Asynchronous-pouring construction (APC) technology employs a suspended hanging basket directly supported by corrugated steel webs (CSWs) with high shear strength, significantly enhancing construction efficiency. To further elucidate the characteristics of APC and promote its application in prestressed concrete (PC) composite box girder bridges with CSWs, this study analyzes the sustainable development of APC from two aspects, including environmental impact and economic performance. Finite element models of APC and traditional balanced cantilever construction (TBCC) were established for the case bridge with a main span of 105 m. The stress distribution and deflection of the main girder in the cantilever construction state are compared with field measurements, and the variations in stress and deflection in typical sections during construction are analyzed. Additionally, a simplified theoretical method is proposed for calculating stress and deflection in PC composite girder bridges during the cantilever construction stage using APC. Results demonstrate that APC demonstrates significant advantages in reducing economic costs and minimizing long-term environmental impacts. Furthermore, this method ensures acceptable stress and deflection throughout construction. The proposed simplified formula for CSW deflection in the maximum segment agrees well with both measured data and finite element results, providing a valuable reference for deflection calculation in APC applications. Full article

Metal inert gas (MIG) brazing was used to join galvanized thin sheets with thicknesses in the range of 0.8 to 2 mm in a lap joint configuration using CuAl₈ wire as filler. The process was used to manufacture built-up cold-formed steel beams composed of corrugated steel webs and flanges made from thin-walled cold-formed steel lipped channel profiles. The effect of heat input and sheet thickness on joint properties, such as macro- and microstructure, wettability, and mechanical characteristics such as microhardness and tensile strength were investigated. The bead geometry was assessed by studying the wettability of the filler material. The microstructure was investigated by digital and scanning electron microscopy, and the composition in the heat-affected zone (HAZ), interface, and bead was determined by energy dispersive spectroscopy. Formation of Fe–Al intermetallics was observed in the bead at the bead–base material interface. Some pores were noticed that formed due to the evaporation of the zinc coating. The bead shape and mechanical properties were found to be the best when 1.2 and 2 mm sheets were brazed using a heat input of 121.4 J/mm. This suggests that not only the heat input but also the thickness of the sheet metal play a crucial role in the production of MIG brazed joints. Full article

This study investigates the vehicle–bridge coupling vibration performance of corrugated steel web box girder bridges under three-dimensional pavement roughness conditions. To effectively account for these roughness characteristics, a three-dimensional contact constraint method is proposed. The accuracy of the proposed method is first verified, followed by an analysis of a 30 m span corrugated steel web box girder bridge to evaluate the influence of vehicle speed, pavement grade, roughness dimensions, and box girder configurations on the impact factor. The results show that the impact factor does not consistently increase with vehicle speed. As pavement conditions worsen, the impact factor shows an upward trend, with each grade of road surface deterioration resulting in an average 19.1% increase in the impact factor. In most scenarios, three-dimensional pavement roughness results in smaller impact factors compared to two-dimensional pavement roughness, with average reductions of 2.4%, 7.3%, and 13.5% for grade A, B, and C roads, respectively. Replacing the corrugated steel web with a flat steel web leads to an average reduction of 4.2% in the mid-span dynamic deflection of the bridge, despite the impact factors of both configurations being relatively similar. Substituting the concrete bottom slab with an equivalent steel bottom slab increases the mid-span dynamic deflection by an average of 28.4% and nearly doubles the impact factor. The impact factors determined by most national standards generally fall within the range for grade A pavement, suggesting that the calculation methods in these standards are mainly suited for newly constructed bridges or those in good maintenance. Full article

The issues of numerous steel beam components and the tendency for deck cracking under negative bending moment zones have long been challenges faced by traditional composite I-beams with flat steel webs. This study introduces an optimized approach by modifying the structural design and material selection, specifically substituting flat steel webs with corrugated steel webs and using ultra-high-performance concrete for the deck in the negative bending moment zone. Three sets of model tests were conducted to compare and investigate the influence of deck material and web forms on the bending and crack resistance of steel–concrete composite I-beams under a negative bending moment zone. The findings indicate that, compared to a conventional steel–normal concrete composite I-beam, incorporating ultra-high performance concrete into the negative bending zone enhances the cracking load by 98%, resulting in finer and denser cracks, and improves the ultimate bearing capacity by approximately 10%. In comparison to the composite I-beam with flat steel webs, the longitudinal stiffness of the composite I-beam with corrugated steel webs is smaller, which can further enhance the bridge deck’s resistance to cracking in the negative bending moment zone, and maximize the steel-strengthening effect of the lower flange of the steel I-beam. Based on the findings of this study, it is recommended to use steel ultra-high-performance concrete composite I-beams with corrugated steel webs due to their superior crack resistance, bending strength, and efficient material utilization. Full article

