Search Results (101)

A Global Navigation Satellite System (GNSS) and Long Range (LoRa) technology play a crucial role in connected vehicles. The demand for antennas that cover both LoRa and GNSS bands is increasing. This work has developed a novel dual-band coplanar waveguide (CPW)-fed interleaved meander line antenna, incorporating a radiating element, ground plane, and feed. The antenna dimension is 90 × 90 × 1.635 mm³. The design employs a planar meander line configuration to effectively cover the 868 MHz LoRa and 1248 MHz GNSS bands. The antenna was integrated with a Frequency Selective Structure (FSS) to improve the parameters. The designed antenna provides sufficient bandwidth of 40 and 110 MHz for the LoRa and GNSS frequency bands, respectively. The CPW-interleaved meander line antenna attains a gain of −0.12 dBi at LoRa and 3.5 dBi at GNSS frequency. It achieves a voltage standing wave ratio of <2 and impedance of 50 Ω. The novelty of the proposed work is integrating FSS with a CPW-interleaved meander line antenna, which achieves dual-band operation. This dual-band low-profile configuration is suitable for connected vehicle communication. Full article

Microfluidic impedance cytometry enables label-free and real-time single-cell analysis by detecting changes in electrical impedance as cells traverse microchannels. Electrode configuration plays a critical role in determining detection sensitivity, signal quality, and spatial resolution. In this study, finite element simulations were conducted to model the impedance response of mammalian red blood cells under various electrode designs, including coplanar, parallel, tilted, and parabolic configurations, as well as electrode layouts coupled with flow velocity. A multiphysics simulation model was established to analyze the effects of geometric parameters on electric field distribution and impedance response. The results demonstrate that optimized electrode arrangements significantly enhance detection performance and enable multi-parameter analysis. Furthermore, the influence of flow dynamics and dielectric properties on impedance signals is explored. These findings provide both theoretical and experimental guidance for the development of high-efficiency, integrated impedance cytometry platforms, contributing to the advancement of microfluidic systems in biomedical diagnostics and single-cell characterization. Full article

This paper describes the status of developing Josephson arbitrary waveform synthesizer (JAWS) chips at NIM (National Institute of Metrology, China). To obtain high junction integration density and fewer data input channels, the chip employs an on-chip Wilkinson power divider and inside/outside dc blocks, enabling both arrays to be driven by a single pulse-generator channel. In addition, the tapered coplanar waveguide structure is used to ensure the microwave uniformity of the long-junction array. Each array consisted of 4000 double-stack Nb/Nb_xSi_1−x/Nb junctions, and 16,000 junctions are integrated in the chip in total. The JAWS chip demonstrates good performance, capable of synthesizing a 300 mV root mean square (rms) voltage with exceptionally low harmonic distortion. Dc and ac voltage-current characteristics measurements indicate that the junctions are with a critical current of 2.5 mA, and a normal-state resistance of 4.5 mΩ per junction. Contact aligners are manually operated to fabricate the chips, and process errors in the fabrication are estimated in this paper. Full article

Accurate volumetric modeling of indoor spaces is essential for emerging 3D cadastral systems, yet existing workflows often rely on manual intervention or produce surface-only models, limiting precision and scalability. This study proposes and validates an integrated, largely automated workflow (named VERTICAL) that converts classified indoor point clouds into topologically consistent 3D solids served as materials for land surveyor’s cadastral analysis. The approach sequentially combines RANSAC-based plane detection, polygonal mesh reconstruction, mesh optimization stage that merges coplanar faces, repairs non-manifold edges, and regularizes boundaries and planar faces prior to CAD-based solid generation, ensuring closed and geometrically valid solids. These modules are linked through a modular prototype (called P2M) with a web-based interface and parameterized batch processing. The workflow was tested on two condominium datasets representing a range of spatial complexities, from simple orthogonal rooms to irregular interiors with multiple ceiling levels, sloped roofs, and internal columns. Qualitative evaluation ensured visual plausibility, while quantitative assessment against survey-grade reference models measured geometric fidelity. Across eight representative rooms, models meeting qualitative criteria achieved accuracies exceeding 97% for key metrics including surface area, volume, and ceiling geometry, with a height RMSE around 0.01 m. Compared with existing automated modeling solutions, the proposed workflow has the ability of dealing with complex geometries and has comparable accuracy results. These results demonstrate the workflow’s capability to produce topologically consistent solids with high geometric accuracy, supporting both boundary delineation and volume calculation. The modular, interoperable design enables integration with CAD environments, offering a practical pathway toward an automated and reliable core of 3D modeling for cadastre applications. Full article

