To explore the influence of mine roof on the damage and failure of sandstone surrounding rock under different pressure rates, mechanical experiments with different strain rates were carried out on sandstone rock samples. The strength, deformation, failure, energy and damage characteristics of rock samples with different strain rates were also discussed. The research results show that with the increases in the strain rate, peak stress, and elastic modulus show a monotonically increasing trend, while the peak strain decreases in the reverse direction. At a low strain rate, the proportion of the mass fraction of complete rock blocks in the rock sample is relatively high, and the shape integrity is good, while rock samples with a high strain rate retain more small-sized fragmented rock blocks. This indicates that under high-rate loading, the bifurcation phenomenon of secondary cracks is obvious. The rock samples undergo a failure form dominated by small-sized fragments, with severe damage to the rock samples and significant fractal characteristics of the fragments. At the initial stage of loading, the primary fractures close, and the rock samples mainly dissipate energy in the forms of frictional slip and mineral fragmentation. In the middle stage of loading, the residual fractures are compacted, and the dissipative strain energy keeps increasing continuously. In the later stage of loading, secondary cracks accelerate their expansion, and elastic strain energy is released sharply, eventually leading to brittle failure of the rock sample. Under a low strain rate, secondary cracks slowly expand along the clay–quartz interface and cause intergranular failure of the rock sample. However, a high strain rate inhibits the stress relaxation of the clay, forces the energy to transfer to the quartz crystal, promotes the penetration of secondary cracks through the quartz crystal, and triggers transgranular failure. A constitutive model based on energy damage was further constructed, which can accurately characterize the nonlinear hardening characteristics and strength-deformation laws of rock samples with different strain rates. The evolution process of its energy damage can be divided into the unchanged stage, the slow growth stage, and the accelerated growth stage. The characteristics of this stage reveal the sudden change mechanism from the dissipation of elastic strain energy of rock samples to the unstable propagation of secondary cracks, clarify the cumulative influence of strain rate on damage, and provide a theoretical basis for the dynamic assessment of surrounding rock damage and disaster early warning when the mine roof comes under pressure. Full article

Hydraulic concrete structures in cold regions often suffer from the combined action of freeze-thaw (FT) cycles and external loads, indicating that these structures often depend on the combined effects of two or more factors. In recent years, researchers around the world have made considerable efforts and explorations to solve this challenge, achieving fruitful research results. This article provides a comprehensive literature review on performance degradation law and model construction of hydraulic concrete under FT cycles. Firstly, the theory and characterization method of FT damage for concrete are introduced. Given the inherent deficiencies of traditional detection methodologies and the constraints imposed by extant computed tomography (CT) technology, there is an urgent need to develop a high-precision segmentation technique for concrete. By capitalizing on the resultant microstructure, a more accurate predictive model can be established. Thereafter, an in-depth discussion is conducted on the damage mechanism of hydraulic structures when subjected to freeze-thaw (FT) cycles in conjunction with external loading scenarios, namely fracture, direct tension, triaxial stress, and hydraulic wear. As the combined effects of different factors cause more serious damage to hydraulic structures than a single factor, the evolution law is more complex. Although researchers have attempted to reveal the deterioration mechanism of multi-factor interaction by means of numerical methods, there are still many fundamental issues that require further exploration and more in-depth research due to the limitations of constitutive models. Finally, the existing research results are summarized, and novel insights are proposed for future research directions. This study promptly identifies the gaps that urgently need to be filled, especially the insufficient understanding of the complex stress state of hydraulic concrete structures and the inadequate research on the performance deterioration law under multi-factor combined action. This investigation aims to determine the future research focus in relation to hydraulic concrete in cold regions that could advance the revelation of the deterioration mechanism caused by multi-factor interaction. By providing a detailed overview of the current hydraulic concrete structures in terms of the combined action of FT cycles and external loads, highlighting the research limitations, and suggesting future research directions, this review seeks to contribute to the safe operation of hydraulic concrete structures in cold regions. Full article

