In the integration of structured light systems (SLSs) into automotive manufacturing pipelines, achieving reliable 3D reconstruction under industrial conditions remains a critical challenge. Factors such as environmental variability, surface reflectivity, and optical configuration often compromise dimensional accuracy and point cloud quality, limiting the deployment of SLSs for inspection tasks. This paper presents a practical metric-based methodology for evaluating the dimensional accuracy and point cloud quality of SLSs targeted at automotive inspection applications. Unlike existing approaches focused primarily on theoretical or hardware-specific parameters, the proposed methodology considers all phases of the acquisition–reconstruction pipeline, including calibration, environmental variability, and image enhancement strategies, to practically guide engineers step-by-step in adapting SLSs to real-world operational constraints. The methodology was experimentally validated through a case study in an automotive production setting, where it enabled the detection of reconstruction biases caused by surface reflectivity and viewing angle. It also demonstrated the ability to quantify improvements obtained through image enhancement algorithms. These results confirm the methodology’s capacity to expose critical performance trade-offs and guide optimization choices in practical inspection scenarios. By offering a repeatable and application-oriented evaluation framework, the methodology supports the robust integration of digital vision systems in industrial workflows, facilitating more informed decisions for system designers, process engineers, and quality control professionals. Full article

This work aimed to develop both a real implementation and a digital twin for a small CNC machining center. The X-, Y-, and Z-axes feed systems were realized as closed-loop motion loops with DC servo motors and encoders. Motion control was provided by Arduino boards and Pololu motor drivers. A simulation study of the step response parameters was carried out, and then the positioning regime was studied, followed by the two-axis simultaneous motion regime (circular interpolation). This study, based on a hybrid simulation diagram realized in Simulink–Simscape, allowed a preliminary tuning of the PID (proportional integral derivative) controllers. Next, the CAE (computer-aided engineering) simulation diagram was complemented with the CAM (computer-aided manufacturing) simulation interface, the two together forming an integrated digital twin system. To validate the contouring performance of the proposed CNC system, a circular groove with an outer diameter of 31 mm and an inner diameter of 29 mm was machined using a 1 mm cylindrical end mill. The trajectory followed the simulated 30 mm circular path. Two sets of controller parameters were applied. Dimensional accuracy was verified using a GOM Atos Core 200 optical scanner and evaluated in GOM Inspect Suite 2020. The results demonstrated good agreement between simulation and physical execution, validating the PID tuning and system accuracy. Full article

Digital time-delay integration (TDI) enhances the signal-to-noise ratio (SNR) in infrared (IR) imaging, but its effectiveness in push-broom scanning is contingent upon maintaining a stable image shift velocity. Unpredictable image shifts and rotations, caused by carrier or scene movement, can affect the imaging process. This paper proposes an advanced technical approach for infrared multispectral TDI imaging. This methodology concurrently estimates the image shift and rotation between frames by utilizing a high-resolution visible camera aligned parallel to the optical axis of the IR camera. Subsequently, parameter prediction is conducted using the Kalman model, and real-time compensation is achieved by dynamically adjusting the infrared TDI integration unit based on the predicted parameters. Simulation and experimental results demonstrate that the proposed algorithm enhances the BRISQUE score of the TDI images by 21.37%, thereby validating its efficacy in push-scan imaging systems characterized by velocity-height ratios instability and varying camera attitudes. This research constitutes a significant contribution to the advancement of high-precision real-time compensation for image shift and rotation in infrared remote sensing and industrial inspection applications. Full article

The subject of the present work is the development and implementation of a novel testing facility to carry out an experimental campaign on an advanced fuselage panel manufactured from both thermoplastic and metallic materials, as well as the validation of its numerical simulation. The experimental arrangement was specifically designed, assembled, and instrumented to have multi-axial loading capabilities. The investigated load cases comprised uniaxial in-plane compression, lateral distributed pressure, and their combination. The introduction of pressure was enabled by inflatable airbags, and compression was applied up to the onset of local skin buckling. Calibration of the load introduction and inspection equipment was performed in multiple steps to acquire accurate and representative measurements. Data were recorded by external sensors mounted on a hydraulic actuator and an optical Digital Image Correlation (DIC) system. A numerical simulation of the fuselage panel and the test rig was developed, and a validation study was conducted. In the Finite Element (FE) model, several of the experimental configuration’s supporting elements and their connections to the specimen were integrated as constraints and boundary conditions. Data procured from the tests were correlated to the simulation’s predictions, presenting low errors in most displacement/strain distributions. The results show that the proposed test rig concept is suitable for stiffened panel level testing and could be used for future studies on similar aeronautical components. Full article