This paper presents a novel self-packaged low-pass filter (LPF) based on the substrate-integrated suspended line (SISL) technique, employing a high-impedance line structure. The core circuit of the proposed LPF integrates three distinct transmission line technologies: stripline (SL), grounded coplanar waveguide (GCPW), and SISL. Leveraging these advanced techniques, the prototype LPF with a cutoff frequency (f₀) of 3 GHz has been successfully designed and fabricated. Comprehensive measurements reveal that the LPF exhibits an insertion loss (S₂₁) of greater than −0.74 dB within the pass-band, while maintaining a stop-band ranging from 5 GHz to 12.2 GHz, achieving a suppression level exceeding 15 dB. Additionally, the highest internal solid-line impedance reaches 110 Ω. Given its superior performance characteristics, the proposed LPF is highly suitable for application in radio frequency (RF) front-end systems, specifically for filtering and screening signals within designated frequency bands. Full article

As a core functional device in microwave systems, attenuators play a crucial role in key aspects such as signal power regulation, amplitude attenuation, and impedance matching. Addressing the pressing technical issues currently exposed by attenuators in practical applications, such as excessive insertion loss, low attenuation accuracy, large physical dimensions, and insufficient process reliability, this paper proposes a design scheme for an RF three-bit reconfigurable stepped attenuator based on radio frequency micro-electromechanical systems (RF MEMS) switches. The attenuator employs planar integration of the T-type attenuation network, Coplanar Waveguide (CPW), Y-shaped power divider, and RF MEMS switches. While ensuring rational power distribution and stable attenuation performance over the full bandwidth, it reduces the number of switches to suppress parasitic parameters, thereby enhancing process feasibility. Test results confirm that this device demonstrates significant advancements in attenuation accuracy, achieving a precision of 1.18 dB across the 0–25 dB operational range from DC to 20 GHz, with insertion loss kept below 1.65 dB and return loss exceeding 12.15 dB. Additionally, the device boasts a compact size of merely 0.66 mm × 1.38 mm × 0.32 mm, significantly smaller than analogous products documented in existing literature. Meanwhile, its service life approaches 5 × 10⁷ cycles. Together, these two attributes validate the device’s performance reliability and miniaturization advantages. Full article

This paper presents the design and performance evaluation of a compact four-element coplanar waveguide (CPW)-fed antenna array operating in the 3.3–3.6 GHz frequency band. The proposed antenna is tailored for sub-6 GHz 5G New Radio (NR) applications, specifically aligning with the n77/n78 bands widely adopted for mid-band 5G deployment. The CPW feeding technique enables low-profile integration and ease of fabrication, while the multi-element configuration supports enhanced gain and spatial diversity. Both simulated and measured results demonstrate good impedance matching (|S₁₁| < −10 dB), stable radiation patterns, and inter-element isolation suitable for MIMO operation. The design offers a promising solution for compact 5G antenna systems and can be extended to future wireless communication platforms requiring high efficiency and compact form factors. Full article

Robust and accurate line segment matching remains a critical challenge in stereo vision, particularly in space-based applications where weak texture, structural symmetry, and strong illumination variations are common. This paper presents a multi-constraint progressive matching framework that integrates epipolar geometry, coplanarity verification, local homography, angular consistency, and distance-ratio invariance to establish reliable line correspondences. A unified cost matrix is constructed by quantitatively encoding these geometric residuals, enabling comprehensive candidate evaluation. To ensure global consistency and suppress mismatches, the final assignment is optimized using a Hungarian algorithm under one-to-one matching constraints. Extensive experiments on a wide range of stereo image pairs demonstrate that the proposed method consistently outperforms several advanced conventional approaches in terms of accuracy, robustness, and computational efficiency, as evidenced by both quantitative and qualitative evaluations. Full article

