Coal mines play an important role in the global energy supply. Monitoring the displacement of open-pit mines is crucial to preventing geological disasters, such as landslides and surface displacement, caused by high-intensity mining activities. In recent years, multi-temporal Synthetic Aperture Radar Interferometry (InSAR) technology has advanced and become widely used for monitoring the displacement of open-pit mines. However, the scattering characteristics of surfaces in open-pit mining areas are unstable, resulting in few coherence points with uneven distribution. Small BAseline Subset InSAR (SABS-InSAR) technology struggles to extract high-density points and fails to capture the overall displacement trend of the monitoring area. To address these challenges, this study focused on the Shengli West No. 2 open-pit coal mine in eastern Inner Mongolia, China, using 201 Sentinel-1 images collected from 20 May 2017 to 13 April 2024. We applied both SBAS-InSAR and distributed scatterer InSAR (DS-InSAR) methods to investigate the surface displacement and long-term behavior of the open-pit coal mine over the past seven years. The relationship between this displacement and mining activities was analyzed. The results indicate significant land subsidence was observed in reclaimed areas, with rates exceeding 281.2 mm/y. The compaction process of waste materials was the main contributor to land subsidence. Land uplift or horizontal displacement was observed over the areas near the active working parts of the mines. Compared to SBAS-InSAR, DS-InSAR was shown to more effectively capture the spatiotemporal distribution of surface displacement in open-pit coal mines, offering more intuitive, comprehensive, and high-precision monitoring of open-pit coal mines. Full article

Interferometric Synthetic Aperture Radar (InSAR) is an invaluable tool for deformation monitoring. However, potential geological disaster hazards occurring in different elevation regions exhibit distinct surface deformation trends and distributions. The applicability of InSAR techniques at different elevations for monitoring potential geohazards remains uncertain. In this paper, the study area is firstly divided into typical geological disaster hazard zones based on mountainous elevation definition and SAR image elevation distribution, including areas below 1000 m, between 1000 m and 3500 m, and above 3500 m. Secondly, the spatial–temporal evolution characteristics of surface deformation from 2018 to 2020 in the study area are investigated, and potential geohazards are monitored by employing time-series InSAR techniques such as Persistent Scatterer InSAR (PS-InSAR), Small Baseline Subset InSAR (SBAS-InSAR), and Distributed Scatterer InSAR (DS-InSAR). Finally, the potential geological hazards detected by different InSAR monitoring algorithms are interpreted, and the characteristics of different InSAR monitoring algorithms in different elevation intervals are compared and analyzed. The results show that potential geological hazards are more frequent in areas between 1000 m and 3500 m in elevation, and DS-InSAR shows the best performance and accuracy in monitoring potential geological hazards in different elevation intervals. Full article

In this work, three carboxymethyl starches (CMS) were obtained by the two-step reaction process of carboxymethylation with different degrees of substitution (0.16, 0.33, and 0.36). From these samples, (bio)polyelectrolyte complexes ((bio)PECs) were obtained with chitosan (Chit) by the mixing of individual solutions of polymers (0.25 wt.%) at different volume ratios. The effect of the biopolymer and ionized groups of z ratios, pH, and degree of substitution of CMS in the formation of PEC were evaluated by turbidimetry and dynamic light scattering. The results showed that increasing the amount of CMS samples (ratio of z) led to an increase in the efficiency of the formation of (bio)PEC using CMS with a high DS value. Using the turbidimetry method for the chitosan and CMS mixtures, it was observed that the formation of (bio)PEC is divided into four transition zones delimited by pH transition points, and the stoichiometric complexation (z = 1) is achieved at a pH that displayed morphological changes “pH_morph”, which is a single point for Chit:CMS 1, and for Chit:CMS 2 and Chit:CMS 3, this is a range of 4.9–6.4 and 4.3–6.4, respectively. Analysis of the structural properties of the structures of (bio)PECs by dynamic light scattering was characterized by monomodal distribution, and the main observed effect was associated with an increase in the value of D_avg with an increase in the ratio of Chit:CMS. Full article