Composite box girders with corrugated steel webs (CBGCWs) have attracted increasing attention in bridge engineering. However, the shear lag effect has an impact on the mechanical behavior of thin-walled box girders and the impact of transverse deformation on this effect is usually neglected. In this study, a modified energy variational method is proposed to quantify the shear lag effect on CBGCWs. The shear deformations of each flange are analyzed based on the mechanical properties of the corrugated steel webs. A shear-lag warpage displacement function is introduced for each flange to account for the shear lag effect due to transverse deformation of the top flange. The formulation for the shear lag effect on CBGCWs is then derived using the principle of the energy variational method. The feasibility and accuracy of the proposed method are validated through a numerical study of a simply supported CBGCW subjected to uniform loading. In addition, a parametric analysis of the shear lag effect on CBGCWs is conducted. The results demonstrate that local bending deformation of the top flange leads to an uneven distribution of shear lag effects and the shear lag effect on corrugated steel webs is significantly influenced by the width–to–span ratio. Full article

Recently, steel girders with sinusoidal corrugations have become increasingly popular compared to those with traditional flat webs. This paper presents the second part of the research on the application of corrugated plates with different sinusoidal profiles as webs in girders. Parametric studies have been carried out in both linear and nonlinear domains, based on a representative numerical model developed and validated by experimental results. The research focused on the influence of the sinusoidal shape of the web on the shear capacity of the girders and the ultimate failure mode. The analyses were carried out using Abaqus software. Based on the results of the numerical analyses, it was concluded that increasing the wavelength of the sinusoidal wave decreases the ultimate shear capacity of the girders. This parameter also influences the failure mode. The results show that the wave amplitude has a small effect on the critical capacity. However, the amplitude influences the increase in the post-critical load and the size of the plastic zones located in the webs during the final phase of failure. With regard to the geometric parameters of the web, it was found that increasing the web thickness significantly improves the performance of the girders, while the web height has a negligible effect. It was also shown that the design guidelines in Eurocode 3 are very conservative in terms of estimating the shear buckling capacity of beams with sinusoidal corrugated webs and significantly underestimate the values. Full article

Corrosive environments can adversely affect the fatigue performance of bridges and other building structures. In order to determine the influence of corrosion on the fatigue failure of concrete composite girders with a corrugated web on a steel bottom plate (hereinafter referred to as CGCWSB), a scaled model test was conducted on a CGCWSB with a span of 30 m, which served as the structural prototype. Through the model test, theoretical analysis, and numerical simulation, the influence of uniform corrosion and pitting corrosion on the fatigue failure of the CGCWSB was determined, and the propagation law of pitting fatigue crack was determined. The results show that (1) the uniform corrosion caused the stress of the CGCWSB to become larger and the performance of the CGCWSB was reduced, the stress growth of the test girder after corrosion was about 10%, the corrosion rate was 9%, the pitting unevenness coefficient was 1.25, and the relative corrosion life was 26.34 years; (2) the fatigue failure of the non-corroded girder belongs to the weld fatigue failure, and the fatigue failure of the corroded girder was the coexistence of weld fatigue failure and pitting fatigue failure; (3) uniform corrosion did not create a new fatigue source, but it did result in the test girder’s fatigue failure ahead of time. Pitting corrosion did, however, create a new fatigue source; (4) an exponential correlation was present between the propagation length of a pitting crack and the number of equal load cycles. The ultimate failure mode of a pitting fatigue crack was when the crack length reached the thickness of the plate and the component was torn and destroyed; (5) following corrosion, the fatigue life of the test girder was found to be reduced by 10.65%, which suggests that salt corrosion had a significant impact on the fatigue life of the composite girder. This research work can provide a reference for the design and promotion of the use of the CGCWSB. Full article

To improve the out-of-plane stability of partially encased composite (PEC) beam webs and enhance the synergy between concrete and section steel, a new type of wavy web PEC beam was designed and fabricated. In this study, the flange thickness and shear–span ratio were varied as key parameters. Low-cycle reversed loading tests were conducted to investigate the effects of these variables on the load-bearing capacity, failure patterns, deformation capacity, hysteretic energy dissipation capacity, and stiffness degradation of the wavy web PEC beams. Numerical simulations were performed using ABAQUS CAE2023, a finite element analysis (FEA) software, under low-cycle reversed loading conditions. The applicability of the ABAQUS software CAE2023 for the corrugated web PEC beam model was validated by comparing test results with finite element analysis results. A detailed parametric analysis was then carried out using the finite element model to further investigate the mechanical properties of the wavy web PEC beams. The research findings are as follows: the wavy web PEC beams exhibited good ductility; a larger shear–span ratio led to a transition in the failure pattern from shear failure to flexural failure; varying the flange thickness significantly affected the failure location and characteristics; and reducing the flange thickness could limit the propagation of concrete cracks, thereby improving toughness and energy dissipation capacity. Full article