This study presents a novel, fully passive radiofrequency (RF)-based localization system designed to detect the position of a robotic hand on a flat surface within its tactile range, particularly in scenarios where other sensing systems may face limitations. The system employs U-shaped, chipless resonator tags printed on the surface using a customized conductive ink, together with a coplanar RF probe integrated into the robotic hand, to determine position through impedance variations. Unlike conventional approaches, the proposed method provides a compact, low-cost, and robust solution that is resilient to variations in lighting, dust, and other environmental conditions. The resonator tags are arranged in a structured grid inspired by a Sudoku pattern, enabling both position and orientation detection in the near-field region. The system is fabricated on 3D-printed flexible substrates using a flexible and stretchable conductive ink, and its performance is validated through both electromagnetic simulations and experimental measurements. The results confirm that the proposed approach enables accurate and repeatable two-dimensional localization of the robotic hand under various configurations. This work introduces a scalable, high-precision, and vision-independent sensing platform with strong potential for robotic manipulation in challenging environments. Full article

A low-profile beam-scanning antenna array for cost-effective 5G millimeter-wave (mmWave) applications is proposed in this work. The array features a compact single-layer substrate structure while achieving a wide operating bandwidth covering the 5G n257 band (26.5–29.5 GHz). A novel antenna element is first designed and analyzed, employing a metallic rectangular patch with shorting pins as the radiator, excited through a modified coplanar waveguide (CPW) feeding structure. Based on this element, four-element and eight-element linear arrays are developed with an overall profile of only 0.07 λ at 28 GHz and fabricated to experimentally assess beam-scanning performance. To accurately characterize and validate the radiation behavior, an mmWave beam box system is utilized for pattern measurements. The results demonstrate that the fabricated arrays achieve an impedance bandwidth fully covering the 5G n257 band with VSWR < 2, while the measured beam-scanning performance closely agrees with simulations. These findings confirm that the proposed design and its extensions offer strong potential for practical integration into future 5G mmWave communication devices. Full article

Robotic hands require reliable and precise sensing systems to achieve accurate object recognition and manipulation, particularly in environments where vision- or capacitive-based approaches face limitations such as poor lighting, dust, reflective surfaces, or non-metallic materials. This paper presents a novel radiofrequency (RF) pre-touch sensing system that enables robust localization and orientation estimation of objects prior to grasping. The system integrates a compact coplanar waveguide (CPW) probe with fully passive chipless RF resonator tags fabricated using a patented flexible and stretchable conductive ink through additive manufacturing. This approach provides a low-cost, durable, and highly adaptable solution that operates effectively across diverse object geometries and environmental conditions. The experimental results demonstrate that the proposed RF sensor maintains stable performance under varying distances, orientations, and inter-tag spacings, showing robustness where traditional methods may fail. By combining compact design, cost-effectiveness, and reliable near-field sensing independent of an object or lighting, this work establishes RF sensing as a practical and scalable alternative to optical and capacitive systems. The proposed method advances robotic perception by offering enhanced precision, resilience, and integration potential for industrial automation, warehouse handling, and collaborative robotics. Full article

Stereotactic radiosurgery (SRS) for multiple brain metastases can be delivered with a single isocenter and non-coplanar arcs, achieving highly conformal dose distributions at the cost of extreme modulation of treatment machine parameters. As a result, SRS plans are at a higher risk of patient-specific quality assurance (PSQA) failure compared to standard treatments. This study aimed to develop a machine-learning (ML) model to predict the PSQA outcome (gamma passing rate, GPR) of SRS plans. Five hundred and ninety-two consecutive patients treated between 2020 and 2024 were selected. GPR analyses were performed using a 3%/1 mm criterion and a 95% action limit for each arc. Fifteen plan complexity metrics were used as input features to predict the GPR of an arc. A stratified and a time-series approach were employed to split the data into training (1555 arcs), validation (389 arcs), and test (486 arcs) sets. The ML model achieved a mean absolute error of 2.6% on the test set, with a 0.83% median residual value (measured/predicted). Lower values of the measured GPR tended to be overestimated. Sensitivity and specificity were 93% and 56%, respectively. ML models for virtual QA of SRS can be integrated into clinical practice, facilitating more efficient PSQA approaches. Full article

