This study investigates the dimensional synthesis of steering mechanisms for front-wheel-drive, two-axle, four-wheeled vehicles using two metaheuristic optimization algorithms: Differential Evolution with golden ratio (DE-gr) and Improved Particle Swarm Optimization (IPSO). The vehicle under consideration has a track-to-wheelbase ratio of 0.5 and an inner wheel steering angle of 70 degrees. The mechanisms synthesized include the Ackermann steering mechanism and two variants (Type I and Type II) of the Watt-I six-bar steering mechanisms, also known as central-lever steering mechanisms. To ensure accurate steering and minimize tire wear during cornering, adherence to the Ackermann steering condition is enforced. The objective function combines the mean squared structural error at selected steering positions with a penalty term for violations of the Grashoff inequality constraint. Each optimization run involved 100 or 200 iterations, with numerical experiments repeated 100 times to ensure robustness. Kinematic simulations were conducted in ADAMS v2015 to visualize and validate the synthesized mechanisms. Performance was evaluated based on maximum structural error (steering accuracy) and mechanical advantage (transmission efficiency). The results indicate that the optimized Watt-I six-bar steering mechanisms outperform the Ackermann mechanism in terms of steering accuracy. Among the Watt-I variants, the Type II designs demonstrated superior performance and convergence precision compared to the Type I designs, as well as improved results compared to prior studies. Additionally, the optimal Type I-2 and Type II-2 mechanisms consist of two symmetric Grashof mechanisms, can be classified as non-Ackermann-like steering mechanisms. Both optimization methods proved easy to implement and showed reliable, efficient convergence. The DE-gr algorithm exhibited slightly superior overall performance, achieving optimal solutions in seven cases compared to four for the IPSO method. Full article

In the field of mechanical engineering, understanding mechanisms is essential for designing and developing devices and systems. Mechanisms, composed of interconnected elements, transform the energy applied to the input link into motion or force in the output link. Mechanisms are found in a wide variety of machines, from industrial machines to household machines. In this paper, a mechanism synthesis method is developed that can model four-bar linkages and build their cognate mechanisms to be able to select the mechanism that best suits the required work. Studying four-bar mechanisms offers a strong foundation for grasping more complex mechanical systems. The concepts and principles learned from four-bar mechanisms are widely applicable to advanced mechanical systems, making them a crucial starting point in mechanical engineering education and research. The mechanism synthesis method proposed in this article is organized into three main sections. The first section provides a comprehensive overview of the theoretical and mathematical foundations required for modeling mechanisms, laying the groundwork for understanding the subsequent calculations. The second section delves into the process of obtaining and analyzing the initial mechanism and constructing cognate mechanisms, detailing the procedures and algorithms used for modeling and calculating the coupling curve. Finally, the third section discusses the practical implementation of the method, including the graphical representation of mechanisms and a comparative analysis of the solutions obtained, assessing dimensional differences, design and manufacturing efficiency, and their suitability for various practical applications. The proposed four-bar mechanism synthesis method serves as a valuable tool for mechanism design, offering versatile and adaptable solutions that can optimize both technical performance and economic viability across a wide range of engineering applications. Full article

This paper presents a novel exoskeleton robot that can be used at home to rehabilitate the index fingers of stroke-affected patients. This exoskeleton is designed as a one-degree-of-freedom four-bar mechanism able to guide the human index finger to perform a finger curl exercise motion. The proposed device is the only lateral, stand-alone mechanism built to date that can carry the weight of the human hand, thus making the user free from wearing it. The design starts by tracing the trajectory of the index finger using ‘Angulus’ software. ‘SALAR Mechanism Synthesizer’ software is used for dimensional synthesis of the four-bar mechanism. Using additive manufacturing technology, a prototype of the proposed device is developed. Static force analysis is performed to select the most appropriate actuator for producing the required torque to manipulate the fingers effectively. The kinematics of the index finger while performing a finger curl exercise is obtained. The proposed linkage mechanism can drive the index fingers of both hands. Simulation and experimental results proved the feasibility and effectiveness of the proposed design to be used for index finger rehabilitation for a wide range of users and applications by making simple minor alterations in the design. Also, a scheme for when the device can be used for rehabilitating the middle finger together with the index finger when performing flexion and extension motions is discussed. Full article