Based on an analysis of the extant literature, this paper summarizes the research progress on the mechanical properties and long-term behavior of corrugated steel web (CSW) box girder bridges. First, the research results of CSW box girder bridges in terms of the shear buckling performance (local shear buckling, overall shear buckling, and interaction buckling), bending performance, bending capacity, torsional capacity, and coefficient of internal force increase are summarized, along with the main factors affecting the mechanical performance of CSW box girder bridges. Second, based on research on the self-oscillation characteristics and dynamic response of CSW box girder bridges, the influence of structural parameters on the self-oscillation characteristics is analyzed. Finally, the long-term mechanical behavior of the CSW box girder bridges is analyzed in terms of fatigue, creep, and temperature effects. The existing research results demonstrate that there still exist deficiencies in the mechanical properties and long-term behavior of CSW box girder bridges, and this paper thus suggests a future research focus on CSW box girder bridges to provide a reference for further improving their basic theoretical system. Full article

This study theoretically and numerically examines the differences in shear performance between tapered and prismatic girder configurations with corrugated steel webs (CSWs) and investigates the influence of the Resal effect on the shear performance of tapered girders with CSWs. The vertical components of the inclined bottom slab forces (which are zero in prismatic cases) may decrease or increase the effective shear force on the CSWs, reflecting the positive and negative influences of the Resal effect. Based on these influences, this study introduces the concepts of positive and negative Resal effects and proposes an improved shear method to predict the effective shear forces acting on tapered CSWs. The results of the theoretical and finite element (FE) analyses show that the traditional shear method, which assumes CSWs bear all the shear force, is not applicable to tapered girders. The improved shear method significantly reduced the error in predicting shear forces within the CSWs, decreasing the maximum error from 42.25% (traditional method) to 7.71% (improved method) in specific sections. Quantitative analyses of three different types of girders with CSWs indicate that the Resal effect is influenced by both the internal forces and the structural form of the box girder. In cases of a positive Resal effect, the inclined bottom slab shares a considerable portion of the shear force with CSWs, resulting in a surplus shear capacity in the CSWs; conversely, under a negative Resal effect, there is an increase in the effective shear force on the web, which could lead to an overestimation of the shear buckling strength of CSWs. These findings highlight the necessity of incorporating Resal effects for accurate shear force predictions in tapered girders. By accurately predicting shear forces, engineers can enhance the performance and reliability of these structures, avoiding both overestimation and underestimation of shear capacities. Full article

The article discusses a solution to the relevant task of analyzing and designing modular buildings made of blocks to be used in industrial and civil engineering. A block that represents a container is a combination of plate and beam systems. The criteria for its failure include both the strength of the individual elements and the loss of stability in a corrugated web. Methods of engineering analysis are hardly applicable to this system. Numerical analysis based on the finite element method is time-consuming, and this fact limits the number of design options for modular buildings made of blocks. Adjustable machine learning models are proposed as a solution to these problems. Decision trees are made and clustered into a single ensemble depending on the values of the design parameters. Key parameters determining the structures of decision trees include design steel resistance values, types of loads and the number of loadings, and ranges of rolled sheet thickness values. An ensemble of such models is used to take into account the nonlinear strain of elements. Piecewise approximation of the dependencies between components of the stress–strain state is used for this purpose. Linear regression equations are subjected to feature binarization to improve the efficiency of nonlinearity projections. The identification of weight coefficients without laborious search optimization methods is a distinguishing characteristic of the proposed models of steel blocks for modular buildings. A modular building block is used to illustrate the effectiveness of the proposed models. Its purpose is to accommodate a gas compressor of a gas turbine power plant. These machine learning models can accurately spot the stress–strain state for different design parameters, in particular for different corrugated web thickness values. As a result, ensemble models predict the stress–strain state with the coefficient of determination equaling 0.88–0.92. Full article

