This study investigates the deformation and fracture mechanisms of a Ti₆₁Al₁₆Cr₁₀Nb₈V₅ multi-principal element alloy (Ti61V5 alloy) under quasi-static and dynamic compression. The alloy comprises an equiaxed BCC matrix (~35 μm) with uniformly dispersed nano-sized B2 precipitates and a ~3.5% HCP phase along grain boundaries, exhibiting a density of 4.82 g/cm³, an ultimate tensile strength of 1260 MPa, 12.8% elongation, and a specific strength of 262 MPa·cm³/g. The Ti61V5 alloy exhibits a pronounced strain-rate-strengthening effect, with a strain rate sensitivity coefficient (m) of ~0.0088 at 0.001–10/s. Deformation activates abundant {011} and {112} slip bands in the BCC matrix, whose interactions generate jogs, dislocation dipoles, and loops, evolving into high-density forest dislocations and promoting screw-dominated mixed dislocations. The B2 phase strengthens the alloy via dislocation shearing, forming dislocation arrays, while the HCP phase enhances strength through a dislocation bypass mechanism. At higher strain rates (960–5020/s), m increases to ~0.0985. Besides {011} and {112}, the BCC matrix activates high-index slip planes {123}. Intensified slip band interactions generate dense jogs and forest dislocations, while planar dislocations combined with edge dislocation climb enable obstacle bypassing, increasing the fraction of edge-dominated mixed dislocations. The Ti61V5 alloy shows low sensitivity to adiabatic shear localization. Under forced shear, plastic-flow shear bands form first, followed by recrystallized shear bands formed through a rotational dynamic recrystallization mechanism. Microcracks initiate throughout the shear bands; during inward propagation, they may terminate upon encountering matrix microvoids or deflect and continue when linking with internal microcracks. Full article

Cyclic straining simulations using incompatibility-incorporated crystal plasticity-FEM, which exhibit PSB ladder structure evolutions as detailed in Part I, are coupled with diffusion analyses of produced vacancies. A new vacancy source model is introduced based on the Field Theory of Multiscale Plasticity (FTMP), interpreting the relationship between the incompatibility rate and the flux of dislocation density as edge dipole annihilation processes. Both direct and indirect coupling diffusion analyses, with and without cyclic straining, demonstrate that varying incompatibility rates tend to further promote vacancy diffusion, leading to surface grooving, enhanced extension rates, and eventual transition to cracks. The findings reveal that (i) the evolved PSB ladder structure serves as a site for vacancy formation, (ii) it provides a diffusion path toward the specimen surface, and (iii) it significantly enhances groove extension rates. These factors effectively facilitate the transition from a “groove” to a “crack”, evidenced by the abrupt acceleration of the extension rate, mirroring systematic experimental observations. These achievements validate the FTMP’s capability to simulate complex phenomena and significantly deepen our understanding of slip band–fatigue crack transition mechanisms. Full article

In this study, Al-Al₄C₃ compounds were manufactured by mechanical milling followed by heat treatment. To analyze the microstructural evolution, the composites were sintered at 550 °C at different sintering times of 2, 4 and 6 h. The mechanical results suggest that dislocation density and crystallite size primarily contribute to hardening before the sintering process, with a minimal contribution from particle dispersion in this condition. The compound exhibited a significant 75% increase in hardness after 2 h of sintering, primarily attributed to the nucleation and growth of Al₄C₃ nanorods. The HRTEM analysis, combined with geometric phase analysis (GPA) at and near the Al-Al₄C₃ interface of the nanorods, revealed strain field distributions primarily associated with partial screw dislocations and the presence of closely spaced dislocation dipoles. These findings are consistent with the microstructural parameters determined from X-ray diffraction pattern analysis using the convolutional multiple whole profile (CMWP) method. This analysis showed that the predominant dislocation character is primarily of the screw type, with the dislocation dipoles being closely correlated. Based on these results, it is suggested that samples with a lower weight percentage of reinforcement and longer sintering times may experience reduced brittleness in Al/Al₄C₃ composites. Strengthening contributions were calculated using the Langford–Cohen and Taylor equations. Full article

