Nowadays, Fused Filament Fabrication (FFF) 3D printing offers promising opportunities for the customized manufacturing of ankle–foot orthoses (AFOs) targeted towards rehabilitation purposes. Polypropylene (PP) represents an ideal candidate in orthotic applications due to its light weight and superior mechanical properties, offering an excellent balance between flexibility, chemical resistance, biocompatibility, and long-term durability. However, Additive Manufacturing (AM) of AFOs based on PP remains a major challenge due to its limited bed adhesion and high shrinkage, especially for making large parts such as AFOs. The primary innovation of the present study lies in the optimization of FFF 3D printing parameters for the fabrication of functional, patient-specific orthoses using PP, a material still underutilized in the AM of medical devices. Firstly, a thorough thermomechanical characterization was conducted, allowing the implementation of a (thermo-)elastic material model for the used PP filament. Thereafter, a Taguchi design of experiments (DOE) was established to study the influence of several printing parameters (extrusion temperature, printing speed, layer thickness, infill density, infill pattern, and part orientation) on the mechanical properties of 3D-printed specimens. Three-point bending tests were conducted to evaluate the strength and stiffness of the samples, while additional tensile tests were performed on the 3D-printed orthoses using a home-made innovative device to validate the optimal configurations. The results showed that the maximum flexural modulus of 3D-printed specimens was achieved when the printing speed was around 50 mm/s. The most significant parameter for mechanical performance and reduction in printing time was shown to be infill density, contributing 73.2% to maximum stress and 75.2% to Interlaminar Shear Strength (ILSS). Finally, the applicability of the finite element method (FEM) to simulate the FFF process-induced deflections, part distortion (warpage), and residual stresses in 3D-printed orthoses was investigated using a numerical simulation tool (Digimat-AM^®). The combination of Taguchi DOE with Digimat-AM for polypropylene AFOs highlighted that the 90° orientation appeared to be the most suitable configuration, as it minimizes deformation and von Mises stress, ensuring improved quality and robustness of the printed orthoses. The findings from this study contribute by providing a reliable method for printing PP parts with improved mechanical performance, thereby opening new opportunities for its use in medical-grade additive manufacturing. Full article

Background/Objectives: We sought to demonstrate the versatility and economy of physician-modified endograft (PMEG) fenestrated endovascular aortic repair (FEVAR) based on the Treo (Terumo Aortic) platform for patients referred for custom-made device (CMD) FEVAR due to a complex abdominal aortic aneurysm (CAAA). Endovascular planning was performed utilizing a standardized design incorporating all visceral arteries with a low supra-celiac landing zone. The pure cost of the aortic components was compared between the PMEG and CMD designs. Methods: A total of 39 consecutive patients treated with CMD FEVAR due to a CAAA between September 2018 and December 2023 were recruited at a tertiary vascular center for a retrospective evaluation. Endovascular planning was performed on readily available computed tomography angiography (CTA) datasets using 3Mensio Vascular (Pie Medical Imaging) software. The actual cost of the major components was compared between the implanted CMD platform produced by Cook and the planned Treo-based PMEG repair. Results: A total of 155 fenestrations were planned on 3 triple-, 34 quadruple-, and two quintuple-fenestrated devices. The 90 mm distance between the proximal edge and the flow divider of the 120 mm long main body of the Treo graft allowed for the placement of all necessary fenestrations of the target arteries without the need to reduce the 3 cm supra-celiac landing zone while also preserving a safety distance of >1 cm to the flow divider. The costs of the components were EUR 33896 for CMD and EUR 8878 for a PMEG. Conclusions: This retrospective study suggests that a quadruple-fenestrated PMEG based on the Treo bifurcation is a highly versatile alternative with a significant price advantage over custom-made devices for the treatment of complex abdominal aortic aneurysms. Full article

