This paper investigates the thermal shock response of a spacecraft solar panel. The panel is represented as a thin homogeneous plate. The governing equations are derived from the coupled thermoelasticity theory for a homogeneous medium, combining the heat equation with compressibility effects and the Lamé equations for the displacement vector. The aim of the paper is to analyze new properties of a specific formulation of the coupled thermoelasticity problem and to establish a justified simplification. New properties follow from a specific formulation of the thermoelasticity problem for a real physical object (a solar panel). They are subjective properties of this formulation and allow, in particular, to reduce the coupled thermoelasticity problem to a simpler, uncoupled problem, with certain limitations. This simplification is driven by the physics of the thermal shock process and the resulting plate deformation, which allows the thermal problem to be reduced to a one-dimensional formulation. The main result is a simplified thermoelasticity model that reveals several new properties. Notably, in the region where longitudinal displacements are negligible, the coupled problem generates into an uncoupled one. This result can be applied to model disturbances caused by thermal shock on spacecraft. Full article

It is difficult for the existing Burgers model to accurately depict the off-axis cyclic drawing process of woven coatings. In this paper, the mechanical deformation of woven PVC (polyvinyl chloride)-coated film at different temperatures is investigated. One-dimensional (1D) and two-dimensional (2D) constitutive models were established to characterize cyclic deformation processes. The 1D model is an improved Burgers model. The effects of the time dependence of the viscosity coefficient and the ratio of elastic to viscous deformation are considered simultaneously. The accuracy of the 1D model for predicting the cyclic nonlinear deformation at different temperatures and loading rates is improved. The 2D model is a nonlinear orthotropic model using polynomials. On the basis of the single-objective genetic algorithm, the inverse algorithm is used to obtain the shear polynomial coefficients in the tension phase and the shear modulus in the unloading phase, which circumvents performing the difficult shear test. UMAT subroutines of off-axis stretching and off-axis cyclic stretching are written separately. The intelligent inverse algorithm program consists of a single-objective genetic algorithm program, a finite element parametric modelling program, and a UMAT subroutine. The simulation results are compared with the off-axis cyclic tensile test data to validate the effectiveness and accuracy of the proposed 2D model for the analysis of the woven PVC-coated films in the tension–shear coupling state. Full article

Converter transformer is the key equipment in UHVDC transmission. If a local overheating fault occurs, it will inevitably form a local hot spot on the core, winding or other structural parts. Among these faults, multipoint grounding and interlaminar short circuit faults account for 30–50% of core accidents. The continuous overheating of 150–250 °C will cause ablation on the silicon steel sheet, which will destroy the insulation material and reduce the insulation performance. In severe cases, it will cause thermal expansion, resulting in local deformation or displacement of the core. Considering the scale of size and temperature parameters, the scale model of converter transformer is established based on the principle of constant magnetic flux density. By using the homogenization theory, the scaled model under multipoint grounding and interlaminar short circuit fault is simulated by electromagnetic heat. First, the single-phase four-column model of the core is established according to the scaled principle, and the core is refined. Secondly, taking the refined model as the research object, the magnetic thermal coupling simulation and analysis are carried out under multi-point grounding and interlaminar short circuit fault, and the magnetic density, eddy current loss and temperature distribution on each lamination are obtained. Finally, the correctness of the simulation is verified by the one-dimensional eddy current loss analytical equation, which provides a reference for the local overheating problem of converter transformers. Full article

Urban areas in Taiwan are densely populated with limited land. Excavation often takes place near existing buildings, necessitating protective measures for adjacent properties. Among these measures, cross walls or buttress walls are commonly employed, especially in weak foundation soils, which have seen many successful applications. These mechanisms mainly contribute to reducing lateral deformation of the diaphragm walls, ground subsidence, and excavation face uplift. However, the behavior of these walls is essentially three-dimensional, and common engineering analyses employing one-dimensional elastoplastic beam analysis cannot adequately simulate their mechanical behavior. This study utilized the PLAXIS 3D 2018 software to analyze real-life cases of buttress walls and cross walls. Then, the results of the numerical models were validated against actual field measurements, and the outcomes were satisfactory, and within the regulatory allowable values. The primary objective of this study was to find the influence of different buttress wall removal timings on the lateral deformation of the diaphragm wall. The findings suggest that the gradual removal of buttress walls will effectively control the lateral deformation of diaphragm walls during the excavation of deeper floors like mezzanines. Full article

Robust detection of deformable linear objects (DLOs) is a crucial challenge for the automation of handling and assembly of cables and hoses. The lack of training data is a limiting factor for deep-learning-based detection of DLOs. In this context, we propose an automatic image generation pipeline for instance segmentation of DLOs. In this pipeline, a user can set boundary conditions to generate training data for industrial applications automatically. A comparison of different replication types of DLOs shows that modeling DLOs as rigid bodies with versatile deformations is most effective. Further, reference scenarios for the arrangement of DLOs are defined to generate scenes in a simulation automatically. This allows the pipelines to be quickly transferred to new applications. The validation of models trained with synthetic images and tested on real-world images shows the feasibility of the proposed data generation approach for segmentation of DLOs. Finally, we show that the pipeline yields results comparable to the state of the art but has advantages in reduced manual effort and transferability to new use cases. Full article