In this paper, the deformation behavior of UNS S32750 (S32750) duplex stainless steel during low cycle fatigue was studied by controlling the number of cycles. The microstructure of the specimens under different cycles was characterized by optical microscope (OM), scanning electron microscope (SEM), electron backscatter diffraction (EBSD), and transmission electron microscope (TEM). The microhardness of the two phases was measured by a digital microhardness instrument. The results showed that the microhardness of ferrite increases significantly after the first 4000 cycles, while the austenite shows a higher strain hardening rate after fatigue fracture, and the microhardness of ferrite and austenite increases by 23 HV and 87 HV, respectively. The two-phase kernel average misorientation (KAM) diagram showed that the continuous accumulation of plastic deformation easily leads to the initiation of cracks inside the austenite and at the phase boundaries. The evolution of dislocation morphology in the two phases was obviously different. With the increase in cycle number, the dislocation in ferrite gradually transforms from dislocation bundles and a dislocation array to a sub-grain structure, while the dislocation in austenite gradually develops from dipole array to an ordered Taylor lattice network structure. Full article

Edge dislocations are crucial in understanding both mechanical and electrical transport in solid and are modeled as line distributions of dipole moments. The calculation of the electronic spectrum for the two dimensional dipole, represented by the potential energy $V(r,\theta )=pcos\theta /r$, has been the topic of several studies that show significant difficulties in obtaining accurate results. In this work, we demonstrate that the source of these difficulties is a logarithmic contribution to the behavior of the wave function at the origin that was neglected by previous authors. By taking into account this non-analytic deviation of the solution of Schrödinger’s equation, superior results, with the expected rate of convergence, are obtained. This goal is accomplished by “adapting” general algorithms for solving partial derivative differential equations to include the desired asymptotic behavior. We illustrate this principle for the variational principle and finite difference methods. Accurate energies and wave functions are obtained not only for the ground state but also for the first eleven excited states and are useful for designing nanoelectronic devices. This paper demonstrates that augmentary knowledge about analytic properties of the solutions leads to the improved convergence and stability of numerical methods. Full article

There are some limitations when conventional ultrasonic testing methods are used for testing early damage in metal parts. With the continuous development of acoustics and materials science, nonlinear ultrasonic nondestructive testing technology has been used for testing of early damage in metal materials. In order to better understand the basic theory and research progress of the nonlinear ultrasonic testing technology, the classical nonlinear ultrasonic theoretical models, including the dislocation monopole model, dislocation dipole model, precipitate-dislocation pinning model, and contact nonlinear ultrasonic theory-microcrack model, are analyzed in depth. This paper introduces the application and research progress of nonlinear ultrasonic detection technology, which is derived from different acoustic nonlinear effects, such as higher harmonic, wave mixing and modulation, sub-harmonic, resonance frequency spectrum analysis, and non-linear ultrasonic phased array imaging. The key technologies and problems are summarized to provide a reference for the further development and promotion of nonlinear ultrasonic non-destructive testing technology. Full article

This research paper studies the fracture and mechanical properties of rippled graphene containing dislocation dipoles. The atomistic simulation is performed to study the deformation behavior of pristine and defective wrinkled graphene. Graphene wrinkling considerably decreases the ultimate tensile strength of graphene with and without defects but increases the fracture strain. For graphene with the dislocation dipoles, temperature increase slightly affects mechanical properties, in contrast to graphene and graphene with Stone–Wales defect. The extremely similar slopes of the stress-strain curves for graphene with the dislocation dipoles with different arms imply that the distance between dislocations in the dipole does not have noticeable effects on the elastic modulus and strength of graphene. Defects in graphene can also affect its wrinkling; for example, preventing wrinkle formation. Full article

The thermodynamic response of dislocation intersections with forest dislocations and other deformation products is recorded using the Eyring rate relation wherein the application of shear stress increases the probability of activation at a given strain rate and temperature. The inverse activation volume, 1/ν, can be directly determined by instantaneous strain-rate change and its dependence on flow stress, τ, defines the strain-rate sensitivity, S, through the Haasen plot slope. A linear slope over a large strain interval is observed even for a heterogeneous distribution of obstacles that could be of more than one type of obstacles encountered by the gliding dislocation. It was deduced that ν and τ at each activation site are coordinated by the internal stress resulting in constant activation work (k/S). The stress changes from down-rate changes become larger than that from up-rate changes due to the formation of weaker obstacles, resulting in a composite S, whereas only forest dislocations are detected by the up-change. The additivity of 1/ν was used to separate obstacle species in specially prepared AA1100 and super-pure aluminum from 78 to 300 K. The deduction that repulsive intersection is the rate-controlling process and creates vacancies at each intersection site depending on temperature was validated by observing the pinning and depinning of dislocations via pipe diffusion above 125 K. A new method to separate S for dislocation-dislocation intersections from the intersections with other obstacles and their temperature dependence is presented and validated. Full article