Passive Dynamic Ankle–Foot Orthoses (PD-AFOs) are medical devices prescribed to individuals with foot drop, a condition characterized by weakness of the ankle dorsiflexor muscles. PD-AFOs can store and release energy during the stance phase of the gait cycle, while supporting the foot in the swing phase. This study aimed at estimating the energetics of a novel fiberglass-reinforced polyamide custom PD-AFO in a population of mild foot drop patients. Eight PD-AFOs were designed and 3D-printed via selective laser sintering for eight participants with a unilateral foot drop condition. Lower limb kinematics and AFO flexion/extension were recorded during comfortable walking speed via skin marker-based stereophotogrammetry. The stiffness of each AFO was measured via an ad hoc experimental setup. The elastic work performed by the PD-AFO during gait was calculated as the dot product of the calf-shell resisting moment and the rotation angle. The average maximum energy stored by the calf-shell across all PD-AFOs was 0.013 ± 0.005 J/kg. According to this study, 3D-printed custom PD-AFOs made with fiberglass-reinforced polyamide can store some elastic energy, which is released to the ankle during push-off. Further studies should be conducted to assess the effect of this energy return mechanism in improving the gait of individuals with deficits of the ankle plantarflexor muscles. Full article

Temporomandibular joint replacement is a critical intervention for severe temporomandibular joint disorders, enhancing pain levels, jaw function and overall quality of life. In this study, we compare two finite element method-based simulation workflows from both academic and industrial perspectives, focusing on a patient-specific case involving a custom-made temporomandibular joint prosthesis. Using computed tomography data and computer-aided design data, we generated different 3D models and performed mechanical testing, including wear and static compression tests. Our results indicate that the academic workflow, which is retrospective, purely image-based and applied post-operatively, produced peak stress values within 9–20% of those obtained from the industrial workflow. The industrial workflow is prospective, pre-operative, computer-aided design-based and guided by stringent regulatory standards and approval protocols. Observed differences between workflows were attributed primarily to distinct modelling assumptions, simplifications and constraints inherent in each method. To explicitly quantify these differences, multiple additional models were generated within the academic workflow using partial data from the industrial process, revealing specific sources of variation in stress distribution and implant performance. The findings underscore the potential of patient-specific simulations not only to refine temporomandibular joint prosthesis design and enhance patient outcomes, but also to highlight the interplay between academic research methodologies and industrial standards in the development of medical devices. Full article

Background and Objectives: Obstructive sleep apnea is an extremely diffuse pathology that, if left untreated, can lead to very serious cardiovascular consequences. The primary goal of treatment is to maintain airflow in the upper airway tract, which can be obtained thanks to orthognathic surgery such as maxillo-mandibular advancement (MMA). This procedure increases the volume of the posterior airway space (PAS)—a parameter considered fundamental in OSA physiology. However, the correlation between the degree of advancement, the volume increase, and the clinical improvement in OSA is not yet clear, even in patients who undergo virtual surgical planning. Aiming to test the correlation of these parameters and the role of PAS volume changes, we present our pre- and post-operative volumetric analysis of the PAS using cone beam computed tomography (CBCT) following CAD/CAM-assisted maxillomandibular advancement. Materials and Methods: We collected information from patients who underwent MMA for moderate or severe OSA, planned virtually with custom-made devices, between 2020 and 2022 at the Maxillofacial Surgery and Odontostomatology Unit of the Policlinico Hospital in Milan. The degree of mandibular advancement (pogonion antero-posterior advancement) was noted. All patients underwent pre- and post-operative CBCT and pre- and post-operative polysomnography to measure the Apnea–Hypopnea Index (AHI) parameters. Both exams were performed within six months before and after surgery. The surgeries were planned virtually along with the production of custom-made devices (cutting guides and mandibular osteosynthesis plates). Volumetric analysis of the PAS was performed pre- and post-CBCT images using medical segmentation software (Mimics, Materialise, Mimcs 26.0). Results: Ten patients (nine men and one woman) with a mean age of 51 years were included in this study. The mean pogonion advancement was 14.5 mm, ranging from 13.8 to 15.6. The mean pre-surgical AHI was 52.31 events/h, while the mean post-surgical AHI was 5.94 events/h (SD 5.34). The improvement in AHI was statistically significant (Wilcoxon matched-pairs signed-rank test, p value 0.004). The mean pre-surgical PAS volume was 8933 mm³, while the mean post-surgical volume was 10,609 mm³. In 8 out of 10 patients, the volume increased, with a mean increase of 2640 mm³ (max. 5183, min. 951), corresponding to a percentage increase variation ranging from 78% to 6%. In two patients, the volume decreased by 1591 (−16%) and 2767 mm³ (−31%), respectively. The difference between pre- and post-operative results was not statistically significant (paired t-test, p value 0.033). Conclusions: The results obtained confirm the efficacy of virtually planned MMA performed with custom-made devices in OSA therapy. However, they also show that PAS volume should not be used as a comprehensive parameter for OSA treatment evaluation because it does not always have a positive correlation with advancement and AHI. Full article

