When wind turbines contribute to system frequency support using virtual synchronous generator (VSG) control, conventional VSG methods often fall short of meeting operational demands, particularly in terms of inertia and frequency support. In this study, considering both the frequency regulation and dynamic performance of VSG, a novel parameter design method that enhances frequency modulation capabilities is proposed in this paper. Initially, VSG control is integrated into the grid-side converter of a direct-drive permanent magnet synchronous generator (D-DPMSG) wind turbine. A small-signal model of the D-DPMSG-VSG active power is then formulated to analyze how the moment of inertia and damping coefficient impact system stability. Subsequently, ensuring that system parameter constraints are met, the key parameters of VSG are adaptively designed to dynamically adjust the system’s frequency and output power during transient responses. Finally, simulation results based on D-DPMSG-VSG in MATLAB/Simulink validated the feasibility, effectiveness, and advantages of the proposed parameter-adaptive VSG control strategy for enhancing the frequency modulation (FM) performance of wind turbines. Full article

At present, most studies use the direct method to analyze the oscillation problem of modern power systems. However, these studies often only simplify the external characteristics of the wind turbine and lack an in-depth understanding of its internal refined energy structure. In this paper, based on the direct-drive permanent magnetic synchronous generator’s detailed model (D-PMSG), combined with the dynamic energy of its port, layers of analysis are performed on the wind turbine’s internal connections, and a detailed model of the energy structure is created. Then, the interaction mechanism of each control link in the wind turbine is analyzed by combining the energy function of the wind turbine with the improved perturbation method. Finally, this paper constructs a sub-synchronous oscillation (SSO) scenario of weak damping and a forcing type and proves the accuracy and effectiveness of the traceability method based on the refined energy of D-PMSG. This traceability method based on refined energy is expected to provide a new solution to the stability problem caused by the integration of new energy. Full article

Ensuring the quality and stability of the electrical grid is of utmost importance during the phase of electrical energy production. As wind energy plays an increasingly significant role in a country’s energy composition, maintaining stability and optimal quality has emerged as a prerequisite for the generated electricity. This article aims to devise a dynamic nonlinear algorithm that can be implemented in the wind energy conversion system (WECS) featuring a direct-drive permanent magnet synchronous generator (PMSG). Notably, the adaptive backstepping control relies on the nonlinear model of the controlled system. It harnesses the principles of the Lyapunov stability theory to regulate various parameters and uphold the overall system’s stability. Employing simulation analysis through the Matlab–Simulink environment, the proposed control strategy is evaluated using a 1.5 MW wind turbine. The results showcase the robust capability of the suggested control algorithm: it effectively maintains the DC bus voltage and produces high-quality electrical energy with a total harmonic distortion (THD) below 0.38%. Moreover, the algorithm demonstrates added resilience. The practical viability of the adaptive control algorithm is validated through an experimental study on the dSPACE DS1104 prototyping platform. This study underscores the algorithm’s proficiency in achieving all control objectives under diverse wind scenarios. Full article

This paper proposes a model predictive controller (MPC) design based on the optimal tip-speed ratio method for maximum power point tracking (MPPT) of a direct-driven permanent magnet synchronous generator (D-PMSG)-based wind energy conversion system (WECS). To eliminate system nonlinearity and time-varying characteristics, a control variable was added at the wind turbine and the system model was feedback-linearized to create a linear time-invariant system, reducing the computational burden of the MPC and improving system performance. MATLAB/Simulink simulations were performed and the results show that the linearized system has high fidelity. Compared to traditional MPC that use an operating point to linearize the system, it has better adaptability to turbulent wind speeds, improving the stability and rapidity of the system. Full article

