of a novel double-pass V-trough solar air heater with semicircular receivers, which was built with low-cost materials readily available in the Mexican market. Thermal performance tests were conducted in accordance with the ANSI-ASHRAE 93-2010 standard. The results indicated a peak collector efficiency of 0.4461 and total heat losses of 8.8793 W/(m² °C), with an air mass flow rate of 0.0174 kg/s. The instantaneous thermal efficiency varied between 0.2603 and 0.5633 with different air flow rates and an inlet air temperature close to the ambient temperature. The outlet air temperature reached 70 °C, making it suitable for dehydrating fruits or vegetables at competitive operating costs. Additionally, a second-law analysis was carried out, and the exergy efficiency was between 0.0037 and 0.0407. Finally, a Levelized Cost of Energy analysis was performed, and the result was USD 0.079/kWh, which was 31% lower than that of a conventional electric air heater system. Full article

The Solar Air Heater (SAH) is considered to be one of the promising devices for the utilization of solar radiation. Extracting more heat to the flowing air is the focus of researchers, and many novel ideas are adopted to improve the efficiency of such collectors. The objective of the present work is the enhancement of thermal performance using a numerical analysis of a single flow double pass solar air heater with two types of arrangements of aerofoil fin configurations. The effect of the aerofoil fin configurations and the height of the fin are investigated for their thermal and thermohydraulic efficiencies. The height of the fin varied parametrically for the Reynolds number ranging from 3000 to 24,000 by keeping the axial pitch of the fin as a constant. It is found that the thermal efficiency increases with the increase in fin height due to an increased flow turbulence causing more absorption of heat to the working fluid. However, it is seen that the varying height of the fin beyond a certain height has yielded an adverse effect in terms of lesser thermal efficiency due to the expected flow blockage in the main stream. The thermohydraulic efficiency increases as the height of the fin decreases. The Computational Fluid Dynamics (CFD) results revealed that the optimum aerofoil fin configuration yields approximately a 23.24% higher thermal efficiency when compared with that of the single pass solar air heater (base model). The thermohydraulic efficiency exceeds the optimum aerofoil fin configuration compared with the base model by approximately 20.94%. Full article

Solar air heaters can reduce climate change by replacing conventional fossil fuel-burning technologies in drying and space heating applications. Concentrating solar technologies, such as compound parabolic concentrators, allow air temperatures up to 120 °C; however, it is desirable to improve their heat transfer to reduce the space requirements for their installation. In this work, a parabolic concentrator composed of a flat receiver designed to recover heat from the cover–receiver–reflectors cavity is analyzed, operating it as a U-shape double pass solar heater. With this operation, first, the air flows through the cavity, and then it is incorporated into the duct, where the dominant heat gain occurs due to the capture of solar radiation. Thus, four input–output configurations in the cavity were modeled through dynamic simulations to determine the influence of the inlet and outlet air flow positions on the solar concentrator outlet temperature. Therefore, the incorporation of the first pass has a contribution of between 36% and 45% in useful energy gain, showing that this appropriate and relatively simple strategy can be implemented to improve the thermal performance of solar air collectors, resulting in instantaneous efficiencies higher than 75%. However, the simulation results demonstrate that the position of the inlets and outlets does not significantly impact the efficiency and outlet temperature. Full article

The scientific literature extensively mentions the use of a solar air heater (SAH) by utilizing solar energy for heating purposes. The poor heat-transfer rate of an SAH with a flat plate is caused by developing a laminar sub-layer near the heated base plate. The plate temperatures improve significantly, resulting in losses and a decrease in performance. The passive approach entails the placement of fins/turbulators/pouring material/ribs to the surface where the boundary layer forms to disrupt it. Artificially roughened SAH for gathering and efficiently using solar radiations for thermal purposes is extensively described in the literature. This paper includes a thorough literature overview of the history, basics, roughness evolution, forms of SAH, and recent breakthroughs in thermal performance improvement techniques for SAH compiled by several researchers. This paper uses a comparative evaluation of several roughness geometries and kinds of SAH to uncover thermohydraulic performance factors that may be considered in future research to pick the optimal configuration. Full article