In design matters, mechanisms with deformable elements are a step behind those with rigid bars, particularly if dimensional synthesis is considered a fundamental part of mechanism design. For the purposes of this work, a hybrid rigid–flexible four-bar mechanism has been chosen, the input bar being a continuum tendon of constant curvature. The coupler curves are noticeably more complex but offer more possibilities than the classical rigid four-bar counterpart. One of the objectives of this work is to completely characterize the coupler curves of this hybrid rigid–flexible mechanism, determining the number and type of circuits as well as constituent branches. Another important aim is to apply optimization techniques to the dimensional synthesis of path generation. Considerable progress in finding the best design solutions can be obtained if all the acquired knowledge about the coupler curves of this hybrid mechanism is integrated into the optimization algorithm. Full article

Mechanisms have allowed for the automation of complex, repetitive, demanding, or dangerous tasks for humans. Among the different mechanisms, those with a closed kinematic chain are more precise and robust compared to open chain ones, which makes them suitable for many applications. One of the most widely used closed-chain alternatives is the four-bar Grashof-type mechanism, as it can generate highly nonlinear closed trajectories with a single degree of freedom. However, the dimensional synthesis of these mechanisms to generate specific trajectories is a complex task. Fortunately, computational methods known as metaheuristics can solve such problems effectively. Differential Evolution (DE) is a metaheuristic commonly used to tackle the dimensional synthesis problem. This paper presents a comparative study of the most commonly used variants of DE in solving the dimensional synthesis problem of four-bar Grashof-type mechanisms. The purpose of the study is to provide guidelines to choose the best DE alternative for solving problems of this type, as well as to support the development of DE-based algorithms that can solve more specific cases effectively. After analysis, the rand/1/exp variant was found to be the most effective in solving the dimensional synthesis problem, which was followed by best/1/bin. Based on these results, a Simple and Improved DE (SIDE) variant based on these two was proposed. The competitive performance of the SIDE with respect to the studied DE variants and in contrast to the results of algorithms used in the recent specialized literature for mechanism synthesis illustrates the usefulness of the study. Full article

The design optimization of mechanisms is promising as it results in more energy-efficient machines without compromising performance. However, machine builders do not apply state-of-the-art methods, as these algorithms require case-specific theoretical analysis. Moreover, the design synthesis approaches in the literature predominantly utilize heuristic optimizers, leading to suboptimal local minima. This paper introduces a widely applicable workflow, guaranteeing the global optimum. The constraints describing the feasible region of the possible designs are essential to find the global optimum. Therefore, kinematic analysis of the point-to-point planar four-bar mechanism is discussed. Within the feasible design space, objective value samples were generated through the CAD multi-body software. These motion simulations determine the required torque to fulfill the movement for a combination of design parameters. This replaces the cumbersome analytic derivation of the torque. This paper introduces sparse interpolation techniques to avoid brute force sampling of the design space. The advantage of this approach is that it is easily scalable to more design parameters, as the interpolation method minimizes the number of necessary samples. This paper explains the mathematical background of our developed interpolation approach. However, a step-by-step procedure is introduced to allow the employment of the interpolation technique by machine designers without the necessity to understand the underlying mathematics. Finally, the mathematical expression, obtained from the interpolation, enables applying global optimizers. In a case study of an emergency ventilator mechanism with three design parameters, 1870 CAD motion simulations allowed reducing the RMS torque of the mechanism by 67%. Full article

Four-bar linkages are one of the most widely used mechanisms in industries. This paper presents a comparative study on the accuracy and efficiency of the optimum synthesis of path-generating four-bar linkages using five metaheuristic optimization algorithms. The utilized metaheuristic methods included two swarm intelligence-based algorithms, i.e., particle swarm optimization and hybrid particle swarm optimization, and three evolutionary-based algorithms, i.e., differential evolution, ensemble of parameters and mutation strategies in differential evolution, and linearly ensemble of parameters and mutation strategies in differential evolution. The objective function to be minimized is the sum of squares of the distance between the generated points and the precision points of a coupler point. The optimal design of four-bar linkages must meet the Grashof’s criteria and exhibit sequential constraints that can prevent the occurrence of order defect. This study investigated five representative cases of the dimensional synthesis of four-bar path generators with and without prescribed timing and compared the optimal solutions of the utilized five metaheuristic methods to those of previously reported algorithms in literature. The improved metaheuristic methods exhibited superior optimal solution and enhanced reliability compared to the original methods. Moreover, three improved metaheuristic methods were not only easy implemented, but also more efficient for solving the optimal synthesis problems, particularly for high dimensional problems. Full article