The dynamics of wind power generation cannot be neglected in the modern power system and could have a great impact on the system dynamics, even raising the risk of a blackout. Because of this, power system simulation has to include the model of wind power generation. However, due to the high order of the full model of the wind power generator, it is impossible to model them in detail in the use of the power system dynamic simulation considering the thousands of wind generators in the grid. In this context, a simplified model is normally used with the trade-off in lower accuracy. As a direct-drive permanent magnet synchronous wind power generation system (D-PMSG) would take up a certain occupation in the modern power system, a proper D-PMSG simplified model is needed in the power system simulation. For a different research purpose in a different timescale, a different complexity of the model can be used to maximize the accuracy, in the meantime speeding up the simulation. This paper proposes a set of simplified models of the direct-drive permanent magnet synchronous wind power generation system (D-PMSG) and classifies them according to the timescale of the dynamics and the use cases, i.e., faults (transient stability analysis), system contingencies (voltage and frequency stability analysis) and wind speed variations (energy transformation). The accuracy of the proposed simplified models is verified by comparing them with the detailed D-PMSG electromagnetic transient mode in Matlab/Simulink, and their use case of the power system simulation is validated based on the case study of the IEEE 39-bus system considering the above scenarios. Full article

To research the chaotic motion problem of the direct-drive permanent magnet synchronous generator (D-PMSG) for a wind turbine with uncertain parameters and fractional order characteristics, a control strategy established upon fuzzy state feedback is proposed. Firstly, according to the working mechanism of D-PMSG, the Lorenz nonlinear mathematical model is established by affine transformation and time transformation. Secondly, fractional order nonlinear systems (FONSs) are transformed into linear sub-model by Takagi–Sugeno (T-S) fuzzy model. Then, the fuzzy state feedback controller is designed through Parallel Distributed Compensation (PDC) control principle to suppress the chaotic motion. By applying the fractional Lyapunov stability theory (FLST), the sufficient conditions for Mittag–Leffler stability are formulated in the format of linear matrix inequalities (LMIs). Finally, the control performance and effectiveness of the proposed controller are demonstrated through numerical simulations, and the chaotic motions in D-PMSG can be eliminated quickly. Full article

This paper presents a new method to optimize, from a working cycle defined by torque and speed profiles, both the design and the control strategy of permanent magnet synchronous generators (PMSGs). The case of a 10 MW direct-drive permanent magnet generator for an Offshore wind turbine was chosen to illustrate this method, which is based on the d–q axis equivalent circuit model. It allows to optimize, with a reduced computation time, the design, considering either a flux weakening control strategy (FW) or a maximum torque per Ampere control (MTPA) strategy, while respecting all the constraints—particularly the thermal constraint, which is characterized by a transient regime. The considered objective is to minimize the mass and the average electric losses over all working points. Thermal and magnetic analytical models are validated by a 2D finite element analysis (FEA). Full article

Subsynchronous oscillation (SSO) is a critical issue for the direct-drive permanent magnet synchronous generator (D-PMSG) based wind farm integrated to a weak onshore AC grid. To analyze the mechanism of the SSO phenomenon of D-PMSG based wind farm, widely used impedance-based stability analysis method is utilized in this paper. First, the impedance model based on the harmonic linearization theory of grid-connected D-PMSG is proposed, and the mechanism of sub/supsynchronous currents coupling is analyzed quantitatively for the first time. Then, based on the impedance model and relative stability criterion, the influence of wind farm operating parameters and grid impedance on stability is discussed. Simulations are carried out to verify the correctness of theoretical analysis. Full article

This paper proposes a novel optimal current given (OCG) maximum power point tracking (MPPT) control strategy based on the theory of power feedback and hill climb searching (HCS) for a permanent magnet direct drive wind energy conversion system (WECS). The presented strategy not only has the advantages of not needing the wind speed and wind turbine characteristics of the traditional HCS method, but it also improves the stability and accuracy of MPPT by estimating the exact loss torque. The OCG MPPT control strategy is first carried out by simulation, then an experimental platform based on the dSPACE1103 controller is built and a 5.5 kW permanent magnet synchronous generator (PMSG) is tested. Furthermore, the proposed method is compared experimentally with the traditional optimum tip speed ratio (TSR) MPPT control. The experiments verify the effectiveness of the proposed OCG MPPT strategy and demonstrate its better performance than the traditional TSR MPPT control. Full article