To investigate the relationship between the dislocation configuration and the grain refinement in the NV E690 cladding layer caused by laser shock peening, NV E690 high-strength steel powder was used to repair prefabricated pits in samples of 690 high-strength steel by laser cladding, where the laser shock peening of the cladding layer was performed by laser shock at different power densities. X-ray diffraction, scanning electron microscopy, and transmission electron microscopy were used to observe the microstructures of these samples before and after the laser shock process. The results showed that the metallurgical bonding between the cladding layer and the substrate after laser cladding repair was good. When the laser power density was 4.77 GW/cm², multiple edge dislocations, dislocation dipoles, and extended dislocations were distributed over the cladding layer. When the laser power density was 7.96 GW/cm², a geometrically necessary dislocation divided the large original grain into two subgrains with different orientations. When the laser power density was 11.15 GW/cm², geometric dislocations divided the entire large grain into fine grains. The grain refinement model of the NV E690 cladding layer, when treated by laser shock peening, can describe the grain refinement process induced by the dislocation movement of this cladding layer. Full article

This paper aims to investigate the influence of thermal aging on a crosslinked polyethylene (XLPE) cable, and the relationships between the macroscopical high-voltage dielectric and the microscopical physicochemical properties are also elucidated. To better simulate thermal aging under working condition, the medium-voltage-level cable is subjected to accelerated inner thermal aging for different aging times. Then, high-voltage frequency domain spectroscopy (FDS) (cable sample) and analyses of microscopic physical and chemical properties (sampling from the cable), including Fourier transform infrared spectroscopy (FTIR), X-ray diffraction (XRD), and elongation at the break (EAB), are conducted at different cable aging stages. The dielectric test results show that after a certain aging time, the high-voltage FDS curves of the cable have layered characteristics, and this phenomenon is more obvious as the aging degree increases. Moreover, the slope and the integral of the high-voltage FDS curves rise with aging time. The mechanism is deduced by the physicochemical results that thermo-oxidative aging results in increasing polar groups and dislocation defects in the crystal region, which leads to the above phenomenon. On the one hand, the appearance of polar groups increases the density of the dipole. On the other hand, the destruction of the crystal region increases the probability and amplitude of dipole reversal. In addition, the breaking of molecular bonds and the increase in the amorphous phase also reduce the rigidity of the XLPE molecular main chain. The above factors lead to obvious delamination and larger dielectric parameters of the thermally aged cable. Finally, according to the experimental results, an on-site diagnosis method of cable insulation thermal aging based on high-voltage FDS is discussed. Full article

This paper presents an overview of the self-heating phenomena and the continuum thermodynamics framework related to the damping and fatigue of metals. The self-heating process under cyclic loading generally undergoes three phases: Phase I with gradually increasing temperature to a stabilized or steady-state in Phase II, followed by Phase III with an accelerated temperature increase until the test sample ruptures. Although energy dissipation and heat generation are all captured by the first law of thermodynamics, the functional form of the heat source(s) with entropy change is not formulated for engineering materials. Experimentally, infrared (IR) thermographic techniques can measure the surface temperature variation during constant-amplitude fatigue testing. The observed relationship between the stabilization temperature or temperature increase rate and the applied stress amplitude is often used to infer the fatigue endurance limit, above which point heat generation from “damage” leads to acceleration of self-heating. The IR thermographic fatigue testing offers a rapid alternative method to assess the material’s fatigue strength. But, the full physical interpretation of the phenomena remains a challenge. On the other hand, the Tanaka-Mura–Wu model is introduced to describe fatigue crack nucleation via accumulation of dislocation dipole pile-up, which provides a class-A prediction (forecast before even happening) for fatigue crack nucleation life in terms of the material’s elastic modulus, Burgers vector, surface energy, and the loading parameter such as cyclic stress/strain range. Then, the release of dislocation dipole pile-up energy to form new crack surfaces is brought into the energy argument. With the inclusion of crack formation energy in the first law of thermodynamics, a unified framework of deformation, damping, fatigue, and self-heating may be established for structural design. Full article

Microscopic phase-field chemomechanics (MPFCM) is employed in the current work to model solute segregation, dislocation-solute interaction, spinodal decomposition, and precipitate formation, at straight dislocations and configurations of these in a model binary solid alloy. In particular, (i) a single static edge dipole, (ii) arrays of static dipoles forming low-angle tilt (edge) and twist (screw) grain boundaries, as well as at (iii) a moving (gliding) edge dipole, are considered. In the first part of the work, MPFCM is formulated for such an alloy. Central here is the MPFCM model for the alloy free energy, which includes chemical, dislocation, and lattice (elastic), contributions. The solute concentration-dependence of the latter due to solute lattice misfit results in a strong elastic influence on the binodal (i.e., coexistence) and spinodal behavior of the alloy. In addition, MPFCM-based modeling of energy storage couples the thermodynamic forces driving (Cottrell and Suzuki) solute segregation, precipitate formation and dislocation glide. As implied by the simulation results for edge dislocation dipoles and their configurations, there is a competition between (i) Cottrell segregation to dislocations resulting in a uniform solute distribution along the line, and (ii) destabilization of this distribution due to low-dimensional spinodal decomposition when the segregated solute content at the line exceeds the spinodal value locally, i.e., at and along the dislocation line. Due to the completely different stress field of the screw dislocation configuration in the twist boundary, the segregated solute distribution is immediately unstable and decomposes into precipitates from the start. Full article