To investigate the influencing range and optimize values of different operational and system parameters on the double-pass parallel flow solar air heater’s (DPPFSAH) thermal, effective, and exergetic efficiencies, an iterative method was used to analyze the governing energy equations using a theoretical model written in MATLAB based on the Nusselt number (Nu) and friction factor (f) correlations developed in the work performed earlier. A comparison between double-pass and single-pass SAHs for mathematical and experimental outcomes was conducted, and the results were found to be fairly consistent. According to the thermo-hydraulic performance indicators, similar to single-pass SAHs, perforated multi-V rib-roughened DPPFSAHs achieve optimum thermal performance for lower Reynolds numbers, which does not change much as the Reynolds number increases above 18,000. This finding can be taken into account when designing any DPPFSAH. Full article

This paper investigates double-pass solar air thermal collectors with lava rock as the porous media. The addition of lava rock serves as short-term sensible thermal storage for a solar drying system. It also enhances the convective heat transfer rate to the airflow due to an increased heat transfer area and increased turbulence in the air channel. A mathematical model was developed based on energy balance equations and was numerically solved in MATLAB. The collector’s thermal performance was studied at various levels of solar intensity and at different wind speeds for different design parameters: collector size, air mass flow rate, and lava rock volume. From the study, the optimum efficiencies that were obtained in the range between the intensities of 500 W/m² and 800 W/m² were 62% to 64%, respectively, with an optimum flow rate of 0.035 kg/s. The optimum porosity of about 89% was selected for the collector by considering the pressure drop and thermal efficiency. An optimal temperature output range between 41.7 °C and 48.3 °C could be achieved and was suitable for agricultural and food drying applications. Meanwhile, compared to conventional DPSAHs, the average percentage increase in the output temperature of the DPSAH with lava rock was found to be higher by 17.5%. Full article

Analyzing the combination of involving parameters impacting the efficiency of solar air heaters is an attractive research areas. In this study, cost-effective double-pass perforated glazed solar air heaters (SAHs) packed with wire mesh layers (DPGSAHM), and iron wools (DPGSAHI) were fabricated, tested and experimentally enhanced under different operating conditions. Forty-eight iron pieces of wool and fifteen steel wire mesh layers were located between the external plexiglass and internal glass, which is utilized as an absorber plate. The experimental outcomes show that the thermal efficiency enhances as the air mass flow rate increases for the range of 0.014–0.033 kg/s. The highest thermal efficiency gained by utilizing the hybrid optimized DPGSAHM and DPGSAHI was 94 and 97%, respectively. The exergy efficiency and temperature difference (∆T) indicated an inverse relationship with mass flow rate. When the DPGSAHM and DPGSAHI were optimized by the hybrid procedure and employing the Taguchi-artificial neural network, enhancements in the thermal efficiency by 1.25% and in exergy efficiency by 2.4% were delivered. The results show the average cost per kW (USD 0.028) of useful heat gained by the DPGSAHM and DPGSAHI to be relatively higher than some double-pass SAHs reported in the literature. Full article

The effect of external-recycle operations on the thermal performance of double-pass cross-corrugated solar air heaters (SAH) under different operating conditions was investigated experimentally and theoretically. Additionally, the simultaneous ordinary equations were solved analytically for each proposed configuration. Four recycling types are introduced for improving the solar thermal performance with different external recycle processes, which are expected to enhance the heat transfer coefficient with a convective turbulent flow between the air and the absorber in the present study. Using recycling double-pass operations, two processes were conducted sequentially: air first flowed over the sinusoidal corrugated absorber plate and then flowed back later over the transverse sinusoidal corrugated bottom plate. Improved device performance was achieved due to the doubled heat transfer area over and under the corrugated absorber plate, from which both the sinusoidal cross-corrugated absorber plate and bottom plate enhanced turbulent intensity. Theoretical predictions and experimental results both indicated that the recycle ratio increased with the SAH thermal efficiency for all proposed designs. The results show a higher heat transfer efficiency for the proposed four configurations using wavelike corrugated plates compared to those conducted in single-pass and flat-plate absorber plates with up to a maximum 133% (from 0.301 to 0.703) increment. The optimal device performance was examined for all external-recycle configurations under the same working dimensions and operational conditions. The best configuration for optimal thermal performance was the device that lengthened the air flow pathway and increased the air velocity within the collector; thus, a higher heat transfer rate was accomplished. The evaluation of increments in the power consumption and of the heat-transfer efficiency enhancement together determined the optimal design based on an economic consideration across various configurations of cross-corrugated double-pass devices. Full article