The Fucheng-1 (FC-1) satellite has successfully transitioned from its initial operational phase and is now undergoing a detailed performance assessment for time-series deformation monitoring. This study evaluates the surface deformation monitoring capabilities of the newly launched FC-1 satellite using the interferometric synthetic aperture radar (InSAR) technique, particularly in urban applications. By analyzing the observation data from 20 FC-1 scenes and 20 Sentinel-1 scenes, deformation velocity maps of a university in Mianyang city were obtained using persistent scatterer interferometry (PSI) and distributed scatterer interferometry (DSI) techniques. The results show that thanks to the high resolution of 3 × 3 m of the FC-1 satellite, significantly more PS points and DS points were detected than those detected by Sentinel-1, by 13.4 times and 17.9 times, respectively. The distribution of the major deformation areas detected by both satellites in the velocity maps is generally consistent. FC-1 performs better than Sentinel-1 in monitoring densely structured and vegetation-covered areas. Its deformation monitoring capability at the millimeter level was further validated through comparison with leveling measurements, with average errors and root mean square errors of 1.761 mm and 2.172 mm, respectively. Its high-resolution and high-precision interferometry capabilities make it particularly promising in the commercial remote sensing market. Full article

The detection of potential rural mountain landslide displacements using time-series interferometric Synthetic Aperture Radar has been challenged by both atmospheric phase screens and decoherence noise. In this study, we propose the use of a combined distributed scatterer (DS) and the Prophet_ZTD-NEF model to rapidly map the landslide surface displacements in Diqing Tibetan Autonomous Prefecture, China. We conducted tests on 28 full-resolution SENTINEL-1A images to validate the effectiveness of our methods. The conclusions are as follows: (1) Under the same sample conditions, confidence interval estimation demonstrated higher performance in identifying SHPs compared to generalized likelihood ratio test. The density of DS points was approximately eight times and five times higher than persistent scatterer interferometry and small baseline subset methods, respectively. (2) The proposed Prophet_ZTD-NEF model considers the spatial and temporal variability properties of tropospheric delays, and the root mean square error of measured values was approximately 1.19 cm instead of 1.58 cm (PZTD-NEF). (3) The proposed Prophet_ZTD-NEF method reduced the mean standard deviation of the corrected interferograms from 1.88 to 1.62 cm and improved the accuracy of the deformation velocity solution by approximately 8.27% compared to Global Position System (GPS) measurements. Finally, we summarized the driving factors contributing to landslide instability. Full article

Landslides have become a common global concern because of their widespread nature and destructive power. The Gaizi Valley section of the Karakorum Highway is located in an alpine mountainous area with a high degree of geological structure development, steep terrain, and severe regional soil erosion, and landslide disasters occur frequently along this section, which severely affects the smooth flow of traffic through the China-Pakistan Economic Corridor (CPEC). In this study, 118 views of Sentinel-1 ascending- and descending-orbit data of this highway section are collected, and two time-series interferometric synthetic aperture radar (TS-InSAR) methods, distributed scatter InSAR (DS-InSAR) and small baseline subset InSAR (SBAS-InSAR), are used to jointly determine the surface deformation in this section and identify unstable slopes from 2021 to 2023. Combining these data with data on sites of historical landslide hazards in this section from 1970 to 2020, we constructed 13 disaster-inducing factors affecting the occurrence of landslides as evaluation indices of susceptibility, carried out an evaluation of regional landslide susceptibility, and identified high-susceptibility unstable slopes (i.e., potential landslides). The results show that DS-InSAR and SBAS-InSAR have good agreement in terms of deformation distribution and deformation magnitude and that compared with single-orbit data, double-track SAR data can better identify unstable slopes in steep mountainous areas, providing a spatial advantage. The landslide susceptibility results show that the area under the curve (AUC) value of the artificial neural network (ANN) model (0.987) is larger than that of the logistic regression (LR) model (0.883) and that the ANN model has a higher classification accuracy than the LR model. A total of 116 unstable slopes were identified in the study, 14 of which were determined to be potential landslides after the landslide susceptibility results were combined with optical images and field surveys. These 14 potential landslides were mapped in detail, and the effects of regional natural disturbances (e.g., snowmelt) and anthropogenic disturbances (e.g., mining projects) on the identification of potential landslides using only SAR data were assessed. The results of this research can be directly applied to landslide hazard mitigation and prevention in the Gaizi Valley section of the Karakorum Highway. In addition, our proposed method can also be used to map potential landslides in other areas with the same complex topography and harsh environment. Full article

Land cover classification of Synthetic Aperture Radar (SAR) imagery is a significant research direction in SAR image interpretation. However, due to the unique imaging methodology of SAR, interpreting SAR images presents numerous challenges, and land cover classification using SAR imagery often lacks innovative features. Distributed scatterers interferometric synthetic aperture radar (DS-InSAR), a common technique for deformation extraction, generates several intermediate parameters during its processing, which have a close relationship with land features. Therefore, this paper utilizes the coherence matrix, the number of statistically homogeneous pixels (SHPs), and ensemble coherence, which are involved in DS-InSAR as classification features, combined with the backscatter intensity of multi-temporal SAR imagery, to explore the impact of these features on the discernibility of land objects in SAR images. The results indicate that the adopted features improve the accuracy of land cover classification. SHPs and ensemble coherence demonstrate significant importance in distinguishing land features, proving that these proposed features can serve as new attributes for land cover classification in SAR imagery. Full article

