Search Results (29)

This study presents an adaptive integrated chassis control strategy for enhancing vehicle stability under different road conditions, specifically through the real-time estimation of tire cornering stiffness. A hierarchical control architecture is developed, combining active front steering (AFS) and direct yaw moment control (DYC). A recursive regularized weighted least squares algorithm is designed to estimate tire cornering stiffness from measurable vehicle states, eliminating the need for additional tire sensors. Leveraging this estimation, an adaptive sliding mode controller (ASMC) is proposed in the upper layer, where a novel self-tuning mechanism adjusts control parameters based on tire saturation levels and cornering stiffness variation trends. The lower-layer controller employs a weighted least squares allocation method to distribute control efforts while respecting physical and friction constraints. Co-simulations using MATLAB 2018a/Simulink and CarSim validate the effectiveness of the proposed framework under both high- and low-friction scenarios. Compared with conventional ASMC and DYC strategies, the proposed controller exhibits improved robustness, reduced sideslip, and enhanced trajectory tracking performance. The results demonstrate the significance of the real-time integration of tire dynamics into chassis control in improving vehicle handling and stability. Full article

Coordinating vehicle handling stability and energy consumption remains a key challenge for distributed driving electric vehicles (DDEVs). In this paper, a hierarchical torque vectoring control strategy is proposed to address this issue. First, a tire road friction coefficient (TRFC) estimator based on the fusion of vision and dynamic is developed to accurately and promptly obtain the TRFC in the upper layer. Second, a direct yaw moment control (DYC) strategy based on the adaptive model predictive control (MPC) is designed to ensure vehicle stability in the middle layer, where tire cornering stiffness is updated dynamically based on the estimated TRFC. Then, the lower layer develops the torque vectoring allocation controller, which comprehensively considers handling stability and energy consumption and distributes the driving torques among the wheels. The weight between stability and economy is coordinated according to the stability boundaries derived from an extended phase-plane correlated with the TRFC. Finally, Hardware-in-the-Loop (HIL) simulations are conducted to validate the effectiveness of the proposed strategy. The results demonstrate that compared with the conventional stability torque distribution strategy, the proposed control strategy not only reduces the RMSE of sideslip angle by 44.88% but also decreases the motor power consumption by 24.45% under DLC conditions, which indicates that the proposed method can significantly enhance vehicle handling stability while reducing energy consumption. Full article

This study proposes an adaptive non-singular fast terminal sliding mode control (NFTSMC)-based direct yaw moment control (DYC) strategy to enhance driving stability in four-wheel independent drive (4WID) electric vehicles. Unlike conventional SMC, the proposed method dynamically adapts to system uncertainties and reduces chattering, a critical issue in control applications. The approach begins with the development of an NFTSMC method, analyzing its performance to identify areas for improvement. To enhance robustness and responsiveness, a novel adaptive NFTSMC method is introduced. This method integrates a non-singular fast terminal sliding mode surface with a novel adaptive fast-reaching control law that combines an adaptive switching mechanism and a fast-reaching law. The designed adaptive switching law adjusts the sliding gain in real time based on system conditions, reducing chattering without needing an upper bound on uncertainties as required by traditional NFTSMC methods. Concurrently, the fast-reaching law ensures rapid convergence from any initial condition and accurate tracking performance. Simulation results across various steering maneuvers, including step, sinusoidal, and fish-hook inputs, demonstrate that the proposed method significantly improves tracking accuracy and driving stability over traditional SMC and NFTSMC methods. Marked reductions in RMS and peak yaw rate errors, and effective chattering mitigation, highlight advancements in vehicle safety and stability. Full article

Distributed drive electric vehicles (DDEV), characterized by their independently drivable wheels, offer significant advantages in terms of vehicle handling, stability, and energy efficiency. These attributes collectively contribute to enhancing driving safety and extending the all-electric range for sustainable transportation. Nonetheless, the challenge persists in designing a control strategy that effectively coordinates the objectives of handling, stability, and energy efficiency under both lateral and longitudinal driving conditions. To this end, this paper proposes a cooperative control strategy for DDEVs, incorporating active rear steering (ARS) and direct yaw moment control (DYC) to enhance handling capabilities, stability, and energy efficiency. A stability boundary is delineated using an analytical expression that correlates with the front wheel steering angle, and an adjustment factor is introduced to quantify vehicle stability based on this input parameter. This factor aids in establishing a coordinated control reference for handling and stability. At the upper-level motion control layer, a model predictive control method is developed to track this reference and implement ARS and DYC for superior performance. Specifically, the rear lateral force serves as the control command for ARS, which is converted into a rear wheel steering angle using a tire inverse model. Meanwhile, the front lateral force is modeled as linear-time-varying to simplify calculations. At the lower-level torque allocation layer, the adjustment factor is utilized to balance tire workload rate and in-wheel motors’ (IWM) energy consumption, enabling efficient switching between energy consumption and driving stability targets, and the torque allocation is conducted to acquire the expected IWMs’ command. Both the upper and lower-level optimization problems are formulated as convex problems, ensuring efficient and effective solutions. Simulations verify the effectiveness of this strategy in improving handling, stability, and energy economy under DLC cases, while maintaining high computational efficiency. Full article

