Search Results (25)

Sand mold milling plays a critical role in digital mold-free casting, but it is prone to damage such as corner collapse, collapse, and cracks during the machining process. To address this issue, ultrasonic vibration was used for sand mold milling in this study. By incorporating the solid–liquid transition model for sand mold cutting and considering the deformation characteristics of the shear zone, a prediction model for ultrasonic milling forces in sand mold was developed and experimentally validated. The results demonstrate that increasing the spindle speed and decreasing the feed rate lead to a decrease in cutting force. At high speeds, there is a 15% error between the dynamic milling force model and experimental values. Compared with conventional processing methods, ultrasonic processing reduces cutting force by 19.5% at a frequency of 25.8 kHz and amplitude of 2.97 μm, minimizes defects like sand particle detachment pits on the surface of sand mold, significantly improves surface quality, and enables precise, stable, high-precision, and efficient sand mold processing. Full article

During the extraction and utilization of coal resources, a large amount of CO₂ and coal-based solid wastes (CBSW), such as coal gangue, are generated. To reduce the carbon and waste emissions, an effective approach is to mineralize the CO₂ with the CBSW and then backfill the mineralized materials into the goaf area. However, efficient CO₂ mineralization is challenging due to the low reactivity of coal gangue. To this end, mechanical activation was used for the modification of coal gangue, and the mechanical activation mechanism of coal gangue was revealed from a microcosmic perspective by dry powder laser particle size testing (DPLPST), X-ray diffractometer (XRD) analysis, Fourier-transform infrared spectrometer (FTIR) analysis, and scanning electron microscopy (SEM). The results showed that compared with the unground coal gangue, the average particle size of coal gangue after 0.5 h, 1 h, and 1.5 h milling decreases by 94.3%, 95%, and 95.3%, respectively; additionally, the amorphous structures of the coal gangue after milling increase, and their edges and corners gradually diminish. After the pressure mineralization of coal gangues with different activation times, thermogravimetric (TG) analysis was performed, and the CO₂ mineralization effect of the mechanically activated coal gangue was explored. It is found that the carbon fixation capacity of the coal gangue after 0.5 h, 1.0 h, and 1.5 h mechanical activation is increased by 1.18%, 3.20%, and 7.57%, respectively. Through the XRD and SEM, the mechanism of CO₂ mineralization in coal gangue was revealed from a microcosmic perspective as follows: during the mineralization process, alkali metal ions of calcium and magnesium in anorthite and muscovite are leached and participate in the mineralization reaction, resulting in the formation of stable carbonates such as calcium carbonate. Full article

It is recommended to use high-speed milling to maintain an effective material removal rate and the required cutting-edge geometry. However, on the other hand, high speed increases wear, so the surface of the cutters is modified by deposition functional coatings. The wear of end mills made of CTS12D and H10F tungsten carbides during the high-speed processing of aluminum A97075 (B95T1) was compared. To increase the durability of the tools, well-proven technologies for deposition diamond-like and polycrystalline diamond coatings in microwave plasma with different film structures, which were determined by the coating growth conditions, were used. The milling cutter corner was mostly worn out, but the nature of the wear had its characteristics. It was revealed that at a forced cutting mode of about 1000 m/min, cutters made of CTS12D alloy with a nanocrystalline diamond coating with a “cauliflower” structure and with a diamond-like film showed 10% higher resistance. The primary wear mechanism was adhesive. Images of worn cutting edges were obtained using a 3D optical digital image processing system. Full article

A thorough procedure was developed to efficiently manufacture dogbone samples using focused ion beam (FIB) milling for micro-tensile testing. A Bruker PI 89 PicoIndenter, Billerica, MA, USA, was used as a case study, although the analysis and results are applicable to other micro-mechanical testing systems capable of mounting a standard, Ø12.7 mm × Ø3.2 mm pin, scanning electron microscopy (SEM) pin stub (Ted Pella, Redding, CA, USA). Nine dogbones were made from an Fe-45Cu alloy additively manufactured using powder-fed laser-directed energy deposition (DED-LB). Testing showed that fracture was confined to the gauge section for all dogbones and that the fracture mode, ductile vs. brittle, was entirely dependent on the grain orientation relative to the loading direction. The analysis showed that the measured plastic strain to failure can vary from >11% (optimal geometry) to <1% (non-optimal geometry) in micro-tensile testing of high-tensile-strength (>1 GPa) metallic materials. Subsequently, a finite element analysis (FEA) was conducted to identify the improved dogbone geometries. A total of ten thousand dogbone geometries were tested, and their dimensions were defined by a set of four adjustable parameters (corner radius, load surface angle, load surface length, and dogbone head length). The gauge width and gauge length were fixed to 4 µm and 10 µm, respectively. Three-dimensional surface plots of the stress concentration as a function of two parameters were used to identify the optimal ranges of parameter values. The addition of maximum width and length constraints, measuring 25 µm and 30 µm, respectively, allowed us to identify an optimal geometry at load surface angles of 30° and 45°. Their respective dimensions (corner radius, load surface length, and dogbone head length) are, in µm, 12, 6, and 7 and 10, 7, and 7. Testing these two optimal geometries with a range of gauge lengths from 4 to 20 µm showed that smaller gauge lengths only slightly reduced the detrimental stress concentration outside the gauge section. However, smaller gauge lengths will notably improve the FIB surface polishing step as tapering is reduced with smaller dogbone lengths. Full article