Objectives: This study aims to develop and validate a standardized methodology for creating high-fidelity, custom-made, patient-specific 3D-printed vascular models that serve as tools for preoperative planning and training in the endovascular treatment of peripheral artery disease (PAD). Methods: Ten custom-made 3D-printed vascular models were produced using computed tomography angiography (CTA) scans of ten patients diagnosed with PAD. CTA images were analyzed using Syngo.via by a specialist to formulate a medical prescription that guided the model’s creation. The CTA data were then processed in OsiriX MD to generate the .STL file, which is further refined in a Meshmixer. Stereolithography (SLA) 3D printing technology was employed, utilizing either flexible or rigid materials. The dimensional accuracy of the models was evaluated by comparing their CT scan images with the corresponding patient data, using OsiriX MD. Additionally, both flexible and rigid models were evaluated by eight vascular surgeons during simulations in an in-house-designed setup, assessing both the technical aspects and operator perceptions of the simulation. Results: Each model took approximately 21.5 h to fabricate, costing €140 for flexible and €165 for rigid materials. Bland–Alman plots revealed a strong agreement between the 3D models and patient anatomy, with outliers ranging from 4.3% to 6.9%. Simulations showed that rigid models performed better in guidewire navigation and catheter stability, while flexible models offered improved transparency and lesion treatment. Surgeons confirmed the models’ realism and utility. Conclusions: The study highlights the cost-efficient, high-fidelity production of 3D-printed vascular models, emphasizing their potential to enhance training and planning in endovascular surgery. Full article

Introduction: Given the high risk of peri-operative morbidity and mortality associated with open repair, endovascular repair for thoraco-abdominal aneurysms is increasingly performed. This study aims to describe mid to long-term results for patients who were treated with COOK Custom-Made Endograft Device at a single Southeast Asian tertiary centre. Methods: Mid to long-term results of patients treated from 2012 to 2022 were retrospectively reviewed. Indications for treatment were aortic diameter > 5.5 cm, enlargement > 5 mm in 6 months or high-risk morphology. Clinical, operative, early to late complications and reintervention details were captured. The endpoints were technical success, primary patency and primary assisted patency. Results: Electronic medical records of 29 consecutive patients (64.4 ± 1.6 years old; 26/29 males 89.6%) were reviewed. 24/29 (83%) were hypertensive, and 20/29 (69%) were smokers. The mean diameter was 5.5 cm, and the majority were treated for Crawford type IV (19/29, 65.5%). Endograft deployment was 100%. Catheterisation of fenestration was successful in 109/116 (94%). 30-day mortality and morbidity were observed in 12/29 (41%), for which access site complications were most common. No significant haemorrhage or graft explant was recorded. The mean follow-up period was 32.4 months (range 1–108 months). Primary patency was 92.9% (95% CI: 83.8–100.0) at 6 months and decreased to 77.7% (95% CI: 63.4–95.2) at 24 months. Sac shrinkage or stability was noted in 17/29 (58.6%). Re-intervention was performed in 9/29 (31%) for limb occlusion (2/9, 22.2%), renal artery stent occlusion (1/9, 11.1%) and endoleaks (6/9, 66.6%). Assisted patency was maintained at 100% for 12 months before decreasing to 66.7% (95% CI: 37.9–100.0) at 24 months. Conclusions: The study reports the first mid-long-term result in this region, though limited by the sample size. Re-intervention at 30% suggests that disease and procedures remain challenging, emphasising the need to assimilate lessons and experience at high-volume centres. Full article