Direct yaw moment control (DYC) and differential drive-assist steering (DDAS) for distributed-drive vehicles are both realized by allocating the in-wheel motor torque. To address the interference caused by overlapping control objectives, this paper proposes a multilayer control strategy that integrates DYC and DDAS, consisting of an upper controller, a coordinated decision layer, and a torque distribution layer. The upper controller, designed based on the vehicle’s dynamic characteristics, incorporates an adaptive fuzzy control DYC system and a dual PID control DDAS system. The coordinated decision layer is developed utilizing a phase-plane dynamic weighting method, delineating region boundaries by applying the double-line and limit cycle methods. The torque distribution strategy is formulated considering motor peak torque and road adhesion conditions. Multi-condition joint simulation experiments indicate that the proposed multilayer control strategy, integrating the advantages of DYC and DDAS, reduces peak steering wheel torque by approximately 10%, peak yaw rate by around 25%, peak sideslip angle by roughly 29%, and peak sideslip angle rate by about 19%, significantly improving driving stability and maneuvering flexibility. Full article

With the ongoing promotion and adoption of electric vehicles, intelligent and connected technologies have been continuously advancing. Electrical control systems implemented in electric vehicles have emerged as a critical research direction. Various drive-by-wire chassis systems, including drive-by-wire driving and braking systems and steer-by-wire systems, are extensively employed in vehicles. Concurrently, unavoidable issues such as conflicting control system objectives and execution system interference emerge, positioning integrated chassis control as an effective solution to these challenges. This paper proposes a model predictive control-based longitudinal dynamics integrated chassis control system for pure electric commercial vehicles equipped with electro–mechanical brake (EMB) systems, centralized drive, and distributed braking. This system integrates acceleration slip regulation (ASR), a braking force distribution system, an anti-lock braking system (ABS), and a direct yaw moment control system (DYC). This paper first analyzes and models the key components of the vehicle. Then, based on model predictive control (MPC), it develops a controller model for integrated stability with double-layer torque distribution. The required driving and braking torque for each wheel are calculated according to the actual and desired motion states of the vehicle and applied to the corresponding actuators. Finally, the effectiveness of this strategy is verified through simulation results from Matlab/Simulink. The simulation shows that the braking deceleration of the braking condition is increased by 32% on average, and the braking distance is reduced by 15%. The driving condition can enter the smooth driving faster, and the time is reduced by 1.5 s~5 s. The lateral stability parameters are also very much improved compared with the uncontrolled vehicles. Full article

Given the increased significance of electric vehicles in recent years, this study aimed to develop a novel form of direct yaw-moment control (DYC) to enhance the driving stability of four-wheel independent drive (4WID) electric vehicles. Specifically, this study developed an innovative non-singular fast terminal sliding mode control (NFTSMC) method that integrates NFTSM and a fast-reaching control law. Moreover, this study employed a radial basis function neural network (RBFNN) to approximate both the entire system model and uncertain components, thereby reducing the computational load associated with a complex system model and augmenting the overall control performance. Using the aforementioned factors, the optimal additional yaw moment to ensure the lateral stability of a vehicle is determined. To generate the additional yaw moment, we introduce a real-time optimal torque distribution method based on the vertical load ratio. The stability of the proposed approach is comprehensively verified using the Lyapunov theory. Lastly, the validity of the proposed DYC system is confirmed by simulation tests involving step and sinusoidal inputs conducted using Matlab/Simulink and CarSim software. Compared to conventional sliding mode control (SMC) and NFTSMC methods, the proposed approach showed improvements in yaw rate tracking accuracy for all scenarios, along with a significant reduction in the chattering phenomenon in control torques. Full article