Cemented tailings backfill (CTB) plays an important role in mine filling operations. In order to study the long-term stability of CTB under the dynamic disturbance of deep wells, ultrafine cemented tailings backfill was taken as the research object, and the true triaxial hydraulic fracturing antireflection-wetting dynamic experimental system of coal and rock was used to carry out a static true triaxial compression test, a true triaxial compression test under unidirectional disturbance, and a true triaxial compression test under bidirectional disturbance. At the same time, the acoustic emission monitoring and positioning tests of the CTB were carried out during the compression test. The evolution law of the mechanical parameters and deformation and failure characteristics of CTB under different confining pressures is analyzed, and the damage constitutive model of the filling body is established using stochastic statistical theory. The results show that the compressive strength of CTB increases with an increase in intermediate principal stress. According to the change process of the acoustic emission ringing count over time, the triaxial compression test can be divided into four stages: the initial active stage, initial calm stage, pre-peak active stage, and post-peak calm stage. When the intermediate principal stress is small, the specimen is dominated by shear failure. With an increase in the intermediate principal stress, the specimen changes from brittle failure to plastic failure. The deformation and failure strength of CTB are closely related to its loading and unloading methods. Under a certain stress intensity, compared with unidirectional unloading, bidirectional unloading produces a greater deformation of the rock mass, and the failure strength of the rock mass is higher. This study only considers the confining pressure within the compressive limit of the specimen. Future research can be directed at a wider range of stresses to improve the applicability and reliability of the research results. Full article

Shale is a common rock in oil and gas extraction, and the study of its nonlinear mechanical behavior is crucial for the development of engineering techniques such as hydraulic fracturing. This paper establishes a new coupled elastic–plastic damage model based on the second law of thermodynamics, the strain equivalence principle, the non-associated flow rule, and the Drucker–Prager yield criterion. This model is used to describe the mechanical behavior of shale before and after peak strength and has been implemented in ABAQUS via UMAT for numerical computation. The model comprehensively considers the quasi-brittle and anisotropic characteristics of shale, as well as the strength degradation caused by damage during both the elastic and plastic phases. A damage yield function has been established as a criterion for damage occurrence, and the constitutive integration algorithm has been derived using a regression mapping algorithm. Compared with experimental data from La Biche shale in Canada, the theoretical model accurately simulated the stress–strain curves and volumetric–axial strain curves of shale under confining pressures of 5 MPa, 25 MPa, and 50 MPa. When compared with experimental data from shale in Western Hubei and Eastern Chongqing, China, the model precisely fitted the stress–strain curves of shale at pressures of 30 MPa, 50 MPa, and 70 MPa, and at bedding angles of 0°, 22.5°, 45°, and 90°. This proves that the model can effectively predict the failure behavior of shale under different confining pressures and bedding angles. Additionally, a sensitivity analysis has been performed on parameters such as the plastic hardening rate b, damage evolution rate B_ω, weighting factor r, and damage softening parameter a. This research is expected to provide theoretical support for the efficient extraction technologies of shale oil and gas. Full article

In order to study the evolution law of uniaxial compression damage and its characterization method, three kinds of rocks with different lithology that commonly exist in coal measure rock were taken as the research objects to explore the relationship between their mineral composition, microstructure and mechanical properties, and the feasibility of acoustic emission (AE) characteristic parameters and AE spatial location to characterize the evolution process of uniaxial compression damage of rocks was compared and analyzed. A damage constitutive model based on AE cumulative ringing count was established and verified by numerical simulation. The results show that the differences in the micromorphology and mineral composition of coal measures with different lithology directly affect their physical and mechanical properties and load damage characteristics. AE characteristic ringing count can effectively represent the damage evolution process of rock during loading. Based on rock porosity characteristics and AE cumulative ringing count during loading, a constitutive model considering initial damage and cumulative damage was established. The theoretical analysis results of the damage constitutive model are in good agreement with the results of laboratory experiments and numerical simulation, which can be used to analyze the damage process of coal measure rock under load. Full article

Numerous studies have demonstrated that under low-velocity, low-energy impact conditions, although the surface damage to fiber-reinforced composite laminates may be minimal, significant internal damage can occur. Consequently, a progressive damage finite element model was specifically developed for thermoplastic carbon fiber-reinforced composite laminates subjected to low-speed impact loads, with the objective of analyzing the damage behavior of laminates under impacts of varying energy levels. The model utilizes a three-dimensional Hashin criterion for predicting intralayer damage initiation, with cohesive elements based on bilinear traction–separation law for predicting interlaminar delamination initiation, and incorporates a damage constitutive model based on equivalent displacement to characterize fiber damage evolution, along with the B-K criterion for interlaminar damage evolution. The impact response of laminates at energy levels of 5 J, 10 J, 15 J, 20 J, and 25 J was analyzed through numerical simulation, drop-hammer experiments, and XCT non-destructive testing. The results indicated that the simulation outcomes closely correspond with the experimental findings, with both the predicted peak error and absorbed energy error maintained within a 5% margin, and the trends of the mechanical response curves aligning closely with the experimental data. The damage patterns predicted by the numerical simulations were consistent with the results obtained from XCT scans. The study additionally revealed that the impact damage of the laminates primarily stems from interlaminar delamination and intralayer tensile failure. Initial damage typically presents as internal delamination; hence, enhancing interlaminar bonding performance can significantly augment the overall load-bearing capacity of the laminate. Full article