Ship detection in synthetic aperture radar (SAR) images has witnessed rapid development in recent years, especially after the adoption of convolutional neural network (CNN)-based methods. Recently, a transformer using self-attention and a feed forward neural network with a encoder-decoder structure has received much attention from researchers, due to its intrinsic characteristics of global-relation modeling between pixels and an enlarged global receptive field. However, when adapting transformers to SAR ship detection, one challenging issue cannot be ignored. Background clutter, such as a coast, an island, or a sea wave, made previous object detectors easily miss ships with a blurred contour. Therefore, in this paper, we propose a local-sparse-information-aggregation transformer with explicit contour guidance for ship detection in SAR images. Based on the Swin Transformer architecture, in order to effectively aggregate sparse meaningful cues of small-scale ships, a deformable attention mechanism is incorporated to change the original self-attention mechanism. Moreover, a novel contour-guided shape-enhancement module is proposed to explicitly enforce the contour constraints on the one-dimensional transformer architecture. Experimental results show that our proposed method achieves superior performance on the challenging HRSID and SSDD datasets. Full article

Orthoimage mosaicking with obvious parallax caused by geometric misalignment is a challenging problem in the field of remote sensing. Because the obvious objects are not included in the digital terrain model (DTM), large parallax exists in these objects. A common strategy is to search an optimal seamline between orthoimages, avoiding the majority of obvious objects. However, stitching artifacts may remain because (1) the seamline may still cross several obvious objects and (2) the orthoimages may not be precisely aligned in geometry when the accuracy of the DTM is low. While applying general image warping methods to orthoimages can improve the local geometric consistency of adjacent images, these methods usually significantly modify the geometric properties of orthophoto maps. To the best of our knowledge, no approach has been proposed in the field of remote sensing to solve the problem of local geometric misalignments after orthoimage mosaicking with obvious parallax. In this paper, we creatively propose a method to optimize local alignment along the seamline after seamline detection. It consists of the following main processes. First, we locate regions with geometric misalignments along the seamline based on the similarity measure. Second, for any one region, we find one-dimensional (1D) feature matches along the seamline using a semi-global matching approach. The deformation vectors are calculated for these matches. Third, these deformation vectors are robustly and smoothly propagated into the buffer region centered on the seamline by minimizing the associated energy function. Finally, we directly warp the orthoimages to eliminate the local parallax under the guidance of dense deformation vectors. The experimental results on several groups of orthoimages show that our proposed approach is capable of eliminating the local parallax existing in the seamline while preserving most geometric properties of digital orthophoto maps, and that it outperforms state-of-the-art approaches in terms of both visual quality and quantitative metrics. Full article

The object of the research is an underground straight horizontal pipeline subjected to seismic impact. The research method was analytical. The results were compared with the experimental results of other authors and computer calculations. It was shown that the main disadvantage of the dynamic theory of seismic resistance of underground pipelines is the neglect of the dynamic stress state in soil under seismic wave propagation. The next drawback of the dynamic theory is an inaccurate, approximate accounting for the displacement of the soil medium to which the underground pipeline is embedded. The complete interaction process includes the stages of nonlinear changes in the interaction force (the friction force) by manifesting its peak value and the Coulomb friction. The contact layer of soil undergoes shear deformations until complete structural destruction of the soil contact layer. The interaction force is the friction force, and its peak value does not appear. The seismic resistance of underground pipelines should be considered based on the theory of propagating seismic waves in a soil medium and the interaction of seismic waves with underground pipelines, i.e., based on the wave theory of seismic resistance of underground pipelines. A one-dimensional coupled problem of seismic resistance of underground pipelines under seismic impacts was posed based on the wave theory. An algorithm and a program for the numerical solution of the stated wave problems were developed using the method of characteristics and the method of finite differences. An analysis of the laws of interaction of underground pipelines with soil under seismic influences shows that it is necessary to use in the calculations the laws of interaction that account for the complete interaction processes observed in experiments. The analysis of the obtained numerical solutions and the posed coupled problems of the wave theory of seismic resistance of underground pipelines show the occurrence mechanisms of longitudinal stresses in underground pipelines under seismic influences. The results of calculations stated that an account for the dynamic stress normal to the underground pipeline’s outer surface leads to multiple increases in longitudinal stress in the underground pipeline. This multiple increase is due to the transformation of the interaction force into an active frictional force, resulting from a greater strain in soil than the one in the underground pipeline. Based on the analysis results, a theory of the seismic wave propagation process in an underground pipeline and surrounding soil was proposed. Full article

Dynamic displacement measurement of objects can be challenging due to the limitations of conventional methods and pricey instrumentation of unconventional methods, such as laser scanners. In this research, Close Range Photogrammetry (CRP) is used as an affordable non-contact method to measure 3D dynamic displacements. It is proposed as a reliable alternative to traditional dynamic deformation measurement methods such as displacement sensors or accelerometers. For this purpose, dynamic displacements of a three-dimensional one-story building frame model on a one-dimensional shake table are determined by using the traditional method of attached accelerometer and CRP. The results of the CRP method are compared with the results of the traditional methods as well as numerical models. The results show a good agreement which evidences the reliability of the CRP with regular cameras. Full article