Obstructive sleep apnea (OSA) is a prevalent source of sleep-disordered breathing. OSA is most commonly associated with dysfunctions in the genioglossus (GG) muscle. In this study, we present the first version of a medical device that produces an electromyogram (EMG) of the GG. The prototype is composed of a (custom-made) 3D-printed mouthpiece. Impressions were taken for the lower arch and scanned with a lab scanner to be converted into digital impressions. ExoCad software was used to design the appliance. Fusion 360 software was then used to modify the design and create tubes to house the electrodes in a bilateral configuration to secure excellent and continuous contact with the GG muscle. Silver–silver chloride electrodes were incorporated within the appliance through the created tubes to produce a muscle EMG. In this preliminary prototype, an EMG amplifier was placed outside the mouth, and isolated electric wires were connected to the amplifier input. To test the design, we ran experiments to acquire EMG signals from a group of OSA patients and a control group in wakefulness. The GG EMGs were acquired from the participants for 60 s in a resting state whereby they rested their tongues without performing any movement. Then, the subjects pushed their tongues against the fontal teeth with steady force while keeping the mouth closed (active state). Several features were extracted from the acquired EMGs, and statistical tests were applied to evaluate the significant differences in these features between the two groups. The results showed that the mean power and standard deviation were higher in the control group than in the OSA group (p < 0.01). Regarding the wavelength during the active state, the control group had a significantly longer wavelength than the OSA group (p < 0.01). Meanwhile, the mean frequency was higher in the OSA group (p < 0.01) at rest. These findings support research that showed that impairment in GG activity continues in the daytime and does not only occur during sleep. Future research should focus on developing the device to be more user-friendly and easily used at home during wakefulness and sleep. Full article

Background: Endotracheal intubation (ETI) is a cornerstone of airway management. The gold standard device for ETI is still the direct laryngoscope (DL). However, video laryngoscopes (VLs) are now also widely available and have several proven advantages. The VL technique has been included in the major airway management guidelines. During the COVID-19 pandemic, supply chain disruption has raised demand for 3D-printed medical equipment, including 3D-printed VLs. However, studies on performance are only sparsely available; thus, we aimed to compare 3D-printed VLs to the DL and other VLs made with conventional manufacturing technology. Methods: Forty-eight medical students were recruited to serve as novice users. Following brief, standardized training, students executed ETI with the DL, the King Vision^® (KV), the VividTrac^® (VT), the AirAngel Blade^® (AAB), and a custom-made 3D-printed VL (3DVL) on the Laerdal^® airway management trainer in normal and difficult airway scenarios. We evaluated the time to and proportion of successful intubation, the best view of the glottis, esophageal intubation, dental trauma, and user satisfaction. Results: The KV and VT are proved to be superior (p < 0.05) to the DL in both scenarios. The 3DVL’s performance was similar (p > 0.05) or significantly better than that of the DL and mainly non-inferior (p > 0.05) compared to the KV and VT in both scenarios. Regardless of the scenario, the AAB proved to be inferior (p < 0.05) even to the DL in the majority of the variables. The differences between the devices were more pronounced in the difficult airway scenario. The user satisfaction scores were in concordance with the aforementioned performance of the scopes. Conclusions: Based upon our results, we cannot recommend the AAB over the DL, KV, or VT. However, as the 3DVL showed, 3D printing indeed can provide useful or even superior VLs, but prior to clinical use, meticulous evaluation might be recommended. Full article