In the field test, we found that the failure depth of the goaf floor strata tends to be further because the periodic breaking and caving of the immediate roof, upper roof, and roof key stratum has dynamic stress disturbance effects on the floor. To further analyze its formation mechanism, this paper studies the damage evolution and fracture mechanism of goaf floor rock under the coupled static-dynamic loading disturbance caused by roof caving, based on the stress distribution state, the damage evolution equation of coal measure rock, the damage constitutive model, and the fracture criterion of floor rock. The main conclusions are listed as follows: 1. Based on the mining floor stress distribution, the floor beam model establishes the response mechanism of floor rock stress distribution. Also, the equation of stress distribution at any position in floor strata under mining dynamic load is given. 2. Combining the advantages of Bingham and the Generalized-Boydin model, the B-G damage constitutive model is established, which can describe the constitutive characteristics of coal measure rock under the coupled static-dynamic loading disturbance well. Furthermore, the variation law of parameters changing with strain rate is analyzed. 3. According to the twin-shear unified strength yield theory and the B-G damage constitutive model, coal measure rock’s twin-shear unified strength damage fracture criterion is established. Finally, the stress distribution expression of floor strata under concentrated and uniform dynamic loads is introduced, and the fracture criterion of goaf floor strata under a coupled static-dynamic loading disturbance is proposed. Full article

The smelting process of Ferronickel in Indonesia produces a significant amount of waste in the form of Ferronickel Slag (FNS), with an annual accumulation of up to 13 million metric tons. Previous studies have shown promising strength results for concrete utilizing FNS as a fine aggregate. This study aims to analyze the mechanical properties of three reinforced concrete (RC) beams measuring 15 cm × 25 cm × 300 cm, each containing FNS as a 50% substitute for fine aggregate. The RC Beams underwent experimental testing using a four-point loading scheme under semi-cyclic loading conditions. Test results show the beams’ capacity had reached up to 8 ton-f and their load–displacement responses show promising results. Digital Image Correlation (DIC) analysis facilitated the observation of surface deformation evolution due to loading, aiding in the identification of concrete crack patterns. Due to semi-cyclic loading, cracks on the beams’ surface were experiencing a crack opening and closing phenomenon, where the propagations of cracks ceased or reclosed throughout the unloading process. Moreover, the opening of residual cracks was also captured by DIC analysis. The experimental finding was validated by finite element analysis. The RC beam numerical model was created using the Timoshenko Multi-fiber element in CAST3M software version 2022. Mazars concrete and elastoplastic steel damage model were used as constitutive laws for numerical modeling. The model’s load–displacement response demonstrated satisfactory agreement compared to the experimental monotonic loading result. However, the model had limitations regarding the simulation of residual displacements of beams due to semi-cyclic loading. Full article

Hydrogel-based devices commonly have a high demand for material durability when subjected to prolonged or cyclic loads. To extend their service life, it is crucial to have a deep understanding of the fatigue mechanisms of hydrogels. It is well-known that double-network (DN) hydrogels are characterized by high strength and toughness and are thus recognized as a promising candidate under load-bearing conditions. However, the existing studies in the literature mainly focus on their resistant capability to fatigue crack growth, while the underlying mechanisms of fatigue crack nucleation are still inconclusive. This work aims to bridge this knowledge gap by formulating a fatigue life predictor for DN hydrogels within the framework of configurational mechanics to elucidate the underlying mechanisms governing fatigue crack nucleation. The fatigue life predictor for DN hydrogels is derived from the configurational stress by incorporating the corresponding constitutive models and the thermodynamic evolution laws for microdamage mechanisms and material viscoelasticity. With the developed fatigue predictor, the effect of the microdamage mechanism on fatigue is elucidated, i.e., the internal damage of the sacrificial network can improve the fatigue life of DN hydrogels. The fatigue life predictor is also adopted to evaluate the effects of some other factors on the fatigue crack nucleation, such as the loading rate, pre-stretching treatment, and water diffusion, identifying feasible loading profiles that could improve material durability. Overall, the theoretical framework and the modeling results in this work are expected to shed light on unveiling the fatigue mechanisms of DN hydrogels and advance the design of hydrogel-based devices. Full article