The objective of this paper is to outline a method for the systematic analysis and calculation of the constrained torsional shear stress in corrugated steel web composite box girders. Initially, leveraging Umansky’s secondary theory, the calculation formula for the constrained torsional shear stress within the composite girder is derived from the conditions of cross-sectional torque equilibrium and continuity in warping displacement. Subsequently, a torsion test is conducted using a scaled model of an actual girder. Finally, the constrained torsional shear stress of the corrugated steel web composite girder is examined based on theoretical analyses and the results of torsion testing. The influence of wing plate length and web thickness on the torsional shear stress of the composite girder is also investigated. The findings reveal a strong agreement between the experimental results obtained from model testing and the theoretical calculations. Notably, under torsional constraint, it is observed that the shear stress in the web is maximal and evenly distributed, followed by the bottom plate and then the top plate, with no discernible shear stress observed at the free end of the cantilever plate. Numerical analysis indicates that an increase in the relative width of the cantilever plate initially leads to an increase in shear stress for both the cantilever plate and roof plate, followed by a decrease until reaching a relative width value around 0.6, where the changes tend to stabilize. Moreover, an increase in web thickness results in a monotonic decrease in web shear stress. Additionally, the shear stress of the roof and bottom plate decreases initially before subsequently increasing. Full article

The theoretical calculation formula for the temperature effect of composite box beams with corrugated steel webs and arbitrary temperature gradient distribution is derived based on the structural characteristics of such beams. This is achieved by considering the deformation coordination condition of the steel and concrete interface, as well as taking into account the longitudinal constraint effect of the web. An analysis is conducted to compare the results obtained from a fine finite element numerical example with those from the theoretical formula. This study also investigates the height of the common flexural zone of corrugated steel web and concrete, confirming the correctness of the theoretical formula. The findings indicate that, when 10% of the height of the corrugated steel web is considered as the common flexural area, there is optimal agreement between the theoretical values and finite element values, resulting in calculated results that are more consistent with actual stress states in this type of box girder bridge. Furthermore, it is observed that the interfacial shear force and interface slip between the steel and concrete in composite beams are not uniformly distributed along their longitudinal axis. Specifically, the interfacial shear force follows a hyperbolic cosine function along this axis, reaching its maximum value at mid-span while being zero at both ends. On the other hand, the interface slip follows a hyperbolic sine function along this axis, reaching its maximum value at the beam end while being zero within the span. It should be noted that factors such as the interface slip stiffness, temperature difference, and linear expansion coefficient have a significant influence on the temperature effects in composite beams. In addition to these factors, a reasonable arrangement of shear nails on steel plates has been identified as an effective method for mitigating adverse effects. Full article

The large-span bridge is highly sensitive to temperature and wind loads. Therefore, it is essential to study the bridge’s fatigue life under the combined effects of temperature and static wind loads. This study focuses on the main bridge of Qiao Jia-fan 2# on the Yinkun Expressway (G85), with a span of 250 m and a configuration of a PC composite box girder bridge with corrugated steel webs. Firstly, on-site temperature and wind direction measurements with wind speed were conducted at the bridge site. Origin 2022 software is used to make mathematical statistics on the data, the representative values of atmospheric temperature difference between day and night and the basic wind speeds are calculated. Secondly, based on the basic wind speed in the most unfavorable wind direction, the static three-component force coefficients of bridge at different angles of attack are calculated by FLUENT 2022 R1 software. By comparison, the most unfavorable wind angle of attack, wind direction and wind load value of Qiao Jia-fan 2# Bridge are obtained. Finally, the finite element software MIDAS/FEA NX 2022 is used to analyze the fatigue life of the main bridge of the Qiao Jia-fan 2# Bridge. The analysis results show that the representative value of the temperature difference between day and night in the area where PC composite box girder bridge with corrugated steel webs is located is 22 °C, the most unfavorable wind direction is NNE wind direction, and the most unfavorable wind attack angle is 3° wind attack angle. It is found that the maximum stress of concrete and corrugated steel webs appears near the 0# block, and the life of corrugated steel webs is far greater than that of concrete. Full article

Corrugated web girders with plate flanges have been widely applied in buildings and bridges due to the large shear capacity of the corrugated web (CW). However, experiments on corrugated web girders with tubular flanges are limited. Accordingly, this paper explores, through four full-scale small-size experimental tests used on buildings, the shear behavior of a type of girder formed with a CW, concrete-filled tubular flange, and bottom flat plate flange (CWGCFTF) with different CW thicknesses, wavelengths, and concrete strengths. Based on the imprecise results of one current test, a novel simple support device is proposed to improve the accuracy of the shear test of the CWGCFTF. The test results also show that the shear ratios of the tubular flange to the entire cross-section range from 15–18% when the loading reaches that of the corresponding shear stress to 80% of the shear yield strength of the CWs. Moreover, local buckling appears at the top surface of the steel tube with the CW shear buckling failure of the CWGCFTF under the shear tests. At the end, a theoretical equation of the shear ratio of the CW to the whole cross-section is derived, and a shear yield strength equation of the CWGCFTF is proposed and verified by comparisons with the test results. Full article