Embedded computers are ubiquitous in products across various industries, including the automotive and medical industries, and in consumer goods such as appliances and entertainment devices. These specialized computing systems utilize Systems on Chips (SoCs), devices that are made up of one or more main microprocessor cores. SoCs are augmented with sub-blocks that perform dedicated tasks to support the system. Sub-blocks contain custom logic or small-footprint microprocessors, depending upon their complexity, and perform support functions such as clock generation, device testing, phase-locked loop synchronization and peripheral management for interfaces such as a Universal Serial Bus (USB) or Serial Peripheral Interface (SPI). SoC designers have traditionally obtained sub-blocks from commercial vendors. While these sub-blocks have well-defined interfaces, their internal implementations are opaque. Without visibility of the specifics of the implementation, SoC designers are limited to the degree to which they can optimize these off-the-shelf sub-blocks. The result is that power and area constraints are dictated by the design of a third-party vendor. This work introduces a novel idea: using an open-source, small, multitasking, real-time operating system inside an SoC sub-block to manage multiple processes, thereby conserving code space. This OS is TurbOS, a new operating system whose primary goal is to provide the highest performance using the least amount of space. It is written in the assembly language of a new pipelined 16-bit microprocessor developed at the University of Florida, the Turbo9. TurbOS is derived from and incorporates the design benefits of an existing operating system called NitrOS-9, and reduces the code size from its progenitor by nearly 20%. Furthermore, it is over 80% smaller than the popular FreeRTOS operating system. TurbOS delivers a rich feature set for managing memory and process resources that are useful in SoC sub-block applications in an extremely small footprint of only 3 kilobytes. Full article

In this comprehensive review, the current state of the art and recent advances in 3D printing in dentistry are explored. This article provides an overview of the fundamental principles of 3D printing with a focus on vat photopolymerization (VP), the most commonly used technological principle in dental practice, which includes SLA, DLP, and LCD (or mSLA) technologies. The advantages, disadvantages, and shortcomings of these technologies are also discussed. This article delves into the key stages of the dental 3D printing process, from computer-aided design (CAD) to postprocessing, emphasizing the importance of postrinsing and postcuring to ensure the biocompatibility of custom-made medical devices. Legal considerations and regulatory obligations related to the production of custom medical devices through 3D printing are also addressed. This article serves as a valuable resource for dental practitioners, researchers, and health care professionals interested in applying this innovative technology in clinical practice. Full article

The Internet of Things (IoT) is rapidly growing and is projected to develop in future years. The IoT connects everything from Closed Circuit Television (CCTV) cameras to medical equipment to smart home appliances to smart automobiles and many more gadgets. Connecting these gadgets is revolutionizing our lives today by offering higher efficiency, better customer service, and more effective goods and services in a variety of industries and sectors. With this anticipated expansion, many challenges arise. Recent research ranked IP cameras as the 2nd highest target for IoT attacks. IoT security exhibits an inherent asymmetry where resource-constrained devices face attackers with greater resources and time, creating an imbalanced power dynamic. In cybersecurity, there is a symmetrical aspect where defenders implement security measures while attackers seek symmetrical weaknesses. The SILEX malware case highlights this asymmetry, demonstrating how IoT devices’ limited security made them susceptible to a relatively simple yet destructive attack. These insights underscore the need for robust, proactive IoT security measures to address the asymmetrical risks posed by adversaries and safeguard IoT ecosystems effectively. In this paper, we present the IoT vulnerabilities, their causes, and how to detect them. We focus on SILEX, one of the famous malware that targets IoT, as a case study and present the lessons learned from this malware. Full article

Introduction: A fenestrated endograft (FE) is the first-line endovascular option for juxta and pararenal abdominal aortic aneurysms. A physician-modified stent-graft (PMSG) and laser in situ fenestration (LISF) have emerged to circumvent manufacturing delays, anatomic standards, and the procedure’s cost raised by FE. The objective was to compare different fenestrations from a mechanical point of view. Methods: In total, five Zenith Cook fenestrations (Cook Medical, Bloomington, IN, USA) and five Anaconda fenestrations (Terumo Company, Inchinnan, Scotland, UK) were included in this study. Laser ISF and PMSG were created on a Cook TX2 polyethylene terephthalate (PET) cover material (Cook Medical, Bloomington, IN, USA). In total, five LISFs and fifty-five PMSG were created. All fenestrations included reached an 8 mm diameter. Radial extension tests were then performed to identify differences in the mechanical behavior between the fenestration designs. The branch pull-out force was measured to test the stability of assembling with a calibrated 8 mm branch. Fatigue tests were performed on the devices to assess the long-term outcomes of the endograft with an oversized 9 mm branch. Results: The results revealed that at over 2 mm of oversizing, the highest average radial strength was 33.4 ± 6.9 N for the Zenith Cook fenestration. The radial strength was higher with the custom-made fenestrations, including both Zenith Cook and Anaconda fenestrations (9.5 ± 4.7 N and 4.49 ± 0.28 N). The comparison between LISF and double loop PMSG highlighted a higher strength value compared with LISF (3.96 N ± 1.86 vs. 2.7 N ± 0.82; p= 0.018). The diameter of the fenestrations varied between 8 and 9 mm. As the pin caliber inserted in the fenestration was 9 mm, one could consider that all fenestrations underwent an “elastic recoil” after cycling. The largest elastic recoil was observed in the non-reinforced/OC fenestrations (40%). A 10% elastic recoil was observed with LISF. Conclusion: In terms of mechanical behavior, the custom-made fenestration produced the highest results in terms of radial and branch pull-out strength. Both PMSG and LISF could be improved with the standardization of the fenestration creation protocol. Full article