Understanding long range internal stresses (LRIS) may be crucial for elucidating the basis of the Bauschinger effect, plastic deformation in fatigued metals, and plastic deformation in general. Few studies have evaluated LRIS using convergent beam electron diffraction (CBED) in cyclically deformed single crystals oriented in single slip and there are no such studies carried out on cyclically deformed single crystals in multiple slip. In our earlier and recent study, we assessed the LRIS in a cyclically deformed copper single crystal in multiple slip via measuring the maximum dislocation dipole heights. Nearly equal maximum dipole heights in the high dislocation density walls and low dislocation density channels suggested a uniform stress state across the labyrinth microstructure. Here, we evaluate the LRIS by determining the lattice parameter in the channels and walls of the labyrinth dislocation structure using CBED. Findings of this work show that lattice parameters obtained were almost equal near the walls and within the channels. Thus, a homogenous stress state within the heterogeneous dislocation microstructure is again suggested. Although the changes in the lattice parameter in the channels are minimal (less than 10⁻⁴ nm), CBED chi-squared analysis suggests that the difference between the lattice parameter values of the cyclically deformed and unstrained copper are slightly higher in the proximity of the walls in comparison with the channel interior. These values are less than 6.5% of the applied stress. It can be concluded that the dominant characteristics of the Bauschinger effect may need to include the Orowan-Sleeswyk mechanism type of explanation since both the maximum dipole height measurements and the lattice parameter assessment through CBED analysis suggest a homogenous stress state. This work complements our earlier work that determined LRIS based on dipole heights by assessing LRIS through a different methodology, carried out on a cyclically deformed copper single crystal oriented for multiple slip. Full article

We review the mechanical theory of dislocation and disclination density fields and its application to grain boundary modeling. The theory accounts for the incompatibility of the elastic strain and curvature tensors due to the presence of dislocations and disclinations. The free energy density is assumed to be quadratic in elastic strain and curvature and has nonlocal character. The balance of loads in the body is described by higher-order equations using the work-conjugates of the strain and curvature tensors, i.e., the stress and couple-stress tensors. Conservation statements for the translational and rotational discontinuities provide a dynamic framework for dislocation and disclination motion in terms of transport relationships. Plasticity of the body is therefore viewed as being mediated by both dislocation and disclination motion. The driving forces for these motions are identified from the mechanical dissipation, which provides guidelines for the admissible constitutive relations. On this basis, the theory is expressed as a set of partial differential equations where the unknowns are the material displacement and the dislocation and disclination density fields. The theory is applied in cases where rotational defects matter in the structure and deformation of the body, such as grain boundaries in polycrystals and grain boundary-mediated plasticity. Characteristic examples are provided for the grain boundary structure in terms of periodic arrays of disclination dipoles and for grain boundary migration under applied shear. Full article

A novel X-ray diffraction-based method and computer program X-TEX has been developed to determine the microstructure in individual texture components of polycrystalline, textured materials. Two different approaches are presented. In the first one, based on the texture of the specimen, the X-TEX software provides optimized specimen orientations for X-ray diffraction experiments in which diffraction peaks consist of intensity contributions stemming from grain populations of separate texture components in the specimen. Texture-specific diffraction patterns can be created by putting such peaks together from different measurements into an artificial pattern for each texture component. In the second one, the X-TEX software can determine the intensity contributions of different texture components to diffraction peaks measured in a particular sample orientation. According to this, peaks belonging mainly to one of the present texture components are identified and grouped into the same quasi-phase during the evaluation procedure. The X-TEX method was applied and tested on tensile-deformed, textured, commercially pure titanium samples. The patterns were evaluated by the convolutional multiple whole profile (CMWP) procedure of line profile analysis for dislocation densities, dipole character, slip systems and subgrain size for three different texture components of the Ti specimens. Significant differences were found in the microstructure evolution in the two major and the random texture components. The dislocation densities were discussed by the Taylor model of work hardening. Full article