The FLASH-COMP project aims to introduce novel inspection and monitoring technologies to develop a digital solution to predict defects during manufacturing, aiming to reach a zero-waste approach in composites manufacturing. Particularly, it’s studied the integration of two different Fiber Optic Sensor (FOS) technologies: Fiber Bragg Grating (FBG) and distributed All Grating Fiber (AGF^®), to retrieve relevant data during the preforming stage and later resin infusion process for aero-space materials. During the study, both FOS technologies were introduced into the materials, varying process conditions and the introduction of some artificial defects to evaluate the sensors response to correlate them after with their signals. Both systems can retrieve relevant information during the process such as vacuum, leaks and temperature changes, presence of voids and air bubbles, detection of dry zones, and resin flow monitoring. Further developments have to be focused on the scalability in the implementation, since FOS are fragile to handle and need specific training to use it in a more industrial field. Full article

Non-destructive examination (NDE) in the field of materials engineering is a technique based on acoustics and optical principles used for detecting and evaluating internal defects in materials without causing any damage. The majority of current research on material damage focuses on the analysis of a single NDE method, resulting in low correlation between different NDE methods, and their results are frequently presented as complex data and images, making it difficult for professionals to obtain intuitive inspection results. Therefore, we propose a visual analytics system, NDEExplorer, aimed at solving these problems through visual analytics techniques. The system supports the use of two NDE methods, Acoustic Emission (AE) and Digital Image Correlation (DIC), providing interactive and intuitive views for observing composite material damage features. In addition, the system features a fusion analysis approach and a view that combines AE and DIC methods, enabling users to explore the correlations and trends in multimodal data generated during the material damage process. For users, the application of this system can help accurately identify the various material damage stages and their accompanying damage modes. To evaluate the effectiveness of the proposed method, we conduct a case study using two modal datasets from the same composite material damage scenario and carry out qualitative interviews with professionals and graduate students in the field. Finally, the quantitative feedback from a user study confirms the usefulness of our visual system for the multimodal analysis of material damage datasets. Full article

In the high-stakes domain of precision manufacturing, Cubic Boron Nitride (CBN) inserts are pivotal for their hardness and durability. However, post-production surface defects on these inserts can compromise product integrity and performance. This paper proposes an automated detection and classification system using machine vision to scrutinize these surface defects. By integrating an optical bracket, a high-resolution industrial camera, precise lighting, and an advanced development board, the system employs digital image processing to ascertain and categorize imperfections on CBN inserts. The methodology initiates with a high-definition image capture by the imaging platform, tailored for CBN insert inspection. A suite of defect detection algorithms undergoes comparative analysis to discern their efficacy, emphasizing the impact of algorithm parameters and dataset diversity on detection precision. The most effective algorithm is then encapsulated into a versatile application, ensuring compatibility with various operating systems. Empirical verification of the system shows that the detection accuracy of multiple defect types exceeds 90%, and the tooth surface recognition efficiency significantly reaches three frames per second, with the front and side cutting surfaces of the tool in each frame. This breakthrough indicates a scalable, reliable solution for automatically detecting and classifying surface defects on CBN inserts, paving the way for enhanced quality control in automated, high-speed production lines. Full article

The wind energy sector is experiencing rapid growth, marked by the expansion of wind farms and the development of large-scale turbines. However, conventional manual methods for wind turbine operations and maintenance are struggling to keep pace with this development, encountering challenges related to quality, efficiency, and safety. In response, unmanned aerial vehicles (UAVs) have emerged as a promising technology offering capabilities to effectively and economically perform these tasks. This paper provides a review of state-of-the-art research and applications of UAVs in wind turbine blade damage detection, operations, and maintenance. It encompasses various topics, such as optical and thermal UAV image-based inspections, integration with robots or embedded systems for damage detection, and the design of autonomous UAV flight planning. By synthesizing existing knowledge and identifying key areas for future research, this review aims to contribute insights for advancing the digitalization and intelligence of wind energy operations. Full article