Beijing, China’s capital city, has experienced decades of severe land subsidence due to the long-term overexploitation of groundwater. The implementation of the South-to-North Water Diversion Project (SNWDP) and artificial ecological restoration have significantly changed Beijing’s hydro-ecological and geological environment in recent years, leading to a widespread rise in groundwater levels. However, whether the related land subsidence has slowed down or reversed under these measures has not yet been effectively monitored and quantitatively analyzed in terms of time and space. Accordingly, in this study, we proposed using an improved time-series deformation method, which combines persistent scatterers and distributed scatterers, to process Sentinel-1 images from 2015 to 2022 in the Beijing Plain region. We performed a geospatial analysis to gain a better understanding of how the new hydrological conditions changed the pattern of deformation on the Beijing Plain. The results indicated that our combined PS and DS method provided more measurements both in total quantity and spatial density than conventional PSI methods. The land subsidence in the Beijing Plain area has been effectively alleviated from a subsidence region of approximately 1377 km² in 2015 to only approximately 78 km² in 2022. Ecological restoration areas in the northeastern part of the Plain have even rebounded over this period, at a maximum of approximately 40 mm in 2022. The overall pattern of ground deformation (subsidence and uplift) is negatively correlated with changes in the groundwater table (decline and rise). Local deformation is controlled by the thickness of the compressible layer and an active fault. The year 2015, when anthropogenic water transfers were eliminated and ecological measures to recharge groundwater were implemented, was the crucial turning point of the change in the deformation trend in the subsidence history of Beijing. Our findings carry significance, not only for China, but also for other areas where large-scale groundwater extractions are causing severe ground subsidence or rebound. Full article

As urban economies flourish and populations become increasingly concentrated, urban surface deformation has emerged as a critical factor in city planning that cannot be overlooked. Surface deformation in urban areas can lead to deformations in structural supports of infrastructure such as road bases and bridges, thereby posing a serious threat to public safety and creating significant safety hazards. Consequently, research focusing on the monitoring of urban surface deformation holds paramount importance. Interferometric synthetic aperture radar (InSAR), as an important means of earth observation, has all-day, wide-range, high-precision, etc., characteristics and is widely used in the field of surface deformation monitoring. However, traditional solitary InSAR techniques are limited in their application scenarios and computational characteristics. Additionally, the manual selection of ground control points (GCPs) is fraught with errors and uncertainties. Permanent scatterers (PS) can maintain high interferometric coherence in man-made building areas, and distributed scatterers (DS) usually show moderate coherence in areas with short vegetation; the combination of DS and PS solves the problem of manually selecting GCPs during track re-flattening and regrading, which affects the monitoring results. In this paper, 45 Sentinel-1B data from 16 February 2019 to 14 December 2021 are used as the data source in the urban area of Horqin District, Tongliao City, Inner Mongolia Autonomous Region, for example. A four-threshold (coherence coefficient threshold, FaSHPS adaptive threshold, amplitude divergence index threshold, and deformation velocity interval) GCPs point screening method for PS-DS, as well as a Small Baseline Subset-Permanent Scatterers-Distributed Scatterers-Interferometric Synthetic Aperture Radar (SBAS-PS-DS-InSAR) method for selecting PS and DS points as ground control points for orbit refinement and re-flattening, are proposed. The surface deformation results obtained using the Small Baseline Subset Interferometric Synthetic Aperture Radar (SBAS-InSAR) and the SBAS-PS-DS-InSAR proposed in this paper were comparatively analysed and verified. The maximum cumulative line-of-sight settlements were −90.78 mm and −83.68 mm, and the maximum cumulative uplifts are 74.94 mm and 97.56 mm, respectively; the maximum annual average line-of-sight settlements are −35.38 mm/y and −30.38 mm/y, and the maximum annual average uplifts are 25.27 mm/y and 27.92 mm/y. The results were evaluated and analysed in terms of correlation, mean absolute error (MAE), and root mean square error (RMSE). The deformation results of the two InSAR methods were evaluated and analysed in terms of correlation, MAE, and RMSE. The errors show that the Pearson correlation coefficients between the vertical settlement results obtained using the SBAS-PS-DS-InSAR method and the GPS monitoring results were closer to 1. The maximum MAE and RMSE were 13.7625 mm and 14.8004 mm, respectively, which are within the acceptable range; this confirms that the monitoring results of the SBAS-PS-DS-InSAR method were better than those of the original SBAS-InSAR method. SBAS-InSAR method, which is valid and reliable. The results show that the surface deformation results obtained using the SBAS-InSAR, SBAS-PS-DS-InSAR, and GPS methods have basically the same settlement locations, extents, distributions, and temporal and spatial settlement patterns. The deformation results obtained using these two InSAR methods correlate well with the GPS monitoring results, and the MAE and RMSE are within acceptable limits. By comparing the deformation information obtained using multiple methods, the surface deformation in urban areas can be better monitored and analysed, and it can also provide scientific references for urban municipal planning and disaster warning. Full article