Direct yaw moment control (DYC) can effectively improve the yaw stability of four-wheel distributed drive electric vehicles (4W-DDEVs) under extreme conditions, which has become an indispensable part of active safety control for 4W-DDEVs. This study proposes a novel hierarchical DYC architecture for 4W-DDEVs to enhance vehicle stability during ever-changing road conditions. Firstly, a vehicle dynamics model is established, including a two-degree-of-freedom (2DOF) vehicle model for calculating the desired yaw rate and sideslip angle as the control target of the upper layer controller, a DDEV model composed of a seven-degree-of-freedom (7DOF) vehicle model, a tire model, a motor model and a driver model. Secondly, a hierarchical DYC is designed combining the upper layer yaw moment calculation and low layer torque distribution. Specifically, based on Matlab/Simulink, improved linear quadratic regulator (LQR) with weight matrix optimization based on inertia weight cosine-adjustment particle swarm optimization (IWCPSO) is employed to compute the required additional yaw moment in the upper-layer controller, while quadratic programming (QP) is used to allocate four motors’ torque with the optimization objective of minimizing the tire utilization rate. Finally, a comparative test with double-lane-change and sinusoidal conditions under a low and high adhesion road surface is conducted on Carsim and Matlab/Simulink joint simulation platform. With IWCPSO-LQR under double-lane-change (DLC) condition on a low adhesion road surface, the yaw rate and sideslip angle of the DDEV exhibits improvements of 95.2%, 96.8% in the integral sum of errors, 94.9%, 95.1% in the root mean squared error, and 78.8%, 98.5% in the peak value compared to those without control. Simulation results indicate the proposed hierarchical control method has a remarkable control effect on the yaw rate and sideslip angle, which effectively strengthens the driving stability of 4W-DDEVs. Full article

To enhance the path tracking capability and driving stability of intelligent vehicles, a controller is designed that synergizes active front wheel steering (AFS) and direct yaw moment (DYC), specifically tailored for distributed-drive electric vehicles. To address the challenge of determining the weight matrix in the linear quadratic regulator (LQR) algorithm during the path tracking design for intelligent vehicles on conventional roads, a genetic algorithm (GA)-optimized LQR path tracking controller is introduced. The 2-degree-of-freedom vehicle dynamics error model and the desired path information are established. The genetic algorithm optimization strategy, utilizing the vehicle’s lateral error, heading error, and output front wheel steering angle as the objective functions, is employed to optimally determine the weight matrices Q and R. Subsequently, the optimal front wheel steering angle control (AFS) output of the vehicle is calculated. Under extreme operating conditions, to enhance vehicle dynamics stability, while ensuring effective path tracking, the active yaw moment is crafted using the sliding mode control with a hyperbolic tangent convergence law function. The control weights of the sliding mode surface related to the center-of-mass lateral declination are adjusted based on the theory of the center-of-mass lateral declination phase diagram, and the vehicle’s target yaw moment is calculated. Validation is conducted through Matlab/Simulink and Carsim co-simulation. The results demonstrate that the genetic algorithm-optimized LQR path tracking controller enhances vehicle tracking accuracy and exhibits improved robustness under conventional road conditions. In extreme working conditions, the designed path tracking and stability cooperative controller (AFS+DYC) is implemented to enhance the vehicle’s path tracking effect, while ensuring its driving stability. Full article

Torque vectoring is a widely known technique to improve vehicle handling and to increase stability in limit conditions. With the advent of electric vehicles, this is becoming a key topic since it is possible to have distributed powertrains, i.e., multiple motors are adopted, in which each motor is controlled separately from the others. Moreover, electric motors deliver the torque required by the controller faster and more precisely than internal combustion engines, active differentials and conventional hydraulic brakes. The state of the art of Direct Yaw Moment Control (DYC) techniques, ranging from classical to modern control theories, are analyzed and discussed in this paper. The aim is to give an overview of the currently available approaches while identifying their drawbacks regarding performances and robustness when dealing with common issues like model uncertainties, external disturbances, friction limit and common state estimation problems. This contribution analyzes all the steps from the lateral dynamics reference generation to the desired control action computation and allocation to the available actuators. In addition, some of the presented control logic is evaluated in a simulation environment for a passenger car. Results of both open-loop and closed-loop maneuvers allow the comparison and clarification of each control strategy’s key advantages. Full article

In order to achieve multi-objective chassis coordination control for 4WID-4WIS (four-wheel independent drive–four-wheel independent steering) electric vehicles, this paper proposes a coordinated control strategy based on the extension dynamic stability domain. The strategy aims to improve trajectory tracking performance, handling stability, and economy. Firstly, expert PID and model predictive control (MPC) are used to achieve longitudinal speed tracking and lateral path tracking, respectively. Then, a sliding mode controller is designed to calculate the expected yaw moment based on the desired vehicle states. The extension theory is applied to construct the extension dynamic stability domain, taking into account the linear response characteristics of the vehicle. Different coordinated allocation strategies are devised within various extension domains, providing control targets for direct yaw moment control (DYC) and active rear steering (ARS). Additionally, a compound torque distribution strategy is formulated to optimize driving efficiency and tire adhesion rate, considering the vehicle’s economy and stability requirements. The optimal wheel torque is calculated based on this strategy. Simulation tests using the CarSim/Simulink co-simulation platform are conducted under slalom test and double-lane change to validate the control strategy. The test results demonstrate that the proposed control strategy not only achieves good trajectory tracking performance but also enhances handling stability and economy during driving. Full article