In mechanism design with symmetrical or asymmetrical motions, obtaining high precision of the input path given by working requirements of mechanisms can be a challenge for dimensional optimization. This study proposed a novel hybrid-combined differential evolution (DE) and Jaya algorithm for the dimensional synthesis of four-bar mechanisms with symmetrical motions, called HCDJ. The suggested algorithm uses modified initialization, a hybrid-combined mutation between the classical DE and Jaya algorithm, and the elitist selection. The modified initialization allows generating initial individuals, which are satisfied with Grashof’s condition and consequential constraints. In the hybrid-combined mutation, three differential groups of mutations are combined. DE/best/1 and DE/best/2, DE/current to best/1 and Jaya operator, and DE/rand/1, and DE/rand/2 belong to the first, second, and third groups, respectively. In the second group, DE/current to best/1 is hybrid with the Jaya operator. Additionally, the elitist selection is also applied in HCDJ to find the best solutions for the next generation. To validate the feasibility of HCDJ, the numerical examples of the symmetrical motion of four-bar mechanisms are investigated. From the results, the proposed algorithm can provide accurate optimal solutions that are better than the original DE and Jaya methods, and its solutions are even better than those of many other algorithms that are available in the literature. Full article

Currently, rehabilitation systems with closed kinematic chain mechanisms are low-cost alternatives for treatment and health care. In designing these systems, the dimensional synthesis is commonly stated as a constrained optimization problem to achieve repetitive rehabilitation movements, and metaheuristic algorithms for constrained problems are promising methods for searching solutions in the complex search space. The Constraint Handling Techniques (CHTs) in metaheuristic algorithms have different capacities to explore and exploit the search space. However, the study of the relationship in the CHT performance of the mechanism dimensional synthesis for rehabilitation systems has not been addressed, resulting in an important gap in the literature of such problems. In this paper, we present a comparative empirical study to investigate the influence of four CHTs (penalty function, feasibility rules, stochastic-ranking, and $ϵ$-constraint) on the performance of ten representative algorithms that have been reported in the literature for solving mechanism synthesis for rehabilitation (four-bar linkage, eight-bar linkage, and cam-linkage mechanisms). The study involves analysis of the overall performance, six performance metrics, and evaluation of the obtained mechanism. This identified that feasibility rules usually led to efficient optimization for most analyzed algorithms and presented more consistency of the obtained results in these kinds of problems. Full article

In this paper, an optimization procedure for path generation synthesis of the slider-crank mechanism will be presented. The proposed approach is based on a hybrid strategy, mixing local and global optimization techniques. Regarding the local optimization scheme, based on the null gradient condition, a novel methodology to solve the resulting non-linear equations is developed. The solving procedure consists of decoupling two subsystems of equations which can be solved separately and following an iterative process. In relation to the global technique, a multi-start method based on a genetic algorithm is implemented. The fitness function incorporated in the genetic algorithm will take as arguments the set of dimensional parameters of the slider-crank mechanism. Several illustrative examples will prove the validity of the proposed optimization methodology, in some cases achieving an even better result compared to mechanisms with a higher number of dimensional parameters, such as the four-bar mechanism or the Watt’s mechanism. Full article

In the design and analysis of morphing wings, several sciences need to be integrated. This article tries to answer the question, “What is the most appropriate actuation mechanism to morph the wing profile?” by introducing the synthesis, analysis, and design of a novel scissor-structural mechanism (SSM) for the trailing edge of a morphing wing. The SSM, which is deployable, is created via a combination of various scissor-like elements (SLEs). In order to provide mobility requirements, a four-bar linkage (FBL) is assembled with the proposed SSM. The SSM is designed with a novel kinematic synthesis concept, so it follows the airfoil camber with minimum design error. In this concept, assuming a fully-compliant wing skin, various types of SLEs are assembled together, and emergent SSM provide the desired airfoil geometries. In order to provide the required aerodynamic efficiency of newly-created airfoil geometries and obtain pressure distribution over the airfoil, two-dimensional (2D) aerodynamic analyses have been conducted. The analyses show similar aerodynamic behavior with the desired NACA airfoils. By assigning the approximate link masses and mass centers, the dynamic force analysis of the mechanism has also been performed, and the required torque to drive the newly-developed SSM is estimated as feasible. Full article