To characterize the failure of rock mass surrounding underground tunnels, biaxial compression tests were conducted on a real sandstone model with a straight-walled arched hole. The acoustic emission (AE) system and digital image correlation (DIC) optical inspection equipment were used to investigate the crack evolution process and failure precursors of the tunnel. A two-dimensional particle flow code (PFC2D) was used to conduct numerical simulations on the sample, so as to investigate the mesoscopic failure mechanism of rock mass. The results show that the failure of the single tunnel constructed in sandstone occurs mainly in the walls on both sides (between the spandrels and arch feet), showing slabbing failure characteristics and a certain abruptness. The crack initiation in sandstone in early stage is not obvious, and the crack propagation in rock mass is rapid when acoustic emissions are enhanced. The small increments in the AE count and amplitude and the continuous reduction in the b-value can be used as precursors for the failure of rock mass. When the height–span ratio is 0.8 and 1.0, the stress distribution around the chamber is more uniform, and when the height–span ratio is greater than 1.0, the stress is mainly concentrated in the vault and arch bottom. In the PFC simulations, tensile fractures firstly initiate in the middle of walls and at the arch feet, arcuate fracture concentration zones are then formed, in which shear fractures appear and a few particles spall from the surfaces. When approaching the ultimate bearing capacity, rock masses on both sides of the tunnel are fractured over large areas, and the slender coalesced fractured zone develops to the deep part of rock mass, causing failure of the sample. Full article

High-resolution coastline detection and monitoring are challenging on a global scale, especially in flat areas where natural events, sea level rise, and anthropic activities constantly modify the coastal environment. While the coastline related to the 0-level contour line can be extracted from accurate Digital Terrain Models (DTMs), the detection of the real-time, instantaneous coastline, especially at low tide, is a challenge that warrants further study and evaluation. In order to investigate an efficient combination of methods that allows to contribute to the knowledge in this field, this work uses topographic total station measurements, Global Navigation Satellite System Real-Time Kinematic (GNSS RTK) technique, and the Structure from Motion (SfM) approach (using a low-cost drone equipped with optical and thermal cameras). All the data were acquired at the beginning of 2022 and refer to the areas of Boccasette and Barricata, in the Po River Delta (Northeastern of Italy). The real-time coastline obtained from the GNSS data was validated using the topographic total station measurements; the correspondent polylines obtained from the photogrammetric data (using both automatic extraction and manual restitutions by visual inspection of orhophotos) were compared with the GNSS data to evaluate the performances of the different techniques. The results provided good agreement between the real-time coastlines obtained from different approaches. However, using the optical images, the accuracy was strictly connected with the radiometric changes in the photos and using thermal images, both manual and automatic polylines provided differences in the order of 1–2 m. Multi-temporal comparison of the 0-level coastline with those obtained from a LiDAR survey performed in 2018 provided the detection of the erosion and accretion areas in the period 2018–2022. The investigation on the two case studies showed a better accuracy of the GNSS RTK method in the real-time coastline detection. It can be considered as reliable ground-truth reference for the evaluation of the photogrammetric coastlines. While GNSS RTK proved to be more productive and efficient, optical and thermal SfM provided better results in terms of morphological completeness of the data. Full article

Multifocal glasses are a new type of lens that can fit both nearsighted and farsighted vision on the same lens. This property allows the glass to have various curvatures in distinct regions within the glass during the grinding process. However, when the curvature varies irregularly, the glass is prone to optical deformation during imaging. Most of the previous studies on imaging deformation focus on the deformation correction of optical lenses. Consequently, this research uses an automatic deformation defect detection system for multifocal glasses to replace professional assessors. To quantify the grade of deformation of curved multifocal glasses, we first digitally imaged a pattern of concentric circles through a test glass to generate an imaged image of the glass. Second, we preprocess the image to enhance the clarity of the concentric circles’ appearance. A centroid-radius model is used to represent the form variation properties of every circle in the processed image. Third, the deviation of the centroid radius for detecting deformation defects is found by a slight deviation control scheme, and we gain a difference image indicating the detected deformed regions after comparing it with the norm pattern. Fourth, based on the deformation measure and occurrence location of multifocal glasses, we build fuzzy membership functions and inference regulations to quantify the deformation’s severity. Finally, a mixed model incorporating a network-based fuzzy inference and a genetic algorithm is applied to determine a quality grade for the deformation severity of detected defects. Testing outcomes show that the proposed methods attain a 94% accuracy rate of the quality levels for deformation severity, an 81% recall rate of deformation defects, and an 11% false positive rate for multifocal glass detection. This research contributes solutions to the problems of imaging deformation inspection and provides computer-aided systems for determining quality levels that meet the demands of inspection and quality control. Full article