Distributed-drive vehicles utilize independent drive motors on the four-wheel hubs. The working conditions of the wheel-hub motors are so harsh that the motors are prone to failing under different driving conditions. This study addresses the impact of drive motor faults on vehicle performance, particularly on slippery roads where sudden faults can lead to accidents. A fault-tolerant control system integrating motor fault diagnosis and a direct yaw moment control (DYC) based fault-tolerant controller are proposed to ensure the stability of the vehicle during various motor faults. Due to the difficulty of identifying the parameters of the popular permanent magnet synchronous wheel hub motors (PMSMs), the system employs a model-free backpropagation neural network (BPNN)-based fault detector. Turn-to-turn short circuits, open-phase faults, and diamagnetic faults are considered in this research. The fault detector is trained offline and utilizes rotor speed and phase currents for online fault detection. The system assigns the torque outputs from both healthy and faulted motors based on fault categories using sliding mode control (SMC)-based DYC. Simulations with four-wheel electric vehicle models demonstrate the accuracy of the fault detector and the effectiveness of the fault-tolerant controller. The proposed system is prospective and has potential for the development of distributed electric vehicles. Full article

A pre-emptive braking control method is proposed to improve the stability of autonomous vehicles during emergency collision avoidance, aiming to imitate the realistic human driving experience. A linear model predictive control is used to derive the front wheel steering angle to track a predefined fifth-degree polynomial trajectory. Based on a two-degrees-of-freedom (DOF) vehicle dynamics model, the maximum stable vehicle speed during collision avoidance can be determined. If the actual vehicle speed exceeds the maximum stable vehicle speed, braking action will be applied to the vehicle. Furthermore, four-wheel steering (4WS) control and direct yaw moment control (DYC) are employed to further improve the stability of the vehicle during collision avoidance. Simulation results under a double lane change scenario demonstrate that the control system incorporating pre-emptive braking, 4WS, and DYC can enhance the vehicle stability effectively during collision avoidance. Compared to the 2WS system without pre-emptive braking control, the maximum stable vehicle speed of the integrated control system can be increased by at least 56.9%. The proposed integrated control strategy has a positive impact on the safety of autonomous vehicles, and it can also provide reference for the research and development of autonomous driving systems. Full article

This paper suggests a hierarchical coordination control strategy to enhance the stability of distributed drive electric bus. First, an observer based on sliding mode observer (SMO) and adaptive neural fuzzy inference system (ANFIS) was designed to estimate the vehicle state parameters. Then the upper layer of the strategy primarily focuses on coordinating active front steering (AFS) and direct yaw moment control (DYC). The phase plane method is utilized in this layer to provide an assessment basis for the switching control safety of AFS and DYC. The lower layer of the strategy designs an integral terminal sliding mode controller (ITSMC) and a non-singular fast terminal sliding mode controller (NFTSMC) to obtain the optimal additional front wheel steering angle to improve handling performance. A fuzzy sliding mode controller (FSMC) is also proposed to obtain additional yaw moment to ameliorate yaw stability. Finally, the strategy proposed in this paper is subjected to simulation testing and compared with the performance of AFS and DYC systems. The proposed strategy is also evaluated for tracking errors in sideslip angle and yaw rate under two conditions. The results demonstrate that the proposed strategy can effectively adapt to various extreme environments and improve the maneuvering and yaw stability of the bus. Full article

Vehicle stability control strategies can improve driving safety effectively; however, there is still a lack of unified evaluation criteria for different control strategies. This paper proposes a vehicle control strategy evaluation method based on the driving stability region and is analyzed by using direct yaw moment control (DYC) and four-wheel steering (4WS) as examples. Firstly, the five-degree-of-freedom (5DOF) vehicle system models including DYC and 4WS are established, and the effectiveness of the control strategies is verified by nonlinear analysis methods; the dynamic characteristics of the system are also analyzed. Following this, a hybrid algorithm combining the Genetic Algorithm (GA) and Sequential Quadratic Programming (SQP) methods is used to solve the system equilibrium points, and the driving stability regions under different control strategies are obtained. Finally, the driving stability regions are tested based on the CarSim and Simulink simulations, and the control performance is evaluated. The results indicate that DYC and 4WS can improve vehicle stability and expand the range of driving stability regions. When the initial longitudinal velocity is below 30 m/s, the driving stability regions under DYC and 4WS expand to different extents compared to the original driving stability region. The expanded driving stability regions show that the stability region of the vehicle with DYC is larger than that of 4WS; thus, the control effect of DYC is better than that of 4WS. The proposed method can be used to evaluate the effective range of different control strategies. Full article