The rotor or impeller is a rotational and key part of a pump and compressor. This article presents the detailed development process of a rotor of small size constructed from an EN8 steel cylindrical blank using a novel technique based on a computer numerical control engraving milling machine (CNC-EMM) equipped with a 4 mm tungsten carbide end mill cutter. We fabricated a total of twenty-eight stepped rotors following the Box–Behnken Design (BBD) DoE technique at fourteen distinct combinations of CNC-EMM variable parameters, namely rotational speed, feed, and plunge feed. Average roughness ‘R_a’, an important surface quality indicator, has been considered and presented in this article, as a quality measure for the fabricated rotors. Feed and plunge feed have been identified as the most influencing variable parameters as per an analysis of variance (ANOVA) test. The lowest average roughness value obtained by this process for the rotor blade was 0.11 µm. A micrograph obtained from a field-emission scanning electron microscope (FE-SEM) showed a uniform and accurate tooth profile along with burr formation at corner edges. This study claims to establish engraving milling as a viable alternative to other manufacturing processes used for rotor blades. The findings of this study are useful to scholars, engineers, and researchers who are exploring new ways to fabricate mechanical parts and components. Full article

The formation of surface texture in milling is a complex process affected by numerous factors. This paper focuses on the surface roughness of X37CrMoV51 steel machined by shoulder milling. The aim of the study was to develop a mathematical model to predict the surface roughness parameter Ra. The proposed model for predicting the surface roughness parameter Ra in shoulder milling takes into account the feed per tooth, f_z, the corner radius, r_ε, and the actual number of inserts involved in the material removal process as well as h_min and D(ξ). The correlation coefficient between the theoretical and experimental data was high (0.96). The milling tests were carried out on a three-axis vertical milling machine using a square shoulder face mill. The geometric analysis of the face mill shows that at a feed rate of 0.04 mm/tooth, cutting was performed by three out of five inserts, and when the feed rate exceeded 0.12 mm/tooth, material was removed by all inserts. The minimum chip thickness parameter and the standard deviation of the relative displacement increased as the feed increased. Over the whole range of feeds per tooth, the displacement increased by 0.63 µm. Higher cutting speeds resulted in lower minimum chip thicknesses and the average standard deviation of the relative displacements for the whole range of cutting speeds was 2 μm. Full article

The design process of an integrated bandpass filter targeted for the noise filtering stage of the synchronous demodulation unit of an electric field mill sensor interface is presented. The purpose of this study of filter integration techniques is to avoid the challenging and, in some cases, impossible passive element integration process and to incorporate the final filter design in an entirely integrated field mill sensing system with superior performance and an optimized silicon-to-cost ratio. Four different CMOS filter implementations in the 0.18 μm process of XFAB, using OTA (Operational Transconductance Amplifier)-based configurations for passive element replacement in cascaded filter topologies and leapfrog techniques, are compared in terms of noise performance, total harmonic distortion, dynamic range, and power consumption, as well as in terms of integrability, silicon area, and performance degradation at process corners/mismatches. The optimum filter design performance-wise and process-wise is included in the final design of the integrated analog readout of a field mill sensor, and post-layout simulation results of the total circuit are presented. Full article

In the development of a tool wear monitoring system in milling, the complex cutting path always brings challenges to the system’s reliability in the production line. The cutting path effect on the acoustic emission (AE) and vibration signals during the micro milling processes was investigated in this study by implementing three types of cutting paths in a micro milling experiment. To generate the data for analysis, an experiment was conducted on a micro milling research platform using an AE sensor and an accelerometer installed on a fixture attached to the spindle housing. To demonstrate the effect of the cutting path on the performance in the monitoring of tool wear, a simple linear classifier is proposed, along with the signal features generated from the different signal lengths and the bandwidth size in the frequency domain. The results show that the signal features generated from the cutting of a straight line, the corner of the square path, and the circle path are different from each other. The increase in the signal length to generate features, which will reduce the corner effect, could improve the performance of the developed monitoring system. However, the results suggest that avoiding the complex cutting path for feature generation might be a better strategy for developing a micro milling tool wear monitoring system. Full article