In recent decades, many cities have become densely populated due to increased urbanization, and the transportation infrastructure system has been heavily used. The downtime of important parts of the infrastructure, such as tunnels and bridges, seriously affects the transportation system’s efficiency. For this reason, a safe and reliable infrastructure network is necessary for the economic growth and functionality of cities. At the same time, the infrastructure is ageing in many countries, and continuous inspection and maintenance are necessary. Nowadays, detailed inspections of large infrastructure are almost exclusively performed by inspectors on site, which is both time-consuming and subject to human errors. However, the recent technological advancements in computer vision, artificial intelligence (AI), and robotics have opened up the possibilities of automated inspections. Today, semiautomatic systems such as drones and other mobile mapping systems are available to collect data and reconstruct 3D digital models of infrastructure. This significantly decreases the downtime of the infrastructure, but both damage detection and assessments of the structural condition are still manually performed, with a high impact on the efficiency and accuracy of the procedure. Ongoing research has shown that deep-learning methods, especially convolutional neural networks (CNNs) combined with other image processing techniques, can automatically detect cracks on concrete surfaces and measure their metrics (e.g., length and width). However, these techniques are still under investigation. Additionally, to use these data for automatically assessing the structure, a clear link between the metrics of the cracks and the structural condition must be established. This paper presents a review of the damage of tunnel concrete lining that is detectable with optical instruments. Thereafter, state-of-the-art autonomous tunnel inspection methods are presented with a focus on innovative mobile mapping systems for optimizing data collection. Finally, the paper presents an in-depth review of how the risk associated with cracks is assessed today in concrete tunnel lining. Full article

In this paper, a conventional camera modified to capture multispectral images, has been used to locate latent forensic traces with a smart combination of wavelength filters, capturing angle, and illumination sources. There are commercial multispectral capture devices adapted to the specific tasks of the police, but due to their high cost and operation not well adapted to the field work in a crime scene, they are not currently used by forensic units. In our work, we have used a digital SLR camera modified to obtain a nominal sensitivity beyond the visible spectrum. The goal is to obtain forensic evidences from a crime scene using the multispectral camera by an expert in the field knowing which wavelength filters and correct illumination sources should be used, making visible latent evidences hidden from the human-eye. In this paper, we show a procedure to retrieve from latent forensic traces, showing the validity of the system in different real cases (blood stains, hidden/erased tattoos, unlocking patterns on mobile devices). This work opens the possibility of applying multispectral inspections in the forensic field specially for operational units for the location of latent through non-invasive optical procedures. Full article

On-line data collection from the manufactured parts is an essential element in Industry 4.0 to monitor the production’s health, which required strong data analytics. The optical metrology-based inspection of highly reflective parts in a production line, such as parts with metallic surfaces, is a difficult challenge. As many on-line inspection paradigms require the use of optical sensors, this reflectivity can lead to large amounts of noise, rendering the scan inaccurate. This paper discusses a method for noise reduction and removal in datapoints resulting from scanning the reflective planar surfaces. Utilizing a global statistic-based iterative approach, noise is gradually removed from the dataset at increasing percentages. The change in the standard deviation of point-plane distances is examined, and an optimal amount of noisy data is removed to reduce uncertainty in representing the workpiece. The developed algorithm provides a fast and efficient method for noise reduction in optical coordinate metrology and scanning. Full article

This paper developed a set of size detection systems with a computer vision method based on the accuracy requirements of the hole saw caps to meet the needs of the accuracy detection machine. The results allow manufacturers to build a digitalized hole saw cap detection system at a low cost. We have designed a measurement system for the hole saw caps with the computer vision method to measure the dimensions of the hole saw caps. However, a valid measurement value of the hole saw caps must be positioned symmetrically. However, in fact, when the measurement system is positioned accurately asymmetrically, it will cause a problem in the measurement data. Therefore, the dark box environment made of a light source and the back plate of the hole saw caps material and two cameras are employed to observe the hole saw caps from both above and the side views. Then, personal desktop computers calculate the size of the hole saw caps based on the camera screen vision with a Python program. The results of the proposed methodology are obtained by measuring 10 workpieces of different sizes, and all the errors within a range of 2 pixels (pixel, px) met the detection standards. Therefore, the developed hole saw cap detection system is in line with expectations. Full article