In this study, an experimental outdoor investigation of the thermal efficiency and outlet air temperature was conducted on an unglazed, double-pass, solar air heater with a perforated absorber plate and packing wire mesh layers as a supplemental absorbent area. This was done to observe their effects on the thermal performance of the solar air heater. The double-pass collector was constructed with a bed height of 0.05 m, and a collection area of 1.5 m². The height of the upper channel was fixed at 0.015 m to improve the thermal efficiency, and the outlet temperature at air flow rates between 0.003 and 0.018 kg/s. The collector was mounted with a slope of 42° facing south, to maximize the intensity of solar irradiance during winter. The effects of the air flow rate, ambient temperature, inlet temperature, outlet temperature, and solar intensity were experimentally investigated. The results showed that thermal efficiency could be improved by increasing the air flow rate, where the highest thermal efficiency achieved was 86% at 0.018 kg/s. However, the temperature difference was increased to a maximum value of 38.6 °C, when the air flow rate was decreased to 0.003 kg/s. Furthermore, the results demonstrated a significant improvement in the thermal efficiency and outlet temperature; and when compared with previous research, the experimental results and the predictions for the outlet temperature using the theoretical model agreed. Full article

The device performance of recycling double-pass solar air heaters with W-ribs by machining on both sides of the absorber plate is investigated experimentally and theoretically. It is emphasized that in comparing various design configurations, they should be compared for the increase of power consumption suffered by the air passing through the collector under the same air mass flow rate and working dimensions. Compared to those of the single-pass and flat-plate double-pass device, both effects of the external recycle and the artificial W-ribs by machining enhance the collector thermal efficiency in this study. This study proposes an optimal design of the recycling W-ribs double-pass device that is expected to consider the compensation between collector thermal efficiency improvement $I_W$ due to the external recycle and the increase of power consumption $I_{P,W}$ owing to pumping the air circulation in the two divided subchannels. The evaluation of a higher ratio of $I_W$ to $I_{P,W}$ leads to economic benefits. It has been observed that a relative higher ratio of collector thermal efficiency improvement to the increase of power consumption occurs at recycle ratio R = 0.5. The results indicated the turbulent intensity increment with the artificial W-ribs by machining on both sides of the absorber plate could compensate for the increase of power consumption with the consideration of economic feasibility. The operation of a recycling W-ribs solar air heater with two covers in a double-pass mode offers an inexpensive method of improving the collector thermal efficiency by about 76.65%. The advantage of the present device is evident and provides a feasible design to improve the solar air heater of which the promotion in turbulence effectively raises the convective heat-transfer coefficient. The collector thermal efficiency enhancement of the double-pass operation is much higher than that in the smooth plate under different recycle ratios and mass flow rates. Full article

In this study, a typical Grey–Taguchi method has been applied in order to select the optimal configuration of a solar air heater to achieve optimum performance. The analysis is performed for different system configurations in terms of collector type, mass flow rate, and cover type. The Grey–Taguchi method, which requires the minimum possible numbers of the demanded experiments for accomplishing a robust statistical decision for a given experimental problem, has been employed, and temperature difference and thermal performance have been used as the two main criteria. It is found that by considering the temperature difference criterion, at a mass flow rate of 0.011 kg/s, the best configuration is the double-pass solar collector owning a one-fourth pierced Plexiglas cover with a distance of 60 mm between the centers of the holes. On the other hand, by considering the thermal performance as the criterion, the best configuration at a mass flow rate of 0.032 kg/s is found to be the double-pass solar collector holding a half-pierced Plexiglas cover and a distance of 60 mm distance between the centers of the holes. Finally, once both factors are taken into consideration, the optimal configuration suggested by the method is the double-pass collector with a one-quarter pierced Plexiglas cover. The method also suggests keeping a 30 mm distance between the centers of the holes and applying 0.032 kg/s of the mass flow rate to achieve the highest performance. Full article