Protein aggregation is linked to many chronic and devastating neurodegenerative human diseases and is strongly associated with aging. This work demonstrates that protein aggregation and oligomerization can be evaluated by a solid-state nanopore method at the single molecule level. A silicon nitride nanopore sensor was used to characterize both the amyloidogenic and native-state oligomerization of a model protein ß-lactoglobulin variant A (βLGa). The findings from the nanopore measurements are validated against atomic force microscopy (AFM) and dynamic light scattering (DLS) data, comparing βLGa aggregation from the same samples at various stages. By calibrating with linear and circular dsDNA, this study estimates the amyloid fibrils’ length and diameter, the quantity of the βLGa aggregates, and their distribution. The nanopore results align with the DLS and AFM data and offer additional insight at the level of individual protein molecular assemblies. As a further demonstration of the nanopore technique, βLGa self-association and aggregation at pH 4.6 as a function of temperature were measured at high (2 M KCl) and low (0.1 M KCl) ionic strength. This research highlights the advantages and limitations of using solid-state nanopore methods for analyzing protein aggregation. Full article

Frequent mining activities create a series of geological and environmental problems resulting in an immeasurable loss of life and property. Adopting effective technologies that monitor the surface subsidence of mining areas reliably and accurately is necessary. Targeting problems associated with conventional distributed scatterers interferometric synthetic aperture radar (DS-InSAR) technology, we propose a DS-InSAR technology integrating unmanned aerial vehicle (UAV) photogrammetry products divided into two key technical contents: generating an external reference digital elevation model (DEM) fused with UAV DEM and refining distributed scatterers candidates (DSCs) fused with an UAV digital orthophoto map (DOM). We selected two mining areas, one in Wu’an, Hebei, and the other in Inner Mongolia, with different surface cover types, mining depths, and topographies as the research area. We used Sentinel-1A SAR images covering a mine in Wu’an from 4 November 2018 to 4 March 2019 and a mining area in Inner Mongolia from 11 June 2018 to 21 October 2018 to compare and analyze the subsidence results. We also combined these results with data from their respective field observation stations to assess accuracy. We could apply DS-InSAR technology integrated with UAV photogrammetry products to the subsidence monitoring of two mining areas with different landforms and mining characteristics. Comparing with the leveling and total station, the experimental results show that the RMSE was reduced by about 2 mm in both mining areas, and accuracy for the Wu’an region improved to a higher degree than Inner Mongolia did. Furthermore, the refinement method of DS eliminated 965 and 2948 lower-quality DSCs in the two mining areas. These demonstrate that our proposed method can effectively improve the accuracy and reliability of subsidence results from two mining areas. Full article

During the interferometric synthetic aperture radar (InSAR)-based ground displacement monitoring in mining areas, the overlying land is mainly covered by low vegetation and arable land, which makes interferograms acquired by InSAR techniques easily susceptible to decorrelation, resulting in the quantity and density of highly coherent points (CPs) are not enough to reflect the spatial location and spatio-temporal evolution process of ground displacement, which is hardly meeting requirements of high-precision ground displacement monitoring. In this study, we developed an approach for monitoring ground displacement in mining areas by integrating Persistent Scatterer (PS), Slowly Decoherent Filtering Phase (SDF), and Distributed Scatterer (DS) based on signal-to-noise ratio (SNR) to increase the spatial density of CPs. A case study based on a mining area in Heze was carried out to verify the reliability and feasibility of the proposed method in practical applications. Results showed that there were four significant displacement areas in the study area and the quantity of CPs acquired by the proposed method was maximum 6.7 times that of conventional PS-InSAR technique and maximum 2.3 times that of SBAS-InSAR technique. The density of CPs acquired by the proposed method increased significantly. The acquired ground displacement information of the study area was presented in more detail. Moreover, the monitoring results were highly consistent with ground displacement results extracted by PS-InSAR and SBAS-InSAR methods in terms of displacement trends and magnitudes. Full article