The massive amounts of dust formed during bamboo CNC milling presents serious risks to human health and equipment. The present study aimed to determine the particle size distribution (PSD) and shape characteristics of bamboo milling dust derived from different average chip thicknesses. Spindle speed and feed rate were varied in combination, in setting up two experimental groups having the same average chip thicknesses. Sieving and flatbed scanning image analyses were collectively utilized for the morphological analysis of bamboo dust. The results showed that less than 5% of the particles were below 100 μm in terms of mass, but represented more than 83% in number. Average chip thickness was positively correlated with a mass proportion of bamboo dust with large size, which was preferably generated when reducing spindle speed instead of increasing feed rate. Spindle speed and feed rate individually affected the particle size and particle size distribution instead of average chip thickness. The aspect ratio, roundness and convexity of bamboo milling dust were augmented with a reduction in particle size, indicating that bamboo milling dust with smaller size had more a regular shape, a smoother profile and fewer corners. These findings provide a theoretical basis for better understanding bamboo milling dust and its related control in the bamboo processing industry. Full article

Real-time tool condition monitoring (TCM) for corner milling often poses significant challenges. On one hand, corner milling requires configuring complex milling paths, leading to the failure of conventional feature extraction methods to characterize tool conditions. On the other hand, it is costly to obtain sufficient test data on corner milling for most of the current pattern recognition methods, which are based on the supervised method. In this work, we propose a time-frequency intrinsic feature extraction strategy of acoustic emission signal (AEs) to construct a cutting condition-independent method for tool wear monitoring. The proposed new feature-extraction strategy is used to obtain the tool wear conditions through the intrinsic information of the time-frequency image of AEs. In addition, an unsupervised tool condition recognition framework, including the unsupervised feature selection, the clustering based on adjacent grids searching (CAGS) and the density factor based on CAGS, is proposed to determine the relationship between tool wear values and AE features. To test the effectiveness of the monitoring system, the experiment is conducted through the corner milling of a titanium alloy workpiece. Five metrics, PUR, CSM, NMI, CluCE and ClaCE, are used to evaluate the effectiveness of the recognition results. Compared with the state-of-the-art supervised methods, our method provides commensurate monitoring effectiveness but requires much fewer test data to build the model, which greatly reduces the operating cost of the TCM system. Full article

Additive manufacturing (AM) is used in many fields and is a method used to replace wood components or wood-jointed furniture components in the furniture industry. Replacing wood joints by 3D printed connectors would be an advantage, considering the fact that during the process of assembling furniture, the execution technology of the joints is difficult, time-consuming, and labor-intensive. Advanced technology of AM applied in furniture manufacturing helps the designers to create new concepts of product design, with no limits of shape, number of joints, color, or size. The diversity of 3D printers and AM technologies provides the selection of materials in relation with the applicability of the 3D printed object. In this respect, the objective of the present research is to design a 3D printed connector to be used for jointing three chair components, namely the leg and two stretchers made from larch (Larix decidua Mill.) wood, and to use reinforced polylactic acid (PLA) fiberglass (20 wt. %) filament for 3D printing this connector using AM with fused filament fabrication (FFF) technology. The design of the connector, the possibility of using this type of material, and the deposition method of filament were investigated in this research. For this purpose, several evaluation methods were applied: microscopic investigation with 50×, 100×, and 200× magnifications, both of the filament and of the 3D printed connector; mechanical testing of corner joint formed with the help of connector between chair leg and the two stretchers; and a microscopic investigation of the connectors’ defects that occurred after applying the compression and tensile loads on the diagonal direction of the L-type joint. The microscopic investigation of the composite filament revealed the agglomerations of glass fibers into the core matrix and areas where the distribution of the reinforcements was poor. The heterogeneous structure of the filament and the defects highlighted in the 3D printed connectors by the microscopic investigation contributed to the mechanical behavior of L-type connecting joints. The bending moments resulting from compression and tensile tests of the 3D printed connectors were compared to the results recorded after testing, under the same conditions, the normal mortise–tenon joint used to assemble the abovementioned chair components. The larch wood strength influenced the mechanical results and the conclusions of the microscopic investigations, as well as the analysis of the broken connectors after testing recommended the change of connector design and filament deposition direction. Full article