In the field of oilfield fracturing development, a profound understanding of the evolution and propagation of damage during the fracturing process is crucial for preventing well water coning and channeling. This study aimed to unravel the complexity of damage evolution during fracturing and elucidate the causes of well water flooding phenomena. To accurately describe the damage propagation laws, a damage constitutive model considering compaction and post-peak correction parameters was established in this research. The model, through parameter adjustment, enhances the precision of stress calculation during the rock compaction phase and accounts for the stress degradation pattern subsequent to damage. This model was applied to simulate the damage evolution under various conditions in oil layer profiles and wellbore cross-sections, including the impact of different perforation angles, natural fracture patterns, and the ratio of longitudinal to transverse boundary pressures. The research concludes that well water channeling and flooding are primarily caused by damage propagation and the connectivity with adjacent water-bearing formations. The proposed rock damage constitutive model demonstrated an accuracy improvement of more than 3% compared to previous studies. Additionally, the study discovered that when the angle between the perforation section and the formation exceeds 30°, the risk of fracture propagation into adjacent layers increases, leading to an elevated risk of post-fracturing water flooding. The presence of natural fractures in the oil layer provides a conduit for damage propagation, accelerating the process of damage in the oil layer. Furthermore, the perforation angle and the ratio of boundary pressure loads during the fracturing process were identified as the main factors influencing the direction change of fracture propagation. The conclusions drawn from this study provide a scientific basis for preventing post-fracturing water channeling and flooding issues and offer new perspectives for the development of well fracturing technology, aiding in the resolution of water flooding problems associated with well fracturing. Full article

Revealing the damage mechanism of jointed rocks under a cyclic loading and formulating the corresponding dynamic constitutive model to meet the requirements for the evaluation of anti-vibration safety for critical engineering construction and operation is an essential, urgent and basic subject. Based on the breakage mechanics for geological material, jointed rock is considered as a binary-medium material composed of the bonded elements and frictional elements. The bonded elements are regarded as elastic-brittle elements, and the frictional elements are regarded as elastic-plastic elements. Firstly, the static binary-medium model for jointed rock is established based on the homogenization method and by introducing the breakage ratio and the strain concentration coefficient. Then, the dynamic binary-medium model for jointed rock under cyclic loads is established considering the nonlinear damage effect resulting from cyclic loads. The breakage ratio formula is improved, and the Drucker–Prager criterion is introduced. During the unloading stage, it is supposed that the breakage ratios and strain concentration coefficients remain unchanged and the stress–strain ratios of both bonded elements and frictional elements are constant. The model is verified by static and dynamic triaxial tests of jointed rock samples with an interpenetrated joint. It is found that the model can describe the nonlinear stress–strain characteristics of a jointed rock subjected to cyclic loads relatively well and can reflect the effects of cyclic loading on the deformation and damage, including the lateral deformation characteristics. Meanwhile, the typical three-stage (varying from sparse to dense to sparse) evolution laws of the stress–strain curves are also reflected relatively well. Full article

We chose to study the bottom structure stress evolution law in the process of undercut area advancement via the block caving method, reveal the influence law of the undercut rate on the effect of the ore body caving process, and assess the floor stress evolution law in the process of the undercut area with a different undercut rate in order to guide the production of a natural disintegration method under horizontal ground stress and also provide some reference value for rock damage assessment. According to the actual engineering and physical parameters of the mine, a numerical simulation model was created by using finite discrete element software GPI-3D-FDEM, and the Neo–Hookean hyperelastic constitutive model was adopted for calculation purposes. The simulation process follows a backward bottoming approach and monitors and analyses the stress state of the substructure after each bottoming step. The indoor physical model is employed to conduct similar two–dimensional simulation experiments on similar materials, investigating the motion laws of overlying rock layers. The research findings indicate that as bottom blasting progresses, a gradual concentration of compressive stress occurs in the foundation structure ahead of the advancing line. If this stress surpasses the rock mass’s shear failure limit, ground pressure failure may ensue. During mineral extraction from the bottom, internal stress within the fractured fault zone significantly diminishes compared to adjacent rock and ore deposits. Full article