The device performance of cross-corrugated double-pass solar air heaters under external recycle conditions was investigated experimentally and theoretically, and solved numerically using the Newton method. Comparisons were made and represented graphically among three different configurations of the single-pass, flat-plate double-pass and cross-corrugated double-pass devices. Air flowing simultaneously over the wavelike corrugated absorbing plate and in-between both wavelike cross-corrugated absorbing and transverse bottom plates was conducted under double-pass operations. A considerable heat-transfer efficiency enhancement is obtained employing such a recycling double pass device with welding cross-corrugated absorbing plates, instead of using the flat-plate device. An effective thermal performance was achieved because the heat transfer area is doubled and the turbulent intensity is enhanced as well. The power consumption increment owing to the reduction in the cross-sectional area was taken into account associated with the heat-transfer efficiency enhancement for comparisons in determining the optimal design on an economic consideration for the recycling cross-corrugated double-pass device. Full article

Among solar thermal technologies for indoor heating, solar air heaters (SAH) are appealing for implementation on existing buildings due to their simplicity, fewer risks related to the working fluid, and possible independence from the building structure. However, existing research work mainly focuses on winter use and still fails in providing effective solutions for yearly operation, which would enhance their interest. With the aim of analysing an alternative summer use, this work firstly characterises a double channel-single pass solar air collector through experimentation. From the obtained results, modelling and simulation tasks have been conducted to evaluate the possibilities of using hot air, provided by the SAH, while operating under summer conditions within a closed loop, to feed an air-to-water heat exchanger for domestic hot water (DHW) production. The system is studied through simulation under two different configurations for a case study in Valladolid (Spain), during the period from May to September for different airflows in the closed loop. Results show that daily savings can vary from 27% to 85% among the different operating conditions; a configuration where make-up water is fed to the heat exchanger being preferable, with a dedicated water tank for the solar heated water storage of the minimum possible volume. The more favourable results for the harshest months highlight the interest of extending the use of the solar air heaters to the summer period. Full article

The influence of recycling on double-pass solar air collectors with welding of the V-corrugated absorber has been studied experimentally and theoretically. Welding the V-corrugated absorber and the recycle-effect concept to the solar air collector was proposed to strengthen the convective heat-transfer coefficient due to turbulence promotion. Both the recycle effect and the V-corrugated absorber can effectively enhance the heat transfer efficiency compared to various designs such as single-pass, flat-plate double-pass, and double-pass wire mesh packed devices. Recycling operations and welding the V-corrugated absorber could enhance the collector efficiency by increasing the recycle ratio, incident solar radiations, and air mass flow rates. The most efficient and economical operating conditions were found at R ≈ 0.5, with relatively small hydraulic dissipated energy compensation. It was found that the turbulence intensity increase from welding the V-corrugated absorber into the solar air collector channel could compensate for the power consumption increase, when considering economic feasibility. Full article

The improvement of device performance of a recycling solar air heater featuring a wire mesh packing was investigated experimentally and theoretically. The application of the wire mesh packing and recycle-effect concept to the present study were proposed aiming to strengthen the convective heat-transfer coefficient due to increased turbulence. Comparisons were made among different designs, including the single-pass, flat-plate double-pass and recycling double-pass wire mesh packed operations. The collector efficiency of the recycling double-pass wire mesh packed solar air heater was much higher than that of the other configurations for various recycle ratios and mass flow rates scenarios. The power consumption increment due to implementing wire mesh in solar air heaters was also discussed considering the economic feasibility. A fairly good agreement between theoretical predictions and experimental measurements was achieved with an analyzed error of 1.07%–9.32%. Full article