There is increasing interest in furfurylated wood, but the polymerization mechanism between its internal polyfurfuryl alcohol (PFA) and lignin is still uncertain. This paper investigated the distribution of PFA and the feasibility of the polymerization of PFA with lignin in furfurylated balsa wood. The wood first immersed in the furfuryl alcohol (FA) solution followed by in situ polymerization and the distribution of PFA was characterized by Raman, fluorescence microscopy, SEM, and CLSM. Then, the mill wood lignin (MWL) of balsa wood and lignin model molecules were catalytically polymerized with PFA, respectively, studying the mechanism of interaction between PFA and lignin. It was concluded that PFA was mainly deposited in cell corner with high lignin concentration, and additionally partly deposited in wood cell cavity due to high concentration of FA and partial delignification. TGA, FTIR, and NMR analysis showed that the cross-linked network structure generated by the substitution of MWL aromatic ring free position by PFA hydroxymethyl enhanced the thermal stability. New chemical shifts were established between PFA and C₅/C₆ of lignin model A and C₂/C₆ of model B, respectively. The above results illustrated that lignin-CH₂-PFA linkage was created between PFA and lignin in the wood cell wall. Full article

The mechanical properties of continuous fiber-reinforced thermoplastic (C-FRTP) composites are commonly lower than those of continuous fiber-reinforced thermosetting plastic (C-FRP) composites. We have developed a new molding method for C-FRTP. In this study, pre-impregnated materials were successfully prepared by polymer solution impregnation method and, finally, C-FRTP was fabricated. The viscosity of the thermoplastic matrix was decreased to approximately 3dPa×s, the same level of epoxy, and the fiber volume fraction was increased from approximately 45 to 60%. The cross-section of specimens were polished by an ion milling system and impregnation condition was investigated by scanning electron microscopy (SEM). The micrographs suggested that thermoplastic polymer was impregnated to every corner of the fiber, and no void was found on the cross-section. It revealed that void-free composites with perfect mechanical properties can be manufactured with this new molding method. All specimens were submitted to a mechanical measuring equipment, and the mechanical properties of the composite specimens were investigated. Mechanical analysis revealed that tensile property and flexural property of C-FRTP were enhanced up to the same level with C-FRP. Full article

We report on a comprehensive study to evaluate fundamental properties of a hybrid manufacturing approach, combining selective laser melting and high speed milling, and to characterize typical geometrical features and conclude on a catalogue of design rules. As for any additive manufacturing approach, the understanding of the machine properties and the process behaviour as well as such a selection guide is of upmost importance to foster the implementation of new machining concepts and support design engineers. Geometrical accuracy between digitally designed and physically realized parts made of maraging steel and dimensional limits are analyzed by stripe line projection. In particular, we identify design rules for numerous basic geometric elements like walls, cylinders, angles, inclinations, overhangs, notches, inner and outer radii of spheres, chamfers in build direction, and holes of different shape, respectively, as being manufactured by the hybrid approach and compare them to sole selective laser melting. While the cutting tool defines the manufacturability of, e.g., edges and corners, the milling itself improves the surface roughness to Ra < 2$\mathsf{\mu }$m. Thus, the given advantages of this hybrid process, e.g., space-resolved and custom-designed roughness and the superior geometrical accuracy are evaluated. Finally, we exemplify the potential of this particular promising hybrid approach by demonstrating an injection mold with a conformal cooling for a charge socket for an electro mobile. Full article

Aluminium matrix composites (AMCs) represent suitable materials for lightweight design applications. The abrasive ceramic reinforcements typically require diamond cutting materials to prevent excessive tool wear. In milling with diamond cutting materials the influence of cutting parameters was already examined to a significant extent. Investigations concerning the effect of modified tool geometries are limited and the potentials with regard to the geometrical and physical surface properties are unclear. Accordingly, experimental investigations in milling of a 10 vol.% $\mathrm{SiC}$ particle-reinforced aluminium wrought alloy EN AW-2017 T4 were addressed. The effect of modified corner and minor cutting edge geometries were investigated based on mono crystalline diamond (MCD)-tipped tools to benefit stable process conditions. The results indicated achievable areal roughness values in the range around $0.2\mathsf{\mu }\mathrm{m}$. Especially the application of the lowest cutting edge angle and a trailing minor cutting edge led to strong fluctuations of the surface parameters. The lowest valley void volumes were achieved with an arched minor cutting edge. Generally, finish machining led to stronger compressive residual stresses compared to the state prior to machining. The strongest increase was achieved using a corner radius combined with a straight minor cutting edge. It is concluded that reduced effective radii generating the surface enable an acceptable surface structure and strong compressive residual stresses and should be addressed in further investigations. Full article