Additive manufacturing (AM) technologies enable the production of customized and personalized medical devices that facilitate users’ comfort and rehabilitation requirements according to their individual conditions. The concept of a tailor-made orthopedic device addresses the accelerated recovery and comfort of the patient through the utilization of personalized rehabilitation equipment. Direct modeling, with an increasing number of approaches and prototypes, has provided many successful results until now. The modeling procedure for 3D-printed orthoses has emerged as the execution of steady and continuous tasks with several design selection criteria, such as cutting, thickening the surface, and engraving the shell of the orthosis. This publication takes into consideration the aforementioned criteria and proposes the creation of a holistic methodology and automated computational design process for the customization of orthotic assistive devices, considering aspects such as material properties, manufacturing limitations, recycling, and patients’ requirements. This proposal leads to the designing and manufacturing of a wrist orthopedic device based on reverse engineering, Design for AM (DfAM), and Design for Recycling (DfR) principles. The proposed methodology can be adjusted for different limbs. A dual-material approach was attained utilizing rigid, mechanically enhanced feedstock material and soft elastic material with reduced skin irritation risks to achieve both mechanical requirements and adequate cushioning for user comfort during rehabilitation. Recyclable thermoplastic matrices were selected, which also allow for the option to create washable devices for product life extension. Then, 3D scanning procedures were implemented to acquire the initial anatomic measurements for the design of the WHO and ensure and assess the dimensional accuracy of the final product. Physical mechanical testing was implemented to evaluate the WHO’s mechanical behavior and verify its functionality during basic wrist movements. The extracted dimensional data for the two main orthosis components that indicated approximately 50% and 25% of the tolerance values, respectively, were within the range (−0.1 mm, 0.1 mm). Full article

Three-dimensional (3D) printed splints must be lightweight and adequately ventilated to maximize the patient’s convenience while maintaining requisite strength. The ensuing loss of strength has a substantial impact on the transformation of a solid splint model into a perforated or porous model. Thus, two methods for making perforations—standard approach and topological optimization—are investigated in this study. The objective of this research is to ascertain the impact of different perforation shapes and their distribution as well as topology optimization on the customized splint model. The solid splint models made of various materials have been transformed into porous designs to evaluate their strength by utilizing Finite Element (FE) simulation. This study will have a substantial effect on the designing concept for medical devices as well as other industries such as automobiles and aerospace. The novelty of the research refers to creating the perforations as well as applying topology optimization and 3D printing in practice. According to the comparison of the various materials, PLA had the least amount of deformation and the highest safety factor for all loading directions. Additionally, it was shown that all perforation shapes behave similarly, implying that the perforation shape’s effect is not notably pronounced. However, square perforations seemed to perform the best out of all the perforation shape types. It was also obvious that the topology-optimized hand splint outperformed that with square perforations. The topology-optimized hand splint weighs 26% less than the solid splint, whereas the square-perforated hand splint weighs roughly 12% less. Nevertheless, the user must choose which strategy (standard perforations or topology optimization) to employ based on the available tools and prerequisites. Full article