Statistically homogeneous pixel (SHP) selection is an important process in the distributed scatterer interferometric synthetic aperture radar (DS-InSAR) approach. However, prevalent methods struggle to appropriately balance the efficiency and accuracy of selection. To solve this problem, the authors of this study improved the Hypothesis Test of Confidence Interval (HTCI) to propose an adaptive method to select the level of saliency and confidence interval for the HTCI, called Adp-HTCI. The proposed method can accurately select homogeneous pixels while inheriting the high efficiency of the HTCI. Once homogeneous pixels have been chosen, the eigenvalue decomposition of the covariance matrix is used to optimize their phase and perform temporal processing. We used the proposed method along with data on 31 scenes from the Sentinel-1 satellite from 2 June 2021 to 28 May 2022 to monitor the deformation of the surface of the fire zone in the Sikeshu coalfield. The selection results of homogeneous pixels indicate that the proposed Adp-HTCI algorithm can increase the number of selected homogeneous pixels while ensuring the accuracy of the selection results, thereby enhancing the estimation accuracy and reliability of subsequent parameter solving. The DS-InSAR results showed that the cumulative maximum subsidence in the study area within a year reached—138 mm and the point density used by the DS-InSAR approach was 17.28 times higher than that used by the StaMPS approach. The results of cross-analysis with the results of StaMPS verified the accuracy of the DS-InSAR-based approach. Full article

Health monitoring is important for densely distributed urban infrastructures, particularly in cities undergoing rapid economic progress. Permanent scatterer interferometry (PSI) is an advanced remote sensing observation technique that is commonly used in urban infrastructure monitoring. However, the rapid construction of infrastructures may easily cause a loss of coherence for radar interferometry, inducing a low density of effective permanent scatterer (PS) points, which is the main limitation of PSI. In order to address these problems, a novel time-series synthetic aperture radar interferometry (InSAR) process based on the adaptive window homogeneous pixel selection and phase optimization (AWHPSPO) algorithm and thermal expansion linear model (TELM) is proposed. Firstly, for homogeneous point selection, information on both the time-series intensity and deformation phases is considered, which can compensate for the defects of insufficient homogeneous samples and low phase quality in traditional distributed scatterer interferometric synthetic aperture radar (DS-InSAR) processing. Secondly, the physical, thermal expansion component, which reflects the material properties of the infrastructures, is introduced into the traditional linear model, which can more rationally reflect the temporal evolution of deformation variation, and the thermal expansion coefficients can be estimated simultaneously with the deformation parameters. In order to verify our proposed algorithm, the Orange Island area in Changsha City, China, was selected as the study area in this experiment. Three years of its historical time-series deformation fields and thermal expansion coefficients were regenerated. With the use of high-resolution TerraSAR-X radar satellite images, a maximum accumulated settlement of 12.3 mm and a minor uplift of 8.2 mm were detected. Crossvalidation with small baseline subset interferometric synthetic aperture radar (SBAS-InSAR) results using Sentinel 1A data proved the reliability of AWHPSPO. The proposed algorithm can provide a reference for the control of the health and safety of urban infrastructures. Full article

The Sichuan–Tibet Railway (STR) is currently under construction and serves as an important transportation route in western China. Identifying potential geohazards along the route is important for project construction. However, research on the frozen soil of the Western Sichuan Plateau, and on frozen soil identification using interferometric synthetic aperture radar (InSAR) is relatively negligible. As a low-cost, all-weather spatial geodesy tool, InSAR is frequently used for geohazard identification. We selected a study area located along the Litang section of the STR, starting from Litang County in the east and extending 60 km to the west. The geological conditions along the line are complex, with numerous fault zones and hidden danger points for landslide. To identify unstable slopes along the line, distribute scatterer InSAR (DS-InSAR) was used to obtain surface displacement information from 2018 to 2021. Based on the displacement information obtained from the ascending and descending orbit images from Sentinel-1, a spatial density clustering method identified 377 and 388 unstable slopes in the study area, respectively, of these, 132 were consistent. The identified unstable slopes were mostly located in areas with a relatively high altitude and moderate slope. The Luanshibao landslide, which is a typical landslide in the study area, had notable signs of displacement, where the displacement rate along the back edge of the landslide can reach 20 mm/a. An inversion method for the seasonal frozen soil area distribution was proposed based on the periodic subsidence and uplift model and time-series monitoring data; the calculated seasonal freeze–thaw amplitude exceeded 20 mm. Further analysis revealed a 2-month lag in the response of the freeze–thaw phenomenon to the air temperature. This study demonstrated that DS-InSAR offers optimal surface displacement data, which can provide an important basis to identify engineering geological hazards. Full article