This study proposes a dual-element wideband circularly polarized (CP) slot-integrated multiple-input multiple-output (MIMO) antenna with an X-notch square-shaped artificial magnetic conductor (AMC) for dedicated short-range communications (DSRC) applications. The proposed antenna design consists of two substrate layers separated by an air gap. The upper layer features a dual-element coplanar waveguide-fed slot antenna and a defected ground structure decoupling isolator, while the lower layer comprises an 8 × 8 array of X-notch square-shaped elemental units, functioning as an AMC reflector. Characteristic mode analysis shows that circular polarization is produced by the dominant orthogonal mode pair (modes J₅ and J₆), whose modal significance exceeds 0.92 and whose characteristic angle separation is 82° around the 5.9 GHz DSRC band. An I-shaped slot embedded in the ground plane of the upper layer serves as a defected ground structure isolator to suppress mutual coupling between antenna elements. Meanwhile, the X-notch square AMC reflector enhances radiation characteristics and antenna gain. The measured return loss bandwidth and axial ratio bandwidth are 32% (4.72–6.61 GHz) and 21.18% (5.2–6.45 GHz), respectively. The dual-element antenna scheme achieves high isolation exceeding 19 dB, with a maximum gain of 8.6 dBic at 5.9 GHz. The envelop correlation coefficient remains below 0.003, while the diversity gain exceeds 9.98 dB. Full article

To address the limitations of existing LiDAR–visual fusion methods in adequately accounting for map uncertainties induced by LiDAR measurement noise, this paper introduces a LiDAR–inertial–visual odometry framework leveraging mergeable probabilistic voxel mapping. The method innovatively employs probabilistic voxel models to characterize uncertainties in environmental geometric plane features and optimizes computational efficiency through a voxel merging strategy. Additionally, it integrates color information from cameras to further enhance localization accuracy. Specifically, in the LiDAR–inertial odometry (LIO) subsystem, a probabilistic voxel plane model is constructed for LiDAR point clouds to explicitly represent measurement noise uncertainty, thereby improving the accuracy and robustness of point cloud registration. A voxel merging strategy based on the union-find algorithm is introduced to merge coplanar voxel planes, reducing computational load. In the visual–inertial odometry (VIO) subsystem, image tracking points are generated through a global map projection, and outlier points are eliminated using a random sample consensus algorithm based on a dynamic Bayesian network. Finally, state estimation accuracy is enhanced by jointly optimizing frame-to-frame reprojection errors and frame-to-map RGB color errors. Experimental results demonstrate that the proposed method achieves root mean square errors (RMSEs) of absolute trajectory error at 0.478 m and 0.185 m on the M2DGR and NTU-VIRAL datasets, respectively, while attaining real-time performance with an average processing time of 39.19 ms per-frame on the NTU-VIRAL datasets. Compared to state-of-the-art approaches, our method exhibits significant improvements in both accuracy and computational efficiency. Full article

To address the high-precision measurement requirements for container pose on dual-trolley quayside crane-transfer platforms, this paper proposes a machine vision-based measurement method that resolves the challenges of multi-scale lockhole detection and precision demands caused by complex illumination and perspective deformation in port operational environments. A hardware system comprising fixed cameras and edge computing modules is established, integrated with an adaptive image-enhancement preprocessing algorithm to enhance feature robustness under complex illumination conditions. A multi-scale adaptive frequency object-detection framework is developed based on YOLO11, achieving improved detection accuracy for multi-scale lockhole keypoints in perspective-distortion scenarios (mAP@0.5 reaches 95.1%, 4.7% higher than baseline models) through dynamic balancing of high–low-frequency features and adaptive convolution kernel adjustments. An enhanced EPnP optimization algorithm incorporating lockhole coplanar constraints is proposed, establishing a 2D–3D coordinate transformation model that reduces pose-estimation errors to millimeter level (planar MAE-P = 0.024 m) and sub-angular level (MAE-$\theta$ = 0.11°). Experimental results demonstrate that the proposed method outperforms existing solutions in container pose-deviation-detection accuracy, efficiency, and stability, proving to be a feasible measurement approach. Full article