Nuclear power is a high-quality clean energy source, but nuclear waste is generated during operation. The waste continuously releases heat during disposal, increasing the adjoining rock temperature and affecting the safety of the disposal site. Basalt is widely considered a commonly used rock type in the repository. This study of basalt’s mechanical characteristics and damage evolution after thermal damage, with its far-reaching engineering value, was conducted by combining experimental work and theory. Uniaxial compression tests were conducted on basalt exposed to 25 °C, 500 °C, 700 °C, 900 °C, and 1100 °C conditions, and acoustic emission (AE) equipment was utilized to observe the acoustic emission phenomenon during deformation. This study was carried out to examine the mechanical characteristics, the sound emission features, the progression of damage laws, and the stress–strain framework of basalt after exposure to different types of thermal harm. As the temperature rises, the rock’s maximum strength declines steadily, the peak strain rises in tandem, the rock sample’s ductility is augmented, the failure mode changes from shear to tensile failure, and cracks in the failure area are observed. At room temperature, the acoustic emission signal is more vigorous than in the initial stage of rock sample loading due to thermal damage; however, after the linear elastic stage is entered, its activity is lessened. In cases where the rock approaches collapse, there is a significant surge in acoustic emission activity, leading to the peak frequency of acoustic emission ringing. The cumulative ring count of acoustic emission serves as the basis for the definition of the damage variable. At room temperature, the damage evolution of rock samples can be broken down into four distinct stages. This defined damage variable is more reflective of the entire failure process. After exposure to high temperatures, the initial damage of the rock sample becomes more extensive, and the damage variable tends to be stable with strain evolution. The stress–strain constitutive model of basalt deformation is derived based on the crack axial strain law and acoustic emission parameters. A powerful relationship between theoretical and experimental curves is evident. Full article

The current constitutive model and damage evolution law of crumb rubber concrete (CRC) were obtained by fitting and changing parameters based on the normal concrete model. However, this model does not accurately reflect the characteristics of the material. In this paper, we studied the energy dissipation in the failure process of CRC to derive the constitutive model and damage evolution law of CRC based on the energy method. Four substitution rates of 5%, 10%, 15%, and 20% were selected, and the rubber concrete prism was prepared by replacing the natural fine aggregate with the same volume of crumb rubber aggregate. After that, uniaxial compressive tests were conducted. The energy lost due to the damage was calculated and analyzed, and the energy method was used to establish the damage evolution law and damage model of the crumb rubber concrete. The results demonstrated that the Guo Zhenhai damage model, which is based on the energy method, can more effectively explain the crumb rubber concrete stress–strain full curve, and the energy consumed as a result of the damage exhibits a growing and then reducing pattern with the increase in rubber doses. When the energy-based method is used, the Guo Zhenhai damage evolution model is similar to the damage evolution law calculated using the SIR damage evolution model. During uniaxial compression damage, rubber concrete with various rubber dosages demonstrated varying energy absorption in different deformation phases. When the rubber particle content was 10%, the energy absorption capacity of the specimen was 6.9% higher than that of normal concrete. Full article

A statistical damage model (SDM) of fully-graded concrete was created using statistical damage theory, based on the mechanical properties of axial tension and axial compression of the material. The SDM considers two damage modes, fracture and yield, and explains the intrinsic connection between the mesoscopic damage evolution mechanism and the macroscopic nonlinear mechanical behavior of fully-graded concrete. The artificial bee colony (ABC) algorithm was used to obtain the optimal parameter combination through an intelligent search of parameters ${\epsilon }_a$, ${\epsilon }_h$, ${\epsilon }_b$ and $H$ in the constitutive model by taking the test data as the target value, and the sum of the squares of the differences between the target value and the predicted value as the objective function. The SDM numerical simulation model of fully-graded concrete is proposed by compiling subroutines in FORTRAN by constructing two modules of data model and damage analysis. The numerical results under uniaxial and biaxial forces are in agreement with the experimental results, which verifies the accuracy of the program. The model also analyzes the characteristics of mesoscopic damage evolution and predicts the mechanical properties under triaxial forces. The results show that the proposed numerical simulation model can reflect the salient features for fully-graded concrete under uniaxial, biaxial and triaxial loading conditions, and the evolution law of mesoscopic parameters. Therefore, the proposed model serves as a basis for the refined finite element analysis of hydraulic fully-graded concrete structures and reveals the mesoscopic damage mechanism of concrete under different load environments. Full article
